Moog Videolarm SView IGDW7CN-3 Manual de usuario

•

Ideal for high temperature environments up to 75°C / 167°F

•

Liquid cooled; utilizes low toxicity Propylene Glycol coolant

formula that is safe for the environment

•

Includes heavy-duty air ltration system

•

110/220VAC powers entire unit

Key Features

Restricted by intense heat and humidity? Moog Videolarm’s Igloo Dome provides you with an air-conditioned camera housing

solution for excessive heat climates. The unit operates on low toxicity Propylene Glycol coolant that cools the internal temperature

within the camera enclosure, resulting in an ideal environment for your surveillance equipment. As an added safety benet, when

outside temperatures exceed +75°C, the AC unit and camera system temporarily shut down for cooling. Once a safe operating

environment has been reestablished, all units reactivate.

Capable of resisting vandalistic attacks, the rugged Igloo Dome also comes with an IP66 rating for the prevention of water and dust

intake. IP Ready, the Igloo Dome is compatible with today’s leading network cameras and Moog Videolarm’s SView.

Igloo Dome

•

Rugged, vandal-resistant construction with polycarbonate dome

•

Includes built-in aluminium sunshield for added protection from

direct light

•

Comes standard with separate wall/pole mount for

simple installation

•

110/220VAC powers entire unit

Air-Conditioned Solution for Hot, Humid Climates

CERTIFIED

LOWERING

DEVICES_

IGLOO DOME_

Model for IP Ready PTZ Camera:

SView Camera System IP Ready and Analog PTZ:

IGDW75C1N

IP network ready 7” outdoor air conditioned dome housing with wall and pole

mount, clear polycarbonate dome, with 240VAC input, heater/blower, for an IP

network PTZ camera, 120 to 24VAC transform

Model for Fixed Camera:

IGDW75CF1

7” outdoor air conditioned dome housing with wall and pole mount, clear dome,

with 240VAC input, heater/blower, for an analog xed camera

IGDW7CN-3 / IGDW75CS-3

Outdoor air conditioned dome housing IP network PTZ camera system, 36x zoom

day/night camera, with wall and pole mount, clear dome, with 240VAC input,

heater/blower. The IGDW75CS-3 has a analog PTZ camera system, 36x zoom

day/night camera, with wall and pole mount, clear dome, with 240VAC input,

heater/blower

SPECIFICATIONS:

Mechanical Specications

Size (h*w*d):

21.6” x 16.5” x 23.2” (550.2 x 419.1 x 590.1mm)

Weight:

40 lbs (18.14 kg)

Construction TOP:

Aluminum alloy

Construction DOME:

Polycarbonate

Electrical Specications

Power Requirements:

120VAC / 240VAC 50/60 Hz 450W

Environmental Specications

Operating Temperature:

-40° F to 167° F Max (-40° C to 75° C) Max

Dimensions / Architectural Drawings

Shipping Specications

MODEL SHIPPING WEIGHT BOX DIMENSIONS

IGDW7C1N

50 lbs (22.7kg) Call for details

Certications and Ratings

UL Listed WEEE CE RoHS

13.50

342.9

22.77

578.3

18.17

461.6

13.36

339.4

12.50

317.5

9.25

235.0

4.81

122.2

23.21

589.7

IGDW75

13.50

342.9

22.77

578.3

18.17

461.6

13.36

339.4

12.50

317.5

9.25

235.0

4.81

122.2

23.21

589.7

IGDW75

Dimensions are in inches

Product and company names listed are trademarks or trade names of their respective companies.

Tinted and clear domes available. Specify “C” for

Clear or “T” for Tinted.

COMPATIBLE CAMERAS:

ACM-8201/8211,ACM-8511, CAM-6510 iCanView 250/252

213, 214, 215, 231D, 232D, 233D

VB-C300, VB-C50i, VB-C60, VC-C50i

dcs 5000 Series, dcs 6600 Series

PTC-200C, PTC-400C, PTC-401C IP

IK-WB21A

VN-C625U, VN-V685U,

VN-V686BU, VN-V686U

BB-HCE381A, BB-HCE481A,

BB-HCE580A, BB-HCE581A,

BB-HCE581A-W, WV-NS202A

SNC-RH124, SNC-RS44/46,

SNC-RX530/550/570

SNC-RZ25, SNC-RZ30,

SNC-RZ50

CAN

To view the latest listing of compatible cameras please visit

www.videolarm.com/thirdparty.jsp

PTZ:

FIXED COMPATIBLE CAMERAS ALSO AVAILABLE

For detailed list see web site****

Moog Videolarm, 2525 Park Central Boulevard, Decatur, GA 30035 USA + 1.800.554.1124 www.videolarm.com

500-666 + 07-30-2010
