84VP5/84VM5 Installation Guide (using four 42VM5 or 42VP5 Plasma Displays)

(also a reference for optional Quad Mount used with 42VM5 or 42VP5) v1.3

www.necvisualsystems.com Page 1 of 14

Contents

Product Description and Notes Page 1

SystemDimensions Page 2

System Ventilation Requirements Page 3

Quad Mount Isometric Drawing Page 4

Mounting Points for Quad Mount Page 5

Control Page 6

ProductDescription

Type: Plasma Display System (2x2 Matrix Screen Surface: 42VM5:Anti-Reflective

using either 42VM5 or 42VP5) 42VP5:Anti-Glare

84VP5/84VM5 System Resolution: 1706x960 84VP5/84VM5 System Dimensions: 80.2”(W) x 48.0”(H) x 8.0”(D)

42VP5/42VM5 Display Resolution: 853x480 42VP5/42VM5 Display Dimensions: 40”(W) x 24”(H) x 3.5”(D)

Aspect Ratio: 16:9 84VP5/84VM5 System Weight: 319.2 lbs

Color Correction: NEC CCF (Capsulated Color Filter) 42VP5/42VM5 Display Weight: 61.8 lbs (Quad Mount Wt: 72 lbs)

Notes

This document is intended to be used as a reference guide to supply useful information for a design or installation. It is not

intended to be a step-by step procedure for installation.

Any ceilings or walls must be strong enough to support the display system and the installation must be in accordance with any

local building codes. All mounts should make secure contact to wood studs.

4:3 sources can be displayed on the 16:9 screen in either normal aspect ratio with bars on the left or right, or stretched

horizontally to fill the screen using the menus (see “Aspect Modes” in menus and user manual).

The recommended PC resolution is 1365 x 768, next recommended resolution is 848 x 480

Distances are in inches, for millimeters multiply by 25.4.

Distances may vary ±5%.

853 x 480 853 x 480

Total Resolution: 1706 x 960

NEC Solutions (America), Inc.

VisualSystems

84VP5/84VM5 Installation Guide (using four 42VM5 or 42VP5 Plasma Displays)

(also a reference for optional Quad Mount used with 42VM5 or 42VP5) v1.3

www.necvisualsystems.com Page 2 of 14

System Dimensions

Dimensions are in inches. For millimeters multiply by 25.4.

8.0

48.0

80.2

NEC Solutions (America), Inc.

VisualSystems

84VP5/84VM5 Installation Guide (using four 42VM5 or 42VP5 Plasma Displays)

(also a reference for optional Quad Mount used with 42VM5 or 42VP5) v1.3

www.necvisualsystems.com Page 3 of 14

System Ventilation Requirements

Dimensions below show minimum requirements for ventilation.

Wall

Minimum Wall Recess Opening 84.2" x 52.0"Ventilation Requirement is 2" around the units

Wall

2.0

52.0

84.22.0

2.0

NEC Solutions (America), Inc.

VisualSystems

84VP5/84VM5 Installation Guide (using four 42VM5 or 42VP5 Plasma Displays)

(also a reference for optional Quad Mount used with 42VM5 or 42VP5) v1.3

www.necvisualsystems.com Page 4 of 14

Quad Mount Isometric Drawing

NEC Solutions (America), Inc.

VisualSystems

84VP5/84VM5 Installation Guide (using four 42VM5 or 42VP5 Plasma Displays)

(also a reference for optional Quad Mount used with 42VM5 or 42VP5) v1.3

www.necvisualsystems.com Page 5 of 14

Mounting Points for Quad Mount

Dimensions are in inches. For millimeters multiply by 25.4.

16.0

24.0

16.0

32.1

24.124.0

5.95.9

18.1

4.5

NEC Solutions (America), Inc.

VisualSystems

84VP5/84VM5 Installation Guide (using four 42VM5 or 42VP5 Plasma Displays)

(also a reference for optional Quad Mount used with 42VM5 or 42VP5) v1.3

www.necvisualsystems.com Page 6 of 14

Control

Connections

Connections should be made as described below.

1) Connector on the plasma monitor side: EXTERNAL CONTROL connector.

Type of connector: D-Sub 9-pin male

o. Pin Name

1 No Connection

2 RXD (Receive data)

3 TXD (Transmit data)

4 DTR (DTE side ready)

5 GND

6 DSR (DCE side ready)

7 RTS (Ready to send)

8 CTS (Clear to send)

9 No Connection

2) Connector on the external equipment side: Serial port (RS-232C) connector. See the specifications of the equipment that

is to be connected for the type of connector and the pin assignment.

3) Wiring

Use a crossed (reverse) cable.

Wire the cable so that each pair of data lines cross between the two devices. These data line pairs are RXD (Receive

data) and TXD (Transmit data), DTR (DTE side ready) and DSR (DCE side ready), and RTS (Ready to send) and CTS

(Clear to send).

Communication Parameters

(1) Communication system Asynchronous

(2) Interface RS-232C

(3) Baud rate 9600 bps

(4) Data length 8 bits

(5)Parity Odd

(6) Stop bit 1 bit

(7) Communication code Hex

plasma monitor External equipment

e.g., Personal computer

NEC Solutions (America), Inc.

VisualSystems

84VP5/84VM5 Installation Guide (using four 42VM5 or 42VP5 Plasma Displays)

(also a reference for optional Quad Mount used with 42VM5 or 42VP5) v1.3

www.necvisualsystems.com Page 7 of 14

Communication Format

Command1

Command 1, along with command 2, is a number used to distinguish each command.

When making it operate using ID, bit1 and bit0 are set up as follows.

Bit1,Bit0 Unit ID distinction bit

11B :Usually, a form (with no ID)

10B :Usually, a form (with no ID)

01B :Set ID

00B :Video wall ID

In the case of ACK, when the lower order 4 bits is FH (as in 3FH and 7FH), this indicates that the commands and data of the

supported equipment have been received. When the lower order 4 bits is BH (as in 3BH and 7BH), this indicates that

unsupported commands and data have been received.

Unit ID1,2 (UA1,UA2)

Unit ID 1 and unit ID 2 are numbers used to identify the equipment that is to be connected.

60H is used for the plasma monitor and 80H is used for external control equipment such as a personal computer.

Unit ID 1: Indicates the equipment sending the signal. When supporting Set ID

by the command 1, 4 bits of low ranks of Set ID are set up.

Unit ID 2: Indicates the equipment receiving the signal. When supporting Set ID by the command 1, 4 bits of higher ranks of

Set ID are set up.

* Set ID : it is the apparatus number assigned to each plasma monitor.

Command 2

Command 2, along with command 1, is a number used to distinguish each command.

Check Sum (CKS), Error Processing, and ACK

The check sum described below and RS-232C odd parity are used together for a check of the received data. The check sum

is the lower order 8 bits of one frame of sent or received data comprising the sum total of Command 1, Unit ID 1 and 2,

Command 2, Data Length, and Data.

Command 1

Unit ID 1

Unit ID 2

Command 2

Data length

Data

Check sum

8bit 8bit 8bit 8bit 8bit 8bit 8bit 8bit

NEC Solutions (America), Inc.

VisualSystems

84VP5/84VM5 Installation Guide (using four 42VM5 or 42VP5 Plasma Displays)

(also a reference for optional Quad Mount used with 42VM5 or 42VP5) v1.3

www.necvisualsystems.com Page 8 of 14

Check Sum Example

2) Error Processing

• When the communication interval is vacant for more than 4 ms, thereafter a received Command 1 will be recognized. If, at

this time, meaningful data cannot be recognized, that data will not be recognized (as valid data).

• An ACK will not be returned unless the receive data error, the check sum error, and the receive data are all taken in.

The control method of the set by Set ID

When controlling two or more sets of plasma monitors, if the command using Set ID is used, it will become controllable

individually.

The example of the POWER ON command to the plasma monitor which set ID as "5" is shown below.

It is not based on ID but is the POWER ON command to all sets.

9F 80 60 4E 00 CD

In ID= "5", the value of ID-1=4 is set up.

9D 84 60 4E 00 CF

The example of a change in the single mode of a 4th page multi-system configuration and the multi-mode is shown below.

ID of the set used as a master(etc PC) is set to 50, and it assumes that ID is shaken by AUTO ID to each set. ID shaken at

each set is as follows.

Upper left set (master) ID = 50 = 32h

Upper right set ID = 51 = 33h

Lower right set ID = 52 = 34h

Lower left set ID = 53 = 35h

Transmission Data

DD 81 63 03 03 03 01 00 CB

DD 82 63 03 03 03 02 00 CD

DD 83 63 03 03 03 03 00 CF

DD 84 63 03 03 03 04 00 D1

Transmission of the above command performs a 4th page multi SPLIT display.

Moreover, the following commands are published in order to change a 4th page multi-display into a single mode display.

DF 80 60 03 03 01 01 00 C7

All sets become a single mode display by the above-mentioned command.

Since this command does not specify Set ID, all sets execute it.

*:Control by ID may not be able to be performed depending on connection with external control apparatus.

Total 208H

DFH 80H 60H 47H 01H 01H 08H

Command1 Unit ID1 Unit ID2 Command2 Data Length Data Check Sum

NEC Solutions (America), Inc.

VisualSystems

84VP5/84VM5 Installation Guide (using four 42VM5 or 42VP5 Plasma Displays)

(also a reference for optional Quad Mount used with 42VM5 or 42VP5) v1.3

www.necvisualsystems.com Page 9 of 14

Command Codes

01. Power ON

Function

The external control equipment switches on the power of the plasma monitor.

Transmission Data

9FH 80H 60H 4EH 00H CKS

ACK

The plasma monitor returns the following ACK when the power is switched on.

3FH 60H 80H 4EH 00H CKS

02. Power OFF

Function

The external control equipment switches off the power of the plasma monitor.

Transmission Data

9FH 80H 60H 4FH 00H CKS

ACK

The plasma monitor returns the following ACK when the power is switched off.

3FH 60H 80H 4FH 00H CKS

03. Input Switch Change

Function

The external control equipment switches the input of the plasma monitor.

Transmission Data

DFH 80H 60H 47H 01H DATA00 CKS

DATA00 : Input Select 01H : Video1

02H : Video2

03H : Video3

05H:HD(HD1orDTVorDTV1)

06H: HD2 (DTV2 or SCART1/SCART2)

07H:RGB1/PC1

08H:RGB2/PC2

0CH:RGB3/PC3

0DH:HD3(SCART3)

ACK

The plasma monitor returns the following ACK when the input is switched.

3FH 60H 80H 47H 00H CKS

04. AUDIO Mute ON

Function

The external control equipment switches on AUDIO Mute of the plasma monitor.

Transmission Data

9FH 80H 60H 3EH 00H CKS

ACK

3FH 60H 80H 3EH 00H CKS

05. AUDIO Mute OFF

Function

The external control equipment switches off AUDIO Mute of the plasma monitor.

Transmission Data

9FH 80H 60H 3FH 00H CKS

NOTE: Do not set the Power ON or Power OFF command continuously.

NEC Solutions (America), Inc.

VisualSystems

84VP5/84VM5 Installation Guide (using four 42VM5 or 42VP5 Plasma Displays)

(also a reference for optional Quad Mount used with 42VM5 or 42VP5) v1.3

www.necvisualsystems.com Page 10 of 14

ACK

3FH 60H 80H 3FH 00H CKS

06. PICTURE MODE Select

Function

The external control equipment sets the picture mode of the plasma monitor.

Transmission Data

DFH 80H 60H 0AH 01H DATA00 CKS

DATA00: 01H : NORMAL

02H : THEATER1(It cannot choose in the still picture input of a personal computer.)

03H : THEATER2(It cannot choose in the still picture input of a personal computer.)

04H : Default

ACK

7FH 60H 80H 0AH 01H DATA00 CKS

DATA00: 01H : NORMAL

02H:THEATER1

03H:THEATER2

04H : Default

07.SCREEN MODE Select

Function

The external control equipment switches the screen mode of the plasma monitor.

Transmission Data

DFH 80H 60H 51H 01H DATA00 CKS

DATA00 02H : STADIUM

03H:ZOOM

04H:NORMAL

05H : FULL

06H:REAL

08H : UNDERSCAN

09H : 14:9

ACK

7FH 60H 80H 51H 01H DATA00 CKS

DATA00 02H : STADIUM

03H:ZOOM

04H:NORMAL

05H : FULL

06H:REAL

08H : UNDERSCAN

09H : 14:9

08. AUTO PICTURE Select

Function

The external control equipment switches on or off the AUTO PICTURE of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00 : USER PICTURE Gain Flag 03H

DATA01 : AUTO PICTURE Select Flag 09H

DATA02 00H : ON

01H:OFF

ACK

7FH 60H 80H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00 : USER PICTURE Gain Flag 03H

DATA01 : AUTO PICTURE Select Flag 09H

DATA02 00H : ON

01H:OFF

Otros manuales para PlasmaSync 84VM5

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de NEC

NEC

NEC LCD3215 - MultiSync - 32" LCD Flat Panel... Manual de usuario

NEC

NEC MultiSync LCD5710 Manual de usuario

NEC

NEC LCD2190UXI - MultiSync - 21.3" LCD Monitor Manual de usuario

NEC

NEC MultiSync XV17 Manual de usuario

NEC

NEC LCD2090UXI - MultiSync - 20.1" LCD Monitor Manual de usuario

NEC

NEC MultiSync FP912SB Manual de usuario

NEC

NEC JB-1201MR Manual de usuario

NEC

NEC MultiSync X462S Manual de usuario

NEC

NEC LCD1525M - MultiSync - 15" LCD Monitor Guía

NEC

NEC AccuSync LCD4010 Manual de usuario

NEC

NEC LCD175VX - MultiSync - 17" LCD Monitor Manual de usuario

NEC

NEC LCD71V - AccuSync TFT LCD Flat Panel Monitor Guía del usuario

NEC

NEC NEC MultiSync LCD1850E LCD1850E LCD1850E Manual de usuario

NEC

NEC PX-42XM4A Manual de usuario

NEC

NEC MultiSync P552 Manual de usuario

NEC

NEC PlasmaSync 50XM5 Guía del usuario

NEC

NEC MultiSync EA275WMi Manual de usuario

NEC

NEC PlasmaSync 42MP3 Manual de usuario

NEC

NEC AccuSync LCD73V Manual de usuario

NEC

NEC P221W-BK - MultiSync - 22" LCD Monitor Manual de usuario

NEC

NEC S521-AVT Manual de usuario

NEC

NEC P461 - MultiSync - 46" LCD Flat Panel... Manual de lista de piezas

NEC

NEC MultiSync PA231W Manual de usuario

NEC

NEC V423 Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación

LG M1950D-PZ Manual de usuario
