YOUR TWO YEAR

GUARANTEE

It is important to retain the

retailers receipt as proof of

purchase. Staple your

receipt to this back cover

for future reference.

Please quote the following

information if the product

develops a fault. These

numbers can be found on

the base of the product.

Model no.

Serial no.

All Morphy Richards

products are individually

tested before leaving the

factory. In the unlikely event

of any appliance proving to

be faulty within 28 days of

purchase it should be

returned to the place of

purchase for it to be

replaced.

If the fault develops after

28 days and within 24

months of original

purchase, you should

contact the Helpline

number quoting Model

number and Serial number

on the product, or write to

Morphy Richards at the

address shown.

You will be asked to return

the product (in secure,

adequate packaging) to the

address below along with a

copy of proof of purchase.

Subject to the exclusions

set out below (see

Exclusions) the faulty

appliance will then be

repaired or replaced and

dispatched usually within 7

working days of receipt.

If for any reason this item is

replaced during the 2 year

guarantee period, the

guarantee on the new item

will be calculated from

original purchase date.

Therefore it is vital to retain

your original till receipt or

invoice to indicate the date

of initial purchase.

To qualify for the 2 year

guarantee the appliance

must have been used

according to the

manufacturers instructions.

For example fryers should

have been regularly

cleaned.

EXCLUSIONS

Morphy Richards shall not

be liable to replace or

repair the goods under the

terms of the guarantee

where:

1The fault has been caused

or is attributable to

accidental use, misuse,

negligent use or used

contrary to the

manufacturers

recommendations or where

the fault has been caused

by power surges or

damage caused in transit.

2The appliance has been

used on a voltage supply

other than that stamped on

the products.

3Repairs have been

attempted by persons

other than our service staff

(or authorised dealer).

4Where the appliance has

been used for hire

purposes or non domestic

use.

5Morphy Richards are not

liable to carry out any type

of servicing work, under

the guarantee.

6Plastic filters for all Morphy

Richards kettles and coffee

makers are not covered by

the guarantee.

• This guarantee does not

confer any rights other than

those expressly set out

above and does not cover

any claims for

consequential loss or

damage. This guarantee is

offered as an additional

benefit and does not affect

your statutory rights as a

consumer.

• This guarantee is valid in

the UK and Ireland only.

Morphy Richards products are intended for household use only.

Morphy Richards has a policy of continuous improvement in product quality and

design. The company, therefore reserves the right to change the specification of its

models at any time.

The After Sales Division

Morphy Richards Ltd

Mexborough, SouthYorkshire,

England, S64 8AJ

Helpline (office hours)

UK 0870 060 2604

Republic of Ireland 1800 409119

45076 MUK Rev1 02/07

FFoorrddeettaaiillssooffootthheerrpprroodduuccttssiinntthheeMMoorrpphhyyRRiicchhaarrddssrraannggeepplleeaasseesseeeeoouurrwweebbssiittee......

For electrical products sold within the

European Community. At the end of the

electrical products useful life it should

not be disposed of with household

waste.

Please recycle where facilities exist.

Check with your Local Authority or

retailer for recycling advice in your

country.

45076 rev1 22/3/07 08:52 Page 1

Harry Ramsden’s Large Family Fryer

Please read and keep these instructions

Getting the best from your new fryer...

Safety first: Hot oil

Don’t attempt to move the fryer while it is still hot

- wait 3 hours after frying for your fryer to cool.

Easy cleaning

Your fryer breaks down into component parts for

easy cleaning with a removable oil tank, lid and control panel.

Ladle

For the best results with battered items,

take out the basket and use the ladle to turn items.

45076 MUK Rev 1

For replacement parts, help with using your Morphy Richards product,

problems and lots more, contact us by phone or through our website.

UUKKHHeellpplliinnee::0088770000660022661133

RReeppllaacceemmeennttppaarrttss::0088770011667766664444

IIrreellaanndd11880000440099111199

Takes apart

for easy

cleaning

Easy

clean

system

45076 rev1 22/3/07 08:52 Page 2

Helpline 0870 060 2614 Replacement Parts 0870 157 6645 Ireland Helpline 1800 409119

IMPORTANT

SAFETY

INSTRUCTIONS

The use of any electrical

appliance requires the following

common sense safety rules.

Primarily there is danger of

injury or death and secondly the

danger of damage to the

appliance. These are indicated in

the text by the following two

conventions:

WARNING: Danger to the

person!

IMPORTANT: Damage to the

appliance! In addition we offer

the following safety advice.

Personal safety

•WARNING: Never attempt to

move your fryer until it is

completely cool. This can

take up to three hours. Use

the carrying handles. Î

•WARNING: To protect

against the risk of electric

shock do not immerse the

fryer body in water or other

liquid.

• Unplug from the electrical outlet

when not in use and before

cleaning. Allow to cool before

putting or taking off parts, and

before cleaning the appliance.

• Never leave the fryer unattended

when connected to the

electricity supply.

• Never lean over the fryer when it

is in use.

• When opening the lid, stand

back as some hot steam may be

released.

• Always use oven gloves when

removing or replacing lid during

use.

• Be careful not to touch those

surfaces of the fryer which

become hot when in use.

• This appliance is not attended

for use of persons (including

children) with reduced physical,

sensory or mental capabilities,

or lack of experience and

knowledge, unless they have

been given supervision or

instruction concerning use of

the application by a person

responsible for their safety.

Product safety

WARNING: The control pod

must never be immersed in

water.

WARNING: When unpacking

the fryer, make sure all

packing material is

removed.

• Never connect the fryer to the

electricity supply without oil in

the tank.

• Never operate with the oil level

below minimum mark (2.0 litres)

or above maximum mark (3.1

litres).

Location

• Place the appliance on a

horizontal, flat and stable

surface away from a heating

source and where it cannot be

splashed by water.

• Allow adequate air space above

and on all sides for air

circulation.

• Do not use your fryer under

cupboards or shelves.

• Do not use outdoors.

Other safety

considerations

• Do not operate any appliance

with a damaged cord or plug or

after the appliance malfunctions

or has been damaged in any

manner. Telephone the helpline

number (the telephone number

can be found on the front cover)

for advice on examination and

repair.

• Do not use the fryer for anything

other than its intended purpose.

• The use of attachments or tools

not recommended or sold by

45076 rev1 22/3/07 08:52 Page 3

2244

Morphy Richards may cause

fire, electric shock or injury.

• Always dry food before frying

eg. chips which are too wet can

cause the hot oil to froth

excessively.

• Never pour oil out of the fryer

with the bowl in position.

Children

• Never allow a child to operate

this appliance. Teach children to

be aware of dangers in the

kitchen, warn them of the

dangers of reaching up to areas

where they cannot see properly

or should not be reaching.

• Children should be supervised

to ensure that they do not play

with the appliance.

Scalds

• Run cold water over the affected

area immediately. Do not stop to

remove clothing, seek medical

help immediately.

Mains lead

• The mains lead should reach

from the socket to the base unit

without straining the

connections.

• Do not let the cord hang over

the edge of the table or the

counter and keep it away from

any hot surface.

• Do not let the lead run across an

open space eg. between a lower

socket and table.

ELECTRICAL

REQUIREMENTS

Check that the voltage on the

rating plate of your appliance

corresponds with your house

electricity supply which must be

A.C. (Alternating Current).

If the socket outlets in your

home are not suitable for the

plug supplied with this appliance

the plug should be removed and

the appropriate one fitted.

WARNING: The plug

removed from the mains

lead, if severed must be

destroyed as a plug with a

bared flexible cord is

hazardous if engaged into a

live socket outlet.

Should the fuse in the 13 amp

plug require changing, a 13 amp

BS1362 fuse must be fitted.

WARNING: This appliance

must be earthed.

45076 rev1 22/3/07 08:52 Page 4

33UUKKHHeellpplliinnee0088770000660022661144RReeppllaacceemmeennttPPaarrttss0088770011557766664455IIrreellaannddHHeellpplliinnee11880000440099111199

Features

⁄ Spring loaded removable lid

¤Lid location guides (not shown)

‹Viewing window

›Steam vents

ﬁLid release button

ﬂBasket

‡Basket handles x 2

·Handle release button

‚Basket rest

„Lid lock catch

‰Basket handle rest position

ÂRemovable oil tank

ÊOil tank finger lifting lip

ÁPower on light (red)

ËTemperature ready light (green)

ÈVariable temperature control

ÍMin and max oil levels inside

tank

ÎCarrying handles

ÏNon slip feet on base

ÌFryer body

ÓLadle

ÔOil storage container

⁄

‹

›

ﬁ

ﬂ

‡

‚

„

‰

ﬂ

45076 rev1 22/3/07 08:52 Page 5

4466

BEFORE FIRST USE

Refer to the assembly sequence

in section

‘Assembly/disassembly

sequence’.

When unpacking the fryer, make

sure all packaging material is

removed.

WARNING: make sure that

your fryer is disconnected

from the electricity supply.

Please note: Remove the filter

from the lid before washing lid.

Remove the oil storage

container, ladle, frying basket,

non stick oil tank, lid, body and

wash these by hand in hot

soapy water. Please note: do not

leave in water to soak for a long

period of time.

WARNING: Do not immerse

the control panel in water.

Dry all parts of your fryer

thoroughly and replace the oil

tank, basket and lid.

Replace the oil tank with the

max/min lines to the rear.

(Please follow the cleaning

instructions).

OPERATION

Lid operation

Press the lid release button, the

lid is spring loaded and will rise

up on its own A.

In the upper position the lid will

lift out of its guides at the back

for easy cleaning.To replace,

locate in the guides and slide

back into position.

Close the lid by pressing down

in the centre and ensure locking

catch „is fully engaged B.

Attaching the handle

to a basket

Rest the basket on a level, firm

surface, locate the handle into

the slots of the basket and pull

upwards against the spring

force C.

Removal of handles

Rest the basket on a level, firm

surface, press the handle down

against the spring force and

remove D.

Basket operation

The handles are removable so

they can be attached to the

basket D.

Location of basket to

drain

With the lid open and in the

vertical position, the basket can

be raised into the rest draining

position or removed completely

When in the draining position

the basket should be hooked on

the basket rest lip (shown by the

arrow). When lowering the

basket back, lift up to remove

from the basket rest position,

push forward slightly and lower

down. Press the basket release

button and allow the handle to

lower.

When using the basket, both

basket release buttons must be

pressed to allow the basket to

lower into the oil F.

Assembly/

Disassembly

sequence

The fryer has to be

disassembled and assembled

following this procedure.

• Open the lid and remove.

• Remove the basket.

• Lift out the tank.

• Pull out the control panel.

Assembly is the reverse of the

above process.

45076 rev1 22/3/07 08:52 Page 6

5577

Removal of the

control panel

1Lift up the fryer body at the front

as shown and pull out the

control panel G.

2Replace by locating the control

panel in the guides and push

fully in.

3Once the control panel is in

place route the mains cable to

the side or out of the back,

whichever is convenient.

Replacing the oil tank

Ensure tank contacts are dry

before replacing H.

Filter

Press the 2 locking tabs back

and lift out the panel. The mesh

filter can be left to soak in hot

soapy water to clean. Allow to

drain and dry before replacing

Filling with oil

Pour oil into the tank up to the

maximum level indicated

(approx. 3.1 litres of oil).

Lightly smear the inside of the

viewing window with the oil to

inhibit any condensation which

could reduce visibility.

Use good quality liquid

vegetable oil, see ‘Getting the

best from your fryer’ on page 6.

COOKING

WARNING: Never operate

the fryer without oil in the

oil tank.

1Lower the basket (if required)

and close the lid.

2Plug into the mains and switch

the power on at the socket.

3The red power light and green

temperature light will illuminate.

4Set the variable temperature

control to the required setting

see ‘frying times and

temperature section’ on page

9/10.

5The fryer is now pre-heating the

oil, the green temperature light

may go out and come back on

once or twice during pre-heat.

This is normal. After approx. 15

minutes the oil will be at the

correct temperature.

6Lift the lid.

• Do not over fill the basket when

frying, the food must be covered

with the bubbling hot oil,

depending on the size and

shape of the food to be cooked.

There are two methods of

cooking in your fryer, one

general method for most food

types and another for home

battered products.

General cooking

method (with the basket)

1Place the basket in the raised

position. The basket should

always be in the raised position

when it is to be filled with food.

2Place the food, which should be

dry as possible, into the raised

basket. When frying frozen food,

avoid adding ice particles to the

hot oil. Remove the basket from

the fryer, add the frozen food

and shake the basket to remove

excess ice and frost. The oil

temperature and oil life

expectancy will be improved.

3Lower the basket onto the

basket rest ‚.

UUKKHHeellpplliinnee0088770000660022660044RReeppllaacceemmeennttPPaarrttss00887700116677666633IIrreellaannddHHeellpplliinnee11880000440099111199

45076 rev1 22/3/07 08:52 Page 7

8866

4Lower the lid (to prevent spitting

of hot oil).

5Lower the basket to the frying

position.

• You can observe the cooking

process by raising the lid or

looking through the viewing

window to observe progress.

6When the food is cooked, raise

the lid, lift the basket out of the

oil, give it a shake, and place it

in its raised rest position for a

few seconds to drain.

7Lift the basket out and shake

the fried food into a dish with oil

absorbing kitchen paper.

8After use, disconnect from the

mains supply and allow to cool.

Wipe any spilt oil from the fryer

body.

Cooking home-

battered foods

(without the basket)

This method allows for the fact

that if wet batter is placed in the

basket prior to cooking the food

may stick.

1Leave the basket fully

submerged in the oil.

2Dip food in the batter until it is

evenly coated and allow to drain

for a moment to remove excess

batter.

• To check that the oil is hot

enough for your battered food,

drop a drip of batter into the oil.

If the oil is hot enough the batter

should immediately rise to the

surface but should not smoke. If

this action causes any smoke

then the temperature is too high

and should be reduced.

3Once evenly coated, carefully

lower your battered food into the

hot oil and allow to ‘seal’ for

about 30 seconds before

turning. See table on page 9/10

for frying times and quantities of

food per fry.

4Fry until batter is golden brown

and the food inside is cooked

but not dried out.

WARNING: Take care as the

oil may spit as the food is

added.

45076 rev1 22/3/07 08:52 Page 8

GETTING THE BEST

FROM YOUR FRYER

Oil

• Always ensure that you use

good quality oil for deep frying.

We recommend liquid vegetable

oils, alternatively use corn,

groundnut or rapeseed oil. Avoid

mixing oils of different types and

quality.

• Solid fat (lard) and solid oil can

be used, this should be first

melted in a pan until softened,

then carefully transferred into

the fryer tank.

• Change the oil when it becomes

brown or cloudy in colour,

usually after frying 15 times.

IMPORTANT: Do not switch the

fryer on until the fryer tank is

filled with oil or solid oil or lard.

Cooking tips

• Your food must always be

completely dry in order to avoid

overflowing, to prolong the use

of the oil and to give a crispier

finish to the food.

• Pieces of food should be of the

same size and thickness.

• As a general guide pre-cooked

foods need a higher cooking

temperature than raw foods.

• Do not overload the basket as it

may cause a drop of

temperature that may leave the

food greasy.

• Cook your food thoroughly.

Remember that your food may

begin to turn golden brown

before it is cooked through.

• Avoid leaving food to drain for

too long in the basket as the

food may become soft and lose

its crunchiness.

• Select your cooking utensils

with care. Do not use utensils

that may melt. When using metal

utensils, take care not to

damage the non-stick coating of

the bowl.

• All foodstuffs contain moisture.

When lowered into the hot oil

the water turns to steam. Most

of the steam escapes

harmlessly through the lid vent,

but trapped steam may escape

when opening the lid - so care is

needed.

Chips

• Old potatoes are ideal for

making chips.Your chips should

be evenly sized so that they

cook evenly. They should be

rinsed in a colander under a

cold tap and dried using a

kitchen towel or absorbent

paper. For best results fry your

chips for 10-12 minutes; shaking

the basket at intervals to ensure

chips get an overall browning.

• For best results, we recommend

no more than 900g of frozen

chips or 1.2kg of fresh chips are

fried per batch.

UUKKHHeellpplliinnee0088770000660022660044RReeppllaacceemmeennttPPaarrttss00887700116677666633IIrreellaannddHHeellpplliinnee11880000440099111199

45076 rev1 22/3/07 08:52 Page 9

EMPTYING,

CLEANING &

STORING

WARNING: Cleaning should

only be carried out with the

plug removed from the

socket. The fryer should

have completely cooled.

Allow 3 hours for cooling.

1Remove the lid.

2Remove the basket.

3Take the oil storage container

and remove the lid, ensuring the

filter is left in.

4Lift out the tank Jand carefully

pour the oil from the corner of

the tank, Kinto the oil storage

container.

• Once the oil is in the storage

container screw the lid back on.

5Wash the lid, basket, handle,

ladle and the inside of the tank

by hand with hot soapy water.

• The lid can be washed in a

dishwasher.

• The basket and tank should

NOT be washed in a

dishwasher.

6Clean the body of the fryer with

a warm moistened cloth,

washing up liquid can be used.

WARNING: Never immerse

the control panel in water,

if required remove any

stains with a moistened

cloth.

7Dry all parts of your fryer

thoroughly and reassemble all

parts with the max and min at

the back of the oil tank. Refer to

the ‘Assembly Sequence’ on

page 4.

• The outside of the tank is not

non-stick coated, if care is

taken, it is unlikely to become

dirty. If oil does drip down the

exterior when the oil is being

emptied out, make sure that it is

hand washed thoroughly. The

exterior may appear

discoloured, this is quite normal

and will not detract from the

performance of the fryer.

8Place the basket back into the

tank, then the oil storage

container and ladle L. This

allows for efficient storage.

HELPLINE

If you have any difficulty with

your appliance, please do not

hesitate to call us.

We are more likely to be able to

help than the store from where

you bought it.

Please have the following

information ready to enable our

staff to deal with your query

quickly.

• Name of the product.

• Model number as shown on the

underside of the appliance.

• Serial number as shown on

underside of the appliance.

UK Helpline 0870 0602604

Replacement Parts 0870 1676635

Ireland Helpline 1800409119

45076 rev1 22/3/07 08:52 Page 10

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Freidora de Morphy Richards

Morphy Richards

Morphy Richards IB45061 Manual de usuario

Morphy Richards

Morphy Richards bowl fryer Manual de usuario

Morphy Richards

Morphy Richards 3-in-1 basket fryer Manual de usuario

Morphy Richards

Morphy Richards ESSENTIALS COOLWALL FRYER Manual de usuario

Morphy Richards

Morphy Richards DF45040 Manual de usuario

Morphy Richards

Morphy Richards 480001 Manual de usuario

Morphy Richards

Morphy Richards IBFRYDAY Manual de usuario

Morphy Richards

Morphy Richards DF45075M Manual de usuario

Morphy Richards

Morphy Richards IB45410 Manual de usuario

Morphy Richards

Morphy Richards 45081 Manual de usuario

Morphy Richards

Morphy Richards 45078 PROFESSIONAL STEEL FRYER Manual de usuario

Morphy Richards

Morphy Richards 480002 Manual de usuario

Morphy Richards

Morphy Richards DF45079 Manual de usuario

Morphy Richards

Morphy Richards 480003 Manual de usuario

Morphy Richards

Morphy Richards IB45460 Manual de usuario

Morphy Richards

Morphy Richards 7984 Manual de usuario

Morphy Richards

Morphy Richards Harry Ramsden’s 45362 Manual de usuario

Morphy Richards

Morphy Richards IB45065 Manual de usuario

Morphy Richards

Morphy Richards DF45070M Manual de usuario

Morphy Richards

Morphy Richards MRAF72BK Manual de usuario

Morphy Richards

Morphy Richards IB45470 Manual de usuario

Morphy Richards

Morphy Richards Compact Fryer Manual de usuario

Morphy Richards

Morphy Richards REMOVABLE BOWL FRYER - REV 1 Manual de usuario

Manuales populares de Freidora de otras marcas

Innsky

Innsky 55SA1US Manual de usuario

Falcon

Falcon G350/11 Guía del usuario

GoWISE USA

GoWISE USA GW22612 Manual de usuario

Wolf

Wolf IF15/S Manual de usuario

Electrolux

Electrolux Thermetic 9CHG583284 Guía rápida

Gourmia

Gourmia GAF799 Manual de usuario

DeLonghi

DeLonghi D677UX Manual de usuario

SEVERIN

SEVERIN DEEP FRYER - Guía del usuario

Toastmaster

Toastmaster TMFG18-NAT Manual de usuario

Domo

Domo DO465FR Manual de usuario

Henny Penny

Henny Penny PFG-691 Manual de usuario

Farberware

Farberware FBW FT 43721 B Manual de usuario

GERMANICA

GERMANICA GEAF5L3LD Manual de usuario

Roller Grill

Roller Grill MF 120 R Manual de operación

Philips

Philips HD9211 Manual de usuario

Linea 2000

Linea 2000 Domo DO536FR Manual de usuario

Lakeland

Lakeland 31796 Manual de usuario

Dash

Dash Tasti-Crisp DFAF755 Manual de usuario
