Introduction to the NEC MultiSync

LCD1510+ / LCD1510V+

Congratulations on your purchase of the NEC MultiSync LCD1510+/

LCD1510V+ full colour monitor!

NuCycle Plastic

A special silicone compound for PC resin, being extremely flame-retardant,

safe and environmentally friendly.

Wide Viewing Angle Technology

(MultiSync LCD1510+only)

Allowstheusertobeabletoseethemonitorfromanyangle(160degrees)

from any orientation –Portrait or Landscape. Provides full 160˚viewing

angles either up, down, left or right.

Analog Advantage (MultiSync LCD1510V+only)

Capable of displaying unlimited colours in a continuous spectrum,

providing a truer representation of colour. The monitor’s high contrast

LCD enhances colour vibrancy and improves focus with no geometric

distortion.

Wider Compatibility

Because the MultiSync LCD monitor is analog through and through, it

does not require special analog to digital display or interface cards but

can accept RGB input directly.

Reduced Footprint

Provides the ideal solution for environments requiring superior image

qualitybutwithsizeandweightlimitations.Themonitor’ssmallfootprint

and low weight allow it to be moved or transported easily from one

location to another.

Introduction to the NEC MultiSync LCD

1510

+ / LCD

1510V

E - 1

78134712 99/11/16, 3:44 PM15

E - 2

Introduction to the NEC MultiSync LCD

1510+

/ LCD

1510V+

Colour Control system

Allowsyoutoadjustthe colours on your screen and customize thecolour

accuracy of your monitor to a variety of standards.

OSM (On-Screen Manager) Controls

Allow you to quickly and easily adjust all elements of your screen image

via simple to use on-sreen menus.

ErgoDesign Features

Enhance human ergonomics to improve the working environment,

protect the health of the user and save money. Examples include OSM

controls for quick and easy image adjustments, tilt/swivel pivot stand

for preferred angle of viewing, small footprint and compliance with

MPRII and TCO guidelines for lower emissions.

Pivoting Stand

Allows users to adjust the monitor to the orientation that best fits their

application,either Landscape orientation for wide documents, or portrait

orientation for the ability to preview a full page on one screen at one

time. The Portrait orientation is also perfect for full screen video

conferencing.

Plug and Play

The Microsoft solution with the Windows operating system facilitates

setup and installation by allowing the monitor to send its capabilities

(suchasscreen size and resolutions supported) directly to your computer,

automatically optimizing display performance.

IPM (Intelligent PowerManager) System

Provides innovative power-saving methodes that allow the monitor to

shift to a lower power consumption level when on but not in use, saving

two-thirds of your monitor energy costs, reducing emissions and

lowering the air conditioning costs of the workplace.

78134712 99/11/16, 3:44 PM16

Introduction to the NEC MultiSync LCD

1510+

/ LCD

1510V+

E - 3

Multiple frequency Technology

Automatically adjusts monitor to the display card’s scanning frequency,

thus displaying the resolution required.

FullScan Capability

Allowsyou to use the entire screen area in mostresolutions, significantly

expanding image size.

VESA Standard Mounting Interface

Allows users to connect their MultiSync monitor to any VESA standard

third party mounting arm or bracket. Allows for the monitor to be

mounted on a wall or an arm using any third party compliant device.

78134712 99/11/16, 3:44 PM17

Contents of Package

Your new MultiSync LCD monitor box should contain the following:

E - 4 Contents of Package

–NEC MultiSync LCD1510+(Model LA-157lHMW-1)/

NEC MultiSync LCD1510V+(Model LA-1573JMW-1).

–AC power cable.

–AC Adapter

(Type. A1240T01)

–Video Signal Cable –15 pin mini D-SUB to 15 pin mini D-SUB.

–User’s manual.

–NEC LCD Setup Software, Pivot Software and other helpful

files.

Remember to save the original box and packing materials to transport or

ship the monitor.

MultiSync LCD1510+/ LCD1510V+

monitor with Video Signal Cable

and AC Adapter

78134712 99/11/16, 3:44 PM18

Recommended Use

For optimum performance, please note the following when setting up

and using the MultiSync LCD1510+/ LCD1510V+colour monitor:

•DO NOT OPEN THE MONITOR. There are no user

serviceable parts inside and opening or removing covers may

expose you to dangerous shock hazards or other risks. Refer

all servicing to qualified service personnel.

•The optimum monitor position is facing away from direct

sunlight.

•Do not spill any liquids into the cabinet or use your monitor

near water.

•Do not insert objects of any kind into the cabinet slots, as they

may touch dangerous voltage points, which can be harmful or

fatal or may cause electric shock, fire or equipment failure.

•Do not place any heavy objects on the power cord. Damage to

the cord may cause shock or fire.

•Do not place this product on a sloping or unstable cart, stand or

table, as the monitor may fall, causing serious damage to the

monitor.

•Use the monitor in a clean and dry area.

•The power cable connector is the primary means of detaching

the system from the power supply. The monitor should be

installed close to a power outlet which is easily accessible.

•Use supplied AC Adapter. No Object shall be placed on AC

Adapter. AC Adapter shall not be used outdoors.

•The inside of the fluorescent tube located within the LCD

monitor contains mercury. Please follow the bylaws or rules of

your local municipality to dispose of this tube property.

Recommended Use E - 5

78134712 99/11/16, 3:44 PM19

E - 6 Recommended Use

•Clean the LCD monitor surface with a lint-free, non-abrasive

cloth. Avoid using any cleaning solution, glass cleaner or tissue

paper.

•For optimum performance, allow 20 minutes for warm-up.

•Avoid displaying fixed patterns on the monitor for long periods

of the time to avoid image persistence (after-image effects.)

•Avoid applying pressure to the LCD monitor surface.

Immediatelyunplugyourmonitor from the wall outlet and refer servicing

to qualified service personnel under the following conditions:

•When the power supply cord or plug is damaged.

•Ifliquid has been spilled or objects have fallen into the monitor.

•If the monitor has been exposed to rain or water.

•If the monitor has been dropped or the cabinet is damaged.

•Ifthemonitordoes not operate normally by following operating

instructions.

CAUTION:

•Allow adequate ventilation around the monitor so that heat can

properly dissipate. Do not block ventilated openings or place

the monitor near a radiator or other heat sources. Do not put

anything on top of monitor.

•The power cable connector is the primary means of detaching

the system from the power supply. The monitor should be

installed close to a power outlet which is easily accessible.

•Use caution when carrying the monitor, as the compact stand

may extend automatically.

•Handle with care when transporting. Save packaging for

transporting.

78134712 99/11/16, 3:44 PM20

CORRECT PLACMENT AND ADJUSTMENT OF THE MONITOR

CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK

THE FOLLOWING WHEN YOU POSITION THE MONITOR:

•Adjust the monitor height so that the top of the screen is at or

slightly below eye level. Your eyes should look slightly

downward when viewing the middle of the screen.

•Positionyour monitor no closer than 40 cm and no further away

than 70 cm from your eyes. The optimal distance of MultiSync

LCD1510+/ LCD1510V+is 53 cm.

•Rest your eyes periodically by focusing on an object at least

6 m away. Blink often.

•Position the monitor at a 90°angle to windows and other

light sources to minimize glare and reflections. Adjust the

monitor tilt so that ceiling lights do not reflect on your screen.

•If reflected light makes it hard for you to see your screen, use

an anti-glare filter.

•Adjustthe monitor’s brightness and contrastcontrolstoenhance

readability.

•Use a document holder placed close to the screen.

•Positionwhatever you are looking atmostof the time (the screen

or reference material) directly in front of you to minimize

turning your head while you are typing.

•Get regular eye checkups.

Recommended Use E - 7

78134712 99/11/16, 3:44 PM21

Installation

Connection to your Personal Computer

TheMultiSync LCD1510+/ LCD1510V+fullcolour monitor complements

PC compatible computers. Your system has one of two configurations:

–the video controller is built into the computer.

–the video controller is in the form of a display card (sometimes

referred to as graphics card, video adapter or graphics board).

Both configurations have a video connector (or a CRT PORT on laptop

computers). If you are not sure which connector is the video connector,

refer to your computer or display card manual.

To attach the monitor to your system, follow these instructions:

1. Turn off the power to the monitor and computer.

2. If necessary, installthedisplay card. For more informationabout

installing your card, refer to the display card manual.

3. Connect the 15-pin mini D-SUB of the appropriate signal

cable to the connector of the display card in your computer.

Tighten all screws (Figure A.1).

4. Connect the 15-pin mini D-SUB of the video signal cable and

the AC Adapter cable to the appropriate connectors on the back

of the monitor (Figure C.1). Place the AC adapter cable under

Clip A ( Figure C.1A).

NOTE: Incorrect cable connections may result in irregular operation,

damage display quality/components of LCD module and/or shorten the

module’s life.

5. Connect one end of the power cord to the AC Adapter and the

other end to the power outlet (Figure E.1).

6. Turn on the monitor (Figure F.1) and the computer.

E - 8 Installation

78134712 99/11/16, 3:44 PM22

Otros manuales para MULTISYNC LCD1510+

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de NEC

NEC

NEC 65" InfinityBoard 2.1 Manual de usuario

NEC

NEC MultiSync LCD1980SX-BK Manual de usuario

NEC

NEC MultiSync V552 Manual de usuario

NEC

NEC AccuSync LCD22WMGX, AccuSync LCD24WMCX Manual de usuario

NEC

NEC 175VXM Manual de usuario

NEC

NEC EA223WM-BK Manual de usuario

NEC

NEC MultiSync EA242WU Guía del usuario

NEC

NEC MultiSync P402 Guía

NEC

NEC MultiSync V651 Guía

NEC

NEC 60XM5 - PlasmaSync - 60" Plasma Panel Manual de usuario

NEC

NEC LCD8205 - MultiSync - 82" LCD Flat Panel... Manual de uso y mantenimiento

NEC

NEC M40 - MULTEOS - 40" LCD TV Manual de usuario

NEC

NEC X461UN - MultiSync - 46" LCD Flat Panel... Manual de uso y mantenimiento

NEC

NEC MultiSync LCD1735NXM Manual de usuario

NEC

NEC NEC MultiSync LCD1550X LCD1550X LCD1550X Manual de usuario

NEC

NEC MultiSync LCD1525X Manual de usuario

NEC

NEC ASPV46-AVT - AccuSync - 46" LCD TV Manual de usuario

NEC

NEC MultiSync V322 Guía

NEC

NEC M40 - MULTEOS - 40" LCD TV Manual de usuario

NEC

NEC MultiSync UX552 Manual de usuario

NEC

NEC NMV 1700V Manual de usuario

NEC

NEC MultiSync LCD1990FXp Manual de usuario

NEC

NEC MultiSync LCD2060NX Manual de usuario

NEC

NEC V421-2-R Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación

LG M1950D-PZ Manual de usuario
