NEC 200 Manual de usuario

MultiSync LCD200

User’s Manual

Declaration of the Importer

We hereby certify that the

Color monitor LA-1221JMW

MultiSync LCD200

is in compliance with

Council Directive 73/23/EEC:

- EN 60950

Council Directive 89/336/EEC:

- EN 55022

- EN 60555-2

- EN 60555-3

- EN 50082-1

(IEC 801-2)

(IEC 801-3)

(IEC 801-4)

and marked with

NEC Europe Ltd. Ismaning Office

Steinheilstraße 4-6

D-85737 Ismaning, Germany

Safety Instruction

Caution:

When operating the LA-1221JMW with a 220-240V AC power source

in Europe except UK, use the power cord provided with the monitor.

In UK, a BS approved power cord with moulded plug has a Black (five

Amps) fuse installed for use with this equipment. If a power cord is not

supplied with this equipment please contact your supplier.

When operating the LA-1221JMW with a 220-240V AC Power source

in Australia, use the power cord provided with the monitor.

For all other cases, use a power cord that matches the AC voltage of the

power outlet and has been approved by and complies with the safety

standard of your particular country.

IBM PC/XT/AT, PS/2, MCGA, VGA, 8514/A and XGA are registered trademarks of

International Business Machines Corporation.

Apple and Macintosh are registered trademarks of Apple Computer Inc.

Microsoft and Windows are registered trademarks of the Microsoft Corporation.

NEC is a registered trademark of NEC Corporation. ErgoDesign, IPM, OSM, ColorControl,

OptiClear, CROMACLEAR and Advanced Digital Control System are trademarks of NEC Home

Electronics, Ltd.

MultiSync is a registered trademark of NEC Technologies, Inc in U.S., and of NEC Home

Electronics, Ltd in Canada, U.K., Germany, France, Spain, Italy, Austria, Benelux,

Switzerland, Denmark, Finland, Norway and Saudi Arabia.

All other trademarks or registered trademarks are property of their respective owners.

English

Deutsch

Français

Italiano

Español

Appendix

English

Introduction to the NEC MultiSync LCD200

Congratulations on your purchase of the NEC MultiSync LCD200 true

color monitor!

True Color Monitor

The MultiSync LCD200 monitor incorporates NEC’s own l2.1" true

color active matrix thin-film-transistor (TFT) liquid crystal display to

provide superior display performance and a reduced footprint. Less than

18 cm in depth, the MultiSync LCD200 monitor is ideal for

environments with space and weight constraints that require superior

image quality. A high resolution of 1024 x768 and a fine dot pitch of

0.24mm are ideal for displaying complex graphics and high definition

images. The MultiSync LCD200 monitor also supports 800 x 600 and

VGA graphics and text modes. Other examples of features that enhance

the MultiSync LCD200 monitor’s performance are Microsoft’s Plug and

Play compatibility, NEC’s ErgoDesign features and OSM (On Screen

Manager) controls. This LCD monitor also carries the MultiSync brand

name, ensuring greater compatibility with today’s sophisticated

computer platforms.

Analog Advantage

Because NEC incorporates only its own patented analog LCD modules

into its MultiSync LCD monitors, the MultiSync LCD200 monitor is

capable of displaying over 16.7 million colors in a continuous spectrum,

providing a truer representation of color. Like its analog predecessors

based on CRT technology, the MultiSync LCD200 monitor displays a

continuous gray scale and does not require the use of dithering

techniques, a mainstay of digital LCD panels, to approximate

intermediate shades of gray. In addition, the monitor’s high contrast

LCD enhances color vibrancy and improves focus with no geometric

distortion.

Introduction to the NEC MultiSync LCD200 E-1

Wider Compatibility

Adapting the latest advances in satellite technology to the circuitry

employed within the MultiSync LCD200 monitor, NEC provides wide

range compatibility with today’s graphics driver technology. Because

the MultiSync LCD200 monitor is analog through and through, it does

not require special analog to digital display or interface cards but can

accept RGB input directly. Consequently, the same display cards that

are used to drive the Multisync LCD200 monitor can also be used to

drive standard CRT monitors. NEC’s MultiSync LCD200 monitor can

be used with a wide range of systems such as IBM PC compatible

computers, Macintosh and Power Macintosh.

FullScan Capability

Using NEC’s own FullScan Capability, all of the resolutions supported

on the MultiSync LCD200 monitor are displayed full screen, utilizing

the most of the monitor’s large display area. Rather than displaying

640x480 resolution as a small box in the center of the MultiSync

LCD200 monitor’s display, this VGA resolution is displayed full screen,

allowing for greater visibility.

Reduced Footprint

The MultiSync LCD200 monitor offers nearly the same viewable image

size as conventional 14-inch and 15-inch CRTs at 40% of the depth and

30% of the weight. With a depth of about 17 cm and a weight of 4 kg,

the reduced footprint of NEC’s MultiSync LCD monitor provides the

ideal solution for environments requiring superior image quality but

with size and weight limitations. And the monitor’s small footprint and

low weight allow it to be moved or transported easily from one location

to another.

Low Power Consumption

The MultiSync LCD200 monitor has been designed with NEC’s IPM

(Intelligent Power Manager) System. When utilized with an Energy

Star system or display card, the MultiSync LCD200’s IPM System is an

innovative power-saving utilily that complies with both the EPA’s

Energy Star requirements and Europe’s NUTEK power management

E - 2 Introduction to the NEC MultiSync LCD200

requirements. With a maximum power consumption of 33 watts, the

MultiSync LCD200 monitor consumes over 50% less power than

conventional CRTs and emits less heat. In its power-saving mode, the

MultiSync LCD200 monitor consumes less than 6 watts. All this

translates into energy savings, environmental protection, reduced

emissions and reduced air conditioning costs of the work environment.

The MultiSync LCD200 monitor follows the Video Electronics Standard

Association (VESA) approved power-down signaling method. Endorsed

by the EPA, VESA’s Display Power Management Signaling (DPMS)

method is the power-down process a system should use to communicate

to the monitor to save power. Power-down functions can be utilized

only with an Energy Star system or display card which adheres to the

VESA DPMS standard. By using the monitor’s horizontal and vertical

SYNC signals, the monitor can be prompted into the different IPM

modes. The following is the description of the LED indicator for the

IPM power-saving modes:

Mode LED Indicator Power Consumption

ON Green Typical: 33 watts

Standby & Suspend Amber Typical: About 6 watts

Power Switch OFF No Light No Power Used

Plug and Play

Plug and Play is the new Microsoft solution with Windows 95 to

provide automatic peripheral connections without confusing and

time-consuming setup. NEC developed the monitor’s Plug and Play

capability that allows your Plug and Play compatible system to

automatically identify, configure and optimize the monitor connected to

it. The MultiSync LCD200 monitor automatically tells the system its

identification and capabilities. NEC’s partnership with Microsoft

provides you with simple installation, setup and service.

Introduction to the NEC MultiSync LCD200 E-3

ErgoDesign Features

The MultiSync LCD200 monitor utilizes NEC’s ErgoDesign features

philosophy that adapts technology to the way you work, increasing

productivity through enhancements in comfort and ease of use.

ErgoDesign features include a low glare screen treatment, power and

brightness controls that are positioned within easy reach, easy-to-use

on-screen controls and a tilt base that easily adjusts to each individual’s

preferred angle of vision.

Reduced Emissions

Incorporating NEC’s own Reduced Magnetic Field technology, the

MultiSync LCD200 monitor has minimal field emissions and follows the

strictest international magnetic field, alternating electric field and

electrostatic guidelines.

OSM (On-Screen Manager) Controls

The OSM (On-Screen Manager) controls simplify the MultiSync’s

Advanced Digital Control System. The control system is easily

accessed. Just touch the PROCEED button on the front of the monitor,

which gives you access to the Position, Image Adjust and Contrast

controls, the ColorControl System and many others. Use the front

controls for navigation.

Position

Image Adjust

Contrast

AccuColor

OSM Location

OSM Turn Off Time

OSM Lock Out

ON SCREEN MANAGER

E - 4 Introduction to the NEC MultiSync LCD200

Through the OSM control’s enhanced ColorControl System, you can

better match your image color to a variety of standards such as:

–Your personal preference (depending upon the application

used).

–A color standard such as Pantone or Trumatch.

–Another monitor.

–Your printer or Service Bureau output.

Additional OSM controls are available such as OSM Location, OSM

Turn Off Time, OSM Lock Out, Display Mode, Language Select and

Factory Preset.

Introduction to the NEC MultiSync LCD200 E-5
