Mitsubishi LANCER 2017 Guía del usuario

Owner’s Handbook

(6/16)

www.mitsubishicars.com

2017 LANCER

Dieline -DO NOT PRINT!

PLEASE PLACE COPIES OF THE FOLLOWING ITEMS IN THE POCKET BELOW:

1. Pre-Delivery Inspection Form (Customer Copy)

2. Triple Diamond Delivery Checklist (Customer Copy)

3. Salesperson or Key Dealership Contact’s Business Card

Owner’s Handbook

(6/16)

www.mitsubishicars.com

2017 LANCER

Dieline -DO NOT PRINT!

Thank you for buying a Mitsubishi Lancer. There’s no doubt you’ve already realized how well

your car drives on the open road. What you may not know is all the great features that help

your car perform the way it does. In the pages ahead we’re going to run through the basics

and prepare you for the road.

We hope you will visit the Mitsubishi Owner’s site where we store the latest Mitsubishi news

and special offers. Here you can also keep track of your car’s warranty and servicing needs,

get Roadside Assistance Information and tap into other owner-centric details. Just log on to

www.Mitsubishicars.com/ownersonly.

Driver’s View ..................... Page 2-3

Controls ............................ Page 4-6

Own the Road................... Page 7

Technology ....................... Page 8

Display Audio System........ Page 9

Bluetooth® ....................... Page 11

FAQ’s................................ Page 12-13

Table of Contents

Driver’s View

1Headlights and Fog Lights............ Page 4

2Side

Mirror Adjustment

................. Page 5

3Trunk & Fuel Release Levers ........ Page 5

4 Automatic Temperature Control .... Page 6

5Windshield Wiper Lever................ Page 6

6Cruise Control ............................. Page 7

7 Multi-Information Display (MID) ... Page 8

8Display Audio System................... Page 9

9Audio Remote Control Switch ....... Page 10

10 USB Port ..................................... Page 10

11 Bluetooth®Controls...................... Page 11

(Inside Front

Center Console)

The phone and cord are not included

in the purchase of the vehicle.

4CONTROLS

Regular Headlights Auto ON/OFF Headlights (if equipped)

Headlights and other lights on.

Parking, tail, front and rear sidemarker lights, license plate and

instrument panel lights on.

Headlights and other lights turn on and off automatically in

accordance with outside light level.

All lights off

AUTO

OFF

Fog Lights

High/Low Beam Switch

Fog Lights will illuminate only when headlights are on low beam.

Turning the knob in the direction of the ON position turns on the

fog lights. Turning the knob in the direction of the OFF position

turns off the fog lights. The knob will return to the neutral

position when released.

To change the headlights from

high beam to low beam and vice

versa, pull the turn signal lever fully

towards you (1). An illuminated

blue light in the instrument cluster

indicates when the headlights are on

high beam.

• Headlight ﬂasher

You can ﬂash the high beams by

pulling the lever gently towards

you (2).

LED Running Lights

Off - The LED Running Lights illuminated

AUTO - The LED Running Lights illuminated

(when it is light outside the vehicle)

Headlights and other lights turn on and off

automatically in accordance with outside light

level.

Note - Once the LED Running Lights come on,

they do not go out until the key is turned to the

LOCK or ACC position.

OFF

AUTO

CONTROLS

Side Mirror Adjustment

Seat Heater Switch (if equipped)

Position - Action

(HI) - Provides a higher level of heating

(LO) - For lower level of heating

Trunk and Fuel Release Levers

Both the trunk and the fuel release levers are located on the

driver’s side ﬂoor next to the seat. To release the Trunk, pull

up on the larger, outer release lever.

To release the Fuel door, pull up on the smaller, inside lever.

To adjust the mirrors

on each side, slide

the switch toward the

mirror you would like

to adjust and use the

directional pad to make

the needed changes.

A- Turn for temperature control

B- Push to select outside air (Indicator light off) or recirculated air (Indicator light on)

C- Turn to select the blower speed. To the right increases blower speed. To the left decreases

blower speed. Turned all the way to the left places the blower in AUTO mode.

Note: OFF is located above AUTO.

D- Push for air conditioning ON/OFF (Indicator light on/Indicator light off).

E- Turn to select the air ﬂow and direction mode

F- Push to defog the rear window (Indicator light on). Rear window

defogger light automatically turns off after 20 minutes.

To defog front windshield

1. Set the Mode Dial Eto defrost position.

2. Set the blower speed Cto the maximum position.

3. Set the temperature Ato highest position.

A C EB D F

The wipers will operate once.

INT: Intermittent intervals can be

adjusted by turning the knob

AUTO: The wipers will be operated

automatically by rain sensor

(if equipped).

Slow

Fast

Rain Sensing Wipers (if equipped)

It is possible to adjust the sensitivity of the rain sensor

by turning the AUTO ring C .

+ Higher sensitivity to rain

– Lower sensitivity to rain.

Windshield Wipers

CONTROLS

Automatic Temperature Controls

A -CANCEL: To deactivate the cruise control

B -ACC RES: To increase the set speed or resume previously set cruise control operation

C- COAST SET: To set the desired speed and to reduce the set speed

D- ON/OFF: To turn ON/OFF cruise control

To set a cruising speed

1. Press Dand the CRUISE indicator light in the meter cluster will be turned on.

2. Accelerate or decelerate to your desired speed (above 25 mph). Press

Cand remove your foot from the accelerator pedal.

To accelerate or decelerate speed

Press

Bto increase set cruising speed.

Press

Cto decrease set cruising speed.

To cancel the cruising speed

Press Aor press brake pedal, or press D .

OWN THE ROAD

Drive Mode Selector (if equipped)

The drive mode can be selected by pressing the

switch while the ignition switch is in the ON

position.

2WD: This mode is for economical driving on normal

dry roads and freeways.

4WD AUTO: This mode is for all driving conditions on

various roads.

4WD LOCK: This mode is for driving in slippery

conditions such as on snow-covered roads or sand.

Cruise Control

8TECHNOLOGY

Multi-information Meter Switch (INFO Button)

Keyless Entry System

FAST-Key Normal Key

LOCK

Press: Lock all doors

UNLOCK

Press: Unlock driver door

Twice – Unlock all doors

TRUNK

Press twice to open trunk lid.

PANIC

Press and hold. Press any button to

turn off panic.

To lock or unlock the doors while

carrying the FAST-key, press the

driver’s or front passenger’s door

lock/unlock switch A .

Change display information

by pushing the INFO button:

Warnings, Odometer/

Tripmeter, Service Reminder,

Average and Momentary

Fuel Consumption, Driving

Range, Average Speed, etc.

Multi-information

meter

Tire Pressure Monitoring System (TPMS)

The Tire Pressure Monitoring System light illuminates when one or more

of your tires is signiﬁcantly underinﬂated. Please note that changes in the

outside temperature may decrease tire pressure causing the TPMS light to

turn on. If the TPMS light remains illuminated, check your tire pressure.

Warning light

illuminates when

tire pressure is

too low.

If warning light

illuminates, contact your

local Mitsubishi dealer.

(May be a TPMS system

issue or malfunction).

ECO Driving (if equipped)

When the ECO

indicator light is on,

your current driving

style supports good

fuel economy.
