Midea WQP12-5203 Manual de usuario

PART Ⅰ: Generic Version

WQP12-5203

Please read this manual carefully

before using the dishwasher and

Keep this manual for future reference.

SAFETY INFORMATION

CONTENTS

PRODUCT OVERVIEW

USING YOUR DISHWASHER

Loading The Salt Into The Softener

Basket Used Tips

MAINTENANCE AND CLEANING

External Care

Internal Care

Caring For The Dishwasher

INSTALLATION INSTRUCTION

About Power Connection

Water Supply And Drain

Connection Of Drain Hoses

Position The Appliance

Free Standing Installation

Built-In Installation(for the integrated model)

NOTE:

Reviewing the section on troubleshooting Tips will help you solve some

common problems by yourself.

If you cannot solve the problems by yourself, please ask for help from a

professional technician.

The manufacturer, following a policy of constant development and updating of

the product, may make modifications without giving prior notice.

If lost or out-of-date, you can receive a new user manual from the manufacturer

or responsible vendor.

TROUBLESHOOTING TIPS

LOADING THE BASKETS ACCORDING TO EN50242

SAFETY INFORMATION

WARNING

When using your dishwasher, follow the

precautions listed below:

Installation and repair can only be carried out by a

qualified technician

This appliance is intended to be used in household

and similar applications such as:

-staff kitchen areas in shops, offices and other

working environments;

-farm houses;

-by clients in hotels, motels and other residential type

environments;

-bed and breakfast type environments.

This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

Children shall not play with the appliance. Cleaning

and user maintenance shall not be done by children

without supervision. (For EN60335-1)

This appliance is not intended for use by persons

(including children ) with reduced physical, sensory or

mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a

person responsible for their safety. (For IEC60335-1 )

Packaging material could be dangerous for children!

This appliance is for indoor household use only.

To protect against the risk of electrical shock, do not

immerse the unit, cord or plug in water or other liquid.

Please unplug before cleaning and performing

maintenance on the appliance.

Use a soft cloth moistened with mild soap, and then

use a dry cloth to wipe it again.

Earthing Instructions

This appliance must be earthed. In the event of a

malfunction or breakdown, earthing will reduce the

risk of an electric shock by providing a path of least

resistance of electric current. This appliance is

equipped with an earthing conductor plug.

The plug must be plugged into an appropriate

outlet that is installed and earthed in accordance

with all local codes and ordinances.

Improper connection of the equipment-earthing

conductor can result in the risk of an electric shock.

Check with a qualified electrician or service

representative if you are in doubt whether the

appliance is properly grounded.

Do not modify the plug provided with the

appliance; If it does not fit the outlet.

Have a proper outlet installed by a qualified

electrician.

Do not abuse, sit on, or stand on the door or dish

rack of the dishwasher.

Do not operate your dishwasher unless all enclosure

panels are properly in place.

Open the door very carefully if the dishwasher is

operating, there is a risk of water squirting out.

Do not place any heavy objects on or stand on the

door when it is open. The appliance could tip

forward.

When loading items to be washed:

1) Locate sharp items so that they are not likely to

damage the door seal;

2) Warning: Knives and other utensils with sharp

points must be loaded in the basket with their

points facing down or placed in a horizontal

position.

Some dishwasher detergents are strongly alkaline.

They can be extremely dangerous if swallowed.

Avoid contact with the skin and eyes and keep

children away from the dishwasher when the door

is open.

Check that the detergent powder is empty after

completion of the wash cycle.

Do not wash plastic items unless they are marked

“dishwasher safe” or the equivalent.

For unmarked plastic items not so marked, check the

manufacturer's recommendations.

Use only detergent and rinse agents recommended for

use in an automatic dishwasher.

Never use soap, laundry detergent, or hand washing

detergent in your dishwasher.

The door should not be left open, since this could

increase the risk of tripping.

If the supply cord is damaged, it must be replaced by

the manufacturer or its service agent or a similarly

qualified person in order to avoid a hazard.

During installation, the power supply must not be

excessively or dangerously bent or flattened.

Do not tamper with controls.

The appliance needs to be connected to the main

water valve using new hose sets. Old sets should not be

reused.

To save energy, in stand by mode, the appliance will

switch off automatically while there is no any operation

in 30 minutes .

The maximum number of place settings to be washed

is 12.

The maximum permissible inlet water pressure is 1MPa.

The minimum permissible inlet water pressure is

0.04MPa.

Disposal

For disposing of package and the

appliance please go to a recycling center.

Therefore cut off the power supply cable

and make the door closing device

unusable.

Cardboard packaging is manufactured from recycled

paper and should be disposed in the waste paper

collection for recycling.

By ensuring this product is disposed of correctly, you

will help prevent potential negative consequences

for the environment and human health, which could

otherwise be caused by inappropriate waste

handling of this product.

For more detailed information about recycling of this

product, please contact your local city office and

your household waste disposal service.

DISPOSAL: Do not dispose this product as

unsorted municipal waste. Collection of such

waste separately for special treatment is

necessary.

PRODUCT OVERVIEW

To get the best performance from your dishwasher, read all operating instructions

before using it for the first time.

IMPORTANT:

Pictures are only for reference, different models may be different. Please prevail

in kind.

NOTE:

Cutlery basket Lower basket

upper spray arm

Upper basket

Cup rack

Dispenser

Salt container Filter assembly

Lower spray arm

Inner pipe

Loading The Salt Into The Softener

Only use salt specifically designed for dishwashers use!

Every other type of salt not specifically designed for dishwasher use,

especially table salt, will damage the water softener. In case of damages

caused by the use of unsuitable salt the manufacturer does not give any

warranty nor is liable for any damages caused.

Only fill with salt before running a cycle.

This will prevent any grains of salt or salty water, which may have been

spilled, remaining on the bottom of the machine for any period of time,

which may cause corrosion.

WARNING

Always use salt intended for dishwasher use.

The salt container is located beneath the lower basket and should be filled as

explained in the following:

Please check the section 1 “Water Softener” of PART Ⅱ: Special Version,

If you need to set the water softener .

Please check the section 1 “Water Softener” of PART Ⅱ: Special Version,

If you need to set the water softener .

If your model does not have any water softener, you may skip this section.

NOTE:

USING YOUR DISHWASHER

Before using your dishwasher :

Inside Outside

1. Set the water softener

2. Loading the salt Into the softener

3. Loading the basket

4. Fill the dispenser

1. Remove the lower basket and unscrew the reservoir cap.

2. Place the end of the funnel (supplied) into the hole and pour in about 1.5kg of

dishwasher salt.

3. Fill the salt container to its maximum limit with water, It is normal for a small

amount of water to come out of the salt container.

4. After filling the container, screw back the cap tightly.

5. The salt warning light will stop being after the salt container has been filled with salt.

6. Immediately after filling the salt into the salt container, a washing program should

be started (We suggest to use a short program). Otherwise the filter system, pump

or other important parts of the machine may be damaged by salty water. This is

out of warranty.

NOTE:

The salt container must only be refilled when the salt warning light ( ) in the

control panel comes on. Depending on how well the salt dissolves, the salt

warning light may still be on even though the salt container is filled.

If there is no salt warning light in the control panel (for some Models), you can

estimate when to fill the salt into the softener by the cycles that the dishwasher

has run.

If salt has spilled, run a soak or quick program to remove it.

Please follow the steps below for adding dishwasher salt:
