Motorola PHOTON 4G Manual de usuario

HD MULTIMEDIA

DOCK for

MOTOROLA

PHOTON™ 4G

1Congratulations

Congratulations

HD Multimedia Dock for MOTOROLA

Photon™ 4G

Extend the capabilities of your MOTOROLA

PHOTON™ 4G in stunning HD with the HD Multimedia

Dock for MOTOROLA PHOTON™ 4G. Connect to an

HDMI big screen and audio device using the

microHDMI connector.

You can also use a keyboard, mouse, or USB flash

memory with the dock. Connect these to USB ports,

while using the audio jack to connect your powered

speakers or audio system to get a big sound for your

MOTOROLA PHOTON™ 4G.

Warning: For indoor use only. Not designed or

intended for use in a vehicle. To avoid injury, do not use

this product as a vehicle cradle/mount.

Caution: Please read the important safety,

regulatory and legal information at the back of this

guide.

2Connect

Connect

power adapteR

Note: Use insert when using a

Motorola-brand battery

and battery cover. Remove

insert when using a

protective carry case

(optional). Accommodates

cases with maximum

thickness of 1.5mm.

Power

Connection

Note: Only use the Motorola A/C wall charger included in

the box to connect to the dock’s power connector.

3Connect

devices

phone

USB (3 ports)

(to USB devices)

Micro HDMI

(to HDMI video

and audio device)

Audio Jack

(to powered

audio speakers

or your audio

system)

Power

(to wall

charger)

4Operate

Operate

With your phone docked, choose the Smart Mode you

want to use. Each time you dock your phone, your

Smart Mode appears. An option is also provided to

make behavior changes after initially selected.

Your HD Multimedia Dock includes an infrared remote

control.

The remote control uses a standard size CR2032

battery. When inserting the battery, make sure the +

side of the battery is facing out.

Navigation

Key

Media Player

Controls

Phone

Controls

Volume &

Mute Keys

Battery

Door

Use a

coin to

open.

5Support

Support

we’re here to help

If you have questions or need assistance, go to

www.motorola.com/repair (United States) or

www.motorola.com/support (Canada), where you can

select from a number of customer care options.

You can also contact the Motorola Customer Support

Center at: 18007345870 (United States),

18883906456 (TTY/TDD United States for hearing

impaired), or 18004614575 (Canada).

Safety, Regulatory & Legal

Battery Charging

Notes for charging your product’s battery:

•

During charging, keep your battery and charger near room temperature for efficient

battery charging.

•

New batteries are not fully charged.

•

New batteries or batteries stored for a long time may take more time to charge.

•

Motorola batteries and charging systems have circuitry that protects the battery from

damage from overcharging.

Third Party Accessories

Use of third party accessories, including but not limited to batteries, chargers, headsets,

covers, cases, screen protectors and memory cards, may impact your product’s

performance. In some circumstances, third party accessories can be dangerous and may

void your product warranty. For a list of Motorola accessories, visit

www.motorola.com/products

Children

Keep your product and its accessories away from small children.

These products

are not toys and may be hazardous to small children. For example:

•

A choking hazard may exist for small, detachable parts.

•

Improper use could result in loud sounds, possibly causing hearing injury.

•

Improperly handled batteries could overheat and cause a burn.

Symbol Key

Your battery, charger, or accessory product may contain symbols, defined as follows:

European Union Directives Conformance

Statement

EU Conformance

This product complies with the applicable EU requirements and carries the CE mark.

Symbol Definition

Important safety information follows.

Do not dispose of your product or battery in a fire.

Your product or battery may require recycling in accordance with

local laws. Contact your local regulatory authorities for more

information.

Do not dispose of your product or battery with your household waste.

See “Recycling” for more information.

Do not use tools.

For indoor use only.

032374o

032376o

032375o

FCC Declaration of Conformity

FCC DoC

Per FCC CFR 47 Part 2 Section 2.1077(a)

Responsible Party Name: Motorola Mobility, Inc.

Address: 8000 West Sunrise Boulevard, Suite A,

Plantation, FL 33322 USA

Phone Number: 1 (800) 453-0920

Hereby declares that the product:

Product Name: HD Multimedia Dock for MOTOROLA PHOTON™ 4G

Model Number: SJYN0827A

Conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a), 15.107(d)

and section 15.109(a)

FCC Notice to Users

FCC Notice

The following statement applies to all products that bear the FCC logo on the

product label.

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. See 47 CFR Sec. 15.105(b). These limits are

designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and,

if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and the receiver.

•

Connect the equipment to an outlet on a circuit different from that to which the

receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Motorola has not approved any changes or modifications to this device by the user. Any

changes or modifications could void the user’s authority to operate the equipment. See 47

CFR Sec. 15.21.

For products that support W-Fi 802.11a (as defined in the product specifications available

www.motorola.com

), the following information applies. This equipment has the

capability to operate Wi-Fi in the 5 GHz Unlicensed National Information Infrastructure
