VPort 56-2MP Series

Quick Installation Guide

Second Edition, September 2014

- 2 -

Overview

The VPort 56-2MP series is the world’s first rugged IP camera that can

tolerate environmental temperatures ranging from -40 to 75°C without

cooling fan. It is an industrial-grade, H.264 box-type IP camera that

combines Full HD resolution (1920 x 1080), 10x optical zoom, and 16x

digital zoom to enhance surveillance system efficiency while delivering

state-of-the-art video quality. Optional housing and PT scanner

accessories are available for indoor and outdoor installation.

With a built-in removable IR-cut filter and automatic color mode switching,

the VPort 56-2MP series is suitable for both day and night use.

Highly-tuned ROI (Region of Interest), BLC (Back Light Compensation),

and sense up functions enable the VPort 56-2MP to produce exceptionally

clear images. The VPort 56-2MP can encode analog video into both H.264

and MJPEG video streams and can transmit up to 3 independent video

streams (2 in H.264, and 1 in MJPEG) simultaneously. Advanced video

encoding technology enables the camera to support up to 30 fps for each

of the H.264 and MJPEG streams.

Package Checklist

Moxa’s VPort 56-2MP series is shipped with the following items. If any of

these items is missing or damaged, please contact your customer service

representative for assistance.

•1 VPort 56-2MP camera (see ordering information below)

•Terminal block accessory package (3-pin terminal block for power

input, 9-pin terminal block for RS-485 DX+ and DX- and I/O)

•Quick installation guide

•Documentation and software CD (includes user’s manual, quick

installation guide, and VPort utility)

•Warranty card

NOTE

Check the model name on the VPort’s side label to verify that the

model name is correct for your order.

NOTE

This product must be installed in compliance with your local laws

and regulations.

Ordering Information

•VPort 56-2MP-CAM10X: 0 to 60°C operating temperature

•VPort 56-2MP-CAM10X-T: -40 to 75°C operating temperature

•VPort 56-2MP-CAM10X-S-SC: 0 to 60°C operating temperature,

single mode fiber interface

•VPort 56-2MP-CAM10X-S-SC-T: -40 to 75°C operating

temperature, single mode fiber interface

- 3 -

Specifications

Camera

Sensor: 1/2.5” HD progressive scan CMOS

Lens: 6.3 to 63 mm auto focus zoom lens

Illumination:

• Color: 0.2 lux at F1.8

• B/W: 0.05 lux at F1.8

Synchronization: Internal

White Balance: ATW, AWB

Electronic Shutter:

AES: On/Off

Fix: 1/50, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 sec

S/N Ratio: More than 50 dB (AGC off)

ICR Control: Auto (light sensor control) or DI control

DNR: Built-in 3D DNR

AGC Control: On/Off

Backlight Compensation: On/Off

Auto Exposure: On/Off

Image Rotation: Flip, Mirror, and 180° rotation

Auto Sense Up: On/Off, Max. 64x

Image Setting: Manually tune sharpness

Video

Video Compression: H.264 (ISO/IEC 14496-10) or MJPEG

Video Output: via Ethernet

Video Streams: Up to 3 video streams (2 x H.264 and 1 x MJPEG)

• Stream 1: H.264, 1920 x 1080 resolution (max.)

• Stream 2: H.264, 1280 x 720 resolution (max.)

• Stream 3: MJPEG, full D1 resolution (max.)

Video Resolution and FPS (frames per second): Up to 30/25 FPS for

each of 3 independent streams at max resolution.

Video Viewing:

• DynaStream™ supported for automatic adjustment of frame rate

• Image stabilizer to reduce video shaking

• CBR Pro™ for optimized image quality within limited bandwidth

• 8 privacy mask areas provided

• Adjustable image size and quality

• Timestamp and text overlay

• Maximum of 10 simultaneous unicast connections

• ROI (Region of Interest) configuration for up to 3 areas

PTZ: Compatible with Videotec Ulisse Netcam PT scanner

Audio

Audio Inputs: 1 Line-in with 3.5 mm phone jack

Audio Outputs: 1 Line-out with 3.5 mm phone jack

Two-Way Audio: Full duplex two-way audio

Network

Protocols: TCP, UDP, HTTP, SMTP, FTP, Telnet, NTP, DNS, DHCP, UPnP,

RTP, RTSP, ICMP, IGMPv3, QoS, SNMPv1/v2c/v3, DDNS, Modbus/TCP,

802.1X, SSL

Ethernet: 1 10/100BaseT(X) Ethernet port, RJ45 connector, or 1

100BaseFX, single mode

Standard: ONVIF

- 4 -

Serial Interface

RS-485: 1 full-duplex RS-485 port

GPIO

Digital Inputs:

1, max. 8 mA

• High: +13 to +30 V

• Low: -30 to +3 V

Relay Output: 1, max. 24 VDC @ 1 A

LED Indicators

STAT: Indicates if the system is booted properly or not

Network: 10 Mbps or 100 Mbps

Power: Power on/off

Local Storage

SD Socket: Standard SD socket (SDHC, SDXC)

Power Requirements

Input:

12/24 VDC, 24 VAC or Power-over-Ethernet (PoE+, 802.3at),

redundant power design

Power Consumption: 23 W

Physical Characteristics

Camera Body Housing: Metal, IP30 protection

Installation: Wall mounting, ceiling mounting, pole mounting, corner

mounting (optional external housing and mounting accessory may be

required)

Alarms

Video Motion Detection: 3 independently configurable motion areas

Camera Tamper: Sensitivity adjustable camera tamper detection

(Pending)

Scheduling: Daily repeat timing schedule

Imaging: JPEG snapshots for pre/trigger/post alarm images

Custom Alarms: HTTP event and CGI events for setting customized

alarm actions

Email/FTP Messaging: Automatic transfer of stored images via email or

FTP as event-triggered actions

Pre-alarm Buffer: 84 MB video buffer for JPEG snapshot images

Environmental Limits

Operating Temperature:

Standard Models: 0 to 60°C (32 to 140°F)

Wide Temp. Models: -40 to 75°C (-40 to 167°F)

Storage Temperature: -40 to 85°C (-40 to 185°F)

Ambient Relative Humidity: 5 to 95% (non-condensing)

Standards and Certifications

Safety: UL 60950-1, EN 50121-4, NEMA TS2

EMI: FCC Part 15, CISPR (EN 55022) class A

EMS:

EN 61000-4-2 (ESD), Level 3,

EN 61000-4-3 (RS), Level 3,

EN 61000-4-4 (EFT), Level 3,

EN 61000-4-5 (Surge), Level 3,

EN 61000-4-6 (CS), Level 3,

EN 61000-4-8,

EN 61000-4-11

Shock: IEC 60068-2-27

Freefall: IEC 60068-2-32

Vibration: IEC 60068-2-6

- 5 -

Warranty

Warranty Period: 3 years

Details: See www.moxa.com/warranty

Product Description

Front and Top Panels

•SD Card Slot: You can remove the SD card slot cover and insert an

SD card for disconnection/event local storage.

•Mounting Bracket Screw Hole: Screw holes for fastening the

camera to a protective housing.

•Reset Button: Use a pointed object to depress the reset button to

reboot; push and hold to reboot and restore factor defaults.

Rear Panel

1. Phone jack for audio output

2. Phone jack for audio intput

3. RJ45 port for PoE/non-PoE connection

4. Ground screw for connecting a ground wire

5. 3-pin terminal block for power input

6. LED indicator to show network and system status. Green indicates

normal operation.

7. LED indicator to show power status. Green indicates normal

operation.

8. 9-pin terminal block for RS-485 and DI and relay.

- 6 -

NOTE

The VPort 56-2MP can be powered by a 12 VDC, 24 VDC, or 24

VAC

input or Power-over-Ethernet (PoE+, 802.3at). Use an

external power supply together with PoE+ for power redundancy.

Software Installation

Step 1: Configure the VPort 56-2MP’s IP address

When the VPort 56-2MP is first powered on, the POST (Power On Self Test)

will run for a few moments (about 30 seconds). The network environment

determines how the IP address is assigned.

Network Environment with DHCP Server

When DHCP is active, the unit’s IP address will be assigned by the

network’s DHCP server. Refer to the DHCP server’s IP address table to

determine the unit’s assigned IP address. You may also use the Moxa

VPort and EtherDevice Configurator Utility (edscfgui.exe), as described

below:

Using the Moxa VPort and EtherDevice Configurator Utility

(edscfgui.exe)

1. Run the edscfgui.exe program to search for the VPort. After the

utility’s window opens, you may also click on the Search button

to initiate a search.

2. When the search has concluded, the Model Name, MAC address, IP

address, serial port, and HTTP port of the VPort will be listed in the

utility’s window.

3. Double click the selected VPort or use the IE web browser to access

the VPort’s web-based manager (web server).

Non DHCP Server Network Environment

If your VPort 56-2MP is connected to a network that does not have a

DHCP server, then you will need to configure the IP address manually.

The default IP address of the VPort 56-2MP is 192.168.127.100 and the

default subnet mask is 255.255.255.0. Note that you may need to change

your computer’s IP address and subnet mask so that the computer is on

the same subnet as the VPort.

To change the IP address of the VPort manually, access the VPort’s web

server, and then navigate to the System Configuration Network 

General page to configure the IP address and other network settings.

Check the Use fixed IP address option to ensure that the IP address you

assign is not deleted each time the VPort is restarted.

Step 2: Accessing the VPort 56-2MP’s web-based manager

Type the IP address in the web browser’s address input box and then

press enter.

- 7 -

Step 3: Install the ActiveX Control Plug-in

A security warning message will appear the first time you access the

VPort’s web-based manager. The message is related to installing the

VPort AcitveX Control component on your PC or notebook. Click Yes to

install this plug-in to enable the IE web browser for viewing video images.

NOTE

For Windows XP SP2 or above operating systems, the ActiveX

Control component will be blocked for system security

reasons.

In this case,

the VPort’s security warning message window may

not appear. Users should unlock the ActiveX control blo

cked

function or disable the security configuration to enable the

installation of the VPort’s ActiveX Control component.

Step 4: Access the homepage of the VPort 56-2MP’s web-based

manager.

After installing the ActiveX Control component, the homepage of the

VPort 56-2MP’s web-based manager will appear. Check the following

items to make sure the system was installed properly:

1. Video Images

2. Video Information

Step 5: Access the VPort’s system configuration

Click on System Configuration to access the overview of the system

configuration to change the configuration. Model Name, Server Name,

IP Address, MAC Address, and Firmware Version appear in the green

bar near the top of the page. Use this information to check the system

information and installation.

- 8 -

For details of each configuration, check the user’s manual on the software

CD.

Wiring Requirements

SAFETY FIRST!

•

Be sure to disconnect the power cord before installing and/or

wiring your Moxa VPort 56-2MP.

•

Calculate the maximum possible current in each

power wire

and common wire. Observe all electrical codes dictating the

maximum current allowable for each wire size.

•

If the current goes above the maximum ratings, the wiring

could overheat, causing serious damage to your equipment.

You should also pay attention to the following:

•Use separate paths to route wiring for power and devices. If power

wiring and device wiring paths must cross, make sure the wires are

perpendicular at the intersection point.

•You can use the type of signal transmitted through a wire to

determine which wires should be kept separate. The rule of thumb is

that wiring that shares similar electrical characteristics can be

bundled together.

•Keep input wiring and output wiring separated.

•It is strongly advised that you label wiring to all devices in the system

when necessary.

Technical Support Contact Information

www.moxa.com/support

Moxa Americas:

Toll

-free: 1-888-669-2872

Tel:

1-714-528-6777

Fax:

1-714-528-6778

Moxa China (Shanghai office):

Toll

-free: 800-820-5036

Tel:

+86-21-5258-9955

Fax:

+86-21-5258-5505

Moxa Europe

Tel:

+49-89-3 70 03 99-0

Fax:

+49-89-3 70 03 99-99

Moxa Asia

-Pacific:

Tel:

+886-2-8919-1230

Fax:

+886-2-8919-1231

Otros manuales para VPort 56-2MP

Tabla de contenidos

Otros manuales de Cámara IP de Moxa Technologies

Moxa Technologies

Moxa Technologies Vport P16-1MP-M12-IR Series Manual de usuario

Moxa Technologies

Moxa Technologies VPort 06EC-2V36M Manual de usuario

Moxa Technologies

Moxa Technologies VPort P16-1MP-M12 Series Manual

Moxa Technologies

Moxa Technologies VPort 26A-1MP Series Manual de usuario

Moxa Technologies

Moxa Technologies VPORT P06-1MP-M12 Manual de usuario

Moxa Technologies

Moxa Technologies VPort P06HC-1MP-M12 Manual de usuario

Moxa Technologies

Moxa Technologies VPort P06-1MP-M12-CAM36 Manual de usuario

Moxa Technologies

Moxa Technologies VPort 36-1MP Manual de usuario

Moxa Technologies

Moxa Technologies VPort 56-2MP Manual de usuario

Moxa Technologies

Moxa Technologies VPort 16-M12 Series Manual de usuario

Moxa Technologies

Moxa Technologies VPort 36-1MP Manual de usuario

Moxa Technologies

Moxa Technologies VPORT P06-1MP-M12 Manual de usuario

Moxa Technologies

Moxa Technologies VPort P06-2L25M Manual de usuario

Moxa Technologies

Moxa Technologies VPort P06HC-1MP-M12 Manual de usuario

Moxa Technologies

Moxa Technologies VPort 26 Series Manual de usuario

Moxa Technologies

Moxa Technologies VPort 36-1MP Manual de usuario

Moxa Technologies

Moxa Technologies VPort 26A-1MP Series Manual de usuario

Moxa Technologies

Moxa Technologies VPort 36-1MP Manual de usuario

Manuales populares de Cámara IP de otras marcas

FLIR

FLIR Exx series Manual de usuario

Avigilon

Avigilon H4A-BO1-IR Manual de usuario

Digital Watchdog

Digital Watchdog DWCA-C128-64 Manual de usuario

ShareTech

ShareTech AV1 Manual de usuario

Ezviz

Ezviz C6C Manual de usuario

Melchioni

Melchioni UCAM 2015 Manual de usuario

Geutebruck

Geutebruck G-Cam/ESD-4630 Manual de usuario

Arecont Vision

Arecont Vision MegaBall AV3146DN-3310-D-LG Manual de usuario

Mitel

Mitel 6800i Series Manual de servicio

Vitek

Vitek VTC-IR403-212NP Manual de usuario

THOMSON

THOMSON DSC - 323W Manual de usuario

AVer

AVer FB2027 Manual de usuario

ENFORCER

ENFORCER EV-T5105-N2SQ Manual de usuario

Wansview

Wansview NC543 Manual de usuario

Eneo

Eneo MCB-64A0003M0A Manual de usuario

deView electronics

deView electronics CBDNI36F Manual de usuario

Swann

Swann SwannEye Manual de usuario

LevelOne

LevelOne IP CamSecure Manual de usuario
