Morris MAC-16251 Manual de usuario
Tower Fan 3 in 1
Instruction manual
Model: MAC-16251
READ AND SAVE THESE INSTRUCTIONS
Attention: Pictures in the IM are for reference only.
IMPORTANT SAFETY INSTRUCTIONS
Caution
Read Rules for Safe Operation and Instructions Carefully.
WARNING
1. If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
2. Indoor and household use only.
3. To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other liquid.
4.This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be
made by children without supervision.
5. When the appliance is not in use and before cleaning,
unplug it from the outlet.
6. When the fan was assembled, the rotor blade guard shall
not taken off anymore.
1
8.Non-specialized personnel or unauthorized repair
personnel shall not to repair or modify the machine.
9.It is forbidden to operate with wet hands to avoid electric
shock.
10.
11.
It is prohibited to use this unit in environments with
flammable and explosive gases and direct sunlight for a
long period shall be avoided.
12.
Do not place this unit in an inclined or other uneven
place to prevent the unit from falling and causing
damage to the unit or internal parts.
This machine has a safety switch. If the honeycomb filter
support has not been installed well, the unit will not operate
as usual; when the machine is working, do not remove the
honeycomb filter frame.
WARNING
IMPORTANT SAFETY INSTRUCTIONS
2
7. Correct Disposal of this product
This marking indicates that this product should not be
disposed with other household wastes throughout the EU. To
prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To return your
used device, please use the return and collection systems or
contact the retailer where the product was purchased. They can
take this product for environmental safe recycling.
3
20. Do not have the air inlet and outlet of the unit close to
walls, curtains and other objects, or they may block the
airflow and affect air supply.
18. Do not place items on the unit, and covering the outlet is
strictly prohibited.
19.When cleaning the unit body, apply a damp cloth (or add
a little cleaning agent) to wipe, and never use corrosive
cleaning agent or solvent for cleaning. Never rinse the
unit with water.
WARNING
IMPORTANT SAFETY INSTRUCTIONS
14. After the water tank is filled with water, do not tilt or
collide with the unit when placing or moving it. To move
the unit body, please drive it slowly from the side to
prevent water overflow.
15. In using the unit, prohibit overturning to avoid any
accident. If the unit topples over accidentally, and it
contains water, unplug the power cord immediately and
take it to an authorized service center.
13.At any time the water level in the tank must not exceed
"MAX" (maximum) scale, and during humidification, the
total water level in the tank must be controlled, and must
not be below "MIN" (minimum) scale.
16. When the unit is running, do not knock at or shock the
unit body forcibly or it may lead to automatic shutdown,
in which case simply restart the unit.
Be aware that high humidity levels may encourage the
growth of biological organisms in the Environment.
17.
Never insert fingers, pencils, or any other object through
the grille when fan is running.
Disconnect fan when moving from one location to another.
Make sure fan is on a stable surface when operating, to
avoid overturning.
DO NOT use fan close to windows, rain may create
electrical hazard.
Household use only.
•
•
•
•
•
21.
22.
23.
24.
Do not use the unit around the tub, sprinkler or swimming
pool.
25.Use a soft cloth moisten with mild soap, and then use a dry
cloth to wipe it again.
26. Do not permit the area around the humidifier to become
damp or wet. If dampness occurs, turn the output of the
humidifier down. If the humidifier output volume cannot be
turned down, use the humidifier intermittently. Do not allow
absorbent materials, such as carpeting, curtains, drapes, or
tablecloths, to become damp.
Product repair must be carried out in a designated service
center.
To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other liquid.,
Do not place the unit directly below the power outlet.
WARNING
IMPORTANT SAFETY INSTRUCTIONS
4
5
PRODUCT INTRODUCTION
Notice
Pictures in the manual are for reference only, and real objects within the packaging box will
prevail in the end.
Notice
Parts name
Guidance on feeding water, disassembly & washing of the water
tank
INSTRUCTIONS
Please clean up water accumulated at the bottom of the water tank in a timely manner when the product
is left unused.
Please remove the power plug when feeding water and cleaning.
Please make sure that the water pump module is fixed in position before startup. Random displacement
of the water pump module can cause the abnormalities of the product in cool wind function.
Two ways for feeding water:
①Pull out half of the water tank, and feed water directly without disassembling the water pump module.
②
Separate water pump module, and fully pull out the water tank, to feed water or clean the water tank.
Control part
Water tank
buckles
Wet curtain
Ice crystal box
Water tank
6
Pull out the water tank to the position
as shown in the figure (push the water
tank inside after feeding water)
2
Pull the water tank buckle to
the horizontal state.
1
Guidance on feeding water and disassemble & washing of the
water tank
INSTRUCTIONS
Unscrew the rotary knob in "—" shape
manually (90° anticlockwise) to separate
the water tank from the water pump
module (including the water pipe).
3Pull out the water tank slowly to
clean it up or feed water.
4
After feeding water or cleaning the water
tank, install the water pump module in the
water tank. Insert front hook into the slot
of the water tank, and then rotate rotary
knob in "—" shape clockwise for 90°, and
close it as shown in the figure.
5Push the water tank inside slowly, and
stir the water tank buckle to lock it up.
6
Water pump module
Rotary knob in "—" shape
7
1Pull out half of the water tank below
the machine.
①The ice crystal box can be frozen repeatedly and recycled; You can also choose not to use it
based on the temperature.
②Please keep the ice crystal box closed to prevent from damage and liquid leakage.
③The ice crystal box is made of eco-friendly and toxic-free materials, and can be refrigerated in
fridge safely.
④When using the frozen ice crystal box in the water tank, the temperature at the air outlet will drop
after operating cool wind function.
⑤Ice blocks can be used to replace the frozen ice crystal box, to exert the same cooling effect.
⑥Control the water level of the water tank to be lower than the "max" (maximum) indicating scale
when feeding water, and if the water level is lower than "min" (minimum) indicating scale, please
feed water in time.
Take the ice crystal box out of the
package and place it inside a refrigerator
to freeze for more than 3 hours. Put the
frozen ice crystal box in the water tank,
and feed water below "max" (maximum)
indicating scale.
Usage of the ice crystal box
INSTRUCTIONS
Notice
2
Scale of the water tank
8
Press to activate or deactivate the appliance.
Press to activate or deactivate air swing.
Buttons Function description
Startup/Standby
Timing /
Reservation
Wind type
Air swing
Wind speed
Cool wind
Press the button to switch wind speed to low-grade medium grade and high-
grade
Press the button to select among these three types of wind: Normal wind (grade 3,
the wind speed indicator light is on), sleep wind (grade 1, sleep wind, the indi-
cator light is on), natural wind (grade 1, natural wind, the indicator light is on).
The indicator light will be on when pressing the button under startup state, and the
timed shutdown time can be set by shortly pressing the button (the cyclic is based
on 1-2-3···-7-0-1···)
The indicator light will be on when pressing the button under standby state, and the
reserved startup time can be set by shortly pressing the button (the cyclic is based
on 1-2-3···-7-0-1···)
Shortly press to open or close cool wind under startup state. The experience effect
is better, when opening the cool wind function in dry or hot weather conditions.
If indicator light flashes, please feed water in time, and then press again.
INSTRUCTIONS
Operating instructions of the machine body
Control areaDisplay area
Notice!
Notice
The remote control should be normally used within 5 meters of the front of the product and 30
degrees of the deviation angle.
The battery contains many heavy metals, acids and bases, etc., which may threaten human's
health; Waste batteries should be recycled separately.
Note: Both machine body operation " " and remote control " "
are buttons of wind type;
Both machine body operation " " and remote control " "
are buttons of cool wind;
Open/stop
air swing
Startup/Standby
Set the timed shutdown/
reserved startup
"+" indicates accelerating
wind speed
"-" indicates decreasing
wind speed
Set wind
type
Open/close
cool wind
Remote control button description
INSTRUCTIONS
CLEANING AND MAINTENANCE
AAA Battery, 1.5 V
Battery
Use manganese or alkaline batteries of type "AAA".
DO not use rechargeable batteries.
Disconnect the power before cleaning the product. Clean after the product is shut down for two
minutes.
Prevent from using any abrasive tools and solvents that may damage the surface to clean up the
product. Detergent can be used in the cleaning, and then wiped clean with dried cloth in time.
Prevent from washing the machine body with water directly, and wash disassemble parts (wet
curtain parts) with a soft brush and then install them after they are cleaned and dried.
It is not allowed to take the product apart for any modification. It is recommended that this product
should be checked and cleaned regularly in order to extend its service life.
9
