Midea GA Series Manual de usuario

© 2021. Midea UK Copyright LTD.© 2021. Midea UK Copyright LTD.

GAME CHANGING

COOLING & HEATING

GA Series Ducted & CF Quick

Guide

© 2021. Midea UK Copyright LTD.

© 2021. Midea UK Copyright LTD.

Contents

Wiring Guides 3

Controllers

Commissioning / Dip Switches 14

Common Errors 2

Compatibility / Service sizes / Gas Charges 31

Midea YouTube Channel

PAGE

(Click for hyperlink)

© 2021. Midea UK Copyright LTD.

Wiring Guides

Single splits

Twin splits

XYE Adapter

(click for hyperlink)

4

Wiring Guide – Single S lits

HA HB

•Interconnecting power supply must be

locally isolated with a 5amp switch fuse

spur to protect the indoor PCB

•‘S’ must not be switched (crimp straight

through)

L,N,E

1L,2N,E,S L,N,E,S

Controller

© 2021. Midea UK Copyright LTD.

Twin S lit – Ducted / CF

5

•Interconnecting power supply must be locally

isolated with a 5amp switch fuse spur to protect

the indoor PCB

•Controller only wires to the Master

•Link Fan coils on XY terminals with 2 core CY

•The XYE adapter plug in is required to allow the

connection

•Master and Slave are set using SW5

SW5 Bit 1 ON for Master

SW5 Bit 1&2 ON for the Slave

© 2021. Midea UK Copyright LTD.

Twin S lit – Ducted / CF

6

CN49 socket connection XYE Ada ter

The adapters are an optional extra

They are free of charge

Once plugged into CN49 they allow twin comms wiring

and central controller wiring:

X - Green

Y - Yellow

© 2021. Midea UK Copyright LTD.

Controller Guides

Models and Compatibility

Wiring

Wifi HUB

MSmart Home App

Central Controller Wiring

(click for hyperlink)

© 2021. Midea UK Copyright LTD.

KJR120 Controllers

8

The KJR120G features a day timer, information enquiry and follow me

functions

It has 3 distinct versions listed below

The KJR120X is a new controller which has the same features as the

KJR120G with the added ability to change the limits of set points and

other parameters

Model KJR120G2/TFBG-E KJR-120G/TF-E-01 KJR-120G/TF-E-01 KJR120X

Midea Ref. KJR120G2 – P&P KJR120G2 – S2 KJR120G – M2 KJR120X

Wiring Jack plugged 2 core HA/HB 2 core HA/HB 2 core HA/HB

# of units 1 1 1-16 1-16

Bom codes 1 31 100A25533 1 31 100A31648 1 31 100A255 3

© 2021. Midea UK Copyright LTD.

KJR120G S2/M2 & KJR120X

9

HA HB HA HB HA HB

•2 core CY 0.5mm-1/5mm connection between controller and unit(s)

•When controlling more than one system, the units must be addressed using the Rotary

Dial S1 switch on the indoor PCB

•Both the HA/HB and Jack plug versions of the controllers look very similar except for

the fly lead that is connected to the bottom of the jack plugged version. Bear this in

mind when attempting to wire the controllers. The jack plugged version cannot be

connected using HA/HB even though the terminals are present

© 2021. Midea UK Copyright LTD.

Wifi Hub Installation

10

CN49

CN49
