TURF PACKAGE
INSTALLATION AND SETUP INSTRUCTIONS
WARNING
USE OF THE TURF PACKAGE DECREASES THE
LIFTING CAPACITY TO 4000 LBS. TOTAL ( 1000
LBS. PER ARM. )
REMOVE THE FOUR 1-3/8” NYLON LOCK NUTS
FROM THE SWING ARM STUDS. ( TOP SIDE
ONLY ) THESE WILL BE REPLACED BY THE
FOUR 1-3/8“ JAM NUTS PROVIDED. See Figure 1
Figure 1
PLACE THE TURF KIT ARM STOP WELDMENTS
INTO PLACE ON THE CARRIAGES AT EACH
ARM PIN LOCATION.
USING THE FOUR 1-3/8” NYLON JAM NUTS,
ASSEMBLE THE ARM STOP WELDMENTS TO
THE CARRIAGES. See Figure 2
Figure 2
TIGHTEN THE ARM RETAINING BOLTS THAT
SURROUND EACH SIDE OF EACH ARM UNTIL
THEY ARE SECURE.
TIGHTEN THE ARM LOCKING BOLT ON THE
TOP OF THE ARM UNTIL ARM IS SECURE
FROM ROTATION. See Figure 3
Figure 3
REMOVE THE LIFTING PADS FROM THE
SLIDERS. PLACE THE FOUR LIFT PLATFORMS
INTO PLACE AT THE END OF EACH SLIDER ON
THE LIFT. NOTING APPROACH DIRECTION,
PLACE THE SIX APPROACH RAMPS INTO
PLACE ON THE LIFT PLATFORMS. See Figure 4.
Figure 4
RAISE LIFT AND INSTALL HAIRPINS AT THE
BOTTOM OF EACH LIFTING PAD PIN TO
SECURE PADS TO ARMS. See Figure 5.
Figure 5
