Milnor 48040F7J Manual de funcionamiento

Published Manual Number/ECN: MQIHNM01U2/2017135A

• Publishing System: TPAS2

• Access date: 03/30/2017

• Document ECNs: Latest

48040F7J, F7Z, H7R

PELLERIN MILNOR CORPORATION POST OFFICE BOX 400, KENNER, LOUISIANA 70063-0400, U.S.A.

MQIHNM01U2/17135A

1 1. English

3 Maintenance Guide—Rubber Spring-resting, Non-tilt

Washer-extractor MQIHNM01EN/20120917

41 2. Español

43 Mantenimiento—Lavadora-extractora sin inclinación con

soporte de muelles de goma MQIHNM01ES/20120917

English 1

Published Manual Number: MQIHNM01EN

• Specified Date: 20120917

• As-of Date: 20120917

• Access Date: 20120917

• Depth: Detail

• Custom: n/a

• Applicability: IHN

• Language Code: ENG01, Purpose: publication, Format: 1colA

Maintenance Guide—

Rubber Spring-resting,

Non-tilt

Washer-extractor

PELLERIN MILNOR CORPORATION POST OFFICE BOX 400, KENNER, LOUISIANA 70063 - 0400, U.S.A.

Applicable Milnor®products by model number:

48040F7J 48040F7W 48040F7Z 48040H7R 48040H7W

Table of Contents

PELLERIN MILNOR CORPORATION

Table of Contents

Sections Figures, Tables, and Supplements

Chapter 1. Machine Description, Identification, and

Certification

1.1. About This Milnor®Machine—Rubber Spring-resting,

Non-tilt Washer-extractor (Document BIUUUF01)

1.1.1. Functional Description

1.1.2. Machine Identification

1.2. General Content of the EC-Declaration of Conformity

(Document BIWUUL01)

Chapter 2. Safety

2.1. Safety— (Document BIUUUS27)

2.1.1. General Safety Requirements—Vital Information for

Management Personnel (Document BIUUUS04)

2.1.1.1. Laundry Facility

2.1.1.2. Personnel

2.1.1.3. Safety Devices

2.1.1.4. Hazard Information

2.1.1.5. Maintenance

2.1.2. Safety Alert Messages—Internal Electrical and

Mechanical Hazards (Document BIUUUS11)

2.1.3. Safety Alert Messages—Cylinder and Processing

Hazards (Document BIUUUS13)

2.1.4. Safety Alert Messages—Unsafe Conditions (Document

BIUUUS14)

2.1.4.1. Damage and Malfunction Hazards

2.1.4.1.1. Hazards Resulting from Inoperative Safety

Devices

2.1.4.1.2. Hazards Resulting from Damaged Mechanical

Devices

2.1.4.2. Careless Use Hazards

2.1.4.2.1. Careless Operation Hazards—Vital Information

for Operator Personnel (see also operator hazards

throughout manual)

2.1.4.2.2. Careless Servicing Hazards—Vital Information

for Service Personnel (see also service hazards

throughout manuals)

2.2. Prevent Damage From Chemical Supplies and Chemical

Systems (Document BIWUUI06)

2.2.1. How Chemical Supplies Can Cause Damage

2.2.1.1. Dangerous Chemical Supplies and Wash Formulas

Table of Contents

PELLERIN MILNOR CORPORATION

Sections Figures, Tables, and Supplements

2.2.1.2. Incorrect Configuration or Connection of Equipment Figure 1: Incorrect Configurations That

Let the Chemical Supply Go In the

Machine by a Siphon

Figure 2: Incorrect Configurations That

Let the Chemical Supply Go In the

Machine by Gravity

2.2.2. Equipment and Procedures That Can Prevent Damage

2.2.2.1. Use the Chemical Manifold Supplied. Figure 3: Examples of Manifolds for

Chemical Tubes. Your equipment can

look different.

2.2.2.2. Close the line.

2.2.2.3. Do not let a vacuum occur.

2.2.2.4. Flush the chemical tube with water.

2.2.2.5. Put the chemical tube fully below the machine inlet. Figure 4: A Configuration that Prevents

Flow in the Machine When the Pump

is Off (if the chemical tube and tank

have no pressure)

2.2.2.6. Prevent leaks.

Chapter 3. Routine Maintenance

3.1. Routine Maintenance—Rubber Spring-resting, Non-tilt

Washer-extractor (Document BIUUUM09)

3.1.1. How To Show the Maintenance On a Calendar Table 1: Where to Put Marks On a

Calendar

3.1.2. Maintenance Summary Table 2: Guards and Related Components

Table 3: Filters, Screens, and Sensitive

Components

Table 4: Fluid Containers

Table 5: Components that Become Worn

Table 6: Bearings and Bushings. See Table

7 for Motors.

Table 7: Motor Grease Schedule. Use the

data in Section 3.1.4.3 to complete this

table.

Table 8: Mechanisms and Settings

3.1.3. How to Remove Contamination Table 9: Contamination Types, Cleaning

Agents, and Procedures

3.1.4. Lubricant Identification and Procedures Table 10: Lubricant Identification

3.1.4.1. Grease Gun Procedures

3.1.4.2. Procedures for Bearing Components Connected to a

Grease Plate

3.1.4.3. Procedures for Motors Figure 5: Motor Grease Maintenance

Conditions

Table 11: Motor Grease Intervals and

Quantities. Use grease EM (Table 10)
