Motorola ET1 Manual de usuario

ET1

ENTERPRISE TABLET

QUICK START GUIDE

Motorola Solutions reserves the right to make changes to any product to improve reliability, function, or design. Motorola Solutions does not assume any

product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein. No license is granted,

either expressly or by implication, estoppel, or otherwise under any patent right or patent, covering or relating to any combination, system, apparatus,

machine, material, method, or process in which Motorola Solutions products might be used. An implied license exists only for equipment, circuits, and

subsystems contained in Motorola Solutions products.

Warranty

For the complete Motorola Solutions hardware product warranty statement, go to: http://www.motorolasolutions.com/warranty.

User Manuals

For more information about the ET1 Enterprise Tablet refer to the ET1 Enterprise Tablet User Guide and ET1 Enterprise Tablet Integrator Guide. For the

latest version of this guide and all ET1 guides, go to: http://supportcentral.motorola.com.

Service Information

If you have a problem using the equipment, contact your facility’s Technical or Systems Support. If there is a problem with the equipment, they will contact

the Motorola Solutions Global Support Center at: http://www.motorolasolutions.com/support.

Software Support

Motorola Solutions wants to ensure that customers have the latest release of entitled software at the time of product purchase. To confirm that your

Motorola Solutions device shipped with the latest release of entitled software, visit: www.motorolasolutions.com/support. Check for the latest software from

Software Downloads > Product Line/Product > Go. If your device does not have the latest entitled software release as of your product purchase date,

please e-mail a request to Motorola Solutions at: [email protected]. You must include the following essential device information

with your request:

• Model number

• Serial number

• Proof of purchase

• Title of the software download you are requesting.

If it is determined by Motorola Solutions that your device is entitled to the latest software release, you will receive an e-mail containing a link directing you to

a Motorola Solutions Web site to download the appropriate software.

Touch Screen

Decode LED

Front-facing

Camera

eatures

Menu ButtonProgrammable Buttons

Communication LED

Light Sensor

Microphone Battery Charge LED

Home ButtonBack Button

Right Scan/Action

Button

Camera Flash

Headset Jack

Battery

Release Latch

Left Scan/Action

Button

Rear-facing

Camera USB Host

Expansion Module

Secondary Microphone

eatures

HDMI Output Connector

Speaker Speaker

Battery Charging

LED

I/O Connector

Power Button

Getting Started

To get started:

•Install the battery

•Charge the battery

•Start the ET1.

Install the Battery

1. Remove the battery from the packaging.

2. Align the tracks on the sides of the battery with the rails of the

battery compartment.

3. Push the battery in until it snaps into place.

Charge the Battery

Before using the ET1, charge the battery using one of the

following accessories:

•Single-slot USB Docking cradle

•Four-slot Charge Only Docking cradle

•USB/Charge cable and power supply.

1. Ensure that the accessory is connected to power. See the ET1

Enterprise Tablet User Guide for more information.

2. Place the ET1 into a cradle or connect to the USB/Charge

cable.

The Battery Charge LEDs blinks yellow indicating that the

battery is charging. When the battery is fully charged

(approximately six hours) the LEDs becomes solid green.

Startup

Press the Power button to turn on the ET1. As the ET1 starts the

splash screen displays and then the Home screen appears.

Slide up to unlock the screen.

Tracks

Rails

NOTE The battery can be charged separately using the Four-slot

Battery Charger.

NOTE For multi-user mode, refer to the ET1 Enterprise Tablet

User Guide for login procedures.

Launch Applications

To launch an application:

1. Touch the Launcher icon. The Launcher screen displays.

2. Touch an application icon to launch the application.

Configure the ET1

To configure ET1 settings, touch > Settings. Refer to the ET1

Enterprise Tablet User Guide and Integrator Guide for

information on configuring the ET1.

Power Button

Use the Power button to place the ET1 in suspend mode, battery

swap mode, to reset the ET1 or to power off the ET1.

Suspend Mode

Press and release the Power button to place the ET1 in suspend

mode. In Suspend Mode the ET1 turns off the display and goes

into a low power state to conserve battery power.

Press and release the Power button to wake the ET1, and then

slide up to unlock the screen.

Battery Swap Mode

Before replacing the battery, place the ET1 in Battery Swap

Mode. Press and hold the Power button until the Device options

dialog box appears then touch Battery swap.

The Decode LED lights red. When the LED turns off, it is safe to

remove the battery.

Reset

Reset the ET1 if applications stop responding. Press and hold

the Power button until the Device options dialog box appears

then touch Reset.

Launcher

CAUTION Do not remove microSD card during Battery Swap

mode.

Power Off

To power off the ET1, press and hold the Power button until the

Device options dialog box appears, then touch Power off.

When the Power off dialog box appears, touch OK.

Hardware Reset

If the ET1 stop responding, perform a hardware reset.

Simultaneously press the Left Scan/Action, Right Scan/Action

and Power buttons.

Lock the Screen

Lock the screen to protect access to data. When locked, a

Pattern, PIN or Password is required to unlock the ET1. Press

the Power button to lock the screen. The ET1 also locks after a

pre-defined time-out.

Press and release the Power button to wake the ET1.

The Lock screen displays. Slide up to unlock the screen. If

the Pattern screen unlock feature is enabled, the Pattern screen

appears instead of the Lock screen.

If the PIN or Password screen unlock feature is enabled, enter

the PIN or password after unlocking the screen.

Refer to the ET1 Enterprise Tablet User Guide for setup

instruction for locking the screen. If the Multi-user feature is

enabled, contact the system administrator for login information.

Change Volume

Press P1 to decrease the volume. Press P2 to increase the

volume. Note that these buttons are programmable and can be

changed by the user or application.

Scan a Bar Code

Use the rear-facing camera to scan bar codes. Ensure that

DataWedge is enabled and the cursor is in a text field.

1. Point the back of the ET1 at the bar code.

2. Press the Left or Right Scan/Action button. The Decode LED

turns red indicating that a scan is in process.

3. On the screen, align the bar code in the viewing window.

4. The ET1 reads and decodes the bar code data. The Decode

LED turns green indicating a successful decode.

Photos and Videos

Use the rear-facing camera to take photos and capture video.

To take a photo:

1. Touch Launcher > Camera.

2. Point the ET1 at the subject.

3. On the screen, frame the subject in the window and then

touch the on-screen shutter icon .

4. The ET1 takes the photo.

To capture video:

1. Touch Launcher > Camera and then touch the video

icon .

2. Point the ET1 at the subject.

3. On the screen, frame the subject in the window.

4. Touch the on-screen record button to begin recording.

5. Touch the on-screen stop button to end recording.

View photos and videos using the Gallery application.

NOTE The ET1 offers additional data capture options. Refer to

the ET1 Enterprise Tablet User Guide for more

information.

NOTE A microSD card is required to save photos and videos.

Connect to a Bluetooth Device

To enable Bluetooth:

1. Touch > Settings > Wireless & networks.

2. Touch the Bluetooth checkbox. A green check appears in the

checkbox and the Bluetooth icon appears in the Status bar

indicating that Bluetooth is enabled.

3. Under Bluetooth settings, touch Scan for devices. The ET1

begins searching for discoverable Bluetooth devices in the

area and lists them under Bluetooth devices.

4. Scroll through the list and select a device. The Bluetooth

pairing request dialog box appears.

5. Enter a PIN and touch OK, if required.

6. Touch .

Connect to a WLAN Network

To set up a WLAN network:

1. Touch > Settings > Wireless & networks.

2. Touch the Wi-Fi checkbox to turn on Wi-Fi. A green check

appears in the checkbox and the Wi-Fi icon appears in the

Status Bar indicating that Wi-Fi is enabled.

3. Touch Wi-Fi settings. The ET1 searches for WLANs in the

area and lists them under Wi-Fi networks.

4. Select the desired network.

5. For open networks, touch Connect. For secure networks

enter the required password or other credentials then touch

Connect. See the system administrator for more information.

6. Touch .

NOTE Refer to the ET1 Enterprise Tablet User Guide for

supported Bluetooth profiles.

Battery Replacement

To replace the battery:

1. Press and hold the Power button until the Device options

menu displays.

2. Touch Battery Swap. The Scan LED lights red.

3. Wait until the Scan LED turns off.

4. Turn the ET1 over.

5. Press thumb against the side of the ET1 and battery. Using

the index and middle fingers, move the battery release latch

toward thumb and pull the battery out of the battery

compartment.

6. Align the tracks on the side of the replacement battery with the

rails in the battery compartment.

7. Push the battery in until the battery release latch snaps into

place.

8. Press the Power button to turn on the ET1.

Battery Release Latch
