Morphy Richards Orbit Manual de usuario

∂

Orbit travel iron

Please read and save these instructions

C stovní Ž hlička Orbit

Přečtěte si tyto pokyny a uschovejte je

41540MCZOrbit-Rev1:9222 41540 Orbit MEE.q 4 19/9/08 10:25 Page 1

WARNING: Danger to the person!

IMPORTANT: Damage to the appliance!

In addition we offer the following safety

advice.

Location

• Do not use outdoors.

Important safety instructions

The use of any electrical appliance

requires the following common sense

safety rules.

Primarily there is danger of injury or death

and secondly the danger of damage to

the appliance. These are indicated in the

text by the following two conventions:

‹

ﬂ

‡

›

‚ „

⁄

41540MCZOrbit-Rev1:9222 41540 Orbit MEE.q 4 19/9/08 10:25 Page 2

•Do not allow the cord to touch hot

surfaces. Let the iron cool completely

before putting away. Loop cord loosely

around the iron before storing.

Ot er safety considerations

• IMPORTANT : When not in use, your iron

should never be placed flat and left on an

ironing board.

• Do not operate the iron with a damaged

cord or if the iron has been dropped or if

there are visible signs of damage or if it is

leaking. To avoid the risk of electric

shock, do not disassemble the iron, but

telephone for advice. Incorrect

reassembly can cause a risk of electric

shock when the iron is used.

• Always disconnect the iron from the

electrical socket when filling with water,

emptying, cleaning and when not in use.

• To prevent damage to the textile being

ironed, follow the temperature guide

carefully and test the inside of the hem of

the garment.

• When ironing is complete, remove the

plug from the socket, empty any

remaining water from the tank, and allow

to cool before storage.

• If you drop or severely knock your iron

this could cause internal damage even if

the outside appears alright. Have it

checked by a qualified electrician.

• Ensure the product is set to the correct

voltage.

• This product is not for frequent use.

•The iron must be used and rested on a

stable surface.

•When placing the iron on its heel, ensure

that the surface on which the heel is

placed is stable.

C ildren

• Children do not understand the dangers

associated with operating electrical

appliances. Never allow children to use

this appliance.

• Close supervision is necessary when any

appliance is used near children.

• Children should be supervised to ensure

that they do not play with the appliance

Personal safety

•WARNING: Burns can occur from

touching hot metal parts, hot water

or steam. Use caution when you turn

a steam iron upside down, there may

be hot water in the water tan .

•WARNING: To protect against the ris

of electric shoc do not put the

appliance in water or in any other

liquid.

• Do not use the vertical steam feature on

clothes that are being worn.

• Do not leave the iron unattended whilst

plugged in or on an ironing board. Never

allow the mains lead to over hang the

work surface.

• Never yank the cord to disconnect from

the socket, instead, grasp plug and pull to

disconnect.

41540MCZOrbit-Rev1:9222 41540 Orbit MEE.q 4 19/9/08 10:25 Page 3

Components

⁄Dial pointer

¤Temperature control dial

‹Temperature indicator light

›Water inlet cover

Water tank

ﬂSteam control

‡Surge button

·Sole plate

‚Voltage selection switch

„Filler cup

Voltage selection

Set the voltage selection switch ‚to the

correct voltage.

Filling wit water

1With the iron disconnected from the

mains supply, set the steam control ﬂto

off C.

2Pull the water inlet ›cover out and using

the beaker provided fill the iron with

water B.

• Three cups of water will fill the tank

(75ml).

3Replace the water inlet cover.

4Always pour out the remaining water after

use.

In hard water areas the use of distilled or

demineralised water is recommended.

WARNING: When filling your iron with

tap water always use the bea er

provided. Never fill directly under the

tap.

•Use the iron only for its intended use.

• If the supply cord is damaged, it must be

replaced by the manufacturer, its service

agent or similarly qualified persons in

order to avoid a hazard.

• This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities,

or lack of experience and knowledge,

unless they have been given supervision

or instruction concerning use of the

appliance by a person responsible for

their safety.

Electrical requirements

Check that the voltage on the rating plate

of your appliance corresponds with your

house electricity supply which must be

A.C. (alternating current).

WARNING: This appliance must be

earthed.

UK only

If the socket outlets in your home are not

suitable for the plug supplied with this

appliance the plug should be removed

and the appropriate one fitted.

WARNING : The plug removed from

the mains lead, if severed, must be

destroyed as a plug with a bared

flexible cord is hazardous if engaged

into a live soc et outlet.

Where used, should the fuse in the

13amp plug require changing, a 13 amp

BS1362 fuse must be fitted.

41540MCZOrbit-Rev1:9222 41540 Orbit MEE.q 4 19/9/08 10:25 Page 4

3After a few minutes the iron will stabilise

at the required temperature and the

indicator light will go out. It will cycle on-

off during operation to show that the iron

is maintaining the selected temperature.

It is always a good idea to begin with cool

fabrics and work up to higher settings. An

iron heats up quicker than it cools down

so you’ll save time and electricity.

If you do adjust the temperature from a

hot setting to a cooler setting, wait until

the iron temperature has stabilised before

you continue ironing.

IMPORTANT: Never use battery topping

up fluid or water containing any

substances like starch, or sugar, or

defrosted water from a refridgerator.

Temperature control

1Plug in the iron.

2Set the temperature control dial ¤to the

temperature required, but don’t start

ironing immediately. The temperature

indicator light ‹shows that the iron is

warming up.

Heat setting markings on the iron match those of the International Textile Care

Labelling Code.

Textiles and clothes should carry ironing instructions, but if they don’t, follow this fabric

guide. Be sure to test the temperature by ironing the hem of the garment or similar area

first.

Symbol

Cool (120˚C max) Warm (160˚C max) Hot (210˚C max)

Control knob

positions

Do not

iron at all

Fabric Nylon, Acetates

e.g. Acrilan

Courtelle, Orlon

Triacetates, e.g.

Tricel/Polyester

Wool, Polyester

mixtures e.g.

Polyester/Cotton

Cotton, Linen

Rayon, Rayon

mixtures, e.g.

Rayon/Linen

Ironing Iron on wrong

side

If moisture

required use

damp cloth (not

Acetate)

Fabrics requiring

this setting

usually require

steam pressing

for heavy cotton,

denim etc.

With water in tank Dry Steam/

shot-of-steam

Without water in tank Dry ironing

Temperature/fabric guide

41540MCZOrbit-Rev1:9222 41540 Orbit MEE.q 4 19/9/08 10:25 Page 5

Vertical steam

Hold the iron in a vertical position

between 1cm and 2cm away from the

item. Push the surge button.

• This feature is especially useful for

removing creases from hanging clothes,

curtains, wall hangings, etc.

Emptying and storing

When you have finished ironing, unplug

the iron and allow to cool. Ensure that the

steam control is set to the 'off' position.

Remove the water inlet cover and empty

any remaining water out of the filling hole.

Replace the water inlet cover.

Ensure the iron is cool and thoroughly dry

before storing in the bag provided.

IMPORTANT: The flex can be damaged if

wound too tightly around the iron after

use. Make a loose loop with the flex and

wrap it around the iron. The iron must be

cool before winding the flex and storing

on its heel.

Jet cleaning

Your iron has a built-in cleaning system

designed to keep the water valve, steam

chamber and steam vents clear of lint and

loose mineral deposits. Jet clean should

be used after each period of ironing.

1Ensuring that there is a little water in the

tank, place the iron on its heel and turn

the temperature control dial to the 3-dot

setting.

Dry ironing

You do not need to fill the iron with water.

Set the steam control to off.

• Any temperature setting may be used

depending on the garment.

Steam ironing

Turn the temperature control dial to the

steam position and rest the iron on its

heel whilst it warms up.

Turn the steam control to the steam

position C.

• The steam facility should only be used on

garments which are suitable for ironing at

the 3 dot settings.

Surge-of-steam

Push in the surge button ‡to obtain a

boost of extra steam for ironing out

creases in heavy material such as denim

etc D.

• The surge-of-steam can be used whilst

dry ironing, providing there is water in the

tank, and the temperature control is set

within the steam range.

• Do not use surge-of-steam at

temperatures below the steam range

shown on the control dial.

• For optimum steam quality, do not

operate the shot more than three times in

succession.

41540MCZOrbit-Rev1:9222 41540 Orbit MEE.q 4 19/9/08 10:25 Page 6

Helpline

If you have any difficulty with your

appliance, do not hesitate to call us.

We are more likely to be able to help than

the store from where you bought it.

Please have the following information

ready to enable our staff to deal with your

query quickly.

• Name of the product

• Model number as shown on the underside

of the appliance.

YOUR TWO-YEAR

GUARANTEE

This appliance is covered by two-year

repair or replacement warranty.

It is important to retain the retailers

receipt as proof of purchase. Staple your

receipt to this back cover for future

reference.

Please quote the following information if

the product develops a fault. These

numbers can be found on the base of the

product.

Model no. Serial no.

All Morphy Richards products are

individually tested before leaving the

factory. In the unlikely event of any

appliance proving to be faulty within 28

days of purchase it should be returned to

the place of purchase for it to be

replaced.

2Wait for the temperature indicator light to

go out, then unplug the iron and hold it

about 6" (150mm) above the sink in the

ironing position.

3Press the surge button about 10 times in

succession.

4Empty out any remaining water.

IMPORTANT : Do not use descaling

products in this iron.

To clean a coated soleplate

In the unlikely event of any man-made

fibres fusing to the soleplate, set the iron

at the 3-dot position and pass it over a

clean piece of cotton which will draw the

deposit off the surface.

Do not use scouring powder or solution

as this could cause damage to the

coating.

To clean t e exterior

Allow the iron to cool and wipe with a

damp cloth, then dry.

If your iron doesn't work

If the iron does not work, check the

following:

• Has the temperature control been set to

the required temperature?

• Is the plug in its socket?

• Is the plug itself or the socket faulty?

Check by plugging in another appliance.

41540MCZOrbit-Rev1:9222 41540 Orbit MEE.q 4 19/9/08 10:25 Page 7

2The appliance has been used on a

voltage supply other than that stamped

on the products.

3 Repairs have been attempted by persons

other than our service staff (or authorised

dealer).

4 Where the appliance has been used for

hire purposes or non domestic use.

5 Morphy Richards are not liable to carry

out any type of servicing work, under the

guarantee.

6 The guarantee excludes consumables

such as bags, filters and glass carafes.

This guarantee does not confer any rights

other than those expressly set out above

and does not cover any claims for

consequential loss or damage. This

guarantee is offered as an additional

benefit and does not affect your statutory

rights as a consumer.

AUSTRALIAN WARRANTY

This appliance is guaranteed for 2 years

against faulty material, components and

workmanship.

This warranty is in addition and does not

affect your statutory rights.

Proof of purchase must be produced for

any warranty benefit.

In the unlikely event of any appliance

proving to be faulty, securely pack and

return the item to the place of purchase

accompanied by the original receipt or

invoice.

If the fault develops after 28 days and

within 24 months of original purchase,

you should contact Morphy Richards

quoting Model number and Serial number

on the product, or write to Morphy

Richards at the address shown.

You will be asked to return the product (in

secure, adequate packaging) to the

address below along with a copy of proof

of purchase.

Subject to the exclusions set out below

(1-6) the faulty appliance will then be

repaired or replaced and dispatched

usually within 7 working days of receipt.

If for any reason this item is replaced

during the 2-year guarantee period, the

guarantee on the new item will be

calculated from original purchase date.

Therefore it is vital to retain your original

till receipt or invoice to indicate the date

of initial purchase.

To qualify for the 2-year guarantee the

appliance must have been used

according to the manufacturers

instructions. For example, appliances

must have been descaled and filters must

have been kept clean as instructed.

Morphy Richards shall not be liable to

replace or repair the goods under the

terms of the guarantee where:

1 The fault has been caused or is

attributable to accidental use, misuse,

negligent use or used contrary to the

manufacturers recommendations or where

the fault has been caused by power

surges or damage caused in transit.

41540MCZOrbit-Rev1:9222 41540 Orbit MEE.q 4 19/9/08 10:25 Page 8

DŮLEŽITÉ BEZPEČNOSTNÍ

POKYNY

Použití jakéhokoliv elektrického spotřebiče

vyžaduje dodržování následujících

bezpečnostních opatření.

V první řadě zde existuje nebezpečí úrazu

nebo smrtelného úrazu elektrickým

proudem a za druhé je zde nebezpečí

poškození samotného spotřebiče. Tato

nebezpečí jsou vyznačena textem podle

následujících konvencí:

VAROVÁNÍ: N b zp čí úrazu osob!

DŮLEŽITÉ: Hrozí nebezpečí poškození

spotřebiče!

Kromě těchto upozornění poskytujeme

následující bezpečnostní doporučení.

Umístění

•Nepoužívejte venku.

Děti

•Děti nechápou nebezpečí související s

provozováním elektrických spotřebičů.

Nenechávejte je používat tento spotřebičů.

• Při používání jakéhokoliv spotřebiče v

blízkosti dětí je nutný přísný dozor.

Bezpečnost osob

•VAROVÁNÍ: Při kontaktu s horkými

kovovými částmi, horkou vodou n bo

párou mohou vzniknout popál niny. Při

obrac ní ž hličky vzhůru nohama buìt

opatrní, v nádrži na vodu můž být horká

voda.

∂

NOT COVERED BY THIS

WARRANTY (Australian only)

•If the appliance has not been used in

accordance with the manufacturers’

recommendations or Instructions.

• If the fault is deemed to be caused by

abuse, misuse, neglect, modifications or in

proper use and or care

Eg: ettles: Excessive build up of scale.

Toasters: Excessive build up of crumbs or

foreign matter etc.

• Connection to incorrect voltage to that

stamped on the product

• Unauthorised repairs

• Appliance used other than for domestic

purposes.

• Excluding bags, filters, glass, carafes, and

cutting blades.

• Freight and insurance costs.

If for any reason this item is replaced during

the 2 year guarantee period, the guarantee

on the new item will be calculated from

original purchase date. Therefore it is vital to

retain your original receipt or invoice to

indicate the date of original purchase.

Morphy Richards’s policy is to continually

improve quality design and product quality.

The company therefore reserves the right to

change any specifications or to carry out

modifications as deemed worthy at any time.

The Australian supplier AS O Appliances

reserves the right to repair, modify, exchange

or replace the faulty appliance with the same

or similar model or product of equivalent

value.

∂

41540MCZOrbit-Rev1:9222 41540 Orbit MEE.q 4 19/9/08 10:25 Page 9

správné napětí.

• Produkt není určen pro časté používání.

• Používejte žehličku pouze k účelu, ke

kterému je určena.

Požadavky na napájení

Zkontrolujte, zda napětí na výkonovém štítku

spotřebiče odpovídá síťovému napětí v

domácnosti, které musí být střídavé.

Pokud zásuvky v domácnosti nevyhovují

zástrčce dodané s tímto spotřebičem, zástrčka

se musí odstranit a nahradit vhodným typem.

VAROVÁNÍ: Dojd -li k poškoz ní zástrčky

odstraněné z síťového kab lu, musí s

zničit, protož zástrčka s odkrytým kab l m

j po zapoj ní do zásuvky pod proud m

n b zp čná.

VAROVÁNÍ:T nto spotř bič musí být

uz mněný.

So části

⁄točný ukazatel

¤točný regulátor teploty

‹Indikační kontrolka teploty

›Kryt vstupního hrdla vody

Nádrž na vodu

ﬂvladač páry

‡Tlačítko impulsu páry

·Žehlicí plocha

‚Spínač volby napětí

„Plnicí miska

Volba napětí

Nastavte spínač volny napětí ‚na správnou

hodnotu napětí.

•VAROVÁNÍ:Nvklád jt spotř bič do

vody ani jiné kapaliny, abyst s chránili

př d rizik m úrazu l ktrickým proud m.

•Nepoužívejte svislé napařování na oděvech

oblečených na osobách.

• Nenechávejte žehličku bez dozoru, jestliže je

připojená k síti nebo na žehlicím prknu.

Nikdy nenechávejte síťový kabel viset přes

okraj pracovního povrchu.

• Při odpojování ze zásuvky nikdy netahejte

za kabel, místo toho uchopte zástrčku a

vytáhněte ji.

• Zabraňte kontaktu kabelu s horkými

povrchy. Před odložením nechte žehličku

úplně vychladnout. Před uložením oviňte

kabel volně kolem žehličky.

Další bezpečnostní pokyny

•DŮLEŽITÉ: Když se žehlička nepoužívá,

nikdy by neměla ležet naplocho na žehlicím

prkně.

• Nepoužívejte žehličku s poškozeným

kabelem, nebo pokud byla upuštěna nebo

je poškozená. Abyste se vyhnuli riziku úrazu

elektrickým proudem, nedemontujte

žehličku, ale požádejte výrobce telefonicky

o radu. Nesprávná montáž může způsobit

riziko úrazu elektrickým proudem při

používání žehličky.

• Při plnění vodou, vyprazdňování, čištění

nebo když žehličku nepoužíváte, vždy ji

odpojte od elektrické zásuvky.

• Abyste zabránili poškození žehleného textilu,

pečlivě dodržujte pokyny pro volbu teploty a

vyzkoušejte ji na vnitřním lemu oděvu.

• Až skončíte se žehlením, vytáhněte zástrčku

ze zásuvky, vyprázdněte zbývající vodu z

nádrže a před uložením nechte spotřebič

vychladnout.

• Při upuštění nebo silném nárazu by mohlo

dojít k vnitřnímu poškození, i když zvenku

vypadá spotřebič v pořádku. Nechte ho

zkontrolovat kvalifikovaným elektrikářem.

• Zkontrolujte, zda je produkt nastaven na

41540MCZOrbit-Rev1:9222 41540 Orbit MEE.q 4 19/9/08 10:25 Page 10

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Hierro de Morphy Richards

Morphy Richards

Morphy Richards 40725 Manual de usuario

Morphy Richards

Morphy Richards ORBIT TRAVEL 41540 Manual de usuario

Morphy Richards

Morphy Richards ADVANCED FINISH SEMI ELECTRONIC IRON Manual de usuario

Morphy Richards

Morphy Richards Speed Steam Pro Manual de usuario

Morphy Richards

Morphy Richards COMFIGRIP Manual de usuario

Morphy Richards

Morphy Richards IB421XX Manual de usuario

Morphy Richards

Morphy Richards Turbosteam iron Manual de usuario

Morphy Richards

Morphy Richards RN40868 Manual de usuario

Morphy Richards

Morphy Richards Power SteamPro Manual de usuario

Morphy Richards

Morphy Richards NO MODEL NO NUMBER Manual de usuario

Morphy Richards

Morphy Richards IB40310 Manual de usuario

Morphy Richards

Morphy Richards TURBO GLIDE Manual de usuario

Morphy Richards

Morphy Richards Comfigrip Advanced 40741 Manual de usuario

Morphy Richards

Morphy Richards 303100 Manual de usuario

Morphy Richards

Morphy Richards Steam Generator ironing system Manual de usuario

Morphy Richards

Morphy Richards TURBOSTEAM RN40630 MUK REV2 Manual de usuario

Morphy Richards

Morphy Richards Turbosteam Manual de usuario

Morphy Richards

Morphy Richards breeze Manual de usuario

Morphy Richards

Morphy Richards COMFIGRIP RN40854 Manual de usuario

Morphy Richards

Morphy Richards 300002 Manual de usuario

Morphy Richards

Morphy Richards ELITE 42288 Manual de usuario

Morphy Richards

Morphy Richards ORBIT TRAVEL 41540 Manual de usuario

Morphy Richards

Morphy Richards IB40550 Manual de usuario

Morphy Richards

Morphy Richards RN303100MUK Manual de usuario

Manuales populares de Hierro de otras marcas

Clatronic

Clatronic DB 3703 Manual de usuario

TEFAL

TEFAL FV4093Z0 Manual de usuario

Gorenje

Gorenje SIH 2200 BS Manual de usuario

Philips

Philips GC6012 Manual de usuario

Bosch

Bosch 2 Series Manual de usuario

Riffel

Riffel Catena KB-819 Manual de usuario

Texi

Texi Hestia Manual de usuario

Maxwell

Maxwell MW-3010 Manual de usuario

TREVIDEA

TREVIDEA Girmi ST60 Manual de usuario

Philips

Philips HI5914/30 Manual de usuario

Primula

Primula Vapormat Manual de usuario

Magio

Magio MG-541 Manual de usuario

Scarlett

Scarlett SC-1334S Manual de usuario

Bosch

Bosch Sensixx B22L Manual de usuario

Philips

Philips GC651 Manual de usuario

Vitek

Vitek VT-1247 VT Manual de usuario

Cleanmaxx

Cleanmaxx 3397 Manual de usuario

Philips

Philips GC800 Manual de usuario
