INSTRUCTION MANUAL
Model: MREMP4WT & MREMP4TNM
Read these instructions carefully before
using this appliance for the rst time.
STORE THESE INSTRUCTIONS CAREFULLY
MultiPress
For product hints and tips plus more join us at
facebook.com/MorphyRichardsAUS instagram.com/morphyrichardsau
www.morphyrichards.com.au
2
Model: MREMP4WT MREMP4TNM
Colour: White Titanium
Rated Voltage: 220-240V~50-60Hz
Rated Power: 900W
Maximum Temperature: 220°C
External Dimensions (L x W x H): 284 x 257 x 107mm
Net Weight: 4.87kg
NAMES OF PARTS AND ACCESSORIES
Lock
SPECIFICATIONS
Upper Body
Handle
Heat Indicator Lower Body
Power Knob
Power Indicator
j ì äí áéêÉëë=fj =aá~Öê~ã
3
NAMES OF PARTS AND ACCESSORIES
Wooden Spatula Waffle Ladle
Top Pie Plate Bottom Pie Plate
Waffle Plates x 2
Jaffle Plates x 2
Flat Grill Plates x 2
4
WARNING
To reduce the risk of fire, electric shock, injury to persons or damage to
property, follow basic precautions including the following:
• If the supply cord is damaged, it must be replaced by the manufacturer or
its service agent or a similarly qualified person in order to avoid a hazard.
• Keep the appliance and its cord out of reach of children.
• WARNING: Misuse of appliance could cause personal injury.
• This appliance is not intended to be operated by means of an external
timer or a separate remote-control system.
• This appliance is not intended for use by persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge unless
they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with this
appliance.
• In the absence of supervision, the cleaning and maintenance work should
not be done by a child.
• Use of accessories not recommended or sold by the original manufacturer
may cause risks of fire, electric shock or personal injury.
• CAUTION: In order to avoid a hazard due to inadvertant resetting of the
thermal cut-out, this appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is regularly
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: HOT SURFACE
PLEASE BE AWARE OF HOT SURFACES
HANDLE WITH CARE
5
switched on and off by the utility.
• This appliance must be used in accordance with the instructions and must
not be used for other purposes.
• This appliance is intended to be used in household and similar
applications such as:
- staff kitchen areas in shops, offices and other working
environments;
- farm houses;
- by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments.
Location
• Do not use outdoors or near water, for indoor use only.
• Always use the appliance on a secure, dry level surface.
Mains cable
• The mains cable should reach from the socket to the base unit without
straining the connections.
• Do not let the cable hang over the edge of the table or counter and keep it
away from any hot surfaces.
• Do not let the cable run across an open space e.g. between a low socket
and table.
• This appliance has been incorporated with a grounded plug. Please ensure
the wall outlet is well earthed.
Personal safety
• Do not touch hot surfaces. Use handle or knobs only.
• WARNING: To protect against fire, electric shock and personal injury, do
not immerse cord, plugs, or appliance in water or other liquid.
6
• WARNING: Extreme caution must be used when moving the appliance
when containing hot food, water, or other hot liquids.
• Unplug from the wall outlet when not in use, before putting on or taking off
attachments, and before cleaning.
• Do not operate any appliance with a damaged lead or plug, or after an
appliance has malfunctioned, or has been dropped or damaged in any way.
• The outer surface may get hot when the appliance is operating.
Other safety considerations
• Do not use any of the appliance parts in a microwave or on any cooking/
heated surfaces.
• Do not place on or near a hot gas or electric burner, or in a heated oven.
• Do not leave the machine unattended.
• Never insert oversized food or metal foil or metal utensils into the
appliance.
Treating scalds
• Run cold water over the affected area immediately. Do not stop to remove
clothing, get medical help quickly.
Electrical requirements
• Check that the voltage on the rating plate of your appliance corresponds
with your house electricity supply which must be A.C.
• WARNING: This appliance must be earthed.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
7
Before using this product for the first time, please:
• Wash the plates in warm soapy water and dry before use.
• Ensure any plate placed in the unit is fitted correctly.
COOKING TEMPERATURES
BEFORE FIRST USE
USING THE MULTIPRESS
Pre-Heat
• Plug the power cord into the wall outlet and switch on. Turn the power
knob to ON, the POWER and HEAT indicator will both illuminate.
• When the unit reaches the pre-heat temperature (approx. 5 minutes), the
HEAT light goes off and the unit is ready to cook. Please use the handles to
open, as the outer surface will get hot.
Cooking
• Carefully put the food on the cooking plates, as the plates will be HOT.
Depending on which grill plate is being used, the cooking time may vary
from 5 to 20 minutes. Refer to the recipe ideas in this manual.
• The HEAT indicator light will turn off when the temperature reaches its
maximum but will continue to cook.
• Check if the food is cooked to your preference.
• When the food is cooked, turn the power knob to OFF and remove the food
carefully with a plastic or wooden utensil.
• WARNING: The temperature of the cooking plates and outer surface may
still be HOT, please leave to cool before replacing the plates, moving or
cleaning the appliance.
Replacing Cooking Plates
• Ensure the unit is switched OFF and the appliance and plates have cooled
completely. Press and hold the release spring buttons and remove the
plates carefully.
• When adding a new plate, guide the two metal plate lugs into the two top
cover holes and two base holes of the appliance.
8
WARNING: Not Dishwasher safe
• Unplug from outlet when not in use and before cleaning. Always allow
to cool before putting on or taking off parts, and before cleaning the
appliance.
• Wash the cooking plates in warm soapy water after use. Dry with a soft
cloth.
• Do not submerge the base in water.
• Do not use metal scouring pads or abrasive cleaners.
• No parts are dishwasher safe.
CLEANING
MAINTENANCE
If the unit fails to operate efficiently, is broken or other problems arise, unplug
and do not operate.
Ask for advice by calling your local after sales service agent or the Customer
Care Centre on 1300 556 816 (AU) / 0800 666 2824 (NZ).
WARRANTY
Please refer to the warranty card in the box for warranty information. For any
troubleshooting advice, please contact the relative Customer Care Centre below.
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
8 Lakeview Drive, 38 Harris Road, East Tamaki,
Scoresby 3179, Victoria Auckland 2013
Australia New Zealand
Ph: 1300 556 816 Ph: 0800 666 2824
9
RECIPES
The recipes in this book have been designed and tested by Morphy Richards
for use specifically with your MultiPress.
The cooking times for the following recipes are a guide and will be affected by
the size and freshness of the ingredients used.
Always ensure food is thoroughly cooked before serving.
Recipes are designed to serve 4 people. If you are reducing the portion sizes,
please adjust the ingredients and cooking times as appropriate.
For more inspirational recipes for your MultiPress,
visit our website
www.morphyrichards.com.au
10
RECIPES - FLAT GRILL PLATE
Ingredients
• 1 loaf of Turkish bread, cut into four pieces,
each piece sliced open
• 8 pieces of prepared marinated capsicum
• 8 slices or prepared marinated eggplant
• Jar of sundried tomato
• small bag of baby spinach
• 1 small red onion, sliced thinly
• 1 small block of Feta cheese
• 150g-200g shredded cheese
Method
1. Insert the at grill plates into the
MultiPress and pre-heat the appliance.
2. Start with some shredded cheese on
the base of the Turkish slice, and layer the
capsicum, onion, sundried tomato, baby
spinach leaves, eggplant slices on top of
the shredded cheese.
3. Finish with a crumble of Feta cheese,
as much or as little as you would like,
and a bit more of the shredded cheese,
if desired. Close the bread. Repeat with
remaining slices of Turkish bread.
4. When the MultiPress is ready, place two
of the Panini onto the hot at grill plate,
close the lid and cook for 6-8 minutes,
until the cheese is melted and Turkish
bread is crispy. Repeat for the remaining
two Panini.
Ingredients
• 4 large eld mushrooms
• 3 spring onions, thinly sliced
• ¼ red capsicum, nely chopped
• 1 tbsp freshly chopped Thyme
• 1 tbsp freshly chopped Parsley
• 1 garlic clove, crushed
• 1 tsp for each mushroom of one of the
following: bacon, salami or ham, chopped
• 80g shredded cheese
• 2 tbsp softened butter
• Salt and pepper to taste
Method
1. Insert the at grill plates into the
MultiPress and pre-heat the appliance.
2. Using a teaspoon, scrape out the stem
and gills from the mushrooms, and chop
up nely and place in a bowl. To this bowl
add diced capsicum, spring onion, fresh
herbs, crushed garlic, butter, cheese and
meat, if using, mix well together.
3. Place a little of the mixture into each
mushroom, attening the top.
4. When the MultiPress is ready, place
two of the mushrooms onto the hot plate,
close the lid and cook for between 2-4
minutes depending on the thickness of
the mushrooms. Repeat for the remaining
mushrooms.
Variation: instead of butter use some
cream cheese. Other cheese options
would be Feta, Blue cheese, Camembert
or Brie.
Antipasto Panini
Serves 4. Prep 10 minutes. Cook 6-8 minutes
Grilled Stuffed Field Mushrooms
Serves 4. Prep 15 minutes. Cook 2-4 minutes
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Electrodoméstico de cocina de Morphy Richards
Morphy Richards
Morphy Richards Toast and Grill Manual de usuario
Morphy Richards
Morphy Richards Accents 402502 Manual de usuario
Morphy Richards
Morphy Richards 47560 MENO MILK FROTHER Manual de usuario
Morphy Richards
Morphy Richards Cordless grater Manual de usuario
Morphy Richards
Morphy Richards Total control 402054 Manual de usuario
Morphy Richards
Morphy Richards easy juice FP404001 Manual de usuario
Morphy Richards
Morphy Richards 43970 Manual de usuario
Morphy Richards
Morphy Richards IB48850 Manual de usuario
Morphy Richards
Morphy Richards MRSGMP25B Manual de usuario
Morphy Richards
Morphy Richards IB48510 Manual de usuario
Morphy Richards
Morphy Richards 48952 Manual de usuario
Morphy Richards
Morphy Richards Accents Manual de usuario
Morphy Richards
Morphy Richards Total control 402054 Manual de usuario
Morphy Richards
Morphy Richards Soup maker Manual de usuario
Morphy Richards
Morphy Richards FLAVOUR SAVOUR Manual de usuario
Morphy Richards
Morphy Richards EXPRESS STEAMPRO 361050 Manual de usuario
Morphy Richards
Morphy Richards KITCHEN MACHINE 48955 Manual de usuario
Morphy Richards
Morphy Richards 501000 Manual de usuario
Morphy Richards
Morphy Richards HB01 Manual de usuario
Morphy Richards
Morphy Richards Intellichef Manual de usuario
