Installation Guide 1
Model 712
Single Handle Kitchen Faucet
Tools
Certifications & Information
Configuration
Installation Guide
Gather the necessary tools as shown to complete the installation of this faucet.
Connect to water supply lines with TWO
3/8" Compression Faucet Connectors
The following tools are optional:
Flashlight
• ADA Approved
• Limited Lifetime Warranty
Safety Glasses Channel Lock
Adjustable Wrench
Pliers
Water supply
Connector
Phillips Screwdriver
One-Hole Installation
Three-Hole Installation with Base Plate
1 3/8"
S I N K S & F A U C E T S
Flow Rate
1.85gpm at 60PSI
2
Installation Guide
Faucet Installation
E
C
F
A
A. Turn o the water supply. Remove the
faucet with the mounting hardware
attatched from the package.
B. Remove all mounting hardware from
the shanks.
D
B
C. Insert the shank of the faucet body into the
hole of the sink deck. If installing a base
plate, insert the faucet shank through the
base plate rst, followed by the faucet
gasket, and then into the holes of the
sink deck.
D. From the underside of the sink or mounting
surface, attach the washer, followed by the
lock nut, and screws onto the shank.
E. Hand-tighten the lock nut until secure.
F. Then, use a screwdriver to tighten each
screw slightly until all are secure.
shank washer
lock nut
gasket
3
Installation Guide
Important
Faucet Installation Continued
To prevent damage to the tube body, tighten the connections by carefully using two
wrenches as shown. Use caution to not bend the stem.
Check for leaks.
Turn on the water supply SLOWLY, to test for leaks
before completely opening the water lines.
G
Water supply
Connector
G. Connect 3/8" compression ttings to each
hose, and then to each corresponding water
supply line. Secure each tting with a 1/4 turn
of a wrench.
Installation Guide 4
Maintenance & Cleaning
Notes
The faucet can be cleaned by rinsing with clear water or washing with mild detergents. Dry the faucet with a clean, soft cotton cloth.
CAUTION: do not use any cleaning agents containing acids, abrasives, or other harsh chemicals.
Simply rinse and dry faucets with a soft towel every week to prevent
mineral deposits from forming. Clean spills and splatters as they happen.
Do not let soap, toothpaste or other contaminates dry on the faucet, this
can stain or pit the nish. Use a mild soap and soft sponge or towel to
remove residue. Rinse and dry thoroughly.
Never use an abrasive cleaner or rough sponge to clean or dry your faucet.
Harsh cleaners could dull or scratch the nish. Use only a soft disinfectant
that does not contain bleach or chlorine and apply with a soft towel.
www.mrdirectint.com
1-877-946-5725
Warranty Information
MR Direct warrants to the original consumer purchaser that our sinks and faucets will be free from defects in
material and workmanship under normal use for the lifetime of the product. MR Direct may elect to repair or
replace any defective MR Direct product covered by our warranty.
Our warranty does not cover defects caused by misuse, abuse, negligence, alterations, environmental conditions,
improper installation, storage and handling; nor any labor expenses.
From time to time we will change design specications and materials as conditions require and improvements
are developed. We have no obligation to incorporate such changes in products we previously manufactured.
This warranty is in lieu of any and all other warranties, express or implied, including any warranties of
merchantability and of tness for a particular purpose; and excludes any incidental or consequential damages.
No representative has the authority to change or enlarge the above warranty.
This warranty is only valid in the United States of America. Some states do not allow limitations on how long
an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above
limitations or exclusion may not apply. This warranty gives you specic legal rights, and you may also have other
rights which vary from state to state.
One-Year Accessory Warranty
MR Direct warrants to the original purchaser that all of our accessories will be free from defects in material and
workmanship under normal use for one full year.
Our warranty does not cover defects caused by misuse, abuse, negligence, alterations, environmental conditions,
improper installation, storage and handling; nor any labor expenses. MR Direct may elect to repair or replace any
defective MR Direct accessory covered by our warranty.
