Mitsubishi Electric LDT322V Manual de usuario

MITSUBISHI

ELECTRIC

PRESENTATION PRODUCTS

Leading the evoLution of

HIGH-DEFINITION

digital signage

Advanced high-definition digital signage display•

WXGA 1366 x 768 native resolution•

Reduces power consumption by 40%•

Multiple screen saver function•

Programmable scheduling•

www.mitsubishi-presentations.com

888.307.0349

LDT322V

32” LCD Monitor

CLASS 32” (Diagonal) LCD Monitor

VIEWABLE IMAGE SIZE 27.5” x 15.4”

ORIENTATION Landscape / Portrait

BRIGHTNESS/LUMENS 450 cd/m2

PIXEL PITCH 0.511 mm

CONTRAST RATIO 2500:1

DIMENSIONS

(W x H x D in.)

31.1” x 18.8” x 5.2” (without stand)

WEIGHT

(WITHOUT STAND

AND SPEAKERS)

32 lbs. (Net)

BEZEL WIDTH 1.8”

RESPONSE TIME 6.5 ms (gray to gray)

VIEWING ANGLE Horizontal and vertical: 178O

VIDEO/AUDIO

INPUTS AND OUTPUTS

mini D-Sub 15 pin In/Out, DVI-D, BNC

(R,G,B,H,V), S-Video, Composite (BNC,

RCA), Component (BNC), Audio LR

(RCA), Audio Stereo mini jack

SPEAKER OUTPUT External speaker jack

CONTROL INPUT/OUTPUT RS232C (mini D-Sub 9 In/Out)

POWER CONSUMPTION

(WITHOUT SPEAKERS)

85 W

ESTIMATED BACKLIGHT LIFE Up to 50,000 hours*

AUDIO SPEAKER Optional: SP-322V

TABLE STAND Optional: ST-322V

WALL MOUNT

COMPATABILITY

Optional: CTM-VESA

WARRANTY 3-years parts and labor, Express

Replacement Assistance, toll-free 24x7

technical support

*Results may vary depending on usage and operating environment

MITSUBISHI

ELECTRIC

PRESENTATION PRODUCTS

MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC.

Presentation Products Division

Toll Free: 888.307.0349

Email: [email protected]

www.mitsubishi-presentations.com

Canada

Mitsubishi Electric Sales Canada Inc.

Information Technologies Group

Phone: 905.475.7728

www.mitsubishielectric.ca

LITLDT322V

Optional Stand:

ST-322V

LDT322V

32” LCD Monitor

multiple standard input and output connectors

AC IN connector

RGB 1 in (DVI-D)

RGB 2 IN (mini D-Sub 15 pin)

RGB 3 IN (R,G,B,H,V) (BNC)

RGB OUT (mini D-Sub 15 pin)

DVD/HD IN (BNC)

AUDIO IN 1,2,3

AUDIO OUT

VIDEO IN/OUT

EXTERNAL CONTROL (mini D-Sub 9 pin)

EXTERNAL SPEAKER TERMINAL

951

Rear Connector

Panel

Optional Speakers:

SP-322V

789

701

476

395

133
