Movea MotionPod Manual de usuario

EN-2008

MotionPod™

Users’ Guide

TABLE OF CONTENT

I. Terminology ......................................................................................................................................................................3

II. Product diagram ..............................................................................................................................................................3

III. Safety rules.........................................................................................................................................................................4

IV. Introduction.......................................................................................................................................................................6

V. Get Familiar with MOTIONPOD™..............................................................................................................................7

1. MOTIONPOD™..............................................................................................................................................................7

2. The MotionController™............................................................................................................................................8

VI. Usage.....................................................................................................................................................................................9

1. Recharging your MotionPod ..................................................................................................................................9

2. How to switch the MotionPod on and off ...................................................................................................... 10

3. How to wear the MOTIONPOD™........................................................................................................................ 11

VII. Precautions ..................................................................................................................................................................... 11

1. Using environments ............................................................................................................................................... 11

2. Characteristics and environmental conditions ........................................................................................... 13

VIII. Calibration....................................................................................................................................................................... 14

IX. Cleaning............................................................................................................................................................................ 15

1. Cleaning the MOTIONCONTROLLER™............................................................................................................ 15

2. Cleaning the MOTIONPOD™................................................................................................................................ 15

X. Signs and labels............................................................................................................................................................. 16

1. The MOTIONPOD™.................................................................................................................................................. 16

2. The MOTIONCONTROLLER™.............................................................................................................................. 16

XI. Maintenance ................................................................................................................................................................... 16

XII. What to do in case of system breakdown........................................................................................................... 17

I. TERMINOLOGY

Code Name

Description

MPOD

MotionPod, designates the motion sensing case

MOTIONCONTROLLER™

MotionPod Controller or charger/data receiver, a MPOD device.

Designates data receiving and/or recharging case which connects on the

computer via USB port.

II. PRODUCT DIAGRAM

Antenna

Finger grips

On/Off button

Orange LED indicates

recharging

Green LED

indicates

transmission state

Trans parent top cover

Black bottom cover

Orientation arrow

FIGURE 1 : CASING OF MOTIONPOD™

MPOD

charging cavity

Spring contacts for

electrical link with the

MPOD

Light indicators

USB

port

rx tx pwr

Green power light:

indicates that the

Motion Controller is

receiving power

Blue RX/TX lights:

RX signal reception

TX signal transmission

FIGURE 2 : MOTION CONTROLLER

III. SAFETY RULES

Warning

Please read this user’s guide very carefully before use.

Advise all recommendations to end-user and keep him informed of all risks endured using the

system.

MOTIONCONTROLLER™ must be plugged using equipment in compliance with INTO standard

60950-1 via USB2 port with the provided cable. In order to fulfill safety requirements for electro-

medical systems and equipments, power must be supplied by a transformer in compliance with the

EN standard 60601-1.

MOTIONPOD™ is the only part in contact with the patient, so by no means they’re to be in contact

with the MOTIONCONTROLLER™ or the computer during use. Patients are to be held at 1,20m to

1,60m away from this equipment.

Do not open or replace the Li-ion battery of the MOTIONPOD™. Do not use non

rechargeable battery or any other battery other than the one provided by

Movea. It could damage the product and presents health risks or cause

accidents.

DO NOT EXPOSE TO FIRE–Risk of explosion, DO NOT OPEN

CAUTION: For your own safety do not open the charging case, risk of electric shock.

Waste management process of electric and electronic products differs from that of municipal waste

and requires special intervention from waste management services appointed by the government or

the local community. The crossed trashcan shows that the European directive 2002/96/CE applies

to this product.

Waste separation prevents from any negative consequences on the environment or public health. It

is the most important condition for better handling and recycling electric and electronic

components. For more information about handling of worn out equipments, contact your local

waste management service or the nearest product distributor.

It is highly recommended not to connect any peripherals (modem, printers…) other than the

MOTIONCONTROLLER™ on the computer during the use of the system. The MOTIONPOD™ has a Li

Ion battery and therefore must be recycled according to current standards. It must be returned to

the manufacturer.

IV. INTRODUCTION

Thank you for purchasing our motion sensing product MotionPod™.

This user manual was written to familiarize you with the use of this system. Read it carefully in

order to rightfully use the device. Always have this guide near you when you use this product.

The MotionPod is an electronic goniometric recording device with wireless transmission. It was

conceived to provide “movement signature”of a body segment in real time and without cable

connection.

Its main purpose is to compare series of rehabilitation exercises with prior exercises, movement

amplitudes gestures protocols etc… carried out for limb rehabilitation (for example of joint

extensions).

This product designed and manufactured by Movea, is well adapted for biomechanical applications,

rehabilitation and joint assessment in physical therapy. For this reason, it must be used in a

controlled environment, at your work place, and by qualified personnel. The user of MotionPod

must have red and understood this notice.

The MOTIONPOD™ System is provided with software that must be the only software solution to be

used with this product.

V. GET FAMILIAR WITH MOTIONPOD™

Please take a moment to familiarize with the different components of your measuring system. For

the following section it is advised to refer to the material scheme II.

1. MOTIONPOD™

MOTIONPOD™ is standard wristwatch-sized sensor with a transparent casing that embodies the

Motion sensing component on the upper side (Figure 3). It is intended to be worn on the moving

part of the body where we want to perform joint assessment. It must be fixed mechanically by

means of straps or bracelets (not provided) via the black colored mechanical interface.

Photo of MotionPod™

Mechanical interface for bracelet or

strap

Side view of MOTIONPOD™ scheme

Mechanical fixing base

FIGURE 3 : MOTIONPOD™

On the top of MOTIONPOD™ you can see an ellipse shaped facet: it is the antenna with an imprinted

name and logo of the manufacturer (Movea, Motion is Life), the brand name of the product

(MotionPod) and an arrow pointing towards the button located on the side of the casing. The arrow

also indicates the exact orientation to fix the MOTIONPOD™ properly. Please be focused with these

elements for they are useful to establish the MOTIONPOD™ correctly in the application that is

provided with your system.

From a side view (see Figure 3, on the right), you can see a Black bottom cover of the MOTIONPOD™.

This part allows fixing the MOTIONPOD™ on any kind of supporting facet designed to accommodate

it. It can be the charging box (see below) or the mechanical interface for bracelet or strap.

Figure 1 summarizes the first visual elements on the MOTIONPOD™.

2. THE MOTIONCONTROLLER™

The MOTIONCONTROLLER™ is a white case with a surface identical to that of a credit card and

approximately 2cm thick (see Figure 4). On the upper facet you can see an imprinted logo of Movea,

and light indicator inscriptions (see below for their significance).

Connected on the PC via USB port cable (provided), it allows:

-Data reception transmitted from the MotionPod by radio frequency (Band ISM –2.45 GHz)

-Charging of the MOTIONPOD™

Photo of the MotionController™

FIGURE 4 : MOTIONCONTROLLER™

The MOTIONCONTROLLER™ guarantees a wireless link between the MOTIONPOD™ and the

computer where you manage your applications. The data goes to the computer via USB cable.

VI. USAGE

1. RECHARGING YOUR MOTIONPOD™

The MOTIONCONTROLLER™ must be connected to a computer in compliance

with IEC/EN 60950-1 standard. In order to fulfill safety requirements for

electro-medical systems and equipments, power must be supplied by a

transformer in compliance with EN standard 60601-1. Only the MOTIONPOD™ is

in contact with the patient environment. By no means, the patient should be in

contact with the computer and the MOTIONCONTROLLER™ during use.

First connect the MOTIONCONTROLLER™ to the USB port of your computer using the provided

cable.

Once the MOTIONCONTROLLER™ is connected, the light indicator “pwr” goes on and gives a green

continuous light (see Figure 2). The two other light indicators are blue diodes which light up along

with the first one once connected to the USB port. They switch off immediately then blink twice to

finally go off completely.

Put the MOTIONCONTROLLER™ horizontally on a table, facet where the logo is imprinted upwards.

You can see the cavity where you can clip the MotionPod in. Insert the MOTIONPOD™ by its Black

bottom cover directly in the cavity. The button of the MOTIONPOD™ must be pointing to the Logo.

The MOTIONPOD™ must completely fit in the cavity.

A clockwise rotation of approximately 30° mechanically locks the MOTIONPOD™ in the cavity and

therefore electrically connects it to the MOTIONCONTROLLER™. A “click” sound indicates that the

system is suitably locked and started charging (if charging is needed). The whole unit must look like

the photograph on Figure 5.

The MOTIONPOD™ encloses a battery. Battery performance gradually decreases

over an extended period of time (see the number of possible charging cycles). In

case of extended period of no use, it is advised to check the battery condition by

charging it. If the battery does not charge any more it is necessary to return the

product to the manufacturer for maintenance (battery exchange). This

operation cannot be carried out by the user. Opening of MOTIONPOD™ (or

MOTIONCONTROLLER™) will void the manufacturer warranty.

FIGURE 5 : THE MOTIONPOD™ FIXED ON THE MOTIONCONTROLLER™, READY FOR RECHARGE

While charging, an orange light indicator located at the back of the MOTIONPOD™ switches on. It

switches off as soon as the recharging process is complete. Theoretically, charging duration is 3

hours.

When the MOTIONPOD™ is recharged after a very long period of no use, it is possible that the

orange light indicator takes a few minutes before switching on.

If the battery reaches its critical point due to a long period of storage, the only solution is to return

the MOTIONPOD™ to your supplier for battery replacement (at own expense).

It is dangerous and strictly prohibited to use any other charging equipment than

the MOTIONCONTROLLER™ of Movea. Using other charger can damage the

MOTIONPOD™ and will void your manufacturer warranty.

The MOTIONPOD™ should not be opened. The battery replacement should be

carried out by your supplier.

2. HOW TO SWITCH THE MOTIONPOD ON AND OFF

The MOTIONCONTROLLER™ must be connected to the PC. The MOTIONPOD™ must formerly be

recharged. Take the MOTIONPOD™ off the MOTIONCONTROLLER™.

Slightly push the button on the MOTIONPOD™ to switch it on. At this stage, the green light indicator

blinks with a 5 second interval. The MOTIONPOD™ is not in transmitting any data to the

MOTIONCONTROLLER™ at this stage, it is simply on standby. You can switch the MOTIONPOD™ off

by a pressing on the button for 4 seconds. The green light indicator blinks twice before switching off
