NEC FA Series Manual de usuario

Fine Pitch LED Video Display Indoor

NEC FA Series & FE Series

LED Wall Bundle

Quick Start GUIDE

For models:

LED-FA012i2 (110 inch)

LED-FA015i2 (137 inch)

LED-FA019i2 (110 inch)

LED-FA019i2 (165 inch)

LED-FA025i2 (220 inch)

LED-FE012i2 (110 inch)

LED-FE015i2 (137 inch)

LED-FE019i2 (110 inch)

LED-FE019i2 (165 inch)

LED-FE025i2 (220 inch)

2020-08-18

Version 2.0

Languages:

English Page 3

Russian Page 19

Turkish Page 35

Arabic Page 51

Fine Pitch LED Video Display Indoor

NEC FA Series & FE Series

LED Wall Bundle

Quick Start GUIDE - ENGLISH

For models:

LED-FA012i2 (110 inch)

LED-FA015i2 (137 inch)

LED-FA019i2 (110 inch)

LED-FA019i2 (165 inch)

LED-FA025i2 (220 inch)

LED-FE012i2 (110 inch)

LED-FE015i2 (137 inch)

LED-FE019i2 (110 inch)

LED-FE019i2 (165 inch)

LED-FE025i2 (220 inch)

2020-08-18

Version 2.0

Table of Contents

1. About this User Guide................................................................................... 5

1.1 Safety Symbols Used in this Manual .............................................................................................. 5

2. Safety and Compliance Guidelines................................................................. 6

2.1 Qualication of Personnel...................................................................................................................6

2.2 Personal Protection...............................................................................................................................6

2.3 General Safety Guidelines...................................................................................................................6

2.3.1 Risk of Fire...............................................................................................................................................7

2.4 Safety for Electricity and Power Supply .........................................................................................7

2.5 Safe Usage of LED Lamps....................................................................................................................8

3. About The LED WALL..................................................................................... 9

3.1 Turn on the LED Wall.............................................................................................................................9

4. The Video Controller ...................................................................................11

4.1 Front and Rear Panel..........................................................................................................................11

4.2 Display and Menu............................................................................................................................... 12

4.2.1 Select an Input Source .................................................................................................................... 12

4.2.2 Adjust the Brightness.......................................................................................................................13

5. Troubleshooting.........................................................................................14

6. Disposal.....................................................................................................15

6.1 Within the European Union............................................................................................................. 15

6.2 Outside the European Union.......................................................................................................... 15

7. Copyright and Disclaimer ............................................................................16

7.1 Copyright ...............................................................................................................................................16

7.2 Disclaimer ..............................................................................................................................................16

8. Service & Support in Europe.........................................................................17

1. AboutthisUserGuide

Dear customer,

Thank you for choosing one of NEC DISPLAY SOLUTIONS’ne pitch direct view LED

display systems.

In this NEC Quick Start Guide, you can nd a short overview about the components

and handling of the LED Wall.

We hope your experience with our product meets or exceeds your expectations.

Please contact us if you have any questions.

1.1 SafetySymbolsUsedinthisManual

Safety instructions emphasize potential hazards for personal injury or property

damage. This manual uses the following safety notices to indicate the severity of a

potential hazard:

Warning!

A warning for a potentially hazardous situation that can result in death,

personal injury, or property damage if not adhered to.

Caution!

A recommendation for a potentially hazardous situation that may

result in personal injury or property damage if not adhered to.

Notice

A recommendation for a potentially hazardous situation that may result in property damage

if not adhered to.

2. SafetyandComplianceGuidelines

Read the instruction manuals carefully and follow the given instructions and safety

information thoroughly.

The operating safety of the system is only ensured through its proper use.

Only operate the system with supplied accessories and tools.

2.1 QualicationofPersonnel

Only authorized and qualied technical personnel can perform the installation.

Only personal qualied by NEC DISPLAY SOLUTIONS and/or respectively authorized

personal may carry out repairs, service and maintenance work on the system. A

case of service occurs as soon as one component is damaged in any way, is not fully

functional any more.

Only trained personnel, such as electricians or NEC personnel, may connect the

internal power supply to mains power supply.

2.2 PersonalProtection

Warning!

Electric shock hazards.

Follow the relevant legal electric requirements of the country, where the system

will be operated, as well as the existing regulations of the operator, such as work,

operating and safety regulations.

2.3 GeneralSafetyGuidelines

Warning!

Risk of electric shock or re due to high-voltage components.

• Do not expose this unit to rain or moisture.

• Do not submerge this unit partially, or completely in water, or liquids.

• Do not use this unit’s polarized plug with an extension cord receptacle or other

outlets unless the prongs can be fully inserted.

• Do not open the cabinet because of the high-voltage components inside. There are

no user-serviceable parts are inside.

• Only qualied service personnel are allowed to service and open the unit.

Caution!

Risk of electric shock.

• If not in use, fully disengage the power to the unit by disconnecting the power cord

from the AC outlet.

• Do not use damaged cables. Check cables regularly. Replace damaged cables

immediately, they are not user-serviceable.

Caution!

Risk of re and product damage by aggressive substances.

• Keep the system away from aggressive substances, inammable gases

and vapors.

• Clean the unit only with materials or chemicals that are inert,

nonabrasive, noncorrosive and non-marking. Consult the

manufacturer for further advice should any doubts exist regarding any

cleaning procedure.

Caution!

Risk of re, injuries and product damage.

• Keep the system away from ammable material.

• Never block the air ventilation spaces around the LED Wall. Keep them free at all

times.

• Only use the supplied cables, which are t for the system and its components.

Caution!

Risk of product damage due to dusty environment.

Do not operate the system in a dusty environment.

Caution!

Risk of product damage by moisture or water.

Do not clean the system with water. Do not wipe the LED Pixel Cards with a damp cloth.

2.3.1 RiskofFire

Keep ammable materials away from the installation. During operation a lot of

energy is transferred into heat.

Proper ventilation must be provided. Never block the air ventilation holes. Keep them

free at all times.

2.4 SafetyforElectricityandPowerSupply

The electrical systems and their components are not to be opened. The parts inside

modules, which are not user-serviceable, hold high voltages, including when these

components are not in-use for a long time. Accessing these components may lead to

serious injury, or property damage.

Only authorized and qualied personnel may open the system and its

components! All repairs to the system may only be carried out by NEC DISPLAY

SOLUTIONS and/or by respectively authorized and qualied technical personnel.

• The limit values specied in the technical data must never be exceeded.

• Do not operate or touch the system with wet hands.

2.5 SafeUsageofLEDLamps

Caution!

Risk of product damage due to static electricity and surge voltage.

Do not touch the LED display areas.

Caution!

Risk of product damage due to moisture.

The LED lamps may absorb and hold moisture during the LED module

installation or if not used for a long time. Therefore, in such cases, the

brightness must be increased gradually during a break-in period before

setting the normal brightness.

If the LED lamps are lit with 100% brightness while moisture is retained,

the temperature will rise very quickly and the water inside the lamps will

evaporate and expand. This will cause the encapsulating resin to expand,

which may lead to separation of the boundary surface inside the LED

lamps. This separation can cause the LED lamps not to light up properly.

Lampbreak-in

Congure the brightness settings as shown below with a video displayed on the

LED module. After a break-in period of approx. 3 hours, the LED module can be used

under normal conditions.

Time since start-up:

0 hour 1 hour 2 hours 3 hours

(just after start-up)

Full white

Video content

60%40% 80% Normal operation

Brightness

value 20% 50% 70% Normal operation

3. AboutTheLEDWALL

The LED Wall is a high denition LED display product in 16:9 ratio with a high contrast

ratio and refresh rate.

The LED Wall consists of single LED modules, which are interconnected and centrally

controlled. The quantity of the modules depends on the size of your LED Wall.

To display videos, the LED Wall is connected to a video controller. The controller

receives the video input and the control signal from PCs. The Controller converts the

video input signal from the source and sends the video signal to the LED Wall. To

monitor the input source, a regular screen can be connected to the video controller.

Figure 1: General Setup of the LED Wall and Video Controller

ALED Wall FInput Source for Monitoring

BVideo Controller (NovaStar MCTRL660 PRO) GVideo Input to Video Controller

CVideo Output to LED Wall HSource PC with Video Input Material

DPower Supply IControl Signal

EMonitoring Screen JPC with Control Software NovaLCT

JHE

I G F

3.1 TurnontheLEDWall

Notice

The electrical setup of the LED Wall and the video input setup depends on individual customer

requirements. Below, you can nd the most common setups. Before following the instructions, please

ensure that your system ts one of the described setups.

How to turn on the LED Wall, depends on the electrical setup for the LED Wall.

1) The LED Wall is directly connected to mains

The LED Wall is always powered on and turns black if not needed (no

video input).

1. Ensure the video controller and the control PC is turned on.

2. Start the video input on the PC with the video material.

Result: The LED Wall displays the video material.

2) The LED Wall is has to be plugged in to mains (only for smaller LED Walls)

1. Plug in the LED Wall to mains. The amount and type of plugs depends on the

LED Wall setup and your region.

2. Ensure the video controller and the control PC is turned on.

3. Start the video input on the PC with the video material.

Result: The LED Wall displays the video material.

3) Setup with SX ON/OFF Switch

The LED Wall and video controller are connected to a SX ON/OFF

Switch, which turns the LED Wall and the video controller on and o.

1. Press the SX ON/OFF Switch on the system control rack.

2. Ensure the control PC is turned on.

3. Start the video input on the PC with the video material.

Result: The LED Wall displays the video material.

Otros manuales para FA Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Monitor de NEC

NEC

NEC E461 Manual de usuario

NEC

NEC LCD1990SXi BK MultiSync -LCD Manual de usuario

NEC

NEC DS TO DSX - CROSS Manual de servicio

NEC

NEC 42XP10 - PlasmaSync - 42" Plasma Panel Manual de usuario

NEC

NEC MultiSync LCD400V LA-1422JMW LA-1422JMW Manual de usuario

NEC

NEC PlasmaSync 61MP1 Manual de usuario

NEC

NEC P461-AVT - MultiSync - 46" LCD TV Manual de usuario

NEC

NEC MultiSync FE990 Manual de usuario

NEC

NEC NEC MultiSync LCD1525V LCD1525V LCD1525V Manual de usuario

NEC

NEC X461UN - MultiSync - 46" LCD Flat Panel... Manual de uso y mantenimiento

NEC

NEC LCD2470WNX - MultiSync - 24" LCD Monitor Guía del usuario

NEC

NEC MultiSync LCD1530V Manual de usuario

NEC

NEC MultiSync P241W Manual de usuario

NEC

NEC PlasmaSync 42VP4 Manual de usuario

NEC

NEC MultiSync 1940CX Guía

NEC

NEC MD302C6 Instrucciones de funcionamiento y seguridad

NEC

NEC EA191M-BK - MultiSync - 19" LCD Monitor Manual de usuario

NEC

NEC NEC MultiSync LCD1525V LCD1525V LCD1525V Manual de usuario

NEC

NEC P241W-BK Manual de usuario

NEC

NEC PlasmaSync 42VR5 Manual de usuario

NEC

NEC MultiSync E241N Manual de usuario

NEC

NEC MultiSync LCD1700M+ Manual de usuario

NEC

NEC LCD1560NX - MultiSync - 15" LCD Monitor Guía del usuario

NEC

NEC AccuSync LCD19WV Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación

LG M1950D-PZ Manual de usuario
