Contents

FE Series monitor box* should contain the following:

• MultiSync FE Series Monitor with tilt/swivel base

MultiSync FE750 (JC-17W40) or

MultiSync FE950 (JC-19W40) or

MultiSync FE1250 (JC-22W71)

• Power Cord

• Captive Signal Cable

• User’s Manual

* Remember to save your original box and packing material to transport

or ship the monitor.

Power Cord

User's Manual

Captive Signal

Cable

E-1

100

Quick Start

To attach the MultiSync FE Series monitor to your system,

follow these instructions:

1. Turn off the power to your computer and MultiSync monitor.

2. If necessary, install the display card. For more information, refer to the

display card manual.

3. For the PC: Connect the 15-pin mini D-SUB of the captive signal cable

to the connector of the display card in your system (Figure A.1).

Tighten all screws.

For the Mac: Connect the Macintosh Cable Adapter (not included) to the

monitor connector on the Macintosh (Figure B.1). Attach the 15-pin mini

D-SUB end of the captive signal cable to the Macintosh cable adapter on

the computer (Figure B.1). Tighten all screws.

Computer

Captive Signal

Cable

Mac Adapter

(not included)

Figure B.1

Computer

15-pin mini

D-SUB

Captive Signal

Cable

Figure A.1

E-2

100

4. Connect one end of the power

cord to the monitor and the

other end to the power outlet

(Figure C.1).

5. Turn on the monitor (Figure D.1) and the computer.

6. This completes the installation.

NOTE: If you have any problems, please refer to the Troubleshooting

section of this User's Manual.

Power Outlet

Power

Cord

Figure C.1

Power Button

Figure D.1

E-3

100

Controls

OSM (On-Screen Manager) control buttons on the front of

the monitor function as follows:

Main Menu Sub-Menu

EXIT Exits the OSM menu. Exits to the OSM main menu.

CONTROL

▲/▼Moves the highlighted area

up/down to select one of the

controls.

Moves the highlighted area

up/down to select one of the

controls.

CONTROL

-/+

Moves highlighted area

left/right to select one of the

controls.

Moves the bar in the - or +

direction to decrease or

increase the adjustment.

PROCEED Has no function . Only executes control or enters

sub, sub-menu.

RESET Resets all the controls within

the highlighted menu to the

factory setting.

Resets the highlighted control

to the factory setting.

NOTE: When RESET is pressed in the main and sub-menu, a warning

window will appear allowing you to cancel the reset function.

When OSM controls are activated, icons are displayed at the top of the

menu. If an arrow (→) is displayed in a sub-menu, it indicates further

choices are available. To enter a sub, sub-menu, press PROCEED.

ab Brightness/Contrast Controls

BRIGHTNESS: Adjusts the overall image and background screen brightness.

CONTRAST: Adjusts the image brightness in relation to the background.

DEGAUSS: Eliminates the build-up of stray magnetic fields which alter

the correct scan of the electron beams and affect the purity of the screen

colours, focus, and convergence. When activated, your screen image will

jump and waver a bit as the screen is demagnetized.

Caution: Please allow a minimum of 20 minutes to elapse between uses

of the Degauss function.

de Size and Position Controls

AUTO ADJUST: Automatically adjusts the horizontal and vertical size and

position settings for applicable signal timings.

LEFT/RIGHT: Moves the image horizontally (left or right).

DOWN/UP: Moves the image vertically (up or down).

NARROW/WIDE: Decreases or increases the horizontal size of the image.

SHORT/TALL: Decreases or increases the vertical size of the image.

E-4

100

xColor Control

Color Presets 1 through 5, selects the desired color setting. The bar is

replaced by the color setting choice from 1 to 5. Each color setting is

adjusted at the factory to the stated Kelvin. If a setting is adjusted, the

name of the setting will change from Kelvin to Custom.

RED, GREEN, BLUE: Decreases or increases red, green, or blue

depending upon which is selected. The change in color will appear on

screen and the direction (decrease or increase) will be shown by the bars.

pq Geometry Controls

The Geometry controls allow you to adjust the curvature or angle of the

sides of your display.

IN/OUT (pincushion): Decreases or increases the curvature of the sides

either inward or outward.

LEFT/RIGHT (pincushion balance): Decreases or increases the

curvature of the sides either to the left or right.

TILT (parallelogram): Decreases or increases the tilt of the sides either

to the left or right.

ALIGN (trapezoidal): Decreases or increases the bottom of the screen

to be the same as the top.

ROTATE (raster rotation): Rotates the entire display clockwise or

counter clockwise.

?Tools 1

MOIRÉ CANCELER: Moiré is a wavy pattern which can sometimes appear

on the screen. The pattern is repetitive and superimposed as rippled

images. When running certain applications, the wavy pattern is more

evident than in others. To reduce moiré, adjust the ON/Level by using the

–/+ CONTROL buttons.

BASIC CONVERGENCE: Aligns all three colors (R, G, B) to form a single

color (white). The purpose of this control is to ensure that a white line

drawn on the screen is as crisp and clear as possible.

• Use the Horizontal control to adjust the alignment of the white lines in

the up/down direction.

• Use the Vertical control to adjust the alignment of the white lines in the

left/right direction.

E-5

100

AREA CONVERGENCE: A small window will appear to indicate the area

of adjustment — Top Horizontal, Top Vertical, Bottom Horizontal or

Bottom Vertical.

CORNER CORRECTION: Allows you to adjust the geometry of the corners

of your display — Top, Top Balance, Bottom or Bottom Balance.

LINEARITY: The Linearity selection allows you to adjust the spacing of the

areas on the screen. The purpose of this control is to ensure that a 2 cm

circle is a true 2 cm circle wherever it is drawn on the screen. The best

way to determine the vertical linearity is as follows:

• Draw equally spaced horizontal lines using a drawing application that

has a ruler.

• Use the Vertical Balance control to adjust the lines near the top and

bottom of your screen.

• Use the Vertical control to adjust the spacing between the lines near

the centre and top of your screen.

GLOBALSYNC CONTROL (MultiSync FE950 and MultiSync FE1250 only):

Eliminates picture impurities that may result from the earth’s magnetic

field. While in the sub-menus (TOP LEFT, TOP RIGHT, BOTTOM LEFT or

BOTTOM RIGHT), use the –/+ control buttons to fine tune the GlobalSync

corrections.

Note: NEC recommends that you perform GlobalSync correction while

running a typical application such as a spreadsheet or text

document.

FACTORY PRESET: Selecting Factory Preset allows you to reset most OSM

settings back to the factory settings. A warning statement will appear to

confirm that you do want to reset ALL settings. Individual settings can be

reset by highlighting the control to be reset and pressing the RESET button.

?Tools 2

LANGUAGE: OSM menus are available in 7 languages.

OSM TURN OFF: The OSM menu will stay on as long as it is in use. In

the OSM Turn Off sub-menu, you can select how long the monitor waits

after the last touch of a button to shut off the OSM menu. The preset

choices are 10, 20, 30, 60, 120 seconds.

E-6

100

OSM LOCK OUT: This control completely locks out access to all OSM

functions except brightness and contrast controls. When attempting to

activate OSM while in the lockout mode, a screen will appear indicating

that OSM controls are locked out. To activate the OSM Lockout function,

press PROCEED, then press “▲” and hold down simultaneously. To

de-activate the OSM Lockout, press PROCEED, then press “▲” and hold

down simultaneously.

IPM System Off Mode:

ENABLE: The IPM works normally, all stages

of the energy saving are used.

DISABLE: The OFF MODE of the IPM is not

used.

NOTE: For standard computers and display cards you should keep

the factory setting ENABLE.

EDGELOCK CONTROL: Operating your monitor at a non-standard

timing may cause images to appear darker than normal or have color

distortion. Use of the EdgeLock control will adjust images to their normal

state.

REFRESH NOTIFIER: A message will advise you if the refresh rate of the

signal being applied to the monitor by the computer is too low. For

further information, please refer to your display card or system manual.

Factory setting is OFF.

zInformation

Provides you with additional information which includes the following:

DISPLAY MODE: Indicates the current mode and frequency setting of the

monitor.

MONITOR INFO: Indicates the model number and the serial number.

E-7

100

Recommended use

Safety Precautions and Maintenance

FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE

FOLLOWING WHEN SETTING UP AND USING

THE MULTISYNC FE SERIES COLOR MONITOR:

•DO NOT OPEN THE MONITOR. There are no user serviceable parts

inside and opening or removing covers may expose you to dangerous

shock hazards or other risks. Refer all servicing to qualified service

personnel.

• Use the monitor in a clean, dry area.

• Do not spill any liquids into the cabinet or use your monitor near water.

• Do not insert objects of any kind into the cabinet slots, as they may

touch dangerous voltage points, which can be harmful or fatal or may

cause electric shock, fire or equipment failure.

• Do not place any heavy objects on the power cord. Damage to the cord

may cause shock or fire.

• Do not place this product on a sloping or unstable cart, stand or table,

as the monitor may fall, causing serious damage to the monitor.

• Keep the monitor away from high capacity transformers, electric motors

and other devices such as external speakers or fans, which may create

strong magnetic fields.

• If possible, position the monitor so that it is facing the east to minimize

the effects of the earth’s magnetic field.

• Changing the direction of the monitor while it is powered on may cause

image discoloration. To correct this, turn the monitor off for 20 minutes

before powering it back on.

• To separate the equipment from the power source you have to remove

the plug from the inlet socket.

• When operating the MultiSync monitor with its AC 220-240V worldwide

power supply, use a power supply cord that matches the power supply

voltage of the AC power outlet being used. The power supply cord you use

must have been approved by and comply with the safety standards of your

country. (Type H05VV-F should be used except in UK)

• In UK, use a BS-approved power cord with molded plug having a black

(5A) fuse installed for use with this monitor. If a power cord is not

supplied with this monitor, please contact your supplier.

Immediately unplug your monitor from the wall outlet and refer servicing

to qualified service personnel under the following conditions:

• When the power supply cord or plug is damaged.

• If liquid has been spilled, or objects have fallen into the monitor.

E-8

100

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de NEC

NEC

NEC MultiSync E232WMT Manual de usuario

NEC

NEC LCD8205 - MultiSync - 82" LCD Flat Panel... Manual de usuario

NEC

NEC MultiSync EA222WMe Manual de usuario

NEC

NEC MultiSync LCD1525X Manual de usuario

NEC

NEC AccuSync AS172-BK Manual de usuario

NEC

NEC MultiSync InGlass Touch V Series Manual de usuario

NEC

NEC MultiSync MD21GS-3MP Instrucciones de funcionamiento y seguridad

NEC

NEC MultiSync P221W Manual de usuario

NEC

NEC LCD1770GX-BK Manual de usuario

NEC

NEC LCD4010-BK - MultiSync - 40" LCD Monitor Manual de usuario

NEC

NEC AccuSync LCD200VX Manual de usuario

NEC

NEC MultiSync LCD1701 Manual de usuario

NEC

NEC MultiSync FP1350 JC-2241UMW Manual de usuario

NEC

NEC LCD1810 - MultiSync - 18.1" LCD Monitor Manual de usuario

NEC

NEC MultiSync LCD1800 Manual de lista de piezas

NEC

NEC LCD6520L-BK-AV - MultiSync - 65" LCD Flat Panel... Manual de usuario

NEC

NEC ShadowSense Touch MultiSync P404 SST Manual de usuario

NEC

NEC MD210C3 Instrucciones de funcionamiento y seguridad

NEC

NEC M40 - MULTEOS - 40" LCD TV Guía

NEC

NEC PlasmaSync 42VP4DG Manual de usuario

NEC

NEC X754HB Manual de usuario

NEC

NEC NEC MultiSync FE950+ FE950+ FE950+ Manual de usuario

NEC

NEC MultiSync P495 Manual de usuario

NEC

NEC MultiSync V422 Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación

LG M1950D-PZ Manual de usuario
