Mongoose REACT E1 Manual de usuario
OWNERS MANUAL
WARNING
This manual contains important safety and use informaon.
Keep this manual for future reference.
• An adult must read this enre manual
• Adult supervision is required at all mes
R6006AZ
R6007AZ
REACT
REACT
REACT
REACT
REACT
REACT
*Styles may vary
2
Congratulaons on your new scooter!
Proper assembly and operaon of your scooter is important for
your safety and enjoyment. Our customer service department is
dedicated to your sasfacon with Pacic Cycle and its products.
If you have quesons or need advice regarding assembly, parts,
performance, or returns, please contact the experts at Pacic
Cycle. Enjoy the ride!
Toll free: 1-800-626-2811
Customer Service hours: Monday - Friday 8 AM- 5 PM Central
Standard Time (CST)
You may also reach us at:
Web: www.pacic-cycle.com
Email: customerservice@pacic-cycle.com
Mail: P. O. Box 344
4730 E. Radio Tower Lane
Olney, IL 62450
Do not return this item to the store. Please call Pacic Cycle
customer service if you need assistance. You will need your model
number and date code located on the service scker.
About This Manual
It is important for you to understand your new scooter. By reading
this manual before you go out on your rst ride, you’ll know how
to get beer performance, comfort, and enjoyment from your new
scooter. It is also important that your rst ride on your new scooter
is taken in a controlled environment, away from cars, obstacles
and cyclists.
This manual contains important informaon regarding safety,
assembly, use, and maintenance of the scooter but is not intended
to be a complete or comprehensive manual covering all aspects
concerning scooter ownership. We recommend consulng an
expert if you have any doubts or concerns regarding your
experience or ability to properly assemble and maintain the scooter.
A Special Note For Parents and Guardians
As a parent or guardian, you bear the responsibility for the acvies
and safety of your minor child. Among these responsibilies are to
make sure that the scooter which your child is riding is properly
ed to the child; that it is in safe operang condion; that you and
your child have learned, understand and obey not only the
applicable local motor vehicle, scooter, and trac laws, but also the
common sense rules of safe and responsible scoong. As a parent,
you should read this manual before leng your child ride the
scooter. Please make sure that your child always wears an approved
helmet when riding.
3
Product Name Age Max Weight Max Speed
React E1 8+ 55 kg / 120 lb 10 km/h / 6 mph
React E2 8+ 55 kg / 120 lb 16 km/h / 10 mph
Age and Weight Range
Safety
1
WARNING
CAUTION
Indicates a hazard or unsafe pracce that will result in severe injury
or death. Failure to read, understand and follow the safety
informaon in this manual may result in serious injury or death.
Indicates a hazard or unsafe pracce that could result in minor injury.
Indicates a hazard unrelated to personal injury, such as property damage.
NOTICE
Safety Warning Messages
The following Safety Warning Messages indicates a potenal
personal injury hazard. Failure to follow the warnings may result in
damage to property, injury, or death.
This manual contains many Warnings and Cauons concerning the
consequences of failure to follow safety warnings. Because any fall
can result in serious injury or even death, we do not repeat the
warning of possible injury or death whenever the risk of falling is
menoned.
4
-- WARNING
• Read and understand all product & safety warnings
• Do not to modify unit from original design and conguraon.
• Before each use, check to conrm: That all guards and pads in
place and in serviceable condion; That the area that the unit is
to be operated in is safe and suitable for safe operaon; That
the braking system is funconing properly; That all safety labels
are in place and understood by the operator; That any and all
axle guards, chain guards, or other covers or guards are in place
and in serviceable condion; and That res are in good
condion and have sucient tread remaining.
• Do not perform racing, stunt riding, or other maneuvers, which
may cause loss of control, or may cause uncontrolled operator
acons or reacons.
• Do not allow hands, feet, hair, body parts, clothing, or similar
arcles to come in contact with moving parts, wheels, or
drivetrain, while the motor is running.
• The owner shall allow the use and operaon of the unit aer a
demonstraon that such operators can understand and operate
all components of the unit before use.
• Obey all local trac and scooter riding laws and regulaons.
• Do not ride at night. Operate only with adequate daylight
condions of visibility.
• Persons with the following condions shall be cauoned not to
operate: Those with heart condions; pregnant women; persons
with head, back, or neck ailments, or prior surgeries to those
areas of the body; and persons with any mental or physical
condions that may make them suscepble to injury or impair
their physical dexterity or mental capabilies to recognize,
understand, and perform all of the safety instrucons and to be
able to assume the hazards inherent in unit use.
• Always wear safety equipment such as helmet, knee pads, and
elbow pads. Always wear a helmet when riding your scooter
and keep the chinstrap securely buckled. Always wear shoes.
• Wear proper riding are, reecve if possible, and avoid open
toe shoes.
• Avoid sharp bumps, drainage grates, and sudden surface
changes.
• Avoid streets and surfaces with water, sand, gravel, dirt, leaves,
and other debris. Wet weather impairs tracon, braking, and
visibility.
• Never allow more than one rider.
5
Riding a scooter without protecve gear, clothing, shoes, or a
helmet may result in serious injury or death. Always wear
protecve gear, clothing, and helmet when riding the scooter.
Ensure protecve gear does not interfere with steering,
or braking.
WARNING
Protecve Gear and Clothing
Always wear: Figure 1.1
• Colors that are easily seen and, if possible, reecve clothing.
• Clothing appropriate for the weather condions.
• Always wear shoes
• Use of protecve gear such as pads for the knees and elbows is
highly recommended for children.
• A properly ed helmet that complies with ASTM or SNELL
helmet standards.
Do not wear:
• Loose clothing parts, strings, or jewelry that may become
entangled with moving parts on the scooter or interfere with
handling of the scooter.
• Shoes with uned shoe laces.
Figure 1.1
Properly ed
helmet
Elbow pads
Knee pads
Shoes fastened
or ed
Easily seen or
reecve clothing
Personal Safety
6
Helmet Use
Important! Many states have passed helmet laws regarding
children. Make sure you know your states helmet laws. It is your
job to enforce these rules with your children. Even if your state
does not have a children’s helmet law, it is recommended that
everyone wear a properly ed helmet that complies with ASTM
or SNELL helmet standards.
The correct helmet should: Figure 1.2
• Be comfortable
• Have good venlaon
• Fit correctly
• Cover forehead
Incorrect helmet posion: Figure 1.3
• Helmet does not cover the forehead
Figure 1.3
Figure 1.2
7
Baery Warnings
WARNING!
• Liquids on the baery may cause re or electric shock.
Always keep all liquids away from the baery and keep
the baery dry.
• Contact or exposure to baery leakage (lead acid) may
cause serious injury. If contact or exposure occurs
immediately call your physician. If the chemical is on the
skin or in the eyes, ush with cool water for 15 minutes.
If the chemical was swallowed, immediately give the
person water or milk. Do not give water or milk if the
paent is voming or has a decreased level of alertness.
Do not induce voming.
• Baery posts, terminals and related accessories contain
lead and lead compounds (acid), chemicals known to
the State of California to cause cancer, reproducve
harm and are toxic and corrosive. Never open the
baery.
• Tampering or modifying the electric circuit system may
cause a shock, re or explosion and permanently
damage the system. Exposed wiring, circuitry in the
charger may cause electric shock. Always keep the
charger housing closed.
• Never store at freezing temperatures. Freezing will
permanently damage the baery.
Risk of Fire: No User Serviceable Electric Parts. The following
safety hazards may result in serious injury or death to the user of
the scooter:
• Use of a baery or charger other than the supplied
Mongoose rechargeable baeries and charger may
cause a re or explosion. Only use the supplied
Mongoose rechargeable baery and charger with the
scooter.
• Using the Mongoose rechargeable baeries and charger
for any other product may result in overheang, re or
explosion. Never use the Mongoose rechargeable
baeries with another product.
• Explosive gases are created during charging. Charge the
baery in a well venlated area. Do not charge the
baery near heat or ammable materials.
• Contact between the posive and negave terminals
may result in re or explosion. Avoid direct contact
between the terminals. Picking up the baery by the
wires or charger can cause damage to the baery and
may result in a re. Always pick up the baery by its
case or handles.
8
Parts
2Before beginning assembly, check to ensure that the parts are present. Some hardware is aached to the sub assembly.
Tube
Baery charger
Handlebar
Push buon throle
Deck
Brake
Collar clamp
Headset
Steer tube
Charge
port
O n /o
switch
5 mm hex wrench
(included)
Kickstand
(React 2 model only)
Reset buon
9
❶ Loosen the hex bolts on the collar clamp using the included
5 mm hex wrench.
❷ Insert the handlebar/tube assembly onto the headset.
❸ With the front wheel pointed ahead and the handlebars
squared, ghten the hex bolts on the collar clamp using the
hex wrench.
3Assembly
❷
❸
10
Important
Before you ride:
• Check that the brake lever works
• Check all of the locking nuts are firmly
tightened
