Modena Argento Series Manual de usuario

User

Manual Book

Water Dispenser

Argento Series

DD 7170 S

Thank you for your trust in choosing MODENA products for your household

needs. With your satisfaction as our priority, we constantly aim to deliver

stylishly designed products equipped with state-of-the-art technology to

assist you in your daily activities.

This is your guidebook containing everything you need to know about our

product. Please reach out to us if you need further assistance or other

information via our Customer Care or our official website www.modena.com.

TABLE OF CONTENTS PAGE

INTRODUCTION 2

⚫Part 1 : Name of Parts 4

⚫Part 2 : Installation 5

⚫Part 3 : How to Use 7

⚫Part 4 : Maintenance 8

⚫Part 5 : Points of Attention 9

⚫Part 6 : Troubleshooting 11

⚫Part 7 : Specification 12

Fuse

Drip tray

Water tap

Cold water

indicator

On/off

Switch

Condenser

Part 1 : Name of Parts

Door

Water level

indicator

Hot water

indicator

Drain

valve

Please read this operation manual carefully before operating the appliance in order

to use the appliance properly and safely. Pay attention to the entire sign or warning

explained on the pictures or text.

1. Install the dispenser on an even and stable

surface. A minimum distance of 20 cm from

the wall must be provided.

2. Leave the appliance for 1 hour to stabilize

the refrigerant.

3. Insert the Z-pipe into the gallon and then

cover it with the lid.

4. Insert the gallon into the cabinet. Make sure

it is installed properly and close the door.

5. Connect the power cord to the power socket,

and turn on the red switch (heater) located

behind the appliance. Make sure that the

socket/electric source has been grounded to

prevent electric leakage. Turn on the switch

located behind the appliance.

6. For initial use, the inside of the appliance

must be cleaned. Press the hot and cold

water button. Make sure the water dispenses

out of the tap. After that, wait around 20

minutes, then remove the gallon and drain

the water by opening the drain valve. Make

sure the power cord is unplugged from the

power source when draining the remaining

Part 2 : Installation

water.

7. If the gallon is empty, turn off the red switch

(heater) before replacing it with a new one.

Attention!

⚫This appliance is designed for indoor use.

⚫Avoid placing the appliance in a humid, wet, and poor electrical installation

because it can cause an electric shock or fire.

⚫Do not place flammable objects near the dispenser.

⚫Do not expose the appliance to direct sunlight and rain because it can degrade

its performance and cause electrical leakage hazard.

⚫Do not connect this dispenser to the source of electric current or pressing the

heating button if there is no water in the tank or no water flows from the hot water

tap if the button is pressed.

⚫Do not modify the power cord on the appliance or connect using extension cord

to prevent risks of short circuit and fire.

⚫Do not touch the back or the condenser to avoid electric shock.

⚫During a power outage, after the power returns, wait around 5 minutes before

turning the appliance on.

1. Lock/Unlock Button

2. Hot water button

3. Normal water button

4. Cold water button

Hot Water Operation steps:

1. Press the lock button with your finger for three seconds.

2. A beep sound will be heard. Press the hot water button immediately with your

finger. This time, hot water will dispense.

3. When the cup is already filled in with the water, release the button to stop the

water from dispensing. The safety lock will return to the locked state.

Cold Water Operation steps:

1. Press the lock button with your finger for three seconds.

2. A beep sound will be heard. Press the cold water button immediately with your

finger. This time, cold water will dispense.

3. When the cup is already filled in with the water, release the button to stop the

water from dispensing. The safety lock will return to the locked state.

Part 3 : How to Use

Normal water does not need to be unlocked. What you need to do is just press and

hold the normal water button and the machine will pump water directly from the tank.

When the cup is already filled in with the water, release the button to stop the water

from dispensing.

Attention!

⚫Beware! Avoid hazard of hot water.

⚫Cabinet door should always be closed.

⚫Do not allow the children dispense the water without direct adult supervision.

1. In order to avoid unwanted incidents, always disconnect the power cord from the

power source before cleaning the dispenser.

2. This dispenser has been disinfected prior to shipping.

3. Water pipe, water tank, and heating element must be cleaned by expert

technician once a year to maintain its good condition and to extend appliance’s

lifespan. Do not attempt to disassemble the machine in order to avoid damage to

the machine.

4. Use soft and wet cloth to clean the surface of the dispenser. Use soft and dry

cloth to dry the surface. Do not let water enter the appliance’s engine.

5. Make sure the power cord is unplugged from the power source when draining

the remaining water or when in a maintenance or when not in use for a long

time. Meanwhile, when the water from the hot tap is cold, open the drain valve

until there is no water in the appliance.

Part 4 : Maintenance

a. Install the dispenser on even surface. Avoid placing it in a

humid place. A minimum distance of 20 cm from the wall

must be provided. Do not store flammable substances near

the dispenser.

b. To avoid damage to the machine, avoid connecting power

cord or pressing the heating switch (red) until the hot water

comes out of the hot water tap.

c. If the dispenser won’t be used for a long period, turn off the

heating and cooling switches and disconnect the cord from

the power socket and drain the remaining water through the

drainage.

d. Do not use chemical substances or directly pour water to

clean the dispenser. Use soft cloth instead.

e. Do not pull the cord to disconnect the power cord from the

power socket. Hold and unplug it from the head with dry

hand.

f. Do not put the dispenser upside down. The inclination should

not be more than 45° to avoid damage to the compressor.

Part 5 : Precaution Action

g. The thermostat on the dispenser has been adjusted by the

manufacturer. Do not attempt to modify the thermostat by

yourself to avoid unwanted damage.

h. This appliance is designed for use by adults. Do not allow

children to play with the appliance or let them hang on the

door. The appliance may fall over and harm them. Children

should be supervised to ensure that they don’t play with the

appliance. The appliance is not intended for use by individual

(including children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning

the use of the appliance by a person who is responsible for

their safety.

If there is damage to the power cord, contact MODENA

Call Center immediately to do a replacement. The

replacement of power cord must be done by

experienced expert and understands about electricity.

Never replace the power cord on your own, due to the dangers that could lead

to harm yourself and others.

Attention!

This appliance must not be disposed of with other household waste. To

prevent possible harm to the environment or human health from uncontrolled

waste disposal. The appliance contains a gas insulation and refrigerant that must be

disposed of properly. When you want to dispose of the appliance, We advise you to

consult with authorized service providers so that they can learn information required

and official forms. Make sure the pipes and the duct work of refrigerant of the

appliance is not damaged before it was taken by the disposal personnel. Consult

with authorized service providers to ask everything and issues regarding the
