NEC 320Fd Manual

Read Me First: Unpacking

Express5800/320FdSystems

NEC Corporation of America

456-01742-000

Notice

The information contained in this document is subject to change without notice.

UNLESS EXPRESSLY SET FORTH IN A WRITTEN AGREEMENT SIGNED BY

AN AUTHORIZED REPRESENTATIVE OF NEC, NEC MAKES NO WARRANTY

OR REPRESENTATION OF ANY KIND WITH RESPECT TO THE INFORMATION

CONTAINED HEREIN, INCLUDING WARRANTY OF MERCHANTABILITY AND

FITNESS FOR A PURPOSE. NEC assumes no responsibility or obligation of any

kind for any errors contained herein or in connection with the furnishing,

performance, or use of this document.

Software described in NEC (a) is the property of NEC and/or its licensees, (b) is

furnished only under license, and (c) may be copied or used only as expressly

permitted under the terms of the license.

NEC documentation describes all supported features of the user interfaces and the

application programming interfaces (API) developed by NEC and/or its licensees.

Any undocumented features of these interfaces are intended solely for use by NEC

personnel and are subject to change without warning.

This document is protected by copyright. All rights are reserved. No part of this

document may be copied, reproduced, or translated, either mechanically or

electronically, without the prior written consent of NEC Corporation of America.

The NEC Corporation of America logo, Express5800/320Fd, and the

Express5800/320Fdlogo, are trademarks of NEC Corporation of America.

ActiveService Network is a trademark of Stratus Technologies Bermuda, Ltd. All

other trademarks and trade names are the property of their respective owners.

Manual Name: Read Me First: Unpacking Express5800/320FdSystems

Part Number: 456-01742-000

Revision Number: 0

Publication Date: July 2008

NEC Corporation of America

10850 Gold Center Drive, Suite 200

Rancho Cordova, CA 95670

-iii-

Contents

Introduction 1

Before Unpacking the System 4

Unpacking the System 4

Disposing of Packing Materials 6

What to Do Next 6

-iv-

-1-

Introduction

Read Me First: Unpacking Express5800/320FdSystems

explains how to unpack a system from its shipping box.

WARNING

To avoid eye and skin injuries, be careful

when cutting the shipping straps from the

shipping box. The straps can snap with

considerable force when cut.

WARNING

To avoid back injury, do not attempt to remove

an enclosure before you remove the shipping

box from the shipping pallet. When the

shipping box is removed, lift and remove each

enclosure with the assistance of another

person.

WARNING

To avoid back injury, enlist the assistance of

another person to lift and remove the

enclosures and pedestal case.

-2-

Figure 1 shows the packaged components, and the order in which

to remove them, for a rack-mounted system. Figure 2 shows the

packaged components, and the order in which to remove them, for

a pedestal system.

Figure 1. Unpacking a Rack-Mounted System

1 Accessories box

2 Shipping box

3 Shelf unit

4 and 5 CPU-I/O enclosures

asys072

-3-

Figure 2. Unpacking a Pedestal System

1 Pedestal case

2 Accessories box

3 Shipping box

4 and 5 CPU-I/O enclosures

asys073

-4-

Before Unpacking the System

•Check the label or the packing slip on the outside of the

shipping box to verify that you received the correct shipment.

Depending on your order, you have received either a

rack-mountable system or a pedestal system.

•Verify that the Tip-N-Tell and Shockwatch indicators on the

outer sides of the shipping box are not activated.

CAUTION

Do not unpack the system if you did not receive

the correct shipment, or if an indicator on the

shipping box is activated. Contact the shipping

carrier and the purchasing agent for your system

immediately.

Unpacking the System

Tools needed: A pair of scissors or a utility knife

1. Place the shipping box in the location where the system will be

installed, leaving it right side up on its shipping pallet.

2. Use the scissors or knife to cut the shipping straps and remove

them from the shipping box. To avoid injury while cutting each

strap, hold the strap firmly with one hand as you stand away

from it.

WARNING

To avoid eye or skin injuries, be careful when

cutting the straps from the box. The straps

can snap with considerable force when cut.

-5-

3. Open the top cardboard flaps of the shipping box by cutting

through the taped portion of the flaps to release them.

4. If you have received a pedestal system, remove the pedestal

case, place it on a table or other sturdy surface, and remove

its foam packaging material.

WARNING

To avoid back injury, lift and remove the

pedestal case with the assistance of another

person.

5. Remove the accessories box. Open the accessories box and

make sure that it contains (along with other items) the

Express5800/320Fd: Setup Guide.

6. Lift and remove the shipping box from the shipping pallet.

WARNING

To avoid back injury, do not attempt to remove

the shelf unit or enclosures before you

remove the shipping box from the shipping

pallet.

7. If you received a rack-mountable system, remove the shelf

unit and place it on a table or other sturdy surface and remove

its foam packaging material.

-6-

8. Remove each CPU-I/O enclosure, one at a time, from the

shipping pallet. Pull the foam blocks away from the first

enclosure and remove it. Then, do the same for the second

enclosure.

WARNING

To avoid back injury, lift and remove each

enclosure with the assistance of another

person.

9. Remove the enclosures from their plastic bags, then place the

enclosures flat on a table or other sturdy work surface near the

installation area.

Disposing of Packing Materials

The packing materials do not contain any hazardous compounds.

Dispose of them according to applicable procedures or local

regulations.

If, however, you decide to retain the undamaged container and its

packing materials, you can use them to ship the system at a later

time.

What to Do Next

To install the system, see the Express5800/320Fd: Setup Guide.
