Mini Gadgets HCMP4HD Manual de usuario

VIDEO AND VOICE

RECORDER WITH

WIRELESS CHARGING

SKU: HCMP4HD

THANK YOU FOR PURCHASING THE VIDEO AND VOICE

RECORDER WITH WIRELESS CHARGING

Please read this manual before operating the Video and Voice

Recorder with Wireless Charging and keep it handy.

The HCMP4HD is a compact device capable of holding up to 138

hours of audio recordings on its internal 8GB of storage or up to a

massive 546 hours with a 32GB MicroSD card. Not only does this

device has its own internal storage, but it also has the option to take

up to an additional 32GB via its MicroSD slot. The sleek and modern

design fits in almost anywhere. It features a camera capable of

recording clear 720p video as well as a full touchscreen front for easy

control of all aspects of the device! The unit charges easily with the

included USB cable either directly from your PC, wall AC adapter, or

the included wireless charging mat for easy charging. No need to

fiddle with plugging and unplugging cables, just lay it down on the

mat and it automatically start charging! Plenty of storage capacity for

everyday use. Connect to the PC for simple plug-and-play recovery of

your audio and video recordings.

Your purchase should include:

1 x Video and Voice Recorder with Wireless Charging

1 x Micro USB Cable

1 x Wall Adapter

1 x Wireless Charging Mat

1 x Set of Earphone

1 x Instruction Booklet

GET FAMILIAR WITH YOUR VIDEO AND VOICE RECORDER

WITH WIRELESS CHARGING

Microphone

Indicator

Light

Back

Video Record

Audio Record

Photograph

Previous /

Rewind

Volume Down

OK / Play

Next /

Fast Forward

Volume Up

Power

Button

Earphone Jack

Camera Lens

MicroSD Card Slot

Reset Hole

USB Port

OPERATING THE VIDEO AND VOICE RECORDER WITH

WIRELESS CHARGING

HOW TO CHARGE THE DEVICE

Charging via Your Computer

1. Connect the wireless charging pad to your computer using the

included USB cable

The red indicator light on the charging pad will turn on

2. Place the recorder on the charging pad as shown below

The red indicator light on the device will blink while

charging and the screen will show a green battery with

a red lightning bolt

HELPFUL TIP: Charging takes 5 hours using this method

Charging via Household Outlet

1. Plug the included AC adapter into a household outlet

2. Connect the wireless charging pad to the AC adapter using the

included USB cable

The red indicator light on the charging pad will turn on

3. Place the recorder on the charging pad as shown below

The red indicator light on the device will blink while

charging and the screen will show a green battery with

a red lightning bolt

HELPFUL TIP: Charging takes 3 hours using this method

HOW TO POWER THE DEVICE ON AND OFF

1. Press and hold the Power Button for 3 seconds

The screen will initialize

The screen will go to the main menu

2. Press and hold the Power Button for 3 seconds

The screen will power down

HELPFUL TIP: The recorder will turn itself off if left idle for 2

minutes. You can change this in the “How to Change Power Idle

Time”section.

Power on…

Power off…

HOW TO USE VIDEO MODE

1. Use the Previous and Next button to select the Video icon on

the screen (a red box appears around the selected icon)

2. Press the OK button

3. The following video mode screen will appear

How to Adjust the Brightness

1. Press the Volume Up and Volume Down buttons

How to Change the Video Resolution

1. Press the Menu button

2. Press the Previous or Next buttons to select “Video Size”

3. Press the OK button

4. Press the Previous or Next buttons to select HD or VGA

5. Press the OK button

6. Press the Back button

How to Turn the Time Stamp On or Off

1. Press the Menu button

2. Press the Previous or Next buttons to select “REC TimeStamp”

3. Press the OK button to select “On” or “Off”

4. Press the Back Button

How to Record Video

1. Press the Video Record button or simply tap the screen to

start recording

2. The following screen will appear

3. Press the Video Record button or simply tap the screen to stop

recording

HELPFUL TIP: The device automatically saves and starts a new

video every 30 minutes

How to Play Video

1. Ensure you are in the video mode screen

2. Press the OK button

A list of recorded video file names will appear

3. Press the Next or Previous button to browse the list

4. Press the Play button to play the desired video

Press the Play button again to pause the video

Press and hold the Fast Forward or Rewind to perform

these functions

Press the Previous or Next buttons to switch videos

Press the Back button to return to the video list

5. To delete a video, select the desired video file and press the

Menu button

6. Press the Previous or Next buttons to select the desired delete

option

7. Press the OK button

8. Press the Previous or Next buttons to select “Yes” or “No”

9. Press the OK button

Current Time

Battery Life

Live Image Feed

Video Resolution

Recording Time

Battery Life

Live Video Feed

Video File Name

HOW TO USE PHOTOGRAPHY MODE

1. Use the Previous and Next button to select the Photo icon on

the screen (a red box appears around the selected icon)

2. Press the OK button

3. The following photo mode screen will appear

How to Adjust the Brightness

1. Press the Volume Up and Volume Down buttons

How to Change the Photo Resolution

1. Press the Menu button

2. Press the Previous or Next buttons to select “Capture Size”

3. Press the OK button

4. Press the Previous or Next buttons to select 2M, 5M, or 8M

5. Press the OK button

6. Press the Back button

How to Turn the Time Stamp On or Off

1. Press the Menu button

2. Press the Previous or Next buttons to select “Capture

TimeStamp”

3. Press the OK button to select “On” or “Off”

4. Press the Previous or Next buttons to select “HD” or “VGA”

5. Press the OK button

6. Press the Back Button

How to Turn the Sound On or Off

1. Press the Menu button

2. Press the Previous or Next buttons to select “Capture Sound”

3. Press the OK button to select “On” or “Off”

4. Press the Back Button

How to Take a Photo

1. Press the Photograph button or simply tap the screen to start

recording

If the capture sound is on, you will hear a camera

shutter sound

If the capture sound is off, you will not hear anything

How to View Photos

1. Ensure you are in the photo mode screen

2. Press the OK button

A list of photo file names will appear

3. Press the Next or Previous button to browse the list

4. Press the OK button to view the desired photo

Press the Previous or Next buttons to switch photos

Press the Back button to return to the video list

5. To delete a photo, select the desired video file and press the

Menu button

6. Press the Previous or Next buttons to select the desired delete

option

7. Press the OK button

8. Press the Previous or Next buttons to select “Yes” or “No”

9. Press the OK button

Current Time

Battery Life

Live Image Feed

Photo Resolution

HOW TO USE VOICE RECORD MODE

1. Use the Previous and Next button to select the Record icon on

the screen (a red box appears around the selected icon)

2. Press the OK button

3. The following record mode screen will appear

How to Change the Record Quality

1. Press the Menu button

2. Press the Previous or Next buttons to select “Record Quality”

3. Press the OK button

4. Press the Previous or Next buttons to select LP, SP, or HP

5. Press the OK button

6. Press the Back button

How to Change the Voice Activation Level

1. Press the Menu button

2. Press the Previous or Next buttons to select “Voice Set”

3. Press the OK button

4. Press the Previous or Next buttons to select the desired

decibel level

5. Press the OK button

6. Press the Back Button

How to Record Audio

1. Press the Audio Record button to start and stop recording

HELPFUL TIP: The recorder will automatically save and start a new

sound file every 4 hours

How to Play a Recording

1. Ensure you are in the record mode screen

2. Press the OK button

A list of recording file names will appear

3. Press the Next or Previous button to browse the list

4. Press the OK button to listen to the desired recording

Press the Play button again to pause the recording

Press and hold the Fast Forward or Rewind to perform

these functions

Press the Previous or Next buttons to switch

recordings

Press the Back button to return to the recording list

5. To delete a recording, select the desired audio file and press

the Menu button

6. Press the Previous or Next buttons to select the desired delete

option

7. Press the OK button

8. Press the Previous or Next buttons to select “Yes” or “No”

9. Press the OK button

HOW TO CHANGE THE SETTINGS

1. Use the Previous and Next button to select the Record icon on

the screen (a red box appears around the selected icon)

2. Press the OK button

3. You will see a list of settings options

How to Change Languages

1. Press the Previous or Next buttons to select “Language”

2. Press OK

3. Press the Previous or Next buttons to select your desired

language

4. Press OK

Current Time

Battery Life

Record Mode

Record Status

Current Recording Time

Remaining Recording Time

How to Change the Time and Date

1. Press the Previous or Next buttons to select “Time Settings”

2. Press OK

3. Press the Previous or Next buttons to select the day, month,

or year

4. Press the Volume Up or Down buttons to change the day,

month or year

5. Press the Previous or Next buttons to select the hour, minute,

or seconds (military)

6. Press the Volume Up or Down buttons to change the hour,

minute or seconds

7. Press OK

How to Change Storage Directory

1. Press the Previous or Next buttons to select “Storage Dir”

2. Press OK

3. Press the Previous or Next buttons to select your desired

storage type

4. Press OK

How to Change the Power Idle Time

1. Press the Previous or Next buttons to select “PowerOff Set”

2. Press OK

3. Press the Previous or Next buttons to select how long you

want the recorder to wait until it powers itself down

4. Press OK

How to Change the Backlight Timer

1. Press the Previous or Next buttons to select “Backlight Timer”

2. Press OK

3. Press the Previous or Next buttons to select you want the

backlight to stay on

4. Press OK

TROUBLESHOOTING

THE DEVICE WON’T TURN ON

Charge the device for at least 4 hours before the first use

Make sure the charging cable is securely inserted into the

device and into the power source

THE DEVICE ISN’T CHARGING

Replace the battery or charging cable

If you are charging via a wall power source, you may need to

charge via your PC. The AC adapter might be bad.

THE DEVICE HAS CRASHED

You need to reset the device

MY COMPUTER DOESN’T RECOGNIZE THE DEVICE

Unplug the device from your PC and reboot the device

Unplug the device from your PC and reboot your PC

Try using a different USB slot on your PC

Replace the USB cable

THE SOUND OR VIDEO IS UNCLEAR

The device needs charging

Manuales populares de Grabadora de voz de otras marcas

Sony

Sony ICD-UX533F Manual de usuario

RCA

RCA VR5230 Manual de usuario

Ramsey Electronics

Ramsey Electronics BULLSHOOTER ENDLESS LOOP BS2C Guía del usuario

Sony

Sony TCM-400DV Manual de usuario

LogTag

LogTag TREL30-16 Manual de usuario

SVAT

SVAT CVP800 Manual de usuario

Marantz

Marantz PMD620 Manual de usuario

Zoom

Zoom H4next Manual de usuario

Roland

Roland BR-900CD Manual de usuario

JVC

JVC ProHD GY-HMZ1U Manual de operación y mantenimiento

Panasonic

Panasonic PQT8531-P Manual de usuario

Sanyo

Sanyo TRC-6400 Manual de usuario

Tascam

Tascam DR-07 Manual de usuario

Olympus

Olympus DW-90 Manual de usuario

Sanyo

Sanyo ICR-B150 Manual de usuario

Korg

Korg D4 Manual de usuario

Sony

Sony ICD-SX46 - Ic Recorder Manual de usuario

Olympus

Olympus DIGITAL VOICE RECORDER WS-200S Instrucciones de montaje
