NEC MultiSync LCD1525X Manual de usuario

MultiSync LCD1525X

User’s Manual

UÏivatelská pﬁíruãka

Bedienerhandbuch

Οδηγίεσ Χρήσησ

Manual del usuario

Manuel Utilisateur

Manuale utente

Gebruikershandleiding

Podr´cznik u˝ytkowinka

Руководство пользователя

Kullan∂c∂ Klavuzu

00Cover_all.p65 10.10.2000, 18:38 Uhr1

A.1 A.2

B.1 B.2

00Cover_all.p65 10.10.2000, 18:38 Uhr2

C.1

DVI D-SUB

00Cover_all.p65 10.10.2000, 18:38 Uhr3

D.1

E.1

G.1

F.1

00Cover_all.p65 10.10.2000, 18:38 Uhr4

English

âesky

Deutsch

Ελληνικά

Español

Français

Italiano

Nederlands

Polski

Русский

Türkçe

01b_XChapterOpener 10.10.2000, 18:38 Uhr1

01b_XChapterOpener 10.10.2000, 18:38 Uhr2

English-1

English

Declaration of the Manufacturer

We hereby certify that the colour monitor

MultiSync LCD1525X (LA-1526HMW)

are in compliance with

Council Directive 73/23/EEC:

- EN 60950

Council Directive 89/336/EEC:

- EN 55022

- EN 61000-3-2

- EN 61000-3-3

- EN 55024

and marked with

NEC-Mitsubishi Electric Visual Systems, Corp.

686-1, NISHIOI OI-MACHI

ASHIGARAKAMI-GUN

KANAGAWA 258-8533, JAPAN

01b_english 10.10.2000, 18:38 Uhr1

English-2

Contents

Your new NEC MultiSync LCD monitor box should contain the following:

–NEC MultiSync LCD1525X.

–AC Power Cable.

–DVI-A to VGA Cable.

–DVI-D to DVI-D Video Signal Cable.

–USB Cable.

–CD-ROM includes complete User‘s Manual in PDF format and

Windows related files (Inf file and color profile). To see the complete

User‘s Manual, Acrobat Reader 4.0 must be installed on your PC.

–User’s Manual.

Remember to save your original box and packing material to transport or

ship the monitor.

DVI/D-SUB

NEC MultiSync LCD1525X

monitor with DVI-A to VGA Cable.

01b_english 10.10.2000, 18:38 Uhr2

English-3

English

Installation

To attach the MultiSync LCD1525X monitor to your system, follow these

instructions:

1. Turn off the power of your computer.

2. For the PC with DVI digital output: Connect the DVI-D to DVI-D

signal cable to the connector of the display card in your system

(Figure A.1). Tighten all screws.

For the PC with analog output: Connect the DVI-A to VGA cable to

the connector of the display card in your system (Figure A.2).

To connect a secondary PC with analog output, connect the

MultiSync LCD1525X D-SUB to D-SUB (not included) cable to the

connector of the display card in your system.

For the Mac: Connect the MultiSync Macintosh cable adapter to the

computer (Figure B.1). Attach the 15-pin mini D-SUB signal cable to

the MultiSync Macintosh cable adapter (Figure B.1).

NOTE: Macintosh G3 and G4 do not need a Macintosh cable

adapter.

3. Remove connector cover and cable cover. Connect the DVI signal

cable to the connector on the back of the monitor. Place the DVI

video signal cable under Clip A.

Replace connector cover and cable cover.

4. Using the USB cable, connect the B type connector to the USB

upstream port on the back of the monitor and A type connector to the

downstream part on the computer (Figure D.1). If you are using the

cord from the USB device, use one of the downstream ports on the

side of the monitor (Figure E.1).

NOTE: Incorrect cable connections may result in irregular

operation, damage display quality/components of LCD

module and/or shorten the module’s life.

5. Connect one end of the power cord to the MultiSync LCD Series

monitor and the other end to the power outlet (Figure F.1).

6. Turn on the monitor (Figure G.1) and the computer.

01b_english 10.10.2000, 18:38 Uhr3

English-4

Controls

INPUT SELECT

If no OSM menu is displayed, video input and USB upstream can be

changed by pressing the PROCEED button.

: changing only video

: changing video and USB

OSM Controls

The OSM controls on

the front of the monitor

provide the following

functions:

To access OSM press any of the control buttons ( , , , ) or the

PROCEED button

7. To complete the setup of your MultiSync LCD monitor, use the

following OSM controls:

•Auto Adjust Contrast

•Auto Adjust

Refer to the Controls section of this User’s Manual for a full

description of these OSM controls.

NOTE: If you have any problems, please refer to the

Troubleshooting section of this User’s Manual.

01b_english 10.10.2000, 18:38 Uhr4
