Introduction to the NEC MultiSync

LCD1510 / LCD1510V / LCD2010

Congratulations on your purchase of the NEC MultiSync LCD1510/

LCD1510V/LCD2010 true colour monitor!

Wide Viewing Angle Technology

(MultiSync LCD1510 and MultiSync LCD2010 only)

Allowstheusertobeabletoseethemonitorfromanyangle(160degrees)

from any orientation – Portrait or Landscape. Provides full 160˚ viewing

angles either up, down, left or right.

Analog Advantage

Capable of displaying unlimited colours in a continuous spectrum,

providing a truer representation of colour. The monitor’s high contrast

LCD enhances colour vibrancy and improves focus with no geometric

distortion.

Wider Compatibility

Because the MultiSync LCD monitor is analog through and through, it

does not require special analog to digital display or interface cards but

can accept RGB input directly.

Reduced Footprint

Provides the ideal solution for environments requiring superior image

qualitybutwithsizeandweightlimitations.Themonitor’ssmallfootprint

and low weight allow it to be moved or transported easily from one

location to another.

Colour Control system

Allowsyou to adjust the colours on your screen andcustomize thecolour

accuracy of your monitor to a variety of standards.

Introduction to the NEC MultiSync LCD

1510

/ LCD

1510V

/ LCD

2010

E - 1

78133551/Fix.PM5 98.3.17, 8:19 AM15

OSM (On-Screen Manager) Controls

Allow you to quickly and easily adjust all elements of your screen image

via simple to use on-sreen menus.

ErgoDesign Features

Enhance human ergonomics to improve the working environment,

protect the health of the user and save money. Examples include OSM

controls for quick and easy image adjustments, tilt/swivel pivot stand

for preferred angle of viewing, small footprint and compliance with

MPRII and TCO guidelines for lower emissions.

Pivoting Stand

Allows users to adjust the monitor to the orientation that best fits their

application, either Landscape orientation for wide documents, or portrait

orientation for the ability to preview a full page on one screen at one

time. The Portrait orientation is also perfect for full screen video

conferencing.

PlugandPlay(MultiSyncLCD1510andMultiSyncLCD1510Vonly)

The Microsoft solution with the Windows operating system facilitates

setup and installation by allowing the monitor to send its capabilities

(suchasscreensize and resolutions supported) directly toyour computer,

automatically optimizing display performance.

IPM (Intelligent PowerManager) System

Provides innovative power-saving methodes that allow the monitor to

shift to a lower power consumption level when on but not in use, saving

two-thirdsof your monitor energy cost, reducing emissions and lowering

the air conditioning cost of the workplace.

Multiple frequency Technology

Automatically adjusts monitor to the display card’s scanning frequency,

thus displaying the resolution required.

E - 2

Introduction to the NEC MultiSync LCD

1510

/ LCD

1510V

/ LCD

2010

78133551/Fix.PM5 98.3.17, 8:19 AM16

Introduction to the NEC MultiSync LCD

1510

/ LCD

1510V

/ LCD

2010

E - 3

FullScan Capability

Allowsyou to use the entire screen area in mostresolutions, significantly

expanding image size.

VESA Standard Mounting Interface

Allows users to connect their MultiSync monitor to any VESA standard

third party mounting arm or bracket. Allows for the monitor to be

mounted on a wall or an arm using any third party compliant device.

78133551/Fix.PM5 98.3.17, 8:19 AM17

Contents of Package

Your new MultiSync LCD monitor box should contain the following:

E - 4 Contents of Package

MultiSync LCD1510 / LCD1510V

monitor with Video Signal Cable

and AC Adapter

MultiSync LCD2010 monitor

with 15-pin VGA to BNC Cable

and AC Adapter

– NEC MultiSync LCD1510 (Model LA-152lJMW)/

NEC MultiSync LCD1510V (Model LA-1522JMW).

NEC MultiSync LCD2010 (Model LA-2032JMW).

– AC power cable.

– AC Adapter

– Video Signal Cable – 15 pin VGA to 15 pin mini D-SUB

(LCD1510 / LCD1510V).

Video Signal Cable – 15 pin VGA to BNC (LCD2010).

– User’s manual.

Remember to save the original box and packing materials to transport or

ship the monitor.

78133551/Fix.PM5 98.3.17, 8:19 AM18

Recommended Use

For optimum performance, please note the following when setting up

andusingtheMultiSyncLCD1510/ LCD1510V /LCD2010 colourmonitor:

•DO NOT OPEN THE MONITOR. There are no user

serviceable parts inside and opening or removing covers may

expose you to dangerous shock hazards or other risks. Refer

all servicing to qualified service personnel.

•The optimum monitor position is facing away from direct

sunlight.

•Allow adequate ventilation around the monitor so that heat can

properly dissipate. Do not block ventilated openings or place

the monitor near a radiator or other heat sources. Do not put

anything on top of monitor.

•Do not spill any liquids into the cabinet or use your monitor

near water.

•Do not insert objects of any kind into the cabinet slots, as they

may touch dangerous voltage points, which can be harmful or

fatal or may cause electric shock, fire or equipment failure.

•Do not place any heavy objects on the power cord. Damage to

the cord may cause shock or fire.

•Do not place this product on a sloping or unstable cart, stand or

table, as the monitor may fall, causing serious damage to the

monitor.

•Use the monitor in a clean and dry area.

•Handle with care when transporting. Save packaging for

transporting.

•The power cable connector is the primary means of detaching

the system from the power supply. The monitor should be

installed close to a power outlet which is easily accessible.

Recommended Use E - 5

78133551/Fix.PM5 98.3.17, 8:19 AM19

E - 6 Recommended Use

•Use supplied AC Adapter.

•The inside of the fluorescent tube located within the LCD

monitor contains mercury. Please follow the bylaws or rules of

your local municipality to dispose of this tube property.

•Clean the LCD monitor surface with a lint-free, non-abrasive

cloth. Avoid using any cleaning solution, glass cleaner or tissue

paper.

•For optimum performance, allow 20 minutes for warm-up.

•Avoid displaying fixed patterns on the monitor for long periods

of the time to avoid image persistence (after-image effects.)

•Avoid applying pressure to the LCD monitor surface.

Immediatelyunplugyourmonitor from the wall outlet and refer servicing

to qualified service personnel under the following conditions:

•When the power supply cord or plug is damaged.

•Ifliquid has been spilled or objects have fallen intothe monitor.

•If the monitor has been exposed to rain or water.

•If the monitor has been dropped or the cabinet is damaged.

•Ifthemonitordoes not operate normally by following operating

instructions.

78133551/Fix.PM5 98.3.17, 8:19 AM20

CORRECT PLACMENT AND ADJUSTMENT OF THE MONITOR

CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK

THE FOLLOWING WHEN YOU POSITION THE MONITOR:

•Adjust the monitor height so that the top of the screen is at or

slightly below eye level. Your eyes should look slightly

downward when viewing the middle of the screen.

•Positionyour monitor no closer than 40 cm and nofurther away

than 70 cm from your eyes. The optimal distance of MultiSync

LCD1510 / LCD1510V is 53 cm, MultiSync LCD2010 is 61 cm.

•Rest your eyes periodically by focusing on an object at least

6 m away.

•Position the monitor at a 90°angle to windows and other

light sources to minimize glare and reflections. Adjust the

monitor tilt so that ceiling lights do not reflect on your screen.

•If reflected light makes it hard for you to see your screen, use

an anti-glare filter.

•Adjust the monitor’s brightness and contrast control to enhance

readability.

•Use a document holder placed close to the screen.

•Positionwhatever you are looking atmostofthe time (the screen

or reference material) directly in front of you to minimize

turning your head while you are typing.

•Get regular eye checkups.

Recommended Use E - 7

78133551/Fix.PM5 98.3.17, 8:19 AM21

Installation

Connection to your Personal Computer

The MultiSync LCD1510 / LCD1510V / LCD2010 true colour monitor

complements PC compatible computers. Your system has one of two

configurations:

– the video controller is built into the computer.

– the video controller is in the form of a display card (sometimes

referred to as graphics card, video adapter or graphics board).

Both configurations have a video connector (or a CRT PORT on laptop

computers). If you are not sure which connector is the video connector,

refer to your computer or display card manual.

To attach the monitor to your system, follow these instructions:

1. Turn off the power to the monitor and computer.

2. If necessary, installthedisplay card. For more informationabout

installing your card, refer to the display card manual.

3. Connect the 15-pin mini D-SUB of the appropriate signal

cable to the connector of the display card in your computer.

Tighten all screws (Figure A.1).

4. FortheMultiSyncLCD1510, MultiSync LCD1510V:Connect

the 15-pin mini D-SUB of the video signal cable and the AC

Adapter cable to the appropriate connectors on the back of the

monitor (Figure C.1).

Forthe MultiSync LCD2010:Removeconnector cover on back

of monitor. Connect the BNC cables and AC adapter cable to

the appropriate connectors on the back of the monitor. Connect

thered BNC cable to the BNC connector on the monitor labeled

R, the green BNC cable to the BNC connector labeled G/Sync,

the blue BNC cable to the BNC connector labeled B. If you

have a fourth BNC connector (Composite Sync), connect it to

the BNC connector on the monitor labeled H/CS. If you have a

fifth BNC connector (Vertical Sync), connect it to the BNC

E - 8 Installation

78133551/Fix.PM5 98.3.17, 8:20 AM22

Otros manuales para MultiSync LCD1510

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de NEC

NEC

NEC NEC MultiSync LCD1860NX LCD1860NX LCD1860NX Guía del usuario

NEC

NEC MultiSync V801 Manual de usuario

NEC

NEC AccuSync LCD93VX Manual de usuario

NEC

NEC PlasmaSync 42XM2 Manual de usuario

NEC

NEC MULTISYNC PA301W Manual de usuario

NEC

NEC MultiSync LCD1525X Manual de usuario

NEC

NEC NL2501 Manual de usuario

NEC

NEC MD462OR Instrucciones de funcionamiento y seguridad

NEC

NEC MULTEOS M46 Manual de usuario

NEC

NEC MultiSync ME431 Guía del usuario

NEC

NEC LCD2090UXI - MultiSync - 20.1" LCD Monitor Manual de usuario

NEC

NEC M40 - MULTEOS - 40" LCD TV Manual de usuario

NEC

NEC MD211G3 Instrucciones de funcionamiento y seguridad

NEC

NEC 42XM5 - PlasmaSync - 42" Plasma Panel Manual de usuario

NEC

NEC MD205MG-1 - MultiSync - 20.1" LCD Monitor Manual de usuario

NEC

NEC NEC MultiSync LCD1850E LCD1850E LCD1850E Manual de usuario

NEC

NEC MultiSync LCD1850DX Manual de usuario

NEC

NEC MultiSync A900 Manual de usuario

NEC

NEC MultiSync SC40 Manual de usuario

NEC

NEC MultiSync E233WM Manual de usuario

NEC

NEC MultiSync LCD1701 Manual de usuario

NEC

NEC MultiSync LCD1525S Manual de usuario

NEC

NEC FA3435K series Manual de usuario

NEC

NEC MD242C2 Instrucciones de funcionamiento y seguridad

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación

LG M1950D-PZ Manual de usuario
