Quick Start Guide

Vonage

Device Motorola VT2142

1. If you purchased your Vonage®Device from a retail store,

you must first activate your Vonage phone service.

(You will need to provide the MAC ID on the bottom

of the Vonage Device.)

In the U.S., visit www.vonage.com/activate.

In Canada, visit www.vonage.ca/activate.

2. If you received your Vonage Device in the mail

from Vonage, your Vonage phone service has

already been activated.

3. You also need a high-speed Internet connection,

such as DSL or cable, to use Vonage.

Helpful terms:

ISP (Internet Service Provider) –The company that

supplies your high-speed Internet connection.

Modem –Apiece of network equipment that your lnternet

Service Provider (ISP) sent you to gain high-speed

lnternet access – typically either DSL through your

phone line, or cable service.

Router –Arouter lets you connect more than one piece of

equipment (like computers) to your DSL or cable modem

to share one Internet connection. Some ISPs supply

combination modem/routers. (HINT: If you have more

than one computer connected to the Internet, then you

have a router.)

Port –This is an opening on a device where you connect a

cable. An Ethernet port looks like a wide phone jack.

Before you begin

Welcome

to the Quick Start Guide for Vonage®.

Get ready to start saving money on your phone bill with

Vonage – just follow these easy step-by-step instructions to

set up your new Vonage device. Within minutes, you’ll be

making phone calls with high-quality, low-cost Vonage

phone service!

If you have questions along the way, please go to the

Troubleshooting Tips on page 8 or visit:

www.vonage.com/help (U.S.)

www.vonage.ca/help (Canada)

3Easy Steps!

Step 1: Identify the items you’ll need

Step 2: Set up your new Vonage Device

Step 3: Connect your phone

For your convenience, the complete User Guide for this Vonage

Device can be found online at www.vonage.com/vt2142 or in

Canada www.vonage.ca/vt2142

NOTE: Ensureyou areusing the power supply provided with the

Vonage Device. Using the wrong power supply could result in damage

to your equipment.

*Not required for installation.

Identify the items you’ll need

from your Vonage®Startup Kit.

Locate your:

•High-speed/broadband modem

•Telephone

•Ethernet cable that goes from your modem to your

computer or router

Step 1:

Phone Internet Ethernet Power

Vonage Device

Black Power Cord

Base Support*

Blue Cable Yellow Cable

Step 2:

Set up your Vonage®Device

1. Unplug your existing modem’s power cord.

Leave your modem connected to your cable or DSL

phone line that supplies your Internet connection.

2. Unplug the Ethernet cable that connects your modem to

your computer or router. Unplug the cable from both

your modem and your computer (or router).

Note: In some instances the modem may be connected to the computer

via a USB cord and USB ports. If so, disconnect the cord at both ends

(modem and computer).

3. Wait 60 seconds for your modem to clear its

memory completely.

Existing Modem

Ethernet

Port

USB

Port

4. Connect one end of the blue cable to the Ethernet port

on your modem. Connect the other end to the blue port

labeled “Internet” on the back of the Vonage Device.

5. Connect one end of the yellow cable to the yellow port

labeled “Ethernet” on the back of the Vonage Device.

Connect the other end to the Ethernet port on your

computer or router.

NOTE: If you unplugged a USB cord, do not attempt to plug the Ethernet

cordinto the USB port. If your computer does not have an Ethernet port,

you can purchase a USB-to-Ethernet adapter or Ethernet card at your local

electronics store.

Vonage Device

6. Now plug your modem’s power cord back into an

electrical power outlet.

NOTE: You should allow enough time for your modem to complete its start-up

process. If you’re unsure about how long this takes, consult the manual that

came with your modem. Typical modem start-up takes 60 seconds.

7. Next, using the power cord that came with your Vonage

kit, plug the smaller end of the power cord into the

circular power port on the back of the Vonage Device.

Then, plug the larger end of the power cord into an

electrical power outlet.

NOTE: Before continuing, the “Power” and “Internet” lights on the front of the

Vonage Device should both turn on. Wait until the “Power” light stops blinking

and both “Power” and “Phone 1” lights are solid. The “Phone 2” light will be

solid if you have a second Vonage line. Otherwise, it will not light. The “Internet”

light will flicker whenever thereis communication activity.

8. On your computer, open a web browser and check your

Internet connection by visiting any website.

NOTE: After turning on your computer, the Ethernet light on the Vonage Device

will also flicker whenever thereis activity.

•If your Internet connection works,

go to Step 3: Connecting your phone, on page 7.

Vonage Device

1. Unplug the modem for at least 60 seconds. If left off for less

than 60 seconds, it might still “remember” old information that

could prevent it from working properly.

2. If your Internet connection still does not work, you may need to

need the MAC ID on the bottom of the Vonage Device.

1. Make sure you are using a computer that's connected to a yellow

port on your Vonage Device. On your computer, open a web

browser. In the address field, type http://192.168.15.1 (the

default IP address of the VT2142 Home Page) and press Enter.

Alogin window appears.

2. In both the Username and Password fields, type router and click

3. Click the SETUP tab, then WAN Configuration.

From the Type drop-down list, choose PPPoE.

4. In the Username and Password fields, type the username and

password you normally use to login to your DSL service. If you

don’thave your DSL login information,

please contact your ISP

and obtain your DSL Username/Password.

5. In the Keep Alive field, type 0to ensure that your DSL link is

always active.

6. Click Save and then Connect.

7. Click the Tools tab and on the left, a menu will appear.

Select Restart.You will then see the Restart button appear in

the center.Click on it.

If your Internet connection doesn’t work and you

have a cable modem:

If your Internet connection doesn't work and you

have a DSL modem:

Note: If you had an existing router connected to your DSL modem,

but it is now connected to your Vonage device, the router will have

to be set up as a DHCP client instead of PPPoE.

Connecting your phone

1. Plug a standard telephone cord into your phone.

NOTE: If not done so already, disconnect phone card from wall.

2. Plug the other end into the Green Phone 1 Port

on the back of the Vonage Device.

NOTE: Make sure the phone light is solid.

This is what your setup should look like:

3. Pick up your handset. If you hear a dial tone, congratulations!

You’ve set up your Vonage service correctly, and can now start

making calls. To configure your voicemail and other included

services features, simply login to your online account at

www.vonage.com. In Canada visit www.vonage.ca.

NOTE: When you pick up your phone to check for a dial tone, the phone

light will blink.

If you do not hear a dial tone, proceed to Troubleshooting

Tips on page 8. 7

Step 3:

Vonage Device

Existing Modem Phone

Computer

or Router

Vonage Device

You can solve many installation issues by resetting all of your

equipment:

1. First, power down in this order: a. Computer, b. Router, if you

have one, c. Vonage Device, and then d. Modem

NOTE: Leave the modem unplugged for at least 10 minutes. (The 10 minutes is

to ensure the modem doesn’t “remember” old information). Confirm that all

cables are snapped firmly into place.

2. Turn the devices on one at a time in this order:

a. Modem – Wait for the lights to come back on before

continuing. This may take several minutes. Most modems

have a light that should be lit solid when start-up is

complete. If necessary, refer to the information that came

with your modem.

b. Vonage Device – Wait for the power and phone(s) lights

to be a solid green. (The Internet light will blink whenever

there is activity.)

c. Router,if you have one – Wait for the lights to come back

on (consult router manual for sequence) before continuing.

Wait at least 30 seconds after the lights have completed.

d. Computer

At this point, you should have both a dial tone and

Internet connectivity.

3. Try opening your web browser to view a web page. If you cannot

view a web page, check to see whether your Cable or DSL

provider is having connection problems in your area.

Troubleshooting Tips

If your Internet connection doesn’t work:
