MOTO GUZZI BELLAGIO Guía

SERVICE STATION MANUAL

854366

BELLAGIO

SERVICE STATION

MANUAL

BELLAGIO

THE VALUE OF SERVICE

Only the mechanics of the Official Moto Guzzi Service Network know this vehicle well, thanks to constant

technical professional development and Moto Guzzi specific training programmes, and have the tools

needed to carry out maintenance and repair operations correctly.

The reliability of the vehicle also depends on its mechanical conditions. Checking the vehicle before

setting off, carrying out routine maintenance and using only Moto Guzzi Original Spare parts is

fundamental!

For information about the nearest Official Dealer and/or Service Centre, consult the Yellow Pages or

search directly on the inset map in our Official Website:

www.motoguzzi.it

Only by purchasing Moto Guzzi Original Spare Parts will you get a product designed and tested during

the bike designing phase. Moto Guzzi Original Spare Parts are subject to systematic quality control

procedures so that their reliability and performance over time is guaranteed.

The descriptions and illustrations given in this publication are not binding; While the basic features as

described and illustrated in this booklet remain unchanged, Moto Guzzi reserves the right, at any time

and without being required to update this publication beforehand, to make any changes to components,

parts or accessory supplies, which it deems necessary to improve the product or which are required for

manufacturing or commercial reasons.

Not all versions shown in this publication are available in all Countries. The availability of individual

versions should be checked with the Official Moto Guzzi sales network.

prohibited. Moto Guzzi - After sales service.

SERVICE STATION MANUAL

BELLAGIO

This manual provides the main information to carry out regular maintenance operations on your vehicle.

This manual is intended to Moto Guzzi Dealers and their qualified mechanics; several concepts have

been deliberately omitted as they are considered unnecessary. As it is not possible to include complete

mechanical notions in this manual, users should have basic mechanical knowledge or minimum

knowledge about the procedures involved when repairing scooters. Without this knowledge, repairing or

checking the vehicle may be inefficient or even dangerous. As the vehicle repair and check procedures

are not described in detail, be extremely cautious so as not to damage components or injure individuals.

In order to optimise customer satisfaction when using our vehicles, Moto Guzzi s.p.a. commits itself to

continually improve its products and the relative documentation. The main technical modifications and

changes in repair procedures are communicated to all Moto Guzzi Sales Outlets and its International

Subsidiaries. These changes will be introduced in the subsequent editions of the manual. In case of

need or further queries on repair and check procedures, consult Moto Guzzi CUSTOMER

DEPARTMENT, which will be prepared to provide any information on the subject and any further

communications on updates and technical changes related to the vehicle.

NOTE Provides key information to make the procedure easier to understand and carry out.

CAUTION Refers to specific procedures to carry out for preventing damages to the vehicle.

WARNING Refers to specific procedures to carry out to prevent injuries to the repairer.

Personal safety Failure to completely observe these instructions will result in serious risk of personal

injury.

Safeguarding the environment Sectionsmarkedwiththis symbol indicate the correct use of the vehicle

to prevent damaging the environment.

Vehicle intactness The incomplete or non-observance of these regulations leads to the risk of serious

damage to the vehicle and sometimes even the invalidity of the guarantee

INDEX OF TOPICS

CHARACTERISTICS CHAR

SPECIAL TOOLS S-TOOLS

MAINTENANCE MAIN

ELECTRICAL SYSTEM ELE SYS

ENGINE FROM VEHICLE ENG VE

ENGINE ENG

POWER SUPPLY P SUPP

SUSPENSIONS SUSP

CHASSIS CHAS

BRAKING SYSTEM BRAK SYS

BODYWORK BODYW

PRE-DELIVERY PRE DE

INDEX OF TOPICS

CHARACTERISTICS CHAR

Rules

Safety rules

Carbon monoxide

If you need to keep the engine running while working on the vehicle, please ensure that you do so in

an open or very well ventilated area. Never run the engine in an enclosed area. If you do work in an

enclosed area, make sure to use a fume extraction system.

CAUTION

EXHAUSTEMISSIONSCONTAINCARBONMONOXIDE,APOISONOUSGASWHICHCANCAUSE

LOSS OF CONSCIOUSNESS AND EVEN DEATH.

Fuel

CAUTION

THE FUEL USED TO POWER INTERNAL COMBUSTION ENGINES IS HIGHLY FLAMMABLE AND

MAY BE EXPLOSIVE UNDER CERTAIN CONDITIONS. IT IS THEREFORE RECOMMENDED TO

CARRY OUT REFUELLING AND MAINTENANCE PROCEDURES IN A VENTILATED AREA WITH

THE ENGINE SWITCHED OFF. DO NOT SMOKE DURING REFUELLING AND NEAR FUEL VA-

POURS, AVOIDING ANY CONTACT WITH NAKED FLAMES, SPARKS OR OTHER SOURCES

WHICH MAY CAUSE THEM TO IGNITE OR EXPLODE.

DO NOT DISPERSE FUEL IN THE ENVIRONMENT.

KEEP OUT OF THE REACH OF CHILDREN

Hot components

The engine and the exhaust system components become very hot and remain hot for some time after

the engine has been switched off. When handling these components, wear insulating gloves or wait

until the engine and the exhaust system have cooled down.

Used engine oil and transmission oil

CAUTION

IT IS ADVISABLE TO WEAR PROTECTIVE IMPERMEABLE GLOVES WHEN SERVICING THE VE-

HICLE.

THE ENGINE OR GEARBOX OIL MAY CAUSE SERIOUS INJURIES TO THE SKIN IF HANDLED

FOR PROLONGED PERIODS OF TIME AND ON A REGULAR BASIS.

WASH YOUR HANDS CAREFULLY AFTER HANDLING OIL.

HAND THE OIL OVER TO OR HAVE IT COLLECTED BY THE NEAREST USED OIL RECYCLING

COMPANY OR THE SUPPLIER.

DO NOT DISPOSE OF OIL IN THE ENVIRONMENT

KEEP OUT OF THE REACH OF CHILDREN

BELLAGIO Characteristics

CHAR - 7

Brake and clutch fluid

BRAKE AND CLUTCH FLUIDS CAN DAMAGE THE PLASTIC OR RUBBER PAINTED SURFACES.

WHEN SERVICING THE BRAKING SYSTEM OR THE CLUTCH SYSTEM, PROTECT THESE COM-

PONENTS WITH A CLEAN CLOTH. ALWAYS WEAR PROTECTIVE GOGGLES WHEN SERVICING

THESE SYSTEMS. BRAKE AND CLUTCH FLUIDS ARE EXTREMELY HARMFUL FOR YOUR

EYES. IN THE EVENT OF ACCIDENTAL CONTACT WITH THE EYES, RINSE THEM IMMEDIATELY

WITH ABUNDANT COLD, CLEAN WATER AND SEEK MEDICAL ADVICE.

KEEP OUT OF THE REACH OF CHILDREN

Battery electrolyte and hydrogen gas

CAUTION

THE BATTERY ELECTROLYTE IS TOXIC, CORROSIVE AND AS IT CONTAINS SULPHURIC ACID,

IT CAN CAUSE BURNS WHEN IN CONTACT WITH THE SKIN. WHEN HANDLING BATTERY

ELECTROLYTE, WEAR TIGHT-FITTING GLOVES AND PROTECTIVE APPAREL. IN THE EVENT

OF SKIN CONTACT WITH THE ELECTROLYTIC FLUID, RINSE WELL WITH PLENTY OF CLEAN

WATER. IT IS PARTICULARLY IMPORTANT TO PROTECT YOUR EYES BECAUSE EVEN TINY

AMOUNTSOFBATTERYACID MAY CAUSEBLINDNESS.IFTHE FLUID GETSINCONTACTWITH

YOUR EYES, WASH WITH ABUNDANT WATER FOR FIFTEEN MINUTES AND CONSULT AN EYE

SPECIALIST IMMEDIATELY. THE BATTERY RELEASES EXPLOSIVE GASES; KEEP IT AWAY

FROM FLAMES, SPARKS, CIGARETTES OR ANY OTHER HEAT SOURCES. ENSURE ADE-

QUATE VENTILATION WHEN SERVICING OR RECHARGING THE BATTERY.

KEEP OUT OF THE REACH OF CHILDREN

BATTERY LIQUID IS CORROSIVE. DO NOT POUR IT OR SPILL IT, PARTICULARLY ON PLASTIC

COMPONENTS. ENSURE THAT THE ELECTROLYTIC ACID IS COMPATIBLE WITH THE BAT-

TERY TO BE ACTIVATED.

Maintenance rules

GENERAL PRECAUTIONS AND INFORMATION

When repairing, dismantling and reassembling the vehicle, follow the recommendations given below

carefully.

BEFORE DISASSEMBLING COMPONENTS

•Beforedismantling components, remove dirt, mud, dust and foreign bodies from the vehicle.

Use the special tools designed for this bike, as required.

COMPONENTS REMOVAL

•Donotloosenand/or tighten screws and nuts using pliers or any other tools than the specific

wrench.

•Mark positions on all connection joints (pipes, cables etc.) before separating them, and

identify them with distinctive symbols.

•Each component needs to be clearly marked to enable identification during reassembly.

•Clean and wash the dismantled components carefully using a low-flammability detergent.

•Keep mated parts together since they have "adjusted" to each other due to normal wear.

Characteristics BELLAGIO

CHAR - 8

•Some components must be used together or replaced completely.

•Keep away from heat sources.

REASSEMBLING COMPONENTS

CAUTION

BEARINGS MUST ROTATE FREELY, WITHOUT JAMMING AND/OR NOISE, OTHERWISE, THEY

NEED TO BE REPLACED.

•Only use ORIGINAL Moto Guzzi SPARE PARTS.

•Comply with lubricant and consumables use guidelines.

•Lubricate parts (whenever possible) before reassembling them.

•When tightening nuts and screws, start from the ones with the largest section or from the

internal ones, moving diagonally. Tighten nuts and screws in successive steps before ap-

plying the tightening torque.

•Always replace self-locking nuts, washers, sealing rings, circlips, O-rings (OR), split pins

and screws with new ones if their tread is damaged.

•When assembling the bearings, make sure to lubricate them well.

•Check that each component is assembled correctly.

•After a repair or routine maintenance procedure, carry out pre-ride checks and test the ve-

hicle on private grounds or in an area with low traffic density.

•Clean all coupling surfaces, oil guard rims and gaskets before refitting them. Smear a light

layer of lithium-based grease on the oil guard rims. Reassemble oil guards and bearings

with the brand or lot number facing outward (visible side).

ELECTRICAL CONNECTORS

Electric connectors must be disconnected as described below; failure to comply with this procedure

causes irreparable damage to both the connector and the wiring harness:

Press the relative safety clips, if applicable.

•Grip the two connectors and disconnect them by pulling them in opposite directions.

•If any signs of dirt, rust, moisture, etc. are noted, clean the inside of the connector carefully

with a jet of compressed air.

•Ensure that the cables are correctly fastened to the internal connector terminals.

•Then connect the two connectors, ensuring that they couple correctly (if fitted with clips, you

will hear them "click" into place).

CAUTION

DO NOT DISCONNECT CONNECTORS BY PULLING THE CABLES.

NOTE

THE TWO CONNECTORS CAN ONLY BE CONNECTED IN ONE DIRECTION: CONNECT THEM

THE RIGHT WAY ROUND.

TIGHTENING TORQUES

CAUTION

REMEMBERTHATTHETIGHTENING TORQUES FORALLFASTENINGELEMENTS ON WHEELS,

BRAKES, WHEEL AXLES AND ANY OTHER SUSPENSION COMPONENTS PLAY A KEY ROLE

IN ENSURING VEHICLE SAFETY AND MUST COMPLY WITH SPECIFIED VALUES. CHECK THE

BELLAGIO Characteristics

CHAR - 9

TIGHTENING TORQUES OF FASTENING ELEMENTS ON A REGULAR BASIS AND ALWAYS USE

A TORQUE WRENCH TO REASSEMBLE THESE COMPONENTS. FAILURE TO COMPLY WITH

THESE RECOMMENDATIONS MAY CAUSE ONE OF THESE COMPONENTS TO LOOSEN OR

EVEN DETACH, CAUSING A WHEEL TO LOCK OR COMPROMISING VEHICLE HANDLING. THIS

MAY LEAD TO FALLS, WITH THE RISK OF SERIOUS INJURY OR DEATH.

Running-in

Runningtheengineincorrectlyisessentialfor ensuring engine longevity and functionality. Twisty roads

and gradients are ideal for running in the engine, brakes and suspension effectively. Vary your riding

speed during the running in period. This ensures that components operate in "loaded" conditions and

then "unloaded" conditions, allowing the engine components to cool.

CAUTION

THE CLUTCH MAY EMIT A SLIGHT BURNING SMELL WHEN FIRST USED. THIS PHENOMENON

SHOULD BE CONSIDERED NORMAL AND WILL DISAPPEAR AS SOON AS THE CLUTCH

PLATES GET ADAPTED.

ITISIMPORTANTTOSTRAIN ENGINE COMPONENTS DURINGRUN-IN,HOWEVER,MAKESURE

NOT TO OVERDO THIS.

CAUTION

THE FULL PERFORMANCE OF THE VEHICLE IS ONLY AVAILABLE AFTER THE SERVICE AT

THE END OF THE RUNNING IN PERIOD.

Follow the guidelines detailed below:

•Do not fully open the throttle grip abruptly at low engine speeds, either during or after the

running in period.

•During the first 100 Km (62 miles) use the brakes gently, avoiding sudden or prolonged

braking. That is to permit the adequate adjustment of the pad friction material to the brake

discs.

AFTER THE SPECIFIED MILEAGE, TAKE THE VEHICLE TO AN OFFICIAL Moto Guzzi DEALER

FOR THE CHECKS INDICATED IN THE "AFTER RUN-IN" TABLE IN THE SCHEDULED MAINTE-

NANCE SECTION TO AVOID INJURING YOURSELF, OTHERS AND /OR DAMAGING THE VEHI-

CLE.

•Between 1000 km (625 miles) and 2000 km (1250 miles) travelled, ride more vigourously,

vary speeds and twist throttle fully for some short periods for best coupling of the compo-

nents; do not exceed 6000 rpm.

•After 2000 km (1250 miles) a better engine performance may be expected, but without ex-

ceeding the engine maximum rpm allowed (7600 rpm).

Vehicle identification

SERIAL NUMBER LOCATION

These numbers are necessary for vehicle registration.

NOTE

ALTERING IDENTIFICATION NUMBERS MAY BE SERIOUSLY PUNISHABLE BY LAW. IN PAR-

TICULAR, MODIFYING THE FRAME NUMBER IMMEDIATELY VOIDS THE WARRANTY.

Characteristics BELLAGIO

CHAR - 10

Otros manuales para BELLAGIO

Tabla de contenidos

Otros manuales de Motocicleta de MOTO GUZZI

MOTO GUZZI

MOTO GUZZI BREVA V750IE Manual de lista de piezas

MOTO GUZZI

MOTO GUZZI Le mans 1000 Manual de usuario

MOTO GUZZI

MOTO GUZZI NORGE 1200 Manual de usuario

MOTO GUZZI

MOTO GUZZI GRISO 1100 Manual de usuario

MOTO GUZZI

MOTO GUZZI 1000S Manual de usuario

MOTO GUZZI

MOTO GUZZI NORGE 1200 Guía

MOTO GUZZI

MOTO GUZZI CALIFORNIA STONE Manual de usuario

MOTO GUZZI

MOTO GUZZI BREVA V750 IE 2003 Guía del producto

MOTO GUZZI

MOTO GUZZI nevada Manual de usuario

MOTO GUZZI

MOTO GUZZI BREVA V1100 Manual de lista de piezas

MOTO GUZZI

MOTO GUZZI NORGE 1200 Manual de usuario

MOTO GUZZI

MOTO GUZZI V750 Ambassador Manual de usuario

MOTO GUZZI

MOTO GUZZI V750 IE Manual de instrucciones

MOTO GUZZI

MOTO GUZZI California III Manual de usuario

MOTO GUZZI

MOTO GUZZI Nevada Classic 750 ie 2004 Manual de instrucciones

MOTO GUZZI

MOTO GUZZI 1200 SPORT Guía

MOTO GUZZI

MOTO GUZZI nevada Manual de usuario

MOTO GUZZI

MOTO GUZZI California Jackal Manual de usuario

MOTO GUZZI

MOTO GUZZI CALIFOANIA 1000 Manual de instrucciones

MOTO GUZZI

MOTO GUZZI BREVA 750 Manual de usuario

MOTO GUZZI

MOTO GUZZI V 50 Manual de usuario

MOTO GUZZI

MOTO GUZZI 850-T5 Manual de usuario

MOTO GUZZI

MOTO GUZZI 850 Le Mans III Manual de usuario

MOTO GUZZI

MOTO GUZZI 850 Le Mans III Manual de instrucciones

Manuales populares de Motocicleta de otras marcas

OHVALE

OHVALE GP-0 Manual de lista de piezas

Yamaha

Yamaha Star XV19CTSZ 2009 Manual de usuario

KTM

KTM 350 XCF-W USA Manual de usuario

HYOSUNG

HYOSUNG ST7 Manual de usuario

Husqvarna

Husqvarna FC 250 2016 Manual de usuario

Ducati

Ducati SCRAMBLER 800 Manual de instrucciones

APRILIA

APRILIA ETV MILLE CAPONORD - PART1 02-2001 Manual de usuario

Yamaha

Yamaha 2006 YZF-R1V Manual de usuario

KTM

KTM Freeride E-XC 2021 Manual de usuario

Fantic

Fantic Enduro 125 Manual de usuario

Ducati

Ducati Supersport 750 desmodue Manual de usuario

MV Agusta

MV Agusta 2008 F4 312RR 1078 Manual de instrucciones

Yamaha

Yamaha XVS650A Manual de usuario

Yamaha

Yamaha YZF-R6T(C) Manual

Ducati

Ducati 748 monoposto strada Manual de usuario

ATK

ATK 1988 250 Manual de usuario

Excelsior-HENDERSON

Excelsior-HENDERSON 1999 HCX Manual de usuario

Triumph

Triumph Thunderbird Manual de usuario
