MP Glance Manual de usuario
MP
For Anywhere Work Takes You
User’s Manual
GLANCE
User’s Manual
User’s Manual
Read all warnings and follow all instructions . Keep this user guide for later reference.
Do not use this device near water. To reduce the risk of fire or electric shock. do not expose
the device to moisture.
Do not place the device on an uneven or unstable surface. The device may fall over resulting
in an injury or malfunction.
Avoid exposing the device to direct sunlight or other sources of sustained heat.
Always use genuine Mobile Pixels components to ensure safety and product performance.
To avoid the risk of electric shock or component damage. switch oft the power before
connecting other components to the display.
Disconnect the power plug from the AC outlet if the device wil l not be used for a long period
of time.
When connecting to a power outlet. DO NOT remove the grounding prong. Please ensure
grounding prongs are NEVER REMOVED.
Place the device in a well-ventilated area. Do not place anything on the device that prevents
heat dissipation.
The power adaptor must be replaced when using different voltage from that specified in the
User Guide. For more information. please contact us.
Do not overload power strips and extension cords. Overloading can result in fire or electric
shock.
Do not apply pressure to the screen. Excessive pressure may cause permanent damage to the
display.
Plastic bags can be dangerous. Keep plastic bags away from babies and children to avoid
danger of suffocation.
Do not attempt to repair the product by yourself. Opening the back cover may expose you to
high voltages. the risk of electric shock. and other hazards. If repair is required. please contact
us anytime.
If there are visual smoke or sparks. unplug the power cord and contact us. Do not try to repair
the product yourself.
To avoid risk of electric shock . do not touch the power plug and ports with wet hands.
Safety Precautions
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
User’s Manual
Mobilepixels.us
What is in the box
Adjustable angle
Connect the monitor to your computer
External controls
OSD(On-Screen Display) Menu
OSD
Specifications
Troubleshooting
01
01
02
02
03
04
06
07
Table of content
User’s Manual
01
Mobilepixels.us
What is in the box
Take out the monitor from the packaging
and place it on a stable and level
workspace.
Open or close the base. The viewing
angle of the monitor can be adjusted
using the stand. (As shown below,
adjustable angle 0 ~ 180)
Adjustable angle 0 ~ 180
1.
2.
Monitor Mini HDMI Cable USB-C data cable
USB-C power cable
Quick start guide
Charger
User’s Manual
02 Mobilepixels.us
MINI HDMI Cable
Adapter
Type-C cable
Connect the monitor to your computer
a. Connect the Type-C Cable to the
computer.
1. 2.
3. 4.
Port Icon Description
1
2
3
4
Connect to headphone
DC IN.Plug in the adapter (Accessory)
Type C IN.Connect to Notebook Type CDP Alt
Connect to PC or other device HDMI
No. Icon Item Description
a.Press this button to select the desired item
when in OSD menu.
b.Long press this button to adjust the volume.
Press this button to select the desired item
when in OSD menu.
Long press for 3 sec to turn on/off Monitor.
Blue indicates power on. Blinking Blue
indicates standby mode.
*Please make sure to use the original MobilePixels
accessories in order to preserve the quality-aspects.
1 2 3 4
1
2
3
4
External controls
Plug the adaptor of you
monitor into a nearby
electrical outlet.
Use the adaptor to
connect to the
monitor'S Port 2.
Connect Type-C Cable
(Only Type-C-input model)
Conner Mini HDMI Cable
(One HDMl-input model)
a. Connect the Mini HDMI cable to
the computer.
Up/Hot Key
Down
Power Button
LED Indicator
1
2
3
4
Up key
Down key
Power Button
LED Indicator
User’s Manual
03
Mobilepixels.us
Backlight
Volume
Contrast
Saturation
Temperature
9300
Cool+
7500
Cool
6500
Warm
5800 sRGB
HDMI
OFF
OFF ON
MP-Glance-20220818
ON
TypeC 1 TypeC 2
Warm+
Signal
EyeCareMode
Reset
Exit
Backlight
Volume
Contrast
Saturation
Temperature
9300
Cool+
7500
Cool
6500
Warm
5800 sRGB
HDMI
OFF
OFF ON
MP-Glance-20220818
ON
TypeC 1 TypeC 2
Warm+
Signal
EyeCareMode
Reset
Exit
Backlight
Volume
Contrast
Saturation
Temperature
9300
Cool+
7500
Cool
6500
Warm
5800 sRGB
HDMI
OFF
OFF ON
MP-Glance-20220818
ON
TypeC 1 TypeC 2
Warm+
Signal
EyeCareMode
Reset
Exit
OSD(On-Screen Display) Menu
1
2
3
4
1
2
3
Powering On & Off
Volume Up & Down
Press and hold the power button for 3 seconds to turn the monitor ON and off. The
monitor will enter power saving mode when turned on unless is a suitable device
connected.
Press and hold the & up button to enter
Volume Adjustment.
Then adjust the volume with the & Up
button (volume increase) and Down button
(volume decrease).
Quick Menu Backlight
Press any key to enter the quick menu.
Using the Up button, select Backlight from
the menu."
Use the Up and Down buttons to adjust
the backlight between 0-100.
Press Power button to confirm and exit the
menu, or wait 3seconds without pressing
any button."
Input source
Press any key to enter the quick menu.
Using the power button open Input Source
from quick menu, to select a USB-C or
Mini-HDMI input source."
When you are done, use the Power button to
confirm and exit."
Backlight
Signal
Volume
Volume up
Volume Down
Backlight up
Backlight Down
User’s Manual
04 Mobilepixels.us
Backlight
Volume
Contrast
Saturation
Temperature
9300
Cool+
7500
Cool
6500
Warm
5800 sRGB
HDMI
OFF
OFF ON
MP-Glance-20220818
ON
TypeC 1 TypeC 2
Warm+
Signal
EyeCareMode
Reset
Exit
OSD
Powering On I Off
Contrast
The following content is for general reference only.The actual product specific
-ions may vary. The on-screen display (OSD) can be used for adjusting the settings
of your monitor. Press any button to open the Navigation OSD.You can use the OSD
to adjust the picture quality,OSD setting and general settings. Please Up and
Down buttons to navigate the OSD menus, and power button to confirm
selection."
Color Temperature Setting
The colour temperature adjustment
Warm-Normal-Cool corresponds to the colour
temperature of 6500K, 7500K, 9300K and the
User mode has a three.
Contrast
Backlight
Volume
Contrast
Saturation
Temperature
9300
Cool+
7500
Cool
6500
Warm
5800 sRGB
HDMI
OFF
OFF ON
MP-Glance-20220818
ON
TypeC 1 TypeC 2
Warm+
Signal
EyeCareMode
Reset
Exit
Color Temperature
1
2
3
4
Press any key to enter the quick menu.
Using the Up button, select Contrast from
the menu."
Use the Up and Down buttons to adjust
the Contrast between 0-100.
Press Power button to confirm and exit the
menu, or wait 3 seconds without pressing any
button."
Contrast up
Contrast Down
User’s Manual
05
Mobilepixels.us
Backlight
Volume
Contrast
Saturation
Temperature
9300
Cool+
7500
Cool
6500
Warm
5800 sRGB
HDMI
OFF
OFF ON
MP-Glance-20220818
ON
TypeC 1 TypeC 2
Warm+
Signal
EyeCareMode
Reset
Exit
Saturation
Eye Care Mode
Reset
1
2
3
4
Press any key to enter the quick menu.
Using the Up button,select Backlight from
the menu."
Use the Up and Down buttons to adjust
the Backlight between 0-100.
Press Power button to confirm and exit the
menu, or wait 3 seconds without pressing
any button."
1
2
3
Eye Care Mode
Press any key to enter the quick menu.
Using the power button open Eye Care Mode
from quick menu.
When you are done, use the Power button to
confirm and exit.
1
2
3
Reset
Press any key to enter the quick menu.
Using the power button open Reset from
quick menu.
When you are done, use the Power button to
confirm and exit.
Exit the
menu
Saturation up
Saturation Down
Backlight
Volume
Contrast
Saturation
Temperature
9300
Cool+
7500
Cool
6500
Warm
5800 sRGB
HDMI
OFF
OFF ON
MP-Glance-20220818
ON
TypeC 1 TypeC 2
Warm+
Signal
EyeCareMode
Reset
Exit
Saturation
User’s Manual
06 Mobilepixels.us
Specifications
Model E1SN2F-C
362(W)x240(H)x15.6(D)mm
1.1kg
300(typ)
16.2M
800:1
16:9
IPS
60Hz
FHD (1920x1080)
15.6"
170°(H)x170°(V)
1
2
Yes
1W*2
Typ. 8W
0.5W
Dimensions Size
Net Weight
Display Brightness
Colours
Contrast Ratio
Native Aspect Ratio
Panel Type
Refresh Rate
Resolution
Size
Viewing Angle
Inputs HDM1(1.4)
USB Type-C
Outputs Headphone Jack
Audio Speaker
Power Consumption
Standby Consumption
