Model: MRICE12SS
INSTRUCTION MANUAL
Read these instructions carefully before
using this appliance for the rst time.
STORE THESE INSTRUCTIONS CAREFULLY
Compact Ice Maker
For product hints and tips plus more join us at
facebook.com/MorphyRichardsAUS instagram.com/morphyrichardsau
www.morphyrichards.com.au
2
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
To reduce the risk of fire, electric shock, injury to persons or
damage to property, follow basic precautions including the
following:
• WARNING: Misuse of appliance could cause personal injury.
• Check your ice maker to ensure it is in good condition and that
there is no damage to the ice maker, power cord and plug.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• This appliance is intended to be used in household and similar
applications such as
–staff kitchen areas in shops, offices and other working
environments;
–farm houses and by clients in hotels, motels and other residential
type environments;
–bed and breakfast type environments;
IMPORTANT SAFETY INSTRUCTIONS
3
• WARNING: Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
• WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
• WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• WARNING: Do not damage the refrigerant circuit.
• WARNING: Do not pour coloured drinks or congee drinks into
the machine (including the water tank and ice tray).
• WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
• WARNING: Do not locate multiple portable socket-outlets or
portable power supplies at the rear of the appliance.
• WARNING: When disposing of the appliance, do so only at an
authorized waste disposal centre. Do not expose to flame.
• WARNING: This appliance contains a small quantity of R600a
refrigerant which is flammable.
• WARNING: It is hazardous for anyone other than an Authorised
Service Person to service this appliance. In Queensland
- the authorised Service Person MUST hold a Gas Work
Authorisation for hydrocarbon refrigerants to carry out
servicing or repairs where the gas system is being opened or
charged.
WARNING: The refrigerant isobutene (R600a)
is contained within the refrigerant circuit of the
appliance, a natural gas with a high level of
environmental compatibility, which is nevertheless
flammable. During transportation and installation of
the appliance, ensure that none of the components
of the refrigerant circuit becomes damaged.
4
If the refrigerant circuit should be damaged:
• Avoid opening flames and sources of ignition.
• Thoroughly ventilate the room in which the appliance is
situated.
Location
• Before using the Ice Maker for the first time, please wait 2 hours
after positioning it, and keep the transparent lid open for at
least 2 hours.
• For indoor use only. Do not use outdoors or near water.
• Always locate your appliance away from the edge of the
worktop.
• Do not upend this product or incline it over a 45° angle. Ensure
that the appliance is used on a firm, flat surface.
• Keep the appliance 15cm from other objects to ensure the heat
generated is heat released.
• Do not use the appliance close to flames, hot plates or stoves.
Power cord
• WARNING: This appliance should NOT be used with extension
leads and/or power boards.
• WARNING: When positioning the appliance, ensure the supply
cord is not trapped or damaged.
• The power cord should reach from the socket to the appliance
without straining the connections.
• If the power cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
5
• Remove the plug from the socket, grasp the plug and pull out
the power cord, do not pull on the cord directly.
• Do not let the cord hang over the edge of a table or counter and
keep it away from any hot surfaces.
• Do not let the cord run across an open space e.g. between a
low socket and table.
Personal safety
• WARNING: To protect against fire, electric shock and personal
injury do not immerse cord, plug and appliance in water or any
other liquid.
• WARNING: The appliance surface is subject to residual heat
after use.
• WARNING: Fill with potable water only.
• The temperature of accessible surfaces may be high when the
appliance is operating.
• Unplug from the outlet before cleaning and allow to cool before
putting on or taking off parts and before cleaning.
• Do not move the appliance while switched on.
• Do not use accessories which are not recommended by the
manufacturer.
• Do not touch the evaporator when using the ice maker as the
user may suffer from frostbite.
Electrical requirements
• WARNING: This appliance should NOT be used with extension
leads and/or power boards.
• Check that the voltage on the rating label of your appliance
corresponds with your house electricity supply which must be
A.C.
6
Model: MRICE12SS
Colour: Stainless Steel / Black
Rated Power: 150W
Rated Voltage & Frequency: 220-240V~ 50Hz
Water Tank Capacity: 1.8L
Ice Bin Capacity: 0.8 kg
Refrigerant/Refrigerant Amount: R600a/24g
Foaming Agent: EPS
Dimensions (W x D x H): 228 x 336 x 292mm
Net Weight: 7.7kg
SPECIFICATIONS
PRODUCT OVERVIEW
Rear Housing
Ice Scoop
Evaporator
Ice Shovel
Ice Basket
Transparent Lid
Control Panel
Filter
Water Tank
Ice Tray
Top Cover
Front Housing
Drainage Plug
Maximum
Water Level
Infrared light
emitting diode
Infrared light
receiving diode
7
CONTROL PANEL
C01005白色
PANTONE BLACK C
透光区
12
C
D
B
A
1:1
3
C
D
B
4
A
123
2.4mm
1.6mm
2.4mm
2.4mm
1.6
mm
2mm
1mm
2mm
3mm
8mm
7.50 m m
5.2mm
5mm
5mm
PS认证 ITS认证 莱茵认证
ID按证书而更新
安排日期： 面膜
成品尺寸： 1、印刷色： 2、材质 ：PET T=0.2
5、打样要求： ( ）不打样， （ ）打实样：
制作人： 跟进业务：
99.5
24.5
8.0
66.0
4.0
1.5
20.0 20.0
ON/OFF Button - Starts or Stops the appliance.
POWER Indicator - In standby mode the POWER indicator will
blink. During operation the POWER indicator will be solid.
ICE FULL Indicator - When the ice reaches the maximum amount
of ice in the ice tray, the ICE FULL indicator will illuminate.
ADD WATER Indicator - When the ADD WATER indicator illumi-
nates, there is a water shortage in the water tank. You need to
add water and press the ON/OFF button to restart the machine.
SMALL Ice Selection Indicator - When selecting small ice, the
SMALL indicator will illuminate.
LARGE Ice Selection Indicator - When large ice is selected, the
LARGE indicator will illuminate. Large ice is the default setting.
CLEAN Indicator - To run the CLEAN program, press the SELECT
button to select the CLEAN during the standby mode.
SELECT Button - Whilst in the standby mode, press the
SELECT button to select SMALL ice, LARGE ice or CLEAN. After
selecting the desired function, press ON/OFF button to activate.
8
BEFORE FIRST USE
1. Remove all packaging materials and read all instructions.
2. Check that all accessories are complete and the appliance is
not damaged.
3. Clean all parts to remove any dust or manufacturing residue.
4. Clean the water storage tank and ice collecting tray with clean
water.
5. The incline angle of the ice maker should not exceed 45°
during transportation or use. Do not turn the ice maker upside
down. Doing so could cause the compressor or refrigerating
system to operate incorrectly. Please allow time for the liquid
in the compressor to settle after the ice maker is moved or
transported. Before using the ice maker for the first time, please
wait for 2 hours after the unit has been positioned on a level
surface.
6. The appliance must be placed on a dry and level surface with
sufficient ventilation, far from heat sources such as ovens,
heaters and corrosive gases. Leave around 15cm clearance on
all sides of the ice maker for proper ventilation.
7. Do not fill the water reservoir with hot water. This may damage
the ice maker. It is best to fill the water tank with water that is
room temperature or lower. The water quality added to the tank
should be drinkable.
8. Do not use the appliance at a very cold environment (lower than
5°C).
9. Run the Clean Function, as described on page 7.
9
USING YOUR ICE MAKER
1. Ensure the drainage plug at the bottom of the water tank is
closed securely.
2. Plug the ice maker into a wall outlet, the POWER indicator will
blink.
NOTE: The appliance should be rested for 30 minutes before
plugging into a wall outlet, if it has been moved.
3. Open the transparent lid, remove the ice basket and fill the
water tank with drinkable water.
NOTE: Do not fill above the MAX water level mark.
4. Replace the ice basket and close the transparent lid.
5. If you want to clean the appliance, press the SELECT button
and select CLEAN during the standby mode, then press the
ON/OFF button to start cleaning.
6. The ice making cycle will last approximately 7-15 minutes,
depending on the ambient temperature and water temperature.
7. The ice making cycle begins with water being pumped into
the ice tray situated below the evaporator. Over the next 7-15
minutes ice forms on the evaporator. Once this has completed,
the ice tray will tilt backwards and the remaining water in the
ice tray is drained back into the water tank. Ice cubes are then
dropped from the evaporator and pushed forward into the ice
basket by the ice shovel. The ice tray will automatically move
back into position under the evaporator and start the next
cycle.
8. The ICE FULL indicator will illuminate when the ice basket is
full and the ice maker will stop making ice automatically. Gently
remove the ice from the ice basket with the ice scoop. About 5
seconds later, the ice maker will restart its ice making function
automatically.
10
USING YOUR ICE MAKER
9. The ADD WATER indicator will light up when the water tank is
out of water and the ice making cycle will stop automatically.
Remove the ice basket and add water to the water tank, and
then press the ON/OFF button again to restart the ice making
cycle. The appliance will start working automatically after 20
minutes if the user forgets to restart the appliance after refill.
10. When you have the desired amount of ice, stop the ice making
cycle by pressing the ON/OFF button and unplug the unit from
the wall outlet.
11. Open the transparent lid and transfer the ice to a freezer.
12. Allow the ice maker to reach room temperature.
CARE & CLEANING
• Clean the water tank if the appliance has water in the tank and
has not been used for 48 hours.
• If the appliance is left empty for long periods, switch off,
defrost, clean, dry, and leave the lid open to prevent mould
developing within the appliance.
• Tilt the appliance around 30° and move it forward to the
place where the drainage plug is about 60mm away from the
countertop. Open the drainage plug and drain the excess water
(see below).
Drainage Plug
Tabla de contenidos
Otros manuales de Máquina de hielo de Morphy Richards
