NV
915
LCD Monitor
Service Manual
2
FCC Information................................................... 3
Important Safety Precautions ............................ 4
Product Specifications ........................................ 5
Location of Safety Warning Labels..................... 6
Exploded Views and Parts Lists ......................... 7
Troubleshooting...................................................13
Replacing Headphone Jack ................................14
Replacing Keypad ................................................15
Replacing LCD Monitor (M Series Bracket) .......17
Replacing LCD Monitor (T Series Bracket) ........23
Important Contact Numbers ..............................29
Table of Contents
3
Nautilus®NV915 Service Manual
FCC Information
This equipment has been tested and found to comply with limits for a class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment can generate, uses, and radiates radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause unacceptable interference to radio and television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures.
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced Radio/TV technician for assistance.
• Any changes or modifications in construction of this device which are not expressly approved by the party responsible
for compliance could void the users authority to operate the equipment.
A T T E N T I O N
FCC Information
4
Important Safety Precautions
W A R N I N G
IMPORTANT! To reduce the risk of fire, electrical shock or
other injuries, follow these safety precautions
when installing, using and maintaining your
NV915 LCD TV Monitor.
• Any changes or modifications in construction of this device which are not expressly approved by the party responsible
for compliance could void the users authority to operate the equipment.
A T T E N T I O N
• Always disconnect the power before installing or servicing the equipment.
• Disconnect the power cable and signal cable when thunder or lightning is present.
• Do not touch the power cord with wet hands. Make sure the electrical connectors are clean and dry before use.
• Disconnect the power cord when not in use for extended periods of time.
• Do not use if power cord is damaged.
• Do not install LCD Monitor close to heating sources.
• Do not place heavy articles on, or step on the LCD Monitor.
• The product should be installed in a clean and dry place.
• If you detect any smoke, unusual noise or smell, disconnect the electric power and contact service.
• Avoid contact with liquids or beverages.
• Do not use or place any combustible or flammable substances close to the LCD Monitor.
• Do not place the power cord close to any heating devices/sources.
• Do not apply any twisting forces or excess pressure to the LCD Monitor.
• Do not attempt to disassemble, repair or modify the LCD Monitor. If the LCD Monitor needs repair or adjustment, refer
servicing to qualified service personnel.
• When cleaning, do not directly spray with water or use flammable substances.
• Do not allow liquids to penetrate the LCD Monitor.
• When cleaning the LCD Monitor, disconnect the power and use a clean soft cloth. Never use a wet cloth.
W A R N I N G
This symbol appearing throughout this manual means:
Pay Attention! Be Alert! Your Safety Is Involved!
Save these instructions
Read all instructions before using.
5
Nautilus®NV915 Service Manual
NV915 Product Specifications
NV915 LCD TV Monitor
Gross Weight: 12.5 lbs/ 5.7 kg
Net Weight: 9.5 lb/ 4.3 kg
Product Dimensions: 49cm (L) x 17cm (W) x 43cm (H)
19.3” (L) x 6.7” (W) x 16.9” (H)
Power Requirements:
Adaptor Input: 100-240V AC, 50-60Hz
Adaptor Output” DC 12V, 3.33A
Regulatory Information:
FCC:
This device complies with Part 15 of the FCC and the Canadian ICES-003 regulations for Class A apparatus. Operations
is subject to the following two conditions:
(1).This device may not cause harmful Interferences and
(2).This device must accept any interference received, including interference
that may cause undesired operation.
The LCDTV Monitor NV915-000N Model bears the CSA Mark shown with adjacent
indicators ‘C’ and ‘US’
The LCDTV Monitor with PAL tuner bears the CE Mark and meets all safety and
EMC requirements required by the European Union and Australia / New Zealand.
For Customers in the European Union, Do not dispose of this product as refuse.
This product is to be recycled. For information on the proper method of disposal
contact a Nautilus Customer Service Representative. Contact information is available
in the Important Contact Numbers section in this manual.
The LCDTV Monitor with PAL tuner is RoHS compliant.
6
Safety Warning Labels
The following safety warnings are located on the NV915 LCD Monitor.
Please read all safety precautions and warning information prior to using your product.
7
Nautilus®NV915 Service Manual
Exploded View
M Series Bracket Kit
REF# PART# DESCRIPTION
1 001-1915 M Series Bracket Kit Complete
2 001-1894 Console Spacer
3 001-1959 M Series Bracket Kit Installation Manual
4 001-1944 M Series Replacement Hardware Kit (Use if replacement Hardware is needed)
1 2
3
4
8
Exploded View
LCD Monitor Kit
REF# PART# DESCRIPTION
1 001-1924 LCD Monitor with Accessories (US)
1 001-1992 LCD Monitor with Accessories (Euro)
1 001-2013 LCD Monitor with Accessories (Australia)
1 002-3782 LCD Monitor, DT with Accessories (Digital)
2 001-1922 Power Cord (US)
2 001-2015 Power Cord (Continental)
2 001-2019 Power Cord (Australia)
2 001-2017 Power Cord (UK/Ireland)
3 001-1938 Hardware Kit
4 000-8010 Power Brick
4 002-0387 LCD, DT Power Brick (Digital)
5 001-1995 European Adapter Kit (Europe/Australia Only)
6 001-1923 Owners Manual (CD ROM)
6 001-7167 Owners Manual (Digital CD ROM)
1
2 3 4 5 6
9
Nautilus®NV915 Service Manual
Exploded View
REF# PART# DESCRIPTION
1 001-2033 Front Keypad
2 001-1945 Earphone Jack
3 001-1997 Back Cover
LCD Monitor Components
3
2
1
10
Exploded View
REF# PART# DESCRIPTION
1 001-1948 T Series Bracket Kit Complete
2 001-1960 T Series Bracket Kit Installation Manual
3 001-1955 T Series Replacement Hardware Kit (Use if replacement Hardware is needed)
1
T Series Bracket Kit
3
2
