www.necvisualsystems.com 42VP4/42VP4D Page 1 of 11

NEC Solutions (America), Inc.

VisualSystems

42VP4/42VP4D Installation Guide

42” Plasma Displays v2.5

Contents

Product Description and Notes Page 1

Ventilation Requirements Page 2

Display Dimensions

Front,Top&Bottom Page 3

Rear Page 4

Left&RightSide Page 5

Display Dimensions w/Optional Accessories

Front&Top Page 6

Dimensions w/Optional Flat Wall Mount Page 7

Dimensions w/Optional Tilt Wall Mount Page 8

Dimensions w/Optional Ceiling Mount Page 9

Control Codes Page 10

ProductDescription

Type: PlasmaDisplay ColorCorrection: NEC CCF (Capsulated Color Filter, in panel)

Resolution: 853x480 Screen Surface: 42VP4: Anti-Reflective

42VP4D:Anti-Glare

Aspect Ratio: 16:9 Dimensions: 40”(W) x 24”(H) x 3.5”(D)

Weight: 61.8lbs

Notes

 This document is intended to be used as a reference guide to supply useful information for a design or installation. It is not

intended to be a step-by step procedure for installation.

 Any ceilings or walls must be strong enough to support the display and the installation must be in accordance with any local

building codes. All mounts should make secure contact to wood studs.

 4:3 sources can be displayed on the 16:9 screen in either normal aspect ratio with bars on the left or right, or stretched

horizontally to fill the screen using the menus (see “Aspect Modes” in menus and user manual).

 Distances are in inches, for millimeters multiply by 25.4.

 Distances may vary ±5%.

MaximumTiltAngles

Below are the maximum angles that the display can be tilted in both landscape and portrait mode

42VP4/42VP4D Landscape 30°

Portrait 10°

Max Tilt

www.necvisualsystems.com 42VP4/42VP4D Page 2 of 11

Ventilation Requirements (all models)

Dimensions below are minimum required for proper ventilation.

NOTE: The ventilation space should not be covered or closed off at the front of the opening. If for some reason the

opening needs to be covered, other means of ventilation will need to be incorporated into the design. Contact NEC for

design review and recommendations.

WALL

www.necvisualsystems.com 42VP4/42VP4D Page 3 of 11

Display dimensions

Ventilation Openings

Ventilation Openings Ventilation Openings Ventilation Openings

1.38

0.98

1.14

0.38 1.69 0.6334.690.381.690.63

40.08

1.42

1.30

24.02

2.72

0.59

36.76

0.98

2.52

0.79

3.11

0.63 1.69 0.38

23.27

33.25

34.55

33.03

0.81 2.70

16.81

5.53

3.50 0.63

1.14

0.98

1.38

2.171.34

3.95

0.35

www.necvisualsystems.com 42VP4/42VP4D Page 4 of 11

Display dimensions (cont.)

AC IN

+- +-

8-M4

Ventilation Openings

20.879.61

4.13

4.724.96 4.96

5.12

4.25

5.1212.836.06

8.78 1.65 19.21 1.65 8.78

9.61

PC Mount Points

1.78

3.35

17.35

www.necvisualsystems.com 42VP4/42VP4D Page 5 of 11

Display dimensions (cont.)

VIDEO

(IN/OUT)

VIDEO 1

VIDEO 2

YCb/PbCr/Pr

DVD 1/HD 1 AUDIO 2

AUDIO 3

Y Cb/Pb HD VD

RGB 2/DVD 2/HD 2 RGB 1

(IN/OUT)

RGB 3

DVI OUTIN

REMOTE

External Control

Ventilation Openings

1.5°

3.50

0.640.68

22.06

0.63

0.51

0.37

1.57

1.97

0.40

0.06 0.39 23.11 0.39

0.40

0.06

VIDEO 3

Cr/Pr

G/ B/

AUDIO 1

www.necvisualsystems.com 42VP4/42VP4D Page 6 of 11

Dimensions with optional speakers and stand

47.20

0.02 3.54

3.54 0.02

0.75

0.53

1.30

4.41

13.58

11.42 11.42

4.37

1.97

26.59

14.59

2.58

7.28 4.96

15.75

Optional Speakers

www.necvisualsystems.com 42VP4/42VP4D Page 7 of 11

Dimensions with optional Flat Wall Mount Kit (FWMK)

8.45.99.8

16.04.0

12.1

8.1

4.0

8.0

12.0

2.513.51

6.02

www.necvisualsystems.com 42VP4/42VP4D Page 8 of 11

Dimensions with optional Tilt Wall Mount Kit (TWMK)

16.0

4.0

3.51

8.1

12.1

4.08.0

12.0

5.04

8.55

15.0°

Tilt Range

9.7

5.9

8.4

Depth at 15° Tilt

12.1

www.necvisualsystems.com 42VP4/42VP4D Page 9 of 11

Dimensions with optional Ceiling Mount Kit (CMK)

16.0 12.012.2

2.51.5

0.5

8.7

www.necvisualsystems.com 42VP4/42VP4D Page 10 of 11

Connections

VIDEO

(IN/OUT)

VIDEO 1

VIDEO 3

VIDEO 2

AUDIO 1

YCb/PbCr/Pr

DVD 1/HD 1 AUDIO 2

AUDIO 3

Cr/Pr Y Cb/Pb HD VD

RGB 1

(IN/OUT)

RGB 3

DVI

OUTIN

REMOTE

External Control

LOCATED AT

BOTTOM OF DISPLAY

POWER

EXT. SPEAKERS

(MONO) (MONO)

R/ G/ B/

(MONO)

(Digital RGB)

RGB 2/DVD 2/HD 2
