Motic EasyScan One Manual de usuario
EasyScan One
Instruction Manual
If the equipment is used in a manner
not specified by the manufacturer,
the protection provided by the
equipment may be impaired.
Note
Complete reading of this manual
before opeartion is required.
WWW.MOTIC.COM
MOTIC HONG KONG LIMITED
1
TABLE OF CONTENTS
1. Device Safety Instructions 3
1.1 General Safety Tip 3
1.2 Safety Sign 3
1.3 Device Safety and EMC 3
1.4 Warranty Description 4
2. General Description 5
2.1 Product Application Range 5
2.2 System Overview 5
2.2.1 System Diagram 5
2.2.2 System Installation 6
2.2.3 System Connection Diagram 6
2.2.4 Port Description 7
2.2.4.1 Device Hosting Ports Description 7
2.2.4.2 Computer Ports Description 8
2.2.5 System Connection Operation 8
2.3 Slide Tray 10
2.3.1 Placement Procedure 10
2.3.1.1 Slide Loading Procedure 10
2.3.1.2 Slide Unloading Procedure 11
2.3.2 Slide Tray Installation Procedure 12
3. Software Installations and Instructions 13
3.1 Software Installation 13
3.2 User Interface 17
3.3 Slide Scanning 19
3.3.1 Slide Scanning — Operation Interface 19
3.3.2 Slide Scanning — Advanced Setting Interface 20
3.4 For Mobile Device (*Optional) 22
2
4. Operation Guidance 23
4.1 Cautions 23
4.2 Operation Instruction 23
4.3 Complete Scanning 23
5. Maintenance and Troubleshooting 24
5.1 Care and Maintenance 24
5.2 Troubleshooting 24
5.2.1 Software cannot control MoticEasyScan One Operation 24
5.2.2 Scanning Software is not able to Display Image 24
5.2.3 Calibration 25
5.2.3.1 Import Calibration File 25
5.2.3.2 Auto Calibration 26
5.2.3.3 Manual Calibration 27
6. Appendix 34
6.1 Specifications 34
6.2 Electrical Specification 34
6.3 Working Environment 34
6.4 Storage Environment 34
6.5 Digital Camera System Specifications 35
6.6 Device Movement 35
6.7 Component Purchasing 35
6.7.1 Accessory List 35
6.8 Miscellaneous 36
6.9 Lens Cleaning 36
6.10 Cleaning of Components with Painting and Plastic components 36
6.11 Idle Time 36
3
1. DEVICE SAFETY INSTRUCTIONS
1.1 General Safety Tip
Before using the device, make sure to follow the instructions given in the Manual. For installation
instructions, please consult Chapter 2 and 3 of this Manual.
1.2 Safety Sign
The following signs are shown on the system. Every user must make sure to understand the definition of
the safety signs to always operate the device the most secure way.
Sign Meaning
l Main switch (ON)
○Main switch (OFF)
~ AC
Representing uncertainty of the general danger.
Follow the descriptions on the back of signs or
follow manufacturer’s instructions.
For damaged, missing or unreadable labels, please contact Motic Group Corporation for replacement
before continue operation.
1.3 Device Safety and EMC
●MoticEasyScan One is designed, manufactured and inspected in accordance with the IEC
61010-1:2001/EN 61010-1:2001 and GB4793.1-2007 safety standards for electrical measurement,
control, adjustment and laboratory device.
●Electromagnetic is compatible to the standard of GB 18268.1-2010/IEC 61326-1-2005/IEC
61326-2-6:2005 and EN 55011 A level
●Waste treatment disposal is implemented based on WEEE-Regulation 2002/96/EC
4
Summary List
Project Standard
Safety Regulations IEC 61010-1:2001/EN 61010-1:2001、GB4793.1-2007
EMC GB 18268.1-2010/IEC 61326-1-2005/IEC 61326-2-6:2005、
EN 55011 A
Device Scrap Disposal WEEE 2002/96/EC
1.4 Warranty Description
MoticEasyScan One and its components are only allowed to be operated within techniques and
processes described in this operation manual.
The manufacturer does not take any responsibility for damage caused by usage not complying to the
instruction in the Manual.
Please note the following warranty for MoticEasyScan One:
●Manufacturer warranty for material and product quality starts at the time of delivery.
●In case of malfunction, please inform the manufacturer immediately.
●If being notified of such a defect, the manufacturer is obligated to repair the device or deliver an
intact replacement.
●Manufacturer does not assume warranty for those defects caused by natural wearing (especially the
wear parts and consumables) or improper use.
●Operation of the equipment out of the functions described in this manual, negligence or replacing
equipment components will invalidate all warranty rights.
5
2. GENERAL DESCRIPTION
2.1 Product Application Range
MoticEasyScan One is a professional scanning device, with high-precision motion control system and
high-resolution digital imaging system for scanning a single glass slide. Rapid high quality digital slide
scanning can be achieved with Motic digital slide scanning software. It is applicable for scanning, digital
storage, transferring and browsing of histopathology slide, cytology and biology slides etc.
MoticEasyScan One can be remotely controlled through software.
2.2 System Overview
2.2.1 System Diagram
This product consists of device main body, slide tray, and scanning software.
* If the equipment is used in manner not specified by the manufacturer, the protection provided by the
equipment may be impaired.
(Fig. 1)
6
2.2.2 System Installation
Before installation, please be familiar with following parts.
USB 3.0 cable Power Supply Cable
2.2.3 System Connection Diagram
(Fig. 2)
7
2.2.4 Port Description
2.2.4.1 Device Hosting Ports Description
USB port matches macro camera and main camera (USB cable connects to USB3.0 port of host
computer)
(Fig. 3)
8
2.2.4.2 Computer Ports Description
USB port of host computer should be USB3.0 port, which is signed with SS or marked as blue color.
Computer Ports Diagram
(Fig. 4)
2.2.5 System Connection Operation
Please make sure the EVA foam, which is inside the device, is taken out before starting any operation
and connection work. (Fig. 5)
(Fig. 5)
9
●Firstly, manually disassemble the locking screw. (Fig. 6a)
●Then slide the front panel ①, ②out in horizontal direction from the device. (Fig. 6a)
●Take out the EVA foam carefully. (Fig. 6b)
●Snap the front panel back into the device and relock the locking screw. (Fig. 6b)
(Fig. 6a)
(Fig. 6b)
