Microsens RS232 Manual de usuario

RS232/422/485

to Fiber Converter

User’s Manual

(For MS400131-V2 an MS400132-V2)

2011, MICROSENS GmbH & Co.KG All rights reserve . Rev. 1.5.1-pk5011

Table of Contents

AUTION

........................................................................................................ 2

LECTRONIC

MISSION

OTICES

............................................................................ 2

1.INTRODUCTION .......................................................................................... 3

1-1. O

VERVIEW OF FIBER CONVERTER

..................................................................... 3

1-2. C

HECKLIST

............................................................................................... 3

2. INSTALLATION .......................................................................................... 4

2-1. I

NSTALLING THE

IBER CONVERTER

.................................................................. 4

OUNTING ON

DIN-R

AIL

.................................................................................... 4

2-2. DIP-S

WITCH

ETTINGS

............................................................................... 5

2-3. C

ONNECTOR

............................................................................................. 6

2-4. LED D

ESCRIPTION

..................................................................................... 7

2-5.

DC J

ACK AND

AC-DC P

OWER

DAPTER

............................................................ 7

3. TECHNICAL SPECIFICATIONS .................................................................... 7

Caution

Circuit evices are sensitive to static electricity, which can amage their elicate

electronics. Dry weather con itions or walking across a carpete floor may cause you to

acquire a static electrical charge.

To protect your evice, always:

• Touch the metal chassis of your computer to groun the static electrical charge

before you pick up the circuit evice.

• Pick up the evice by hol ing it on the left an right e ges only.

Electronic Emission Notices

Euro ean Community (CE) Electromagnetic Com atibility Directive

This equipment has been teste an foun to comply with the protection requirements

of European Emission Stan ar EN55022/EN60555-2 an the Generic European

Immunity Stan ar EN50082-1.

EMC:

EN55022(1988)/CISPR-22(1985) class A

EN60555-2(1995) class A

EN60555-3

IEC1000-4-2(1995) 4K V CD, 8KV, AD

IEC1000-4-3(1995) 3V/m

IEC1000-4-4(1995) 1KV – (power line), 0.5KV –

(signal line)

1. Introduction

1-1. Overview of fiber converter

The fiber optic converter of RS232/422/485 to Fiber Optic is use to

exten the istance up to 2Km over the multi-mo e fiber or up to 20Km

over single-mo e fiber. The converter is equippe with multiple interface

circuit such as RS232, RS422, RS485 2/4-wire.

Note:

This pro uct has to be use in pairs

1-2. Checklist

Before you start installing the Converter, verify that the package contains

the following:



The RS232/422/485 to Fiber Converter



AC-DC Power A apter (Optional for commercial or in ustrial mo el)



This User's Manual

Please notify your sales representative imme iately if any of the

aforementione items are missing or amage

RS-232/42 2/485 TX RX

Data Pwr

Fig. 1: Front View of RS232/422/485 to Fiber Converter

Fig. 2: RS232/422/485to Fiber Converter Si e Panel

2. Installation

2-1. Installing the Fiber converter

Mounting on DIN-Rail

⇒ Remove the four screws on the both si es of the converter.

⇒ Place the converter on the mounting bracket.

⇒ Align the screw holes on the bracket with the holes on the both si es of

the converter. (See Fig. 3)

⇒ Insert the 2 x 5mm screws an tighten them until they are secure.

Fig. 3

⇒ Position the fixe DIN-rail clip on the backsi e of the bracket on to the

DIN-rail.

⇒ Pull up the moveable DIN-rail clip to attach the bracket to the DIN-rail,

an then release the clip.

(See Fig. 4)

⇒ Make sure the converter is securely mounte on the DIN-rail.

Fig. 4

2-2

DIP-Switch Settings

Fig. 5

•

SW1-1,2

SW1 (Co er Mode Select)

Mode 1 2 Descri tion

RS232 ∗ OFF OFF RS232 mo e

RS422-4W OFF ON RS422 4-wire mo e

(full uplex)

RS485-4W ON OFF RS485 4-wire mo e

(full uplex)

RS485-2W ON ON RS485 2-wire mo e

(half uplex)

∗: Default

•

SW2 (RS-422/RS-485 TERMINATION)

SW2 (Termination select)

1 2 Descri tion

OFF OFF

Termination isable *

OFF ON Insert 120 Ω terminator on

RS-485 TX/RX wires

ON OFF

Insert 100 Ω terminator on

RS-422 TX/RX wires

ON ON Do not use

∗: Default

NOTE: SW2-1 an SW2-2 o not set to ON at the same time.

2-3. Connector

SUB-DB9

Connector

Fig. 6: Female SUB-DB9 connector efinition on cable

Fig. 7: Male SUB-DB9 connector efinition on evice

Fig. 8: Fiber Optic Network Connection

Signal Groun

4 Unuse

3 RS232 TXD or RS422/485-4W TX-

, 2W

TX/RX-

2 RS232 RXD or RS422/485-4W RX+

1 Unuse

Unuse

RS422/485-4W RX- 8

RS422/485-4W TX+ 7

or RS485-2W TX/RX+-

Unuse 6

RS232

RS422

RS485

(SUB-DB9

or Terminal

Block)

Fiber Optic Wire

RS485/422/232

Fiber Converter

1 Unuse

2 RS232 RXD or RS422/485-4W RX+

3 RS232 TXD or RS422/485-4W TX-, 2W

TX/RX-

4 Unuse

5 Signal Groun

Unu

se 6

RS422/485-

4W TX+ 7

or RS485-2W TX/RX+

RS422/485-4W RX-

Unuse 9

2-4

LED Descri tion

LED Color

Function

FX (LNK/ACT)

Green

Lit when fiber connection is

goo

Blinks when fiber ata is

present

DATA

(Copper) Green

Lit when Copper ata is

present

PWR Green

Lit when +5 V power is

coming up

Note: Accor ing to LED Description, check which part is out of work.

Reset this pro uct by power off/on.

2-5. DC Jack and AC-DC Power Ada ter

The DC jack's central post is 2.5mm wi e an it conforms to the DC

receptacle(2.5mm).

＊ AC-DC a apter (VOUT +5 VDC) is require .

3. Technical S ecifications

• Standards: RS-232 TIA/EIA-232

RS-422 TIA/EIA-422

RS-485 TIA/EIA-485

• Network Interface: RS232 (SUB-DB9)

RS485/422 (SUB-DB9)

SC/ST Fiber Transceiver

∗ Any other fiber mo el, such as LC, BiDi, etc. is available upon request.

DC Jack :2.5mm

DC Input :+5V

(DC current: full loa consumption 0.5 A)

Fig.9: DC+5 V Input Jack an imension

• Maximum Cable Distance :

Configuration Max. Distance

RS232 15m(50ft)

RS422/485 1220m (4000ft)

Multi-mo e Fiber 2km

Single-mo e Fiber 20km ∗

＊

Any other istance is upon request.

• Fiber Cable: 50/125, 62.5/125, or 100/140

m multi-mo e

8.3/125, 8.7/125, 9/125 or 10/125

m single-mo e

Bi i-SC 1310 nm, 1550 nm

• Data Transfer Rate : up to 460.8Kbps

• LED : PWR , FX, DATA

• Power Requirement: 1 A@+5 VDC

• Ambient Tem erature: -10 to 60°C(In ustrial)

0 to 50°C (Commercial)

• Humidity : 5% to 90%

• Dimensions: 26.2(H) × 70.3(W) × 94(D) mm

• Com lies with CE Mark
