Operating and installation instructions

Built-in food warming drawer

ESW 47.2

ESW 48.2

To avoid the risk of accidents or

damage to the appliance it is

essential to read these

instructions before it is installed

and used for the first time. M.-Nr. 07 462 960

en-GB

Guide to the appliance .............................................4

Front view.........................................................4

Control panel ......................................................5

Accessories supplied ...............................................6

Warning and Safety instructions .....................................7

Caring for the environment.........................................11

Before using for the first time.......................................12

Operation .......................................................14

Functions ........................................................14

Temperature settings...............................................15

Duration .........................................................15

Sabbath mode ....................................................17

Capacity ........................................................18

Keeping food warm ...............................................19

Settings .........................................................20

Warming crockery ................................................21

Heating up times ..................................................21

Other uses ......................................................22

Cleaning and care ................................................25

General notes ....................................................25

Appliance front and interior ..........................................25

Anti-slip mat ......................................................26

Problem solving guide ............................................27

Optional accessories..............................................29

Contents

Safety instructions for installation...................................30

Building-in dimensions ESW 47*2 ...................................31

Building-in dimensions ESW 48*2 ...................................33

Installing the appliance ............................................34

Aligning the front of the food warming drawer.........................35

Fixing the furniture front ...........................................36

Electrical connection..............................................38

After sales service, data plate ......................................40

Contents

Front view

aControl panel

bAnti-slip mat

cAir vents

dRack

Guide to the appliance

Control panel

Sensor switches

sOn/Off switch for the appliance

Menu For selecting the function

Temp. For setting the temperature

Timer For setting the duration

Displays

Functions:

/For warming cups and glasses

HFor warming plates and dishes

2For keeping food warm

Temperature:

]^^^^

Duration:

1h 1 hour

2h 2 hours

3h 3 hours

4h 4 hours

Guide to the appliance

Accessories supplied

The accessories supplied with your drawer as well as a range

of optional ones are available to order (see "Optional

accessories").

Rack

For increasing the loading area

Anti-slip mat

For keeping crockery secure

Guide to the appliance

This appliance complies with all

relevant local and national safety

requirements. Inappropriate use

can, however, lead to personal injury

and damage to property.

To avoid the risk of accidents and

damage to the appliance, please

read these instructions carefully

before using it for the first time.

They contain important notes on the

installation, safety, operation and

care of the appliance.

Keep these instructions in a safe

place and ensure that all users are

familiar with the contents. Pass them

on to any future owner of the

appliance.

Correct application

~This appliance is intended for

domestic use only, and must only be

used as described in these instructions.

Any other usage is at the owner's risk

and could be dangerous. The

manufacturer cannot be held liable for

damage resulting from incorrect or

improper use or operation.

~This appliance is not intended for

use by persons (including children)

with reduced physical, sensory or

mental capabilities, or lack of

experience or knowledge, unless they

are supervised whilst using it, or have

been shown how to use it correctly by a

person responsible for their safety.

Safety with children

~This appliance is only intended for

use by adults who have read these

instructions. The appliance is not a toy!

To avoid the risk of injury, keep children

away from it at all times, and do not let

them play with it or use the controls.

They will not understand the potential

dangers posed by it. They should be

supervised whenever you are working

in the kitchen.

~Older children may only use the

appliance after its operation has been

clearly explained to them and they are

able to use it safely, recognising the

dangers of misuse.

~The appliance gets hot when in use

and remains hot for quite a while after

being switched off. To safeguard

against burning, keep children well

away from the appliance at all times.

~Packaging, e.g. cling film,

polystyrene and plastic wrappings,

must be kept out of the reach of babies

and young children. Danger of

suffocation. Dispose of or recycle all

packaging safely as soon as possible.

Warning and Safety instructions

Technical safety

~Before installation, check the

appliance for visible signs of damage.

Under no circumstances should you

use it if it has been damaged. A

damaged appliance is dangerous.

~Before connecting the appliance to

the mains supply, make sure that the

connection data on the data plate

(voltage and connected load)

correspond with the mains electricity

supply, otherwise the appliance could

be damaged. If in any doubt, consult a

qualified electrician.

~The electrical safety of this

appliance can only be guaranteed

when continuity is complete between it

and an effective earthing system. It is

most important that this basic safety

requirement is present and regularly

tested, and where there is any doubt,

the household wiring system should be

inspected by a qualified electrician.

The manufacturer cannot be held liable

for the consequences of an inadequate

earthing system (e.g. electric shock).

~This appliance may be connected

via a fused plug and switched socket. If

you wish to connect it to a fused spur

connection unit, or if the appliance is

supplied without a plug, it must be

installed and connected by a suitably

qualified and competent person in strict

accordance with current local and

national safety regulations. The

manufacturer cannot be held liable for

damage caused by incorrect

installation or connection.

~For safety reasons, this appliance

may only be used when it has been

built in.

~Never open the housing of the

appliance.

Tampering with electrical connections

or components and mechanical parts is

highly dangerous to the user and can

cause operational faults.

~Installation, maintenance and

repairs may only be carried out by a

suitably qualified and competent

person in strict accordance with current

national and local safety regulations.

Repairs and other work by unqualified

persons could be dangerous. The

manufacturer cannot be held liable for

unauthorised work.

~If the connection cable is damaged,

it must be replaced by a suitably

qualified electrician with a specialist

connection cable of type H 05 V V-F

(pvc insulated), available from the Miele

Service Department.

~Faulty components must only be

replaced by genuine Miele original

parts. The manufacturer can only

guarantee the safety of the appliance

when Miele replacement parts are

used.

Warning and Safety instructions

~During installation, maintenance and

repair work, the appliance must be

disconnected from the mains electricity

supply. It is only completely isolated

from the electricity supply when:

–the mains fuse is disconnected,

–the screw-out fuse is removed (in

countries where this is applicable),

–it is switched off at the wall socket

and the plug is withdrawn from the

socket, or

–it is switched off at the fused spur

connection unit.

~Do not connect the appliance to the

mains electricity supply by a

multi-socket unit or an extension lead.

These do not guarantee the required

safety of the appliance (e.g. danger of

overheating).

~In countries where there are areas

which may be subject to infestation by

cockroaches or other vermin, pay

particular attention to keeping the

appliance and its surroundings in a

clean condition at all times. Any

damage caused by cockroaches or

other vermin will not be covered by the

guarantee.

Correct use

~For added protection, it is advisable

to use heat-resistant pot holders or

gloves when using the appliance. Do

not let them get damp or wet, as this

causes heat to transfer through the

material more quickly with the risk of

scalding or burning yourself.

~The underside of the drawer gets

hot when switched on. Be careful not to

touch it when the drawer is open.

~Do not store any plastic containers

or inflammable objects in the warming

drawer. They could melt or catch fire

when the appliance is switched on,

causing a fire hazard.

~Take care when opening and

closing the loaded drawer, that liquids

do not spill over and get into the

appliance through the vents. This can

cause lingering odours and the

appliance to short circuit.

~Do not heat up unopened tins or jars

of food in the drawer, as pressure will

build up in the tin or jar, causing it to

explode. This could result in injury and

scalding or damage.

~Ensure food is really hot when

placed inside the warming drawer. The

drawer is designed to keep hot food

warm, and not to warm food up.

~Make sure that the vents inside the

drawer are not covered. Otherwise,

food and crockery will not heat up

evenly.

Warning and Safety instructions

~Do not use the appliance to heat up

the room. Due to the high temperatures

radiated, objects near the appliance

could catch fire. The life of the

appliance could also be reduced.

~Never replace the anti-slip mat

supplied with the appliance with paper

kitchen towel or similar.

~Do not overload the drawer. The

maximum load bearing capacity of the

drawer is 25 kg.

~Only place heat-resistant crockery in

the drawer. Never place plastic or

aluminium foil items in the drawer.

These melt at high temperatures, and

could catch fire.

~Do not sit or lean on the opened

drawer. This can damage the

telescopic runners.

~Make sure that you select a high

enough temperature setting to keep

food warm. Bacteria can develop in the

food if the temperature is too low.

~Never use a steam cleaner to clean

the appliance. The steam could reach

electrical components and cause a

short circuit.

~While the appliance is under

guarantee, repairs should only be

undertaken by a service technician

authorised by the manufacturer.

Otherwise the guarantee is invalidated.

The manufacturer cannot be held

liable for damage caused by

non-compliance with these Warning

and Safety instructions.

Warning and Safety instructions

Tabla de contenidos

Otros manuales de Cajón calentador de Miele

Miele

Miele EGW 5060-14 Hoja de especificaciones

Miele

Miele ESS2060 Manual de usuario

Miele

Miele ESW 4802 FB Instrucciones de uso

Miele

Miele ESW 760-25 MasterChef Guía del usuario

Miele

Miele ESW 4702 FB Instrucciones de uso

Miele

Miele ESW 4724 Instrucciones de uso

Miele

Miele ESW 4701 Manual de usuario

Miele

Miele ESW 6880 Manual de usuario

Miele

Miele ESW 6114 Manual de usuario

Miele

Miele ESW 4088-14 Manual de usuario

Miele

Miele ESW700-25 FB Manual de usuario

Miele

Miele EGW 3060-10 Manual de usuario

Miele

Miele ESW 4726 Instrucciones de uso

Miele

Miele ESW 761-25 Manual de usuario

Miele

Miele ESW 6114 Manual de usuario

Miele

Miele ESW4810 Guía del usuario

Miele

Miele EGW 4060-14 Manual de usuario

Miele

Miele ESW 4084-14 Instrucciones de uso

Miele

Miele ESW7670OB Manual de usuario

Miele

Miele ESW 4086-14 Instrucciones de uso

Miele

Miele ESW 48 SERIES Manual de usuario

Miele

Miele EGW 6210 Manual de usuario

Miele

Miele ESW 5088-14 Manual de usuario

Miele

Miele ESW 4714 Instrucciones de uso

Manuales populares de Cajón calentador de otras marcas

Siemens

Siemens HW 290 Series Manual de usuario

Hatco

Hatco HDW-1 Instrucciones de instalación

APW Wyott

APW Wyott WD-2CMF Manual de usuario

Viking

Viking DEWD102SS Manual de usuario

Brandt

Brandt WD1014X Manual de usuario

KitchenAid

KitchenAid KOWT107ESS Manual de usuario

Gaggenau

Gaggenau WSP 222 Manual de usuario

DCS

DCS WDI Manual de usuario

Fisher & Paykel

Fisher & Paykel OR90SCG6R1 Manual de usuario

Electrolux

Electrolux EED21600X Manual de usuario

Fisher

Fisher PROFESSIONAL WB76SPEX1 Manual de usuario

Electrolux

Electrolux EW30WD55GS Manual de usuario

Hanseatic

Hanseatic TCN14J6D-S Manual de usuario

Jenn-Air

Jenn-Air JWD6030CDX Manual de usuario

Gaggenau

Gaggenau WS482710 Manual de usuario

Bosch

Bosch HWD2720UC Manual de usuario

NEFF

NEFF N29HA11Y2 Instrucciones de funcionamiento y mantenimiento

Fisher & Paykel

Fisher & Paykel WB60SMTB1-SET Manual de usuario
