Motorola LS350 Manual de usuario

USER GUIDE

1031B55-B.fr5 Page -1 Friday, April 23, 1999 3:15 PM

Introduction ...........................................1

Getting Started......................................2

Installing/Replacing the Battery ..........3

Control Buttons...................................4

TurningYour Pager On........................5

TurningYour Pager Off........................6

Sending a Test Page toYourself..........7

Backlight..............................................7

Setting upYour Pager..........................7

Time And Date.......................................8

Setting the Time and Date ..................8

Alerts....................................................11

Selecting the Incoming

Message Alert ..............................11

Alert Audio ........................................12

Messages.............................................14

Reading New Messages...................14

Reading Stored Messages................16

Saving Messages..............................17

Deleting Messages..............................18

Deleting a Single Message ...............18

Deleting All Messages.......................19

Message Folder...................................20

Moving a Message into the Folder....20

Reading Messages in the Folder ......22

Deleting Messages from the Folder ..24

Alarm....................................................25

Setting the Alarm ..............................25

Turning Off a Daily or

Weekly Alarm................................28

Message and Pager Indicators..........29

Indicators.............................................30

Belt Clip................................................31

Use and Care .......................................32

1031B55-B.fr5 Page 0 Friday, April 23, 1999 3:15 PM

Congratulations on purchasing an LS350 pager.Your new pager provides

exciting capabilities in messaging and can become a vital part of your

business and personal life.This compact pager combines messaging and

time keeping functions in a package that is convenient to carry.

If your LS350 has the

symbol, it uses FLEX

™

technology.The Motorola

FLEX protocol-based pagers offer extended battery life and improved

paging reliability.

To fully understand the features this pager offers, please take a few

minutes to read this user’s guide.

This user’s guide also includes a detachable quick reference card on

the back cover.

INTRODUCTION

1031B55-B.fr5 Page 1 Friday, April 23, 1999 3:15 PM

Effective Use ofYour Pager

Your pager can help you keep in contact with everyone important

to you.By giving your pager number to your business associates,

family, and friends, you can be contacted whenever needed.

If you have a cellular phone, give your pager number instead of your

cellular number.Then you can decide who to call back on your cellular

phone without paying for incoming calls.

Battery Information

Your pager operates with one AAA-

size alkaline battery (carbon zinc

batteries are not recommended).

Polarity

Marking Battery

Compartment

GETTING STARTED

1031B55-B.fr5 Page 2 Friday, April 23, 1999 3:15 PM

Installing/Replacing the Battery

➊

Turn the pager off.Refer to “TurningYour Pager Off”on page 6.

➋

Locate the battery door on the back of the pager.

➌

Slide the battery door in the direction of the arrow to unlatch the

battery door.

➍

Lift the battery door up to open.

➎

Remove the old battery, noting the polarity.

➏

Position the new battery so the + and - markings on the battery match

the polarity diagram next to the battery compartment.

➐

Close the battery door.

➑

Slide the door until it is fully closed.

Note:

Check your pager’s clock time after replacing the battery.

GETTING STARTED

1031B55-B.fr5 Page 3 Friday, April 23, 1999 3:15 PM

Control Buttons

Menu Used to access pager menus and to turn on the

backlight.

Read Used to turn the pager on, read messages, and

navigate through menus.

Select Used to select pager settings and features.Also used

to read additional screens of messages.

Read

Button

Select

Button

GETTING STARTED

1031B55-B.fr5 Page 4 Friday, April 23, 1999 3:15 PM

TurningYour Pager On

➊

Press

.The start-up screens are

displayed and your pager activates the

power on chime (when in audible mode).

➋

Press any button to stop the alert.

The unread message (home) screen

is displayed.

When your pager is on and no activity

is taking place, the Standby screen is

displayed.The Standby screen

displays the time and date and may

display other status indicators.

m 88 f hjlb

MOTOROLA

m 88 f hjlb

NEW! 1

m 88 f hjlb

3!30P 07/05

GETTING STARTED

1031B55-B.fr5 Page 5 Friday, April 23, 1999 3:15 PM

TurningYour Pager Off

➊

From the Standby screen, press

twice.

➋

Press and release

until

PAGER OFF

displayed, then press

OFF

is displayed momentarily before

the pager shuts off, and

is removed

from the display.

The off screen displays the time and

date, and if the alarm is set, the alarm

indicator.

m 85 f hjlb e

PAGER OFF

m 85 f ojlb

OFF

m 88 f ojlb

3!30P 07/05

GETTING STARTED

1031B55-B.fr5 Page 6 Friday, April 23, 1999 3:15 PM

Sending aTest Page toYourself

After you have read this guide and your pager has been activated

by your service provider, send yourself a test page.Refer to

“Functionality and Use ofYour Pager” on page 34.

Backlight

In low-light conditions, press and hold

for 2 seconds to turn on the

pager’s backlight.The backlight turns off automatically after the pager

returns to the Standby screen.

Setting upYour Pager

This section gives instructions for setting the time and date.Access to this

feature is obtained through the Setup Pager menu.

GETTING STARTED

1031B55-B.fr5 Page 7 Friday, April 23, 1999 3:15 PM

Setting theTime and Date

➊

From the Standby screen, press

twice.

➋

Press and release

until

SET UP PAGER

is displayed.

➌

Press

TIME/DATE

is displayed.

➍

Press

FORMAT!AM/PM

FORMAT!24HR

displayed.

m 86 f hjlb e

SET UP PAGER

m 81 f hjlb

TIME/DATE

m 85 f hjlbe

FORMAT! AM/PM

TIME AND DATE

1031B55-B.fr5 Page 8 Friday, April 23, 1999 3:15 PM
