Midea MDW45FSS Manual de usuario

PART Ⅰ: Generic Version

Please read this manual carefully before using the dishwasher

Keep this manual for future reference.

SAFETY INFORMATION

CONTENTS

PRODUCT OVERVIEW

USING YOUR DISHWASHER

Basket Used Tips

MAINTENANCE AND CLEANING

External Care

Internal Care

Caring For The Dishwasher

INSTALLATION INSTRUCTION

NOTE:

Reviewing the section on troubleshooting Tips will help you solve some

common problems by yourself.

If you cannot solve the problems by yourself, please ask for help from a

professional technician.

The manufacturer, following a policy of constant development and updating of

the product, may make modifications without giving prior notice.

If lost or out-of-date, you can receive a new user manual from the manufacturer

or responsible vendor.

About Power Connection

Water Supply And Drain

Connection Of Drain Hoses

Position The Appliance

Free Standing Installation

Built-In Installation(for the integrated model)

TROUBLESHOOTING TIPS

27 LOADING THE BASKETS ACCORDING TO AS/NZS 2007.1

SAFETY INFORMATION

WARNING

When using your dishwasher , follow the

precautions listed below:

This appliance is intended to be used in household

and similar applications such as:

-staff kitchen areas in shops, offices and other

working environments;

-farm houses;

-by clients in hotels, motels and other residential type

environments;

-bed and breakfast type environments.

This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

Children shall not play with the appliance. Cleaning

and user maintenance shall not be done by children

without supervision.(For EN60335-1)

This appliance is not intended for use by

persons(including children )with reduced physical,

sensory or mental capabilities, or lack of experience

and knowledge ,unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.(For

IEC60335-1 )

Packaging material could be dangerous for children!

This appliance is for indoor household use only.

To protect against the risk of electrical shock, do not

immerse the unit, cord or plug in water or other liquid.

Please unplug before cleaning and performing

maintenance on the appliance.

Use a soft cloth moistened with mild soap, and then

use a dry cloth to wipe it again.

Earthing Instructions

This appliance must be earthed. In the event of a

malfunction or breakdown, earthing will reduce the

risk of an electric shock by providing a path of least

resistance of electric current. This appliance is

equipped with an earthing conductor plug.

The plug must be plugged into an appropriate

outlet that i s i nstalled a nd earthed in a ccordance

with all local codes and ordinances.

Improper connection of the equipment-earthing

conductor can result in the risk of an electric shock.

Check with a qualified electrician or service

representative if you are in doubt whether the

appliance is properly grounded.

Do not modify the plug provided with the

appliance; If it does not fit the outlet.

Have a proper outlet installed by a qualified

electrician.

Do not abuse, sit on, or stand on the door or dish

rack of the dishwasher.

Do not operate your dishwasher unless all enclosure

panels are properly in place.

Open the door very carefully if the dishwasher is

operating, there is a risk of water squirting out.

Do not place any heavy objects on or stand on the

door when it is open. The appliance could tip

forward.

When loading items to be washed:

1) Locate sharp items so that they are not likely to

damage the door seal;

2) Warning: Knives and other utensils with sharp

points must be loaded in the basket with their

points facing down or placed in a horizontal

position.

Some dishwasher detergents are strongly alkaline.

They can be extremely dangerous if swallowed.

Avoid contact with the skin and eyes and keep

children away from the dishwasher when the door

is open.

Check that the detergent powder is empty after

completion of the wash cycle.

Do not wash plastic items unless they are marked “

dishwasher safe” or the equivalent.

For unmarked plastic items not so marked, check the

manufacturer's recommendations.

Use only detergent and rinse agents recommended for

use in an automatic dishwasher.

Never use soap, laundry detergent, or hand washing

detergent in your dishwasher.

The door should not be left open, since this could

increase the risk of tripping.

If the supply cord is damaged, it must be replaced by

the manufacturer or its service agent or a similarly

qualified person in order to avoid a hazard.

During installation, the power supply must not be

excessively or dangerously bent or flattened.

Do not tamper with controls.

The appliance needs to be connected to the main

water valve using new hose sets. Old sets should not

be reused.

To save energy, in stand by mode , the appliance will

switch off automatically while there is no any

operation in 30 minutes .

Disposal

For disposing of package and the

appliance please go to a recycling centre.

Therefore cut off the power supply cable

and make the door closing device

unusable.

Cardboard packaging is manufactured from recycled

paper and should be disposed in the waste paper

collection for recycling.

By ensuring this product is disposed of correctly, you

will help prevent potential negative consequences

for the environment and human health, which could

otherwise be caused by inappropriate waste

handling of this product.

For more detailed information about recycling of this

product, please contact your local city office and

your household waste disposal service.

DISPOSAL: Do not dispose this product as

unsorted municipal waste. Collection of such

waste separatelyfor special treatment is

necessary.

PRODUCT OVERVIEW

To get the best performance from your dishwasher, read all operating instructions

before using it for the first time.

Top spray arm

Dispenser

Salt container Filter assembly

Lower spray arm

Inner pipe

IMPORTANT:

upper spray arm

Upper basket Lower basket

Cup rack

Cutlery rack

Pictures are only for reference, different models may be different. Please prevail

in kind.

NOTE:

USING YOUR DISHWASHER

1. Loading the basket

2. Fill the rinse aid dispenser (Please check the section 1 of PART Ⅱ: Special Version)

3. Fill in detergent (Please check the section 1 of PART Ⅱ: Special Version)

1. Loading the basket

2. Fill the rinse aid dispenser (Please check the section 1 of PART Ⅱ: Special Version)

3. Fill in detergent (Please check the section 1 of PART Ⅱ: Special Version)

Adjusting the upper basket

The height of the upper basket can be easily adjusted to accommodate taller dishes

in either the upper or lower basket.

To adjust the height of the upper rack, follow these steps:

1Pull out upper basket. 2Remove upper basket.

3Re-attach upper basket to the upper

or lower rollers.

Push in upper basket.

lower position

upper position

Type 1:

Basket Used Tips

Before using your dishwasher :

Inside Outside

1To raise the rack to the upper position,

lift rack until both sides are at the same

height. The rack will secure into place.

2To lower the rack, push down on the

handle and release.

Type 2:

Folding back the cup shelives

To make room for taller items in the dishwasher basket, raise the cup rack upwards.

You can then lean the tall glasses against it. You can also remove it when it is not

required for use.

Folding back the rack shelives

The spikes are used for holding plates and a platter. They can be lowered to make

more room for large items.

raise upwards fold backwards
