OWNER GUIDE

This guide is intended to help you care for your gas stove. Please read thoroughly

before using your gas stove and keep for future reference.

Manufactured by Morsø Jernstøberi A/S, Furvej 6, 7900 Nykøbing Mors, Denmark

Distributed by Baxi Fires Division, Wood Lane, Erdington, Birmingham B24 9QP,

England

INSTALLER: Please leave this guide with the

owner

600B474/03

morsø

SQUIRREL

GAS STOVE

MODEL No. 551 – With Open Flue

MODEL No. 552 – With Balanced Flue

We trust that this guide gives sufficient detail to enable your gas stove to be operated

and maintained satisfactorily. However, if further information is required, our

Technical

Helpline will be pleased to help.

In the United Kingdom Telephone 08706 061 065 (National call rates apply in the

United Kingdom). In the Republic of Ireland Telephone 0044 8706 061 065

THESE APPLIANCES ARE FOR USE WITH NATURAL GAS (G20)

OPEN FLUE STOVE MODEL 551 IS FOR USE WITH PROPANE GAS (G31)

WHEN CONVERTED USING KIT NO. 0555111.

BALANCED FLUE STOVE MODEL 552 IS FOR USE WITH PROPANE GAS

(G31) WHEN CONVERTED USING KIT NO. 0555211.

THESE APPLIANCES ARE SUITABLE ONLY FOR INSTALLATION THE

UNITED KINGDOM (GB) AND THE REPUBLIC OF IRELAND (IE).

Page 2

LIST OF CONTENTS

Heading Page

SAFETY 3

OPERATING YOUR STOVE 5

The Flame Sensing & Flue Blockage Safety System 5

To Light the Main Burner 6

To Light The Pilot 6

To Turn Off the Main Burner and Pilot 6

To Turn Off the Main Burner Only 6

CLEANING YOUR STOVE 7

Cast Iron Surfaces 7

Opening the Door 7

The Glass Window 7

FITTING THE CERAMIC FUEL EFFECT AND

BURNER COMPARTMENT WALLS 8

MAINTENANCE AND SERVICING 11

Thank you for choosing morsø.

All morsø appliances are designed to meet the most stringent quality, performance and

safety requirements to provide our customers with many years’ trouble-free service.

Your owner guide aims to improve your understanding and appreciation of your gas

fire by providing simple and informative instructions to ensure that you benefit from

the excellent performance and features it has to offer.

OWNER GUIDE

SAFETY

Do have the gas stove installed by a competent person. In the United Kingdom,

installation must be in accordance with the latest edition of the Gas Safety (installation

& use) Regulations. In the Republic of Ireland, installation must be in accordance with

all national and local regulations in force.

have the chimney swept prior to installation if it was previously used for solid fuel.

have the gas stove installed in accordance with the installation instructions. On no

account must the fire stand on carpets or other combustible materials. The fire must

stand on a non-combustible hearth surface. The hearth material must be at least 400mm

wide x 420mm deep x 12mm thick.

Do provide the minimum clearances shown in figure 1.

ensure that the flue terminal on the outside wall (Balanced flue model 552) is kept

free from all obstructions and blockages.

Do always use a fireguard complying with BS 8423 for the protection of young

children, the elderly or infirm.The cast iron top, front, rear and sides of this stove are

considered to be working surfaces and so will become very hot when in use. Always

take care when using this appliance. Such a guard is also recommended for the

protection of pet animals.

wait three minutes before attempting to relight if the gas stove is switched off or the

flames are extinguished for any reason.(Your gas stove is fitted with a safety device that

will automatically shut off the gas supply to the gas stove, if for any reason , the flame

goes out)

get advice about the suitability of any wall covering near your gas stove. Soft wall

coverings (e.g. embossed vinyl, etc.) which have a raised pattern are easily affected by

heat. They may, therefore, scorch or become discoloured when close to a heating

appliance. Please bear this in mind whenever you are considering redecorating.

Don’t hang clothing, towels or any other fabrics over the gas stove.

Don’t put more loose ceramic coals on the gas stove than the number given in this

guide or use any ceramic coals other than those authorised for this gas stove. Incorrect

combustion could result.

OWNER GUIDE

Page 3

IF YOU SMELL GAS

DON’T SMOKE

EXTINGUISH ALL NAKED FLAMES

DON’T TURN ELECTRICAL SWITCHES ON OR OFF

TURN OFF THE GAS SUPPLY AT THE METER

OPEN DOORS AND WINDOWS TO GET RID OF THE GAS

IMMEDIATELY CALL THE GAS EMERGENCY SERVICE – SEE YOUR LOCAL TELEPHONE

DIRECTORY

OWNER GUIDE

Page 4

Model 551

Model 552

Figure 1. Appliance dimensions and clearances

Don’t put paper or other materials into your gas stove.

Don’t use the gas stove with damaged base ceramics.

Don’t place any combustible material (rugs, carpet, plastic tiles, etc.) on the hearth

Don’t attempt to clean or service the gas stove until it has been switched off and

allowed to cool completely.

Don’t

use this stove with the door open or with the glass panel damaged or removed.

The door should always be secured with the locking screw (See “Cleaning your stove”).

If the window is damaged or will not close securely the fire must be turned off and not

used until the window is changed or corrected by a competent service engineer.

Don’t leave the stove on if the house is left unoccupied for a long period. We

recommend that the stove is turned fully off.

OPERATING YOUR STOVE

This fire is supplied with ceramic “coals” to simulate a real coal fire. After some use,

the firebox walls and coals may change colour. This is quite normal.

The Flame Sensing & Flue Blockage Safety System.

For your safety, this appliance is fitted with a flue blockage safety device that will shut

down the appliance in the event of abnormal flue conditions. This device is NOT a

substitute for an independently mounted Carbon Monoxide detector.

The device will also automatically shut off the gas supply to the gas stove if the pilot

flame goes out for any reason.

If the device starts to shut off the gas frequently, get

expert advice.

The system incorporates a probe that senses that the heat from the pilot flame is correct.

If this probe is cool, the device will prevent any gas flow unless the control knob is kept

depressed at the PILOT/IGN position.

If, for any reason, the flames go out when the gas stove is hot or if the gas stove is

turned off when hot, always

wait at least three minutes before attempting to relight

Always make sure that the door is securely closed before lighting.

OWNER GUIDE

Page 5

PLEASE NOTE

When operating your stove for the first time, some vapours may be given off which may

cause a slight odour and could possibly set off any smoke alarms in the immediate

vicinity. These vapours are quite normal with new appliances. They are totally harmless

and will disappear after approximately twelve hours use.

To Light The Pilot

sPush in the right control knob (the pilot lighting knob) and, while keeping it

depressed, turn anticlockwise through the ignition position marked and up to

the pilot position marked

. The spark should light the pilot. The pilot flame can

be seen by looking through the gap between

the coals near the front left corner of the fire

bed (See figure 3).

sWhen the pilot has lit, keep the right hand

control knob depressed for a few seconds to

prevent the flame supervision device from

shutting off the gas supply while its probe

warms up, as explained previously, then

release it.

sIf the pilot does not remain alight turn the

knob back to the off position marked •.Wait

a few seconds and repeat the lighting

sequence.

To Light the Main Burner

sPartially depress the right control knob and

turn to the main burner position marked .

The main burner should now light.

sThe left-hand knob is for burner flame

adjustment. Turning it anticlockwise should

gradually increase the flame height and heat output. Turning clockwise reduces the

flame height and heat output.

The burner flame control does not have to be re-set every time the fire is lit. Once set,

it can be left at that position allowing you to use the right hand control only to ignite

the burner at the set flame height.

To Turn Off the Main Burner Only

sTurn the right hand control knob to the pilot position marked .

To Turn Off the Main Burner and Pilot

sTurn the right hand control knob to the pilot position marked

. Push the knob in

at this position and turn to the off position marked •.

OWNER GUIDE

Page 6

Figure 3.

Figure 2.

CLEANING YOUR STOVE

Turn the stove off and allow it to cool completely before attempting any cleaning. Note

that it will retain heat for some time after it has been turned off.

Cast Iron Surfaces

Regular dusting with a dry lint free cloth is all that should normally be necessary. Any

light stains should be removed with a damp lint free cloth. Make sure that the stove

surfaces are completely dry before lighting.

If the paint needs retouching, allow the stove to cool completely. Brush any areas

needing attention with a wire brush (Not enamelled surfaces). Clean off any loose

matter. Touch up with Morsø high temperature stove paint. Apply the paint sparingly.

Two light coats are better than one thick coat.

Opening the Door

The door is secured with a locking screw. Remove the screw

using the special key supplied with the stove (See figure 4).

Always secure the door with the locking screw to prevent

inadvertent opening and consequent injury or damage

while the stove is in use.

The Glass Window

Any stains on the glass can be removed with a non-abrasive

cleaner such as a ceramic hob cleaner. Never use abrasive

cleaners. Clean the window carefully in accordance with the

instructions supplied with the cleaner.

OWNER GUIDE

Page 7

Figure 4.

FITTING THE CERAMIC FUEL EFFECT AND BURNER

COMPARTMENT WALLS

Ceramic fuel effect and Burner compartment

Walls

!This product uses fuel effect pieces and

burner compartment rear wall containing

Refractory Ceramic Fibres (RCF), which are

man-made vitreous silicate fibres. Excessive

exposure to this material may cause irritation

to eyes, skin and respiratory tract.

Consequently, it is important to take care

when handling these articles to ensure that

the release of dust is kept to a minimum.

!Light coatings of soot will usually be burnt

off during the normal operation of the fire.

!Should any soot accumulation become

excessive, the fuel effect pieces and walls should

be removed from the fire for cleaning.

!Cleaning should be carried out in a well

ventilated area or in the open air by gently

brushing with the pieces held away from your face

so that you avoid inhaling the dust.

!We suggest that you remove the coals in the

reverse order to that shown in this section of the

guide. When removing the fuel effect and

burner compartment walls it is important that

the front grate is removed before the fuel effect

pieces. To do this hold the front grate firmly

and lift.

1. Place the rear ceramic wall against the back of

the firebox.

2. The rear ceramic wall must be located onto the

ledges at the back of the rear base ceramic (See figure 5). To achieve this, hold the rear

ceramic wall against the rear of the firebox at its uppermost position. Whilst holding the

rear ceramic wall in this position locate the rear ceramic base coal into position (See

figure 5). The rear wall can now be released. Ensure that the rear ceramic wall sits on

the ledge at the back of the rear base coal.

OWNER GUIDE

Page 8

Figure 6.

Figure 5.

3. Fit the left hand side wall against the left hand

side of the firebox. Locate the bottom of the side

wall into the channel along the bottom of the

firebox (See figure 6). Supplied with the stove

are two ceramic retaining brackets. One for each

side of the firebox. Hold the ceramic side wall

against the steel firebox plate and slide the long

leg of a retaining bracket behind the steel firebox

plate. Push down to hold the ceramic side wall in

place.

4. Fit the right hand side wall against the right

hand side of the firebox. Locate the bottom of

the side wall into the channel along the bottom

of the firebox. Hold the ceramic side wall

against the steel firebox plate and slide the

long leg of a retaining bracket behind the steel

firebox plate. Push down to hold the ceramic

side wall in place.

5. On the front of the burner there is a bracket

for supporting the front ceramic base. At the

rear of the front ceramic base is a recess. Fit

the front ceramic base piece locating the recess

onto the forward projecting part of the burner

bracket (See figure 7).

There are seven overlay coals. There are three

ceramic coals identified with the number’1’. Two

identified with the number ‘2’ and two identified

with the number ‘3’.

6. Locate one of the ceramic coals identified

with a number ‘1’ as in figure 8.

7. Locate the two ceramic coals identified with

a number ‘2’ as in figure 9.

8. Locate the remaining two ceramic coals

identified with a number ‘1’ as in figure 10.

OWNER GUIDE

Page 9

Figure 10.

Figure 9.

Figure 8.

Figure 7.

9. Locate the two ceramic coals identified with a

number ‘3’ as in figure 11.

10. Replace the front grate removed previously.

11. Close and secure the door by refitting the

locking screw.

OWNER GUIDE

Page 10

Figure 11.

Otros manuales para SQUIRREL 552

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cocina de Morso

Morso

Morso 6600 Manual de usuario

Morso

Morso S11-40 Manual de usuario

Morso

Morso 6870 Manual de usuario

Morso

Morso 3400 Series Manual de usuario

Morso

Morso S11 Series Manual de usuario

Morso

Morso 6100 series Manual de usuario

Morso

Morso SQUIRREL 551 Manual de usuario

Morso

Morso 7400 SERIES Manual de usuario

Morso

Morso 553 Manual de usuario

Morso

Morso 3112 Manual de usuario

Morso

Morso 8100 series Manual de usuario

Morso

Morso S12 series Manual de usuario

Morso

Morso S81-90 Manual de usuario

Morso

Morso SQUIRREL 551 Manual de usuario

Morso

Morso 8140 Manual de usuario

Morso

Morso 553 Manual de usuario

Morso

Morso 1410 Manual de usuario

Morso

Morso 1410 Manual de usuario

Morso

Morso S81 Manual de usuario

Morso

Morso 7800 Series Manual de usuario

Morso

Morso 1410 Manual de usuario

Morso

Morso 3100 Series Manual de usuario

Morso

Morso DB15 Manual de usuario

Morso

Morso 3600 Series Manual de usuario

Manuales populares de Cocina de otras marcas

Arada

Arada Cassette Stove Manual de usuario

Parmco

Parmco FS 600 Manual de usuario

MCZ

MCZ SUITE AIR 10 M2 Manual de usuario

HearthStone

HearthStone Stowe DV 8321 Guía de solución de problemas

Cattara

Cattara FAMILY Manual de usuario

Stanley

Stanley Argon F500 OVAL Manual de usuario

Avalon

Avalon B-VENT Manual de usuario

Nordpeis

Nordpeis Vega Manual de usuario

Exquisit

Exquisit EKC601-5 Manual de operación

Stanley

Stanley Oisin Oil MK II Manual del propietario

Thermocet

Thermocet Brookfield S/CC Manual de usuario

HASE

HASE delhi Manual de usuario

Vermont Castings

Vermont Castings Intrepid 2 Manual de usuario

Italiana Camini

Italiana Camini CLASSICA Guía de inicio rápido

Avalon

Avalon Vashon Avanti DVS FS Manual de usuario

Spartherm

Spartherm ambiente a1 Manual de usuario

Dimplex

Dimplex MCFSTV12AU Manual de usuario

Warmlite

Warmlite WL46040 Manual de usuario
