Morphy Richards MRVK15SG Manual de usuario
INSTRUCTION MANUAL
Model: MRVK15SG
Read these instructions carefully before
using this appliance for the rst time.
STORE THESE INSTRUCTIONS CAREFULLY
Venture Pyramid Electric Kettle
For product hints and tips plus more join us at
facebook.com/MorphyRichardsAUS instagram.com/morphyrichardsau
www.morphyrichards.com.au
2
Model: MRVK15SG
Colour: Steel Grey
Rated Voltage: 220-240V~ 50-60Hz
Rated Power: 1850-2200W
Max Capacity: 1.5L
External Dimensions (L x W x H): 220 x 240 x 290mm
Net Weight: 1.75 Kg
NAMES OF PARTS AND ACCESSORIES
SPECIFICATIONS
Handle
Lid handle
Dolly switch
Spout
Power base
Water level indicator
Lid
3
The use of any electrical appliance requires the following
common sense safety rules.
Please read these instructions carefully before using the product.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
• Children shall NOT play with the appliance.
• Cleaning and user maintenance shall not done by children.
• Keep the appliance and its cord out of reach of children.
WARNING: Avoid spillage on the connector.
WARNING: Misuse of appliance could cause personal injury.
WARNING: This appliance has an element which may be subject
to residual heat after use.
WARNING: Do NOT open the lid whilst the water is boiling.
WARNING: Do NOT move kettle while in use.
Location
• WARNING: Do NOT place the appliance onto a metal tray or
metal surface whilst in use.
• This appliance is intended to be used in household and similar
applications such as: farm houses; by clients in hotels, motels
and other residential type environments; bed and breakfast
type environments. It is not suitable for use in staff kitchen
areas in shops, offices and other working environments.
• Always locate your appliance away from the edge of the
worktop.
• Ensure that the appliance is used on a firm, flat surface.
IMPORTANT SAFETY INSTRUCTIONS
4
• Do not use the appliance outdoors or near water.
Power cord
• Do not let the power cord hang over the edge of the worktop
where a child could reach it.
• Do not let the power cord run across an open space e.g.
between a low socket and a table.
• Do not let the power cord run across a cook top or other hot
area which might damage the cord.
• The power cord should reach from the socket to the base unit
without straining the connections.
• If the power cord is damaged, it must be replaced by the
manufacturer, it’s service agent or similarly qualified person in
order to avoid a hazard.
Personal safety
• WARNING: To protect against fire, electric shock and personal
injury do not immerse cord, plug and appliance in water or any
other liquid.
• Always keep the top of the power base dry, especially around
the connection area, disconnect the power supply before drying.
Allow to dry thoroughly before reconnection to the power supply.
• Do not fill above the MAX mark, otherwise boiling water may be
ejected.
• Always pour hot water slowly and carefully without tipping the
appliance too fast to prevent splashing and spillage.
• WARNING: Do not open the lid whilst the water is boiling.
• Do not hold the switch in the on position or tamper with the
switch to fix it in the on position as this may cause damage to
the switch-off mechanism.
• Unplug from the outlet before cleaning.
• Allow to cool before putting on or taking off parts and before
cleaning.
• Do not move the kettle while switched on.
5
1. Before first use, it is recommended to boil the kettle 2 or 3 times
following the instructions below, this will remove any dust or
residue remaining from the manufacturing process.
2. Remove the kettle from the power base before filling.
3. Wherever possible fill through the spout, as this helps to free the
filter from limescale build-up. The integrated water level indicator
allows you to easily see the amount of water in the kettle.
Do NOT fill to above the MAX line on the water gauge. To help
protect the environment, only boil as much water as you need.
4. Place the kettle on the power base, ensuring the kettle is
positioned on the 360° connector.
USING YOUR KETTLE
Other safety considerations
• The use of attachments or tools not recommended or sold by
Morphy Richards, may cause fire, electric shock or injury. The
kettle is only to be used with the base provided.
• Do not use the appliance for any use other than to boil water.
• Do not place the appliance on or near a hot gas or electric
burner or in a heated oven.
• The appliance must not be on the base unit when being filled
with water.
• Unplug from the outlet when not in use.
• WARNING: The appliance must not be immersed for cleaning.
• WARNING: To prevent damage to the appliance, do not use
alkaline cleaning agents when cleaning. Use a soft cloth and
detergent.
Electrical requirements
• Check that the voltage on the rating plate of your appliance
corresponds with your house electricity supply which must be
A.C. (Alternating Current).
• WARNING: This appliance must be earthed.
• WARNING: This appliance is NOT to be used with extension
leads and/or power boards.
6
IMPORTANT: This kettle is fitted with a concealed element, it must
be descaled regularly. The frequency of descaling depends on
usage and the hardness of the water in your area.
Excessive scale can cause the kettle to switch off before boiling
and may damage the element voiding the warranty.
Half fill the kettle with tap water and add the juice of 1 lemon to the
water. Boil this mixture and allow it to stand for 15 minutes. Re-boil
the mixture and allow it to stand a further 15 minutes. Re-boil this
mixture a third time and rinse the kettle well.
DESCALING
1. Allow the kettle to cool completely before removing the filter.
2. Open the lid using the lid handle.
3. Pull the limescale filter upwards from its holder.
4. To re-fit the filter, slide it into the side wall guides of the filter holder
until it clicks into place.
WARNING: Unless the filter is fitted correctly, the kettle lid may not
close and lock securely.
FILTER REMOVAL
5. Plug the cord into a power socket and switch on at the wall.
6. Switch the kettle on by pushing down the Dolly switch. The ‘power
on’ light will illuminate.
7. Rapid boil kettles perform differently, they may sound louder during
boiling, and switch off suddenly with no after noise, this is normal.
8. When boiled, the kettle will switch off automatically.
WARNING: When boiled, allow a few seconds before pouring. Both
the kettle and water will be hot.
9. Lift the kettle from the power base by the handle ensuring you hold
the kettle level. To re-boil, switch ON again. If the kettle has just
switched off wait a minute or two before switching it back on again.
If you do not put in enough water, or switch on the kettle when it is
empty, the safety cut-out will switch off the power automatically. If
this happens, refill and wait a few minutes for the element to cool,
then use as normal.
7
WARNING: Always disconnect the plug from the mains and allow
the kettle to cool completely before cleaning.
CAUTION: To prevent damage to the appliance do not use alkaline
cleaning agents when cleaning, use a soft cloth and a mild
detergent.
Wipe the outside with a damp cloth.
IMPORTANT: Do not use abrasive cleaners on the outside of the
kettle which may scratch the surface.
CLEANING
WARRANTY
Please refer to the warranty card in the box for warranty information.
For any troubleshooting advice, please contact the relative Customer
Care Centre below.
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
8 Lakeview Drive, 38 Harris Road, East Tamaki,
Scoresby 3179, Victoria Auckland 2013
Australia New Zealand
Ph: 1300 556 816 Ph: 0800 666 2824
Alternatively use citric acid crystals (available from most
pharmacies) as follows.
1. Fill the kettle 3/4 full, boil, then unplug the kettle (remove the
kettle from the base unit) and stand it in an empty sink or bowl.
2. Add 50gm of citric acid crystals to the water gradually, then
leave the kettle to stand. Do not use a more concentrated
solution.
3. As soon as the effervescence subsides, empty the kettle and
rinse it thoroughly with cold water.
4. Wipe the outside of the kettle thoroughly with a damp cloth to
remove all traces of acid which may damage the finish.
IMPORTANT: Ensure that the electrical connections are completely
dry before using the kettle.
Glen Dimplex Australia Pty Ltd
8 Lakeview Drive
Scoresby VIC 3179
Phone: 1300 556 816
Email: [email protected]
Web: www.morphyrichards.com.au
Recycling: Do not dispose of electrical appliances
as unsorted municipal waste. Use separate
collection facilities. Contact your local government
for information regarding the collection systems
available. If electrical appliances are disposed
of in landfills or dumps, hazardous substances
can leak into the ground water, polluting the food
chain and damaging health and wellbeing.
© Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in
whole or in part, without prior permission in writing of Glen Dimplex Australia.
MRVK15SG_IM_v1
