Instruction Sheet Subject: FreshBlender Caster Brake Retrofit

SCOPE: ALL MULTIPLEX FRESHBLENDER UNITS

1 of 3

 DocumentNumber:020008727 April14,2021

MULTIPLEX

645 PARK EAST BLVD SUITE 5, NEW ALBANY, IN 47150

844-724-CARE

WWW.MULTIPLEXBEVERAGE.COM

Refreshing the Experience

TwopeoplearerequiredtocompletethisCasterBrake

Retrofit.

TOOLS REQUIRED

• Clean5-gallonbucket

• FreshBlenderDoorKey

• Six(6)Boards,2”x4”boardscutto2’lengths(5cmx

10cmcutto61cmlengths)

• 14mmWrench

• 14mmSocketandDriverorCordlessImpactDrill

PARTS REQUIRED

• BlueLocTite

• 020008731CasterBrakeRetrofitKit(kitpartslisted

below)

PART NO. DESCRIPTION QTY

020008728 BrakeHardwareSet 2

020008727 Instructions 1

BrakeHardwareshownbelow(doesnotincludewheelfork):

NUT

BRAKE BRACKET

BRAKE PEDAL

WAVE WASHER

BOLT

nWarning

NeverleaveunitunattendedduringCasterBrakeRetrofit.

nWarning

Unitisheavy.DoNOTattempttoliftbyhand.

,Caution

Do NOT use a pry bar, crowbar or other sharp ended

objecttoleverageunitup.Sharpobjectswilldamageunit

refrigerationsystem.

REMOVE OLD HARDWARE

1. Pullunit12”(31cm)awayfromwall.

2. Place5-gallon(20liter)bucketunderdrain.

3. Unlockdoor.

4. Openlowerrefrigerationdoor.

5. Stackthree(3)2x4’s(5cmx10cm)flatonthefloor

perpendiculartotherightsideofunit.Positionthese

boards1”(2.5cm)behindtherearofcaster.Thesethree

(3)boardswillbeusedtosupporttheunit.

6. Stacktwo(2)boards6”(15cm)awayandparallelto

frontofunit.Theseboardswillbeusedasafulcrumto

liftfrontofunit.

7. Slideone(1)board3”(8cm)underfrontofunitandlay

perpendicularontopoftwo(2)boardslayinginfront

ofunit.Thisboardwillbeusedasalevertoliftfrontof

unit.

8. Makesurelowerrefrigerationdoorisopen.Doormust

beopentopreventdamagetodoorandunit.

9. Onepersonshouldcarefullysteponendofleverwhile

secondpersonslidesthethree(3)boardstackunder

unit.

10.Verifythethree(3)boardstackisstableandexcessive

lengthofboardscanbeseenonbothsidesofunit.

2 of 3

DocumentNumber:020008727 April14,2021

Subject:FreshBlenderCasterBrakeRetrofit

11.Gentlyreleasepressurefromleveruntilunitrestson

three(3)boardstack.Removeandsetasideleverand

fulcrumboards.Closelowerrefrigerationdoor.

12.Testunitforstability.

13.Removeoldhardware.

A. Placewrenchoncasterboltandplacesocketon

casternut.

B. Turnsockettoremovenutwhileusingwrenchto

holdbolt.Removebolt,nutandwheel.

INSTALL NEW BRAKE

14.PlaceWaveWasherontoBolt.

PlaceBrakeBracketoverwheelfork.VerifytabonBrake

Bracketisinsertedintoslotonwheelfork.

15.PlaceBrakePedalontoBrakeBracket.

16.Insertoldcasterwheelbetweenforksandpressboltinto

assemblyasshownbelow.

3 of 3

DocumentNumber:020008727 April14,2021

Subject:FreshBlenderCasterBrakeRetrofit

17.Place1-2dropsofBlueLocTiteontonutthenthreadnut

ontobolt.

18.Placewrenchoncasterboltandplacesocketoncaster

nut.Turnsockettoinstallnutwhileusingwrenchto

holdbolt.EndofBoltshouldbeflushwithendofnut.

DoNOTovertighten.WithBrakePedalinOFFposition,

wheelshouldturn.

19.Repeatsteps13-18forinstallingbrakehardwarefor

otherfrontwheel.

20.Stacktwo(2)boards6”(2.4cm)awayandparallelto

frontofunit.Theseboardswillbeusedasafulcrumto

liftfrontofunit.

21.Slideone(1)board3”(1.2cm)underfrontofunitand

layperpendicularontopoftwo(2)boardslayinginfront

ofunit.Thisboardwillbeusedasalevertoliftfrontof

unit.

22.Openlowerrefrigerationdoor.Doormustbeopento

preventdamagetodoorandunit.

23.Onepersonshouldcarefullysteponendofleverwhile

secondpersonslidesthethree(3)boardstackoutfrom

underunit.

24.Gentlylowerunitandremoveboards.

25.Testeachnewcasterbrakeassembly.Adjustif

necessary.

26.Closelowerrefrigerationdoorandlockunit.

27.Removedrainbucket.

28.Pushunitintoplace.

29.Connectdrain.
