1BP W1 Basic EN

Display

Read the instructions carefully before using this device.

Intended use:

This oscillometric blood pressure monitor is intended for measuring

non-invasive blood pressure in people aged 12 years or older.

Dear Customer,

Your new

Microlife

blood pressure monitor is a reliable medical device

for taking measurements on the wrist. It is simple to use, accurate and

comes highly recommended for blood pressure monitoring in your

home. This device was developed in collaboration with physicians and

clinical tests prove its measurement accuracy to be very high.*

If you have any questions, problems or want to order spare parts

please contact your local Microlife-Customer Service. Your dealer or

pharmacy will be able to give you the address of the Microlife dealer

in your country. Alternatively, visit the internet at www.microlife.com

where you will find a wealth of invaluable information on our products.

Stay healthy – Microlife AG!

* This device uses the same measuring algorithm as the award

winning BP W100 model tested according to the British and Irish

Hypertension Society (BIHS) protocol.

Microlife BP W1 Basic EN

1ON/OFF button

2Display

3Battery Compartment

4Cuff

5M-button (memory)

6Time Button

7Systolic Value

8Diastolic Value

9Pulse Rate

AT Date/Time

AK Traffic Light Indicator

AL Stored Value

AM Irregular Heartbeat (IHB) Symbol

AN Pulse Indicator

AO Battery Display

AP Arm Movement Indicator

AQ Cuff Check Indicator

AR LED Positioning Indicator

Table of Contents

1. Important Facts about Blood Pressure and Self-Measure-

ment

• How do I evaluate my blood pressure?

2. Using the Device for the First Time

• Inserting the batteries

• Setting the date and time

3. Taking a Blood Pressure Measurement

4. Appearance of the Irregular Heartbeat (IHB) Symbol

5. Traffic Light Indicator in the Display

6. Data Memory

• Viewing the stored values

• Memory full

• Clearing all values

• How not to store a reading

7. Battery Indicator and Battery change

• Low battery

• Flat battery – replacement

• Which batteries and which procedure?

• Using rechargeable batteries

8. Error Messages

9. Safety, Care, Accuracy Test and Disposal

• Safety and protection

•Devicecare

• Cleaning the cuff

• Accuracy test

•Disposal

10. Guarantee

11. Technical Specifications

Guarantee Card (see Back Cover)

Type BF applied part

1. Important Facts about Blood Pressure and Self-

Measurement



Blood pressure

is the pressure of the blood flowing in the arteries

generated by the pumping of the heart. Two values, the

systolic

(upper) value and the

diastolic

(lower) value, are always measured.

The device indicates the pulse rate (the number of times the heart

beats in a minute).

Keep dry

3BP W1 Basic EN

Permanently high blood pressure values can damage your

health and must be treated by your doctor!

Always discuss your values with your doctor and tell him/her if you

have noticed anything unusual or feel unsure. Never rely on

single blood pressure readings.

There are several causes of excessively high blood pressure

values. Your doctor will explain them in more detail and offer

treatment where appropriate. Besides medication, weight loss

and exercise can also lower your blood pressure.

Under no circumstances should you alter the dosages of

drugs or initiate a treatment without consulting your doctor.

Depending on physical exertion and condition, blood pressure is

subject to wide fluctuations as the day progresses. You should

therefore take your measurements in the same quiet condi-

tions and when you feel relaxed! Take at least two readings

every time (in the morning and in the evening) and average the

measurements.

It is quite normal for two measurements taken in quick succession

to produce significantly different results.

Deviations between measurements taken by your doctor or in the

pharmacy and those taken at home are quite normal, as these

situations are completely different.



Several measurements

provide much more reliable information

about your blood pressure than just one single measurement.

Leave a small break of at least 15 seconds between two

measurements.

If you suffer from a cardiac arrhythmia consult with your doctor

before using the device. See also chapter «Appearance of the

Irregular Heartbeat (IHB) Symbol» of this user manual.

The pulse display is not suitable for checking the frequency

of heart pacemakers!

If you are pregnant, you should monitor your blood pressure

regularly as it can change drastically during this time.

A number of factors can affect the accuracy of measure-

ments taken on the wrist. In some cases, the result may

differ from the measurement taken on the upper arm. We

therefore advise you to compare these values with those

produced by the upper arm measurement and discuss them

with your doctor.

How do I evaluate my blood pressure?

Table for classifying home blood pressure values in adults in accordance

with the international Guidelines (ESH, ESC, JSH). Data in mmHg.

Range Systolic Diastolic Recommendation

1. blood pressure

normal < 120 < 74 Self-check

The higher value is the one that determines the evaluation. Example:

a blood pressure value of 140/80 mmHg or a value of 130/90 mmHg

indicates «blood pressure too high».

2. Using the Device for the First Time

Inserting the batteries

After you have unpacked your device, first insert the batteries. The

battery compartment

is at the top of the device. Insert the batteries

(

x 1.5 V, size

AAA

), thereby observing the indicated polarity.

Setting the date and time

1. After the new batteries are fitted, the year number flashes in the

display. You can set the year by pressing the M-button 5. To

confirm and then set the month, press the time button 6.

2. Press the M-button to set the month. Press the time button to

confirm and then set the day.

3. Follow the instructions above to set the day, hour and minutes.

4. Once you have set the minutes and pressed the time button, the

date and time are set and the time is displayed.

5. If you want to change the date and time, press and hold the time

button down for approx. 3 seconds until the year number starts to

flash. Now you can enter the new values as described above.

3. Taking a Blood Pressure Measurement

Checklist for taking a reliable measurement

1. Avoid activity, eating or smoking immediately before the measurement.

2. Sit down on a back-supported chair and relax for 5 minutes. Keep

the feet flat on the floor and do not cross your legs.

3. Always measure in a sitting position and on the same wrist. Use

the wrist which usually shows higher blood pressure values.

4. Remove any items of clothing and your watch, for example, so

that your wrist is free.

5. Always ensure that the cuff is positioned correctly, asshown in the

pictures illustrated on the short instruction card.

2. blood pressure

optimum 120 - 129 74 - 79 Self-check

3. blood pressure

elevated 130 - 134 80 - 84 Self-check

4. blood pressure too

high 135 - 159 85 - 99 Seek medical

advice

5. blood pressure

dangerously high ≥160 ≥100 Urgently seek

medical advice!

Table for classifying home blood pressure values in adults in accordance

with the international Guidelines (ESH, ESC, JSH). Data in mmHg.

Range Systolic Diastolic Recommendation

5BP W1 Basic EN

6. Fit the cuff comfortably but not too tight. The cuff will cover a wrist

circumference of 13.5 - 21.5 cm (5.25 - 8.5 inches).

7. Press the ON/OFF button 1to start the measurement.

8. The LED Positioning Indicator AR is activated. Support your arm

in a relaxed position with the device at the same height as your

heart, move your arm until the LED light is at its brightest and

appears to be in the center of the indicator.

9. After 5 seconds, the cuff will pump up automatically. Relax, do not

move and do not tense your arm muscles until the measurement

result is displayed. Breathe normally and do not talk.

10.When the correct pressure is reached, the pumping stops and the

pressure falls gradually. If the required pressure was not reached,

the device will automatically pump some more air into the cuff.

11.During the measurement, the pulse indicator

flashes in the display.

12.The result, comprising the systolic 7and the diastolic 8blood

pressure and the pulse rate 9is displayed. Note also the expla-

nations on further display symbols in this booklet.

13.Remove and switch off the monitor and enter the result in the

enclosed blood pressure pass. (The monitor does switch off auto-

matically after approx. 1 min.).

You can stop the measurement at any time by pressing the

ON/OFF button (e.g. if you feel uneasy or an unpleasant pres-

sure sensation).

4. Appearance of the Irregular Heartbeat (IHB) Symbol

This symbol AM indicates that an irregular heartbeat was detected. In

this case, the measuredblood pressure may deviate from your actual

blood pressure values. It is recommended to repeat the measure-

ment.

5. Traffic Light Indicator in the Display

The bars on the left-hand edge of the display AK show you the range

within which the indicated blood pressure value lies. Depending on

the height of the bar, the readout value is either within the optimum

(green), elevated (yellow), too high (orange) or dangerously high

(red) range. The classification corresponds to the 4 ranges in the

table as defined by the international guidelines (ESH, ESC, JSH), as

described in «Section 1.».

6. Data Memory

At the end of each measurement, this device automatically stores the

result, including date and time.

Information for the doctor in case of repeated appearance of

the IHB symbol:

This device is an oscillometric blood pressure monitor that also

measures the pulse during blood pressure measurement and

indicates when the heart rate is irregular.

Viewing the stored values

Press the M-button

briefly, when the device is switched off. The

display first shows «

and then a value, e.g. «

M 17

». This means

that there are 17 values in the memory. The device then switches to the

last stored result.

Pressing the M-button again displays the previous value. Pressing the M-

button repeatedly enables you to move from one stored value to another.

Memory full



Pay attention that the maximum memory capacity of 60 memo-

ries is not exceeded.

When the 60 memory is full, the oldest

value is automatically overwritten with the 61st value.

Values should be evaluated by a doctor before the memory

capacity is reached – otherwise data will be lost.

Clearing all values

If you are sure that you want to permanently remove all stored

values, hold down the M-button (the device must have been switched

off beforehand) until «CL» appears and then release the button. To

permanently clear the memory, press the M-button while «CL» is

flashing. Individual values cannot be cleared.

How not to store a reading

As soon as the reading is displayed press and hold the ON/OFF

button 1until «M» AL is flashing. Confirm to delete the reading by

pressing the M-button 5.

7. Battery Indicator and Battery change

Low battery

When the batteries are approximately ¾ empty the battery symbol AO

will flash as soon as the device is switched on (partly filled battery

displayed). Although the device will continue to measure reliably, you

should obtain replacement batteries.

Flat battery – replacement

When the batteries are flat, the battery symbol AO will flash as soon

as the device is switched on (flat battery displayed). You cannot take

any further measurements and must replace the batteries.

1. Open the battery compartment 3by pulling off the cap.

2. Replace the batteries – ensure correct polarity as shown by the

symbols in the compartment.

3. To set date and time, follow the procedure described in «Section 2.».

The memory retains all values although date andtime must be

reset – the year number therefore flashes automatically after

the batteries are replaced.

Which batteries and which procedure?

Use 2 new, long-life 1.5 V, size AAA alkaline batteries.

Do not use batteries beyond their date of expiry.

Remove batteries if the device is not going to be used for a

prolonged period.

7BP W1 Basic EN

Using rechargeable batteries

You can also operate this device using rechargeable batteries.

Only use «NiMH» type reusable batteries.

Batteries must be removed and recharged when the flat

battery symbol appears. They should not remain inside the

device as they may become damaged (total discharge as a

result of low use of the device, even when switched off).

Always remove the rechargeable batteries if you do not intend

to use the device for a week or more.

Batteries cannot be charged in the blood pressure monitor.

Recharge batteries in an external charger and observe the

information regarding charging, care and durability.

8. Error Messages

If an error occurs during the measurement, the measurement is inter-

rupted and an error message, e.g. «ERR 3», is displayed.

* Please immediately consult your doctor, if this or any other problem

occurs repeatedly.

If you think the results are unusual, please read through the

information in «Section 1.» carefully.

Error Description Potential cause and remedy

ERR 1

» Signal too

weak

The pulse signals on the cuff are too weak. Re-

position the cuff and repeat the measurement.*

ERR 2

Error signal During the measurement, error signals were

detected by the cuff, caused for instance by

movement or muscle tension. Repeat the

measurement, keeping your arm still.

ERR 3

No pres-

sure in the

cuff

An adequate pressure cannot be generated

in the cuff. A leak may have occurred. Check

that the cuff is correctly connected and is not

too loose. Replace the batteries if necessary.

Repeat the measurement.

ERR 5

» Abnormal

result

The measuring signals are inaccurate and no

result can therefore be displayed. Read through

the checklist for performing reliable measure-

ments and then repeat the measurement.*

» Pulse or cuff

pressuretoo

high

The pressure in the cuff is too high (over

299 mmHg) OR the pulse is too high (over

200 beats per minute). Relax for 5 minutes

and repeat the measurement.*

» Pulse too

low The pulse is too low (less than 40 beats per

minute). Repeat the measurement.*

Error Description Potential cause and remedy

9. Safety, Care, Accuracy Test and Disposal

Safety and protection

Follow instructions for use. This document provides important

product operation and safety information regarding this device.

Please read this document thoroughly before using the device and

keep for future reference.

This device may only be used for the purposes described in these

instructions. The manufacturer cannot be held liable for damage

caused by incorrect application.

This device comprises sensitive components and must be treated

with caution. Observe the storage and operating conditions

described in the «Technical Specifications» section.

Protect it from:

- water and moisture

- extreme temperatures

- impact and dropping

- contamination and dust

- direct sunlight

- heat and cold

The cuffs are sensitive and must be handled with care.

Only pump up the cuff once fitted.

Do not use this device close to strong electromagnetic fields such

as mobile telephones or radio installations. Keep a minimum

distance of 3.3 m from such devices when using this device.

Do not use this device if you think it is damaged or notice anything

unusual.

Never open this device.

If the device is not going to be used for a prolonged period the

batteries should be removed.



Read the additional safety information provided within the individual

sections of this instruction manual.

The measurement results given by this device is not a diagnosis.

It is not replacing the need for the consultation of a physician,

especially if not matching the patient’s symptoms. Do not rely on

the measurement result only, always consider other potentially

occurring symptoms and the patient’s feedback. Calling a doctor

or an ambulance is advised if needed.

Ensure that children do not use this device unsupervised; some

parts are small enough to be swallowed. Be aware of the risk of

strangulation in case this device is supplied with cables or tubes.

Device care

Clean the device only with a soft, dry cloth.

Cleaning the cuff

Carefully remove any marks on the cuff with a damp cloth and mild

detergent.

Otros manuales para BP W1 Basic

Tabla de contenidos

Idiomas:

Otros manuales de Monitor de presión arterial de Microlife

Microlife

Microlife BP 3AG1 Manual de usuario

Microlife

Microlife BP A200 AFIB Manual de usuario

Microlife

Microlife BP A2 Classic Manual de usuario

Microlife

Microlife WatchBP office Manual de usuario

Microlife

Microlife aponorm Manual de usuario

Microlife

Microlife BP B1 Classic Manual de usuario

Microlife

Microlife BP W70 Manual de usuario

Microlife

Microlife A7 Touch BT Manual de usuario

Microlife

Microlife BP W1 Basic Manual de usuario

Microlife

Microlife Aponorm Professional Control Manual de usuario

Microlife

Microlife BP AG1-20 Manual de usuario

Microlife

Microlife BP W150 IMT Manual de usuario

Microlife

Microlife BP A200 AFIB Manual de usuario

Microlife

Microlife BP B3 Comfort PC Manual de usuario

Microlife

Microlife BP W150 IMT Manual de usuario

Microlife

Microlife BP AG1-20 Manual de usuario

Microlife

Microlife MAM EASY Manual de usuario

Microlife

Microlife BP 2BIO Manual de usuario

Microlife

Microlife BP3AX1-4U Manual de usuario

Microlife

Microlife Premier Automatic Blood Pressure Monitor Manual de usuario

Microlife

Microlife Aponorm Basis Control Manual de usuario

Microlife

Microlife aponorm Professional Manual de usuario

Microlife

Microlife BP 3AG1 Manual de usuario

Microlife

Microlife WatchBP Home Manual de usuario

Manuales populares de Monitor de presión arterial de otras marcas

Mediblink

Mediblink M520 Manual de usuario

Harbor Freight Tools

Harbor Freight Tools 62220 Instrucciones de montaje

Veridian Healthcare

Veridian Healthcare SmartHeart 01-518 Manual de usuario

Melissa

Melissa Automatic Blood Pressure Monitor Manual de usuario

Little Doctor

Little Doctor LD7 Manual de usuario

Panasonic

Panasonic EW3003 - WRIST BP MONITOR Manual de usuario

Omron

Omron HEM-9210T Manual de usuario

Medisana

Medisana 51043 Manual de usuario

HoMedics

HoMedics BPW-710-CA Manual de instrucciones

TechLine

TechLine Z-40 Manual de usuario

MABIS

MABIS SmartRead 04-235-001 Manual

Avita

Avita BPM82 Manual de usuario

VISIOMED

VISIOMED TensioFlash KD-595 Manual de usuario

Omron

Omron R2 Manual de usuario

Medicura

Medicura m255 Manual de usuario

Hartmann

Hartmann Tensoval Manual de usuario

BIOS Diagnostics

BIOS Diagnostics BD240 Manual de usuario

boso

boso medicus vital Manual de usuario
