montpellier MDI500 Manual de usuario
Fully Integrated Dishwasher
MDI500 - Slimline - 45cm
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING
Thank you for choosing this Montpellier Integrated Dishwasher.
Our Integrated Dishwasher has been designed to provide you with the best combination of style, reliability and
performance to give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing or
using your Integrated Dishwasher to ensure you get the most from your purchase.
We recommend that you keep this manual in a safe place for future reference.
Your Integrated Dishwasher is covered by a comprehensive two year Parts &
Labour Guarantee. In the unlikely event that you experience a problem with your
Integrated Dishwasher, you can rest assured that you are fully protected against
the cost of repairs for the rst 24 months . Please note that any claim must
be accompanied by the model reference number, serial number and proof of
purchase.
To activate your guarantee, you will need your product serial number. This can be
found on the rear of the machine.
There are two ways to register your Guarantee:
•Online: Visit the Support page on our website and complete the online Product
Registration form. www.montpellier-appliances.com
•By Post: Simply detach and ll in the form provided, attach a stamp and send
it in the post. Don’t forget to include your e-mail address so that we can send
conrmation through to you.
Welcome
Note: We are unable to take registrations over the phone.
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com
1
CONTENTS
Technical specifications ....................................................................................... 4
Safety information and Recommendations .......................................................... 5
Recycling ............................................................................................................... 5
Safety information ................................................................................................. 5
Recommendations .................................................................................... 8
Items not suitable for dishwashing ..................................................................... 9
Installing the machine ................................................................................................. 9
Positioning the machine ........................................................................................ 9
Water connections ................................................................................................ 10
Water inlet hose .................................................................................................... 11
Water outlet hose ................................................................................................. 12
Electrical connection .................................................................................. 13
Prior to using the machine ......................................................................... 14
Preparing the machine for use ....................................................................... 14
The importance of water decalcification ..................................................... 14
Filling with salt ........................................................................................... 14
Testing strip ............................................................................................... 15
Adjusting salt consumption ........................................................................ 15
Detergent usage ........................................................................................ 17
Filling the detergent compartment .............................................................. 17
Combined detergent .................................................................................. 17
Filling with rinse aid and making the setting ............................................... 18
2
Loading your dishwasher .............................................................................. 19
Top basket ............................................................................................... 19
Alternative basket loads .................................................................................... 22
Programme descriptions ........................................................................................24
Programme items ...............................................................................................24
Getting familiar with your machine ...................................................................... 25
Switching on the machine and selecting a programme .................................. 27
Switching on the machine ................................................................................. 27
Programme follow-up......................................................................................... 27
Changing a programme..................................................................................... 27
Changing a programme with resetting ............................................................ 28
Switching the machine off ................................................................................. 28
Maintenance and Cleaning ..................................................................................... 29
Filters ................................................................................................................... 29
Spray arms .......................................................................................................... 30
Hose filter ............................................................................................................ 30
Failure codes and what to do in case of failure ................................................. 31
Practical and useful information ........................................................................... 33
11
10 1
2
9
3
4
5
8 6
1.
2.
3.
4.
5.
6.
9.
10.
11.
Upper basket with
racks Upper spray arm
Lower basket
Lower spray arm Filters
Rating plate
Salt dispenser
Upper basket track
latch Upper Cutlery
Basket
7
12 Drying with Fan: This system
provides better drying
performance for your dishes.
13
Fixed Top Sprinkler: Provides
better washing performance
for utensils in the upper basket.
3
7. Control Panel
8. Detergent and rinse-aid dis
4
Technical specifications
Capacity 10 place settings
Height 820 mm - 870 mm
Width 450 mm
Depth 550 mm
Net Weight 32 kg
Electricity input 220-240 V, 50 Hz
Total Power 1900 W
Heating Power 1800 W
Pump Power 100 W
Drain Pump Power 30 W
Water supply pressure 0.03 MPa (0,3 bar)-1 MPa (10 bar)
Current 10 A
Conformity with the standards and Test data / EU Declaration of
Conformity
This product meets the requirements of all applicable EU directives
with the corresponding harmonised standards, which provide for CE
marking.
Important Note for User:For softcopy of this user manual, please
contact following address:
"[email protected]”.In your e-mail, please provide the
model name and serial number (20 digits) which you can find on the
appliance door.
5
SAFETY INFORMATIONAND RECOMMENDATIONS Recycling
•
Certain components and the packaging of your machine
have been produced from recyclable materials.
•
Plastic parts are marked with international abbreviations:
(>PE< , >PS< , >POM<, >PP<, )
•
Cardboard parts have been produced from recycled paper
and they should be disposed of into waste paper collection
containers for recycling.
•
Such materials are not suitable for being disposed of into
garbage bins. They should be delivered to recycling centres
instead.
•
Contact relevant centres in order to obtain information on
methods and points of disposal.
Safety Information
When you take delivery of your machine
•
Check for any damage to your machine or to its packaging.
Never start a machine damaged in any way, make sure to
contact an authorised service.
•
Unwrap the packaging materials as indicated and dispose
of them in accordance with the rules.
The points to pay attention during machine installation
•
Choose a suitable, safe and level place to install your
machine.
•
Carry out the installation and connection of your machine by
following the instructions.
•
This machine should be installed and repaired by an
authorised service only.
•
Only original spare parts should be used with the machine.
•
Before installing, be sure that the machine is unplugged.
6
•
Check whether the indoor electrical fuse system is
connected according to the regulations.
•
All electrical connections must match the values
indicated on the rating plate.
•
Pay special attention and be sure that the machine does
not stand on the electricity supply cable.
•
Never use an extension cord or a multiple socket for
making a connection. The plug should be comfortably
accessible after the machine has been installed.
•
After installing the machine to a suitable place, run it
unloaded for the first time.
In daily use
•
This machine is for household use; do not use it for
any other purpose. Commercial usage of the dishwasher
will void the guarantee.
•
Do not get up, sit or place a load on the open door of
the dishwasher, it may fall over.
•
Never put into the detergent and rinse aid dispensers
of your machine anything other than those detergents
and rinse aids which are produced specifically for
dishwashers. Our company will not be responsible for
any damage that might occur in your machine otherwise.
•
The water in the machine's washing section is no
drinking water do not drink it.
•
Due to danger of explosion, do not put into the
machine’s washing section any chemical dissolving
agents such as solvents.
•
Check whether plastic items are heat-resistant
before washing them in the machine.
•
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or
7
mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance.Cleaning and user maintenance
shall not be made by children without supervision.
•
Do not put into your machine those items which are
not suitable for dishwashing. Also, do not fill any basket
above its capacity.Our company will not be responsible
for any scratch or rust to form on the inner frame of
your machine due to basket movements otherwise.
•
Especially because hot water may flow out, the
machine door should not be opened under any
circumstances while the machine is in operation. In any
case, a safety devices ensures that the machine stops if
the door is opened.
•
Do not leave your dishwasher’s door open. Failure to do
so may lead to accidents.
•
Place knives and other sharp-ended objects in the
cutlery basket in blade-down position.
•
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
•
This appliance is not intended for use by persons
(including -children) with reduced physical,sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
•
If EnergySave option is selected as "Yes", The door will
be opened at the end of the program. Do not force to
close the door to avoid harm auto door mechanism
during 1 minutes. The door must be open during 30
minutes to get effective drying.( in models with auto door
opening system ) Warning: Do not stand in front of the
door after the signal sounds belonging auto-open.
8
For your children’s safety
•
After removing the machine’s packaging, make sure
that the packaging material is out of reach of children.
•
Do not allow children to play with or start the machine.
•
Keep your children away from detergents and rinse
aids.
•
Keep children away from the machine while it is
open because there may still be residues of cleaning
substances inside the machine.
•
Be sure that your old machine does not pose any
threat to your children. Children are known to have
gotten themselves locked in old machines. To forestall
such a situation, break your machine's door lock and
tear off the electrical cables. In case of malfunctioning
•
Any malfunction in the machine should be repaired
definitely by qualified persons. Any repair work
performed by anyone other than the authorised
service personnel will cause your machine to be left
outside the scope of warranty.
•
Prior to any repair work on the machine, be sure that
the machine is cut off from the mains.Switch off the fuse
or unplug the machine.Do not pull by the cable when
unplugging. Make sure to turn off the water tap.
Recommendations
•
For energy and water saving, remove coarse
residues on your dishes before placing the dishes into
the machine. Start your machine after having fully
loaded it.
•
Use the pre-wash programme only whenever
necessary.
•
Place such hollow items as bowls, glasses and pots
into the machine in such a way that they will face down.
•
You are recommended not to load into your machine
any dishes different or more than indicated.
Tabla de contenidos
Otros manuales de Lavavajillas de montpellier
montpellier
montpellier MD9INT45W Manual de usuario
montpellier
montpellier MDWBI6095 Manual de usuario
montpellier
montpellier MDWBI6053 Manual de usuario
montpellier
montpellier MDI600 Manual de usuario
montpellier
montpellier MDI655W Manual de usuario
montpellier
montpellier MDI505 Manual de usuario
montpellier
montpellier MDI650X-K-W Manual de usuario
montpellier
montpellier Slimline DW1065W Manual de usuario
montpellier
montpellier MDW1363W Manual de usuario
montpellier
montpellier MDI450-2 Manual de usuario
montpellier
montpellier MDI450 Manual de usuario
montpellier
montpellier MD214FS60W Manual de usuario
montpellier
montpellier MDI700 Manual de usuario
montpellier
montpellier MDW1354W Manual de usuario
montpellier
montpellier MDWBI4553 Manual de usuario
montpellier
montpellier MAB1353C Manual de usuario
montpellier
montpellier MDI805 Manual de usuario
montpellier
montpellier MDI705 Manual de usuario
montpellier
montpellier MAB6015 Manual de usuario
montpellier
montpellier MDI800 Manual de usuario
