PoE•X Open / Close Sensor
User Guide
TABLE OF CONTENTS
I. ABOUT THE PoE•X OPEN / CLOSE SENSOR 1
PoE•X SENSOR FEATURES 1
EXAMPLE APPLICATIONS 1
II. SENSOR SECURITY 2
DATA SECURITY ON THE SENSOR 2
iMONNIT SECURITY 2
III. ORDER OF OPERATIONS 2
SET-UP STEPS 2
IV. REGISTRATION 4
REGISTERING A PoE•X SENSOR 4
V. SETTING UP THE PoE•X SENSOR 5
THE LIGHTING SEQUENCE 5
MOUNTING THE SENSOR 5
VI. SENSOR OVERVIEW 6
MENU SYSTEM 6
INTERFACE SETTINGS 8
VII. ACTIONS OVERVIEW 11
VIII. USING THE LOCAL INTERFACE 14
THE STATUS TAB 16
THE SETTINGS TAB 17
SUPPORT 23
WARRANTY INFORMATION 23
SAFETY RECOMMENDATIONS 25
I. ABOUT THE PoE•X OPEN / CLOSED SENSOR
The Power-over-Ethernet (PoE) Open / Closed Sensor uses an external
magnetic switch to detect the presence or removal of a trigger magnet.
When the sensor detects that the magnet is removed or returned it sends the
information to iMonnit. Notications can be set up through the online system
to alert the user when a magnetic source is present or not with the ability to
only notify within time of day parameters.
PoE•X SENSOR FEATURES
• Plug & play
• No PC required for operation
• Remote software upgrade capability and over-the-air updates
• On-unit LEDs with transmission and online condition indicators
• Works natively in conjunction with the iMonnit portal
• Modbus and SNMP v1 interface capabilities
• 50,000 sensor message memory
• Power-over-Ethernet ready (injector hardware required)
• AC power supply
EXAMPLE APPLICATIONS
• Doors and windows
• IT server closets
• Freezer and cooler door
• Cabinets and lockers
• And many more!
PAGE 1
PAGE 2
II. SENSOR SECURITY
Security is paramount for the PoE•X Sensor when it comes to managing your
data and transferring it to sensors. iMonnit is the online software and central hub
for conguring your device settings. All data is secured on dedicated servers
operating Microsoft SQL Server.
Data Security on the Sensor
The fortied sensor secures your data from attackers and secures the sensor
from becoming a relay for malicious programs. Even when the sensor is at rest,
the PoE•X Sensor is designed to prevent prying eyes from accessing the data.
The Monnit PoE•X Sensor does not run on an o-the-shelf multi-function OS
(operating system). Instead it runs a purpose-specic real-time embedded state
machine that can’t be hacked to run malicious processes. It also provides no
active interface listeners that can be used to gain access to the device over the
network.
iMONNIT Security
Access is granted through the iMonnit user interface, or an Application
Programming Interface (API) safeguarded by 256-bit Transport Layer Security
(TLS 1.2) encryption. TLS is a blanket of protection to encrypt all data exchanged
between iMonnit and you. The same encryption is available to you whether you
are a Basic or Premiere user of iMonnit. You can rest assured that your data is
safe with iMonnit.
III. ORDER OF OPERATIONS
It is important to understand the order of operations for activating your PoE•X
Sensor. If performed out of sequence, your sensor may have trouble
communicating with iMonnit. Please follow the steps below to make sure
you are performing your set-up correctly.
SET-UP STEPS
1. Register your PoE•X Sensor on iMonnit.
Add your PoE•X Sensor to the iMonnit account (see page 3 for
step-by-step directions).
2. Connect the ethernet and power cords to the sensor.
Plug in powered ethernet cable. Depending on your facility, you might need
to plug in both the ethernet cable and power cord.
3. Mount your sensor.
Place your sensor in the desired location using screws or double-sided
tape.
Note: Each step is covered in more detail in the following sections.
IV. REGISTRATION
If this is your rst time using the iMonnit online portal, you will need to create a
new account. If you have already created an account, start by logging in. For
instructions on how to register for an iMonnit account, please consult the iMonnit
User Guide at https://www.monnit.com/support/documentation.
REGISTERING THE PoE•X SENSOR
1. Add the sensor on iMonnit.
Add the sensor to your account by choosing Sensors in the main menu.
Navigate to the Add Sensor button.
2. Find the device ID. See Figure 1.
The Device ID (ID) and Security Code
(SC) are necessary to add a sensor.
These can both be located on the label
on the bottom of your device.
3. Adding your device. See Figure 2.
You will need to enter the Device ID
and the Security Code from your PoE•X
Sensor in the corresponding text boxes.
Use the camera on your smartphone to
scan the QR code on your device. If you
do not have a camera on your phone,
or the system is not accepting the QR
code, you may enter the Device ID
and Security Code manually.
• The Device ID is a uni q u e n u m b e r
located on each device label.
• Next, you’ll be asked to enter the Security Code on your device. A
security code consists of letters and must be entered in upper case, no
numbers. It can also be found on the barcode label of your device.
When completed, select the Add Device button.
PAGE 3
Desktop Mobile
Figure 1
Figure 2
V. SETTING UP YOUR PoE•X SENSOR
Plug in powered ethernet cable.
Depending on your facility, you might need
to plug in both the ethernet cable and power
cord. See Figure 3.
LIGHTING SEQUENCE
The sensor will cycle through three stages as it powers on:
Power-on stage: At this stage, the sensor will analyze electronics and program-
ming. The LED lights will ash red and green, before all becoming green for one
second. In the case of failure, the light sequence will repeat after ten seconds.
Please contact technical support if the lights aren’t green after two minutes.
Connection stage: The sensor will attempt to settle all operational connections.
As the sensor attempts to connect, the Sensor Status LED will be o, waiting for
the ethernet connection to complete. After the ethernet setup is complete, the
Sensor Status Light will briey blink red before turning green and then going o
completely. If the Ethernet Status LED is orange, there is a failure in your ether-
net connection. Check your connection.
Operational stage: In the operational stage, the ethernet lights will remain active
while the Sensor Status light remains o ─ unless there is an issue. See Figure 4
& Figure 5.
PAGE 4
Ethernet Status LED
Steady Blinking Green:
Performing ethernet set up
operations
Solid Green with Flicker:
Connection successful for normal
operation
Ethernet Link LED
O:
No ethernet cable connected
Green:
Ethernet is connected
Figure 3
Figure 4
RESET DC INETHERNETMADE IN THE USA
TOP
BOTTOMFRONT
BACK
PoE Sensor Housing
P E
PAGE 5
Sensor Status LED
O:
Ethernet failure
Blinking Green:
Communication to the server is
successful
Blinking Red:
Failure to communicate with server
MOUNTING THE SENSOR
Monnit sensors feature mounting anges
and can be attached to most surfaces
using the included mounting screws or
double-sided tape. See Figure 6.
RESET DC INETHERNETMADE IN THE USA
TOP
BOTTOMFRONT
BACK
PoE Sensor Housing
P E
Figure 5
Figure 6
Mounting anges
VI. SENSOR OVERVIEW
Select Sensors from the main navigation menu on iMonnit to access the sensor
overview page and begin adjusting your PoE•X Sensors.
MENU SYSTEM
Details - Displays a graph of recent sensor data
Readings - List of all past heartbeats and readings
Actions - List of all actions attached to this sensor
Settings - Editable levels for your sensor
Calibrate - Reset readings for your sensor
Scale - Change the scale of readings for your sensor
Directly under the tab bar is an overview of your sensor. This allows you to see
the signal strength of the selected sensor. A colored dot in the left corner of the
sensor icon denotes its status:
• Green indicates the sensor is checking in and is within user-dened safe
parameters.
• Red indicates the sensor has met or exceeded a user-dened threshold or
triggered event.
• Gray indicates that no sensor readings are being recorded, rendering the
sensor inactive.
• Yellow indicates that the sensor reading is out of date, possibly due to a
missed heartbeat check-in.
Details View
The Details View will be the rst page you see upon selecting which sensor
you would like to modify. See Figure 7.
PAGE 6
A. The Sensor Overview section is at
the top of every page. This will consistently
display the present reading, signal strength,
battery level, and status.
B. The Recent Readings section below the
chart shows your most recent data received
by the sensor.
C. The Readings Chart displays how the
sensor uctuates throughout a set date range.
To change the date range displayed in the
graph, navigate up to the top of the Readings
Chart section on the right-hand corner to
change the “From:” and/or “To:” date.
Figure 7
PAGE 7
Readings View
Selecting the Readings Tab within the tab bar allows you to view the sensor’s
data history as time stamped data.
• On the far right of the Sensor History Data is a cloud icon. ( ) Selecting
this icon will export an Excel le for your sensor into your download folder.
The data le will have the following elds:
MessageID: Unique identier of the message in our database.
Sensor ID: If multiple sensors are exported, you can distinguish between the
sensors using this number — even if the names are the same.
Sensor Name: The name you have given the sensor.
Date: The date the message was transmitted from the sensor.
Value: Data presented with transformations applied, but without additional
labels.
Formatted Value: Data transformed and presented as it is shown in the
monitoring portal.
Raw Data: Raw data as it is stored from the sensor.
Sensor State: Binary eld represented as an integer containing information
about the state or the sensor when the message was transmitted. (See
“Sensor State” explained below.)
Alert Sent: Boolean indicating if this reading triggered a notication to be sent
from the system.
Sensor State
The integer presented here is generated from a single byte of stored data.
A byte consists of 8 bits of data that we read as Boolean (True (1)/False (0))
elds.
Using a temperature sensor as an example:
If the sensor is using factory calibrations, the Calibrate Active eld is set True
(1) so the bit values are 00010000 and it is represented as 16.
If the sensor is outside the Min or Max Threshold, the Aware State is set True
(1) so the bit values are 00000010 and it is represented as 2.
Note: Ensure that you have input the data you need in the “From”
and “To” text boxes. This will be the most recent week by default.
Only the rst 2,500 entries in the selected data range will be
exported.
If the user has calibrated the sensor, the Calibrate Active eld is set False (0)
and the sensor is operating inside the Min and Max Thresholds, the bits look
like 00000000 ─ this is represented as 0.
If the sensor is using factory calibrations and it is outside the threshold, the bit
values are 00010010 and it is represented as 18 (16 + 2 because both the bit
in the 16 value is set and the bit in the 2 value is set).
Settings View
To edit the operational settings for a sensor, choose the Sensor option in
the main navigation menu and then select the Settings Tab to access the
conguration page. See Figure 8.
Finish by selecting the Save button.
A. Sensor Name is the unique name you give the
sensor to easily identify it in a list along with any
notications.
B. Heartbeat Interval is how often the sensor com-
municates with the server if no activity is recorded.
C. Aware State Heartbeat is how often the sensor
communicates with the server while in the Aware
State.
D. Event Aware State when magnet is sets the
sensor to detect when the magnet is removed,
introduced, or a state change.
E. Report as “Open” when magnet is the exact time the door should enter an alert
state when the magnet is removed or introduced.
F. Time to Re-Arm is the time in seconds after a triggering event that the sensor will
wait before re-arming itself.
PAGE 8
Figure 8
Otros manuales para PoE X
1
Tabla de contenidos
Otros manuales de Accesorios de Monnit
Monnit
Monnit ALTA MNS2-4-W2-GS-C2 Manual de usuario
Monnit
Monnit PoE-X Thermocouple Sensor Manual de usuario
Monnit
Monnit PoE-X Open/Close Sensor Manual de usuario
Monnit
Monnit ALTA Wireless Water Rope Sensor Manual de usuario
Monnit
Monnit ALTA Sensor Adapter Series Manual de usuario
Monnit
Monnit ALTA Water Detection Puck Sensor Manual de usuario
Monnit
Monnit PoE-X Low Temperature Sensor Manual de usuario
Monnit
Monnit ALTA MNS2-4-PK-WS-PS Manual de usuario
Monnit
Monnit MNS2-9-W2-OC-ST Manual de usuario
Monnit
Monnit ALTA H2S Manual de usuario
Monnit
Monnit ALTA WirelessCarbon Monoxide Sensor Manual de usuario
Monnit
Monnit ALTA Motion+ Manual de usuario
Monnit
Monnit PoE-X High Temperature Sensor Manual de usuario
Monnit
Monnit ALTA Wireless Carbon Dioxide Sensor Manual de usuario
Monnit
Monnit PoE-X Dry Contact Sensor Manual de usuario
Monnit
Monnit PoE-X Water Detect Rope Sensor Manual de usuario
Monnit
Monnit ALTA Wireless Temperature Sensor Manual de usuario
