Multitone FLA870 Manual de usuario
USER GUIDE
FOR ALPHANUMERIC
RECEIVER FLA 870 AND
SECURE PAGING VARIANTS
9261-6366 iss 2 21/11/02 9:04 am Page 1
9261-6366 iss 2 21/11/02 9:04 am Page 2
FCC Statement OfCompliance
This devicecomplieswith FCCPart15 regulations.
Operation is subject to the following two conditions:-
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Unauthorised modification to this equipment, will void the
user’s authority to operate the device under the terms of
the above regulations.
Contents
Introduction and Getting Started .................. 1
Switching the Pager On ................................ 1
Status and Operating Symbols .................... 2
Setting the Time and Date ............................ 4
Setting the Alarm .......................................... 6
Selecting the Alert ........................................ 8
Selecting Display Options .......................... 10
Receiving a Message ..................................11
Reviewing Stored Messages ...................... 12
Archiving Messages .................................. 13
Reviewing Archived Messages ....................14
Deleting a Message ....................................15
Deleting all Messages ................................15
Reviewing information Service messages .. 17
Secure Messaging Options ........................ 18
Z-Page: Activation and Protection .............. 19
Reading Z-Page Messages ........................ 19
Z-Page: Notes of Caution .......................... 20
(i)
9261-6366 iss 2 21/11/02 9:04 am Page 3
KeyPage Operation .................................... 21
KeyPage Message Access.......................... 22
KeyPage PIN Changes................................ 23
KeyPage PIN Reset .................................... 24
KeyPage Barred Access ............................ 24
Caring for your Pager ................................ 25
Fault-Finding .............................................. 25
(ii)
9261-6366 iss 2 21/11/02 9:04 am Page 4
Introduction and Getting Started
Congratulations on selecting the FLA870
alphanumeric pager from Multitone. Your
pager has all the features you expect from a
top class product yet it retains simplicity of
operation through the superbly designed user
interface and icon menu selection. This guide
will describe the operation of the product and
ensure that you receive the full benefits of
paging with the FLA870.
On the back of your pager you will find the
battery cover. Slide the cover in the direction
of the arrow to remove. Insert the battery
matching the +to +.
Carefully slide the cover back into position.
Switching the pager ON
To turn the pager ON press and hold the •>
button for one second. A short alert will sound
and the pre programmed Switch On message
will be displayed.
1
9261-6366 iss 2 21/11/02 9:04 am Page 5
After one second the time and date will be
shown. This is the standby display.
Standby Screen
Status and Operating Symbols
The standby display shows the current time
and date. It also shows if there are unread
messages, whether audible or vibrate alert is
selected and, if appropriate, gives low battery
and out of Range warnings by displaying the
following symbols:
Status Symbols
14 : 24 20. 02. 00
14 : 26 20. 02. 00
2
9261-6366 iss 2 21/11/02 9:04 am Page 6
The status symbols are as follows:
Unread Messages Low Battery
Audible Alert Out-of-Range
Vibrate Memory Full
From the standby display press •>to enter
the pager options screen. The following
symbols are displayed:-
Pager Option Screen
Alarm Function Alert Selection
Backlight Off
Time Setting and Delete All
Timed Off Setup Messages
Pager Menu Secure Pin
Options entry
3
9261-6366 iss 2 21/11/02 9:04 am Page 7
To turn the pager OFF press •>to show the
pager options and then press <or >
several times until is flashing. Press •>
and the display will show plus flashing .
Press •>again to turn the pager off.
Setting the Time and Date
The pager standby screen will normally show
the time and date. To set the current time and
date press •>once to display the pager
options and then press <or >several times
until the flashes. Press •>twice to display
the time function edit screen.
Time Function Screen
The clock symbol will flash. To set the clock
press •>and the clock symbol will appear
4
9261-6366 iss 2 21/11/02 9:04 am Page 8
with 12 or 24 hour mode indicated. The hour
will flash and the correct value may be
selected by pressing either <or >.
Once the hour is correct press •>and the
tens of minutes will flash.
Press <or >until the correct number is shown
and then press •>.
Press <or >until the correct number is shown
and then press •>to set the minutes.
5
5 : 27pm 20. 02. 00
12
5 : 27pm 20. 02. 00
12
5 : 27pm 20. 02. 00
12
9261-6366 iss 2 21/11/02 9:04 am Page 9
The date is set with the same method.
Once the display shows the correct time and
date the 12 or 24 hour mode can be selected
by pressing the <or >buttons to change as
required.
Press and hold •>for one second to return
the pager to the standby screen.
Setting the Pager Alarm
The pager has a daily alarm feature and it may
be set by pressing the •>to show the pager
options and then selecting symbol using <
or >buttons.
Press the •>to display the alarm options
screen.
6
24
17 : 27 20. 02. 00
