Portable Projector

NP06CM Ceiling Mount Unit

Installation and Adjustment Manual

Thank you for your purchase of the NEC Portable projector ceiling mount unit.

Please read this installation and adjustment manual carefully to ensure proper use.

Special skills are required for the installation of the Portable projector.

This work should never be performed by the customer.

To the Dealer and the Installer

For the safety of the customer, we ask that the installation work be started

after careful attention is paid to the strength of the mounting location to be

sure it will withstand the weight of the Portable projector and mounting

hardware.

CONTENTS

Heed the Following ............................................................................2

Preparation..........................................................................................4

List of Packaged Parts.............................................................................4

Names of the Parts...................................................................................5

Dimensions ...............................................................................................6

Guide to Screen Size and Projector Mounting Position .......................6

Mounting the Projector ......................................................................7

Adjustment of the Projection Angle................................................11

Cleaning the filter ...................................................................................14

Specifications ...................................................................................15

Printed in Japan

NP06CM-0704K-1

PRINTED WITH

SOY INK

Printed on recycled paper.

NP06CM-E07.3.209:02AMページ1

Heed the Following

•When installing the projector, be sure to

do so as explained in this manual. The

projector may fall and cause injury if it is

installed improperly.

•To prevent the projector from falling, install

it in a place and fasten it in a way with

sufficient strength to support the combined

weight (21.6kg) of the projector (17.7kg)

and the ceiling mount unit (3.9kg) for an

extended period of time as well as to

withstand earthquakes. Insufficient

strength or fastening may result in the

projector falling and causing injury.

•To ensure safety, be sure to tighten the

bolts and screws securely. Also be sure to

use the included brackets and other metal

fittings. Failure to do so may result in the

projector falling and causing injury.

•When sliding the opening of the mounting

adapter over the pin of the ceiling

attachment unit, check that the pin of the

ceiling attachment unit is fully seated in

the opening. If not, the projector may fall

and cause injury.

•Do not modify any parts. Doing so may

result in the projector falling and causing

injury.

WARNING

•Do not use broken parts. Doing so may

result in the projector falling and causing

injury. If a part should be broken, consult

your dealer.

•Do not look into the lens when the

projector is turned on. Doing so could

damage your eyesight.

•Make adjustments as described in this

manual.

Incorrect adjustments may result in the

projector falling and causing injury.

This symbol alerts the user that important information concerning the

operation and maintenance of this unit has been provided. The

information should be read carefully to avoid problems.

NP06CM-E07.3.209:02AMページ2

CAUTION

•Do not obstruct the projector's ventilation

holes. Doing so will prevent the dissipation

of heat and may result in fires. In

particular, do not use the projector in the

following ways:

Do not install the projector in a wall or in a

tight place where ventilation is poor, place

a cover it, etc.

•Do not install the projector in front of the

outlets of an air conditioner or heater or in

a place where vibrations are strong.

Doing so may result in fires.

•Do not install the projector in humid or

dusty places or exposed to smoke or

steam (such as near cooking equipment or

humidifiers). Doing so may result in fires.

•When installing the projector, leave

sufficient space between it and

surrounding objects. Failure to leave

sufficient space will prevent the dissipation

of heat and may result in fires.

•When removing the screws on left and

right on the mounting adapter, be sure to

support the projector while doing so.

Failing to do so may result in the projector

swinging back abruptly and causing injury.

•for PLUGGABLE EQUIPMENT, the

socket-outlet shall be installed near the

equipment and shall be easily accessible.

Installation Precautions

•Special techniques are required for the

installation work of the projector and

installation work should only be

undertaken by qualified and licenced

installers.

•NEC Display Solutions will not accept any

responsibility related to any accidents or

incidents due to insufficient or inferior

mounting techniques.

Installation Location

Avoid places of high temperature or low

temperature.

(For ambient operating temperature, see the

user's manual included with the projector.)

Avoid places exposed to direct sunlight and

the vicinity of ventilation holes of room air

conditioning and heating.

Avoid rooms with a lot of dust, humidity,

greasy smoke, or tobacco smoke.

Dirt will adhere to optical parts such as

lenses and mirrors and this will cause a

deterioration of image quality.

Avoid places in which the screen is exposed

to direct sunlight or illumination light.

When surrounding light directly hits the

screen, the image appears washed out and

is difficult to view.

Heed the Following

NP06CM-E07.3.209:02AMページ3

Preparation

List of Packaged Parts

Installation and adjustment manual...1

Up-down angle adjustment screws (M5) ...4

Projector mounting screws (long M4 screws) ...5

Projector mounting adapter...1

Fixed ceiling part...1

Terminal cover...1

Terminal cover mounting screws (short M4 screws) ...4

NP06CM-E07.3.209:02AMページ4

Preparation

Names of the Parts

Inclination axis screws

Left-right angle adjustment

screws

Inclination adjustment screws

Up-down angle adjustment screws

[Front view]

[Right side view]

●

Fixed ceiling part

Projector mounting

adapter

Projector mounting

adapter

Fixed ceiling part

NP06CM-E07.3.209:02AMページ5

For the distance to the screen and the picture size, see the projector's operating instructions.

•The ceiling mount unit can be adjusted up and down a maximum of +/-10˚, but if too much

of an angle is taken the image will show some distortion. Therefore, it is recommended that

an adjustment is made in conjunction with the screen projection angle.

Dimensions

Fixed Ceiling Part Bolt Hole Position Dimensions

Fixed Ceiling Part and Lens Center Dimensions Diagram

Unit: mm

Preparation

210

180

228.9

140

117.4

410

176

120

150

Center line of fixed ceiling part

Lens center

Center line of fixed

ceiling part

Distance to lens end

Guide to Screen Size and Projector Mounting Position

NP06CM-E07.3.209:02AMページ6

Mounting the Projector

Attach the Fixed Ceiling Part to the Ceiling

First, partially tighten the four nuts, then tighten the nuts firmly

after positioning.

Attach the Projector Mounting Adapter to the Projector

Align the holes of the projector mounting adapter with the holes at the bottom surface of

the projector, then securely tighten the five supplied (M4) screws.

Use M8 bolts for the fixed ceiling part.

Use of types other than M8 could

cause the projector to fall.

WARNING!

Fixed ceiling part

WARNING!

The use of screws other than those supplied for mounting purposes may

cause the projector to be damaged or fall and cause injury. Please be sure to

use the supplied screws.

Projector mounting adapter

Bottom surface of projector

Long screw

NP06CM-E07.3.209:02AMページ7

3Suspend the Projector from the Fixed Ceiling Part

Slide the slotted part of the projector mounting adapter over the pin of the fixed ceiling

part and push all the way to the back.

The projector is temporarily suspended in this condition and attention must be paid so

that the unit does not fall since it is not fixed in place.

Slotted part of mounting adapter

Pin of fixed ceiling part

4Temporarily Fasten the Projector Mounting Adapter

Temporarily fasten by partially tightening the four supplied (M5) screws.

Tighten firmly after completing the screen projection angle adjustment.

Mounting the Projector

Temporarily fasten also the other side.

NP06CM-E07.3.209:02AMページ8

Mounting the Projector

5After connecting all the cables, mount the terminal cover.

Line up the projecting parts of the projector mount adapter with the holes in the

included terminal cover, and fasten securely using the four included screws (M4).

Line up the projecting parts with

the positions of the holes

Line up the projecting parts with

the positions of the holes

Short screw

NP06CM-E07.3.209:02AMページ9

Installation Examples

When the Ceiling is Wood Construction:

Mounting board

(Strong enough to support the weight of the whole unit.)

Washer

Beam

Nut and washer

Bolt (M8)

When the Ceiling is Concrete Construction:

Anchor nut (Purchase commercially-available M8-type anchor nuts that are

strong enough to endure the weight of the whole unit.)

Ceiling

Washer

Bolt (M8)

NOTE : Mounting boards, M8-type anchor nuts, bolts, nuts and washers are

commercially available.

Mounting the Projector

NP06CM-E07.3.209:02AMページ10
