Strong points
•High Speed Printing
•Printing with LUS150 ink, CMYK at
a 60m2/h and 45m2/h in a CMYK+W mode
•New combination Print head, LED-UV unit
and UV-Ink
•High Image Quality
•New print head and advanced LED curing to produce an
exceptionally high resolution image quality
•Variable dot sizes enables a rich gradation expression
•Able to print a 2pt font size
3
JFX500-2131
Mimaki Europe B V
Industrial Products
Strong points
•”Speed” & ”Image quality”
•Combines the two essentials of wide-format printing,
at a higher level
•Eco-Friendly
•The adopted LED-UV curing system which leads to
pro-environment production
•User friendly
•Equipped with the several New functions,
•the layout pins
•the degassing system
•the white ink circulation system
•These functions enables the stable and easy printing
JFX500-2131
4
Mimaki Europe B V
Industrial Products
Configuration
5
USB 2 0
5m(15ft) cable is recommended
Corresponds with PS,EPS,TIFF,BMP,JPEG, etc.
Output
Basic Configuration
&
JFX500-2131
Recommended hardware specifications
CPU: Core i5 3.1GHz
Memory: 4GB
HDD: 500GB
I/F : USB2.0 4 ports or higher
ODD: DVD-ROM
OS: Windows7 / 32bit / Pro
Monitor: 1366x768
Mimaki Europe B V
Industrial Products
•The reduction of power consumption and CO2 emission
•Reduction of impact from heat
•With an metal halide lamp the media reaches an temperature of 70˚C or more, which can cause
deformation of the media
•The LED UV lamp generates less heat and opens up the possibility to print on
cheaper and heat sensitive media
•Improvement of the production environment
•Less maintenance with a long-life LED UV lamp (more than 5000 hours)
Note: The lifetime of a general metal halide lamp is about 700 - 1000 hours
Eco-Friendly
6
JFX500-2131
Mimaki Europe B V
Industrial Products
•Comparison of LED UV lamp with a metal halide lamp
Eco-Friendly
7
JFX500-2131
Immediately Uptime / Downtime
+/- 5 minutes
Room temperature Maximum temperature
70℃
More than 5,000 hours About 1000 hours
2kWh 8,2kWh
Generates
Temperature
Life time
Uptime/Downtime
Electric power
Ozone
Controlled air is required to cool down
Metal halide lamp
LED UV lamp
None
CO2 Emission 0,72kg 2,95kg
The power consumption when printing on 20 boards, the size of 1220mm x 2440(4 x 8)
Mimaki Europe B V
Industrial Products
•Newly developed print heads
•An total of 6 print heads
•In staggered configuration, in 3 rows
•Efficient ink jetting
•With LUS150, 60m²/h for CMYK and 45m²/h in combination with white ink is realized
High Speed Printing
8
JFX500-2131
*The print speed using LH-100 is different from LUS-150 because the curing property is different.
Mimaki Europe B V
Industrial Products
7,1
18,1
26,2
33,8
45
10,5
26
37,1
47,1
60
010 20 30 40 50 60 70 80
1200x1200 16P Uni/Nr
600x900 12P Bi/Hi
600x600 8P/Bi/Hi
300x450HQ 6P/Bi/Nr
300x450HQ 3P/Uni/Nr
600x600 4P/Bi/Hi
CMYK CMYK＋W
Print speed (CMYK only!)
m²/h
Production
Standard
Quality
Draft
W
MCYKW
MCYKor
Printing with LUS-150 LED UV Ink
•MAPS-II is available, except in Draft mode
•MAPS-II can be switched by the operation panel. MAPS-II is ON by default
•When using MAPS-II the nozzle recovery function cannot be used
•Supported in 1/20 by F/Wver2.1
9
MAPSⅡ
cannot be
used in Draft
mode
Mimaki Europe B V
Industrial Products
5,9
7,1
9,4
18,1
26,2
0 5 10 15 20 25 30 35 40
1200x1200 32P Uni/Nr
1200x1200 16P Uni/Nr
600x900 24Pass Bi/Hi
600x900 12Pass Bi/Hi
600x600 8P/Bi/Hi
Quality
Standard
Production
m²/h
Print speed (White only / 2-layer printing) W
MCYKW
Printing with LUS-150 LED UV Ink
•The recommended density of white is 100% (set 50% and 50% in
RasterLink) when using Production mode
•The density can be set higher than 100%, but the color of the printed result
may be uneven depending on the media
10
High Quality
High speed
