MobileDemand XTablet Flex 10B Manual de usuario

User Manual

xTablet Flex 10B

1501 Boyson Square Drive – Suite 101 Hiawatha, Iowa 52233 | PH: 319.363.4121 | RuggedTabletPC.com

xTablet Flex 10B

User Manual

xTablet Flex 10B

Contents

1 Introduction 3

Acknowledgments 3

Safety Notice 3

2 xTablet Diagrams 4-5

Use of xTablet and Keyboard 6

3 Introduction to Desktop 7

Image Slide Applications 7

Cortana 7

Introduction to App Interface 8

Start Menu 10

Multitasking Operating Interface 12

Sleep, Shut Down, Restart 13

VIEW

xTablet Flex 10B

1 Introduction

Acknowledgments

Congratulations on the purchase of MobileDemand’s xTablet®Flex 10B. Designed and

tested to meet our exacting standards ensures dependability and customer satisfaction.

Refer to this manual to guide you through the basic functions and features.

Safety Notice

Read the safety instructions carefully and thoroughly. All cautions and warnings on the equipment and

user’s manual should be noted.

Keep this equipment away from humidity, high temperature and ammable liquids.

Adhere to hospital protocol as it pertains to mobile devices to avoid interference with medical equipment

• To avoid damage do not leave the equipment in an unconditioned environment with a

storage temperature above 160ºF or below -22ºF (-30ºC to 71ºC).

• Operating temperature of 32ºF to 120ºF (0ºC to 49ºC) for light loading applications.

When using the USB data line, observe the guidelines provided in this manual to avoid damage.

Do not store near magnetic storage equipment.

Never pour liquid into the opening. Damage to the equipment or electrical shock could result.

xTablet Flex 10B

2 xTablet Diagrams

FRONT CAMERA

Figure A: Front Panel

Figure B: Left Side Panel

TYPE-C

MINI HDMI

USB 3.0

EARPHONE

SD CARD

SPEAKER

Figure C: Right Side Panel

SPEAKER

xTablet Flex 10B

Figure D: Top Side Panel

VOLUME KEYPOWER

Figure E: Bottom Side Panel

REMOVABLE SNAP WALL

POGO PIN

REAR CAMERA

Figure E: Back Panel

REMOVABLE

SNAP WALL

xTablet Flex 10B

Optional Keyboard

4 5

1. Flexible Base Keyboard Interface: Magnetic attachment holds keyboard rmly in place

2. Keyboard Group: Full size QWERTY key.

3. Touch Tablet: Cursor control similar to mouse

4. Left Key

5. Right Key

xTablet Flex 10B

3 Desktop

Windows 10 start image: On the start screen, you can see many programs xed in the image.

These application programs are displayed in the form of “magnet”.

Use Cortana for fast smart searching.

You need to log on your Microsoft account before the application program completely runs

Cortana

Image Slide Application

xTablet Flex 10B

Besides the application programs already xed on the “start” screen, you can also x other applications,

programs, folders, etc to the “start” screen.

If you want to x more application programs on the start interface, see the operation in the gure below.

In the start menu, right-click the application you want to x and select “Pin to Star”.

You can also drag the application onto the “start” screen, as follows:

Conversely, if you want to cancel or delete a certain application in the start screen:

(1) Right-Clicking the application

(2) Click the “Unpin from Start”.

Introduction to App Interface

xTablet Flex 10B

If you want to x more application programs on the taskbar, see the operation in the gure below.

In the start menu, right-click the application you want to x and select “More”, and then select

“Pin to Taskbar”. You can also drag the application onto the “start” screen, as follows:

Conversely, if you want to cancel or delete a certain application in the taskbar:

(1) Right-Clicking the application

(2) Click the “Unpin this program from taskbar”.

xTablet Flex 10B

3.6 Start Menu

Under PC mode, press Start icon, Start Menu will display including:

Start, Device, Setup, Share, and Search Program.
