MGI ZiP Series Manual de usuario
User Manual
VERSION 4.2
Thank you for purchasing the Game Changing MGI Zip
Navigator. To get the most out of your Zip Navigator
please follow these quick steps before use.
•Register your Zip Navigator online [section 1.0]
•Assembling the Zip Navigator [section 3.0]
•Charge the battery [section 4.0]
For Customer Support, please contact MGI directly
for immediate and professional advice.
mgigolf.com
MGI AUSTRALIA
Service Email: customerservice@mgigolf.com
Live Chat: visit mgigolf.com
Toll Free within Australia: 1300 644 523 (excludes mobiles) Western
Australia/ Internal phone +61 3 8872 6700
Local Service Centres: visit mgigolf.com
to locate you local Service Centre.
MGI USA
Service Email: serviceusa@mgigolf.com
Live Chat: visit mgigolf.com
Telephone: 1800 617 2990
MGI GLOBAL
Sales Email: globalsales@mgigolf.com
Service Email: globalservice@mgigolf.com
Live Chat: visit mgigolf.com
NOTE: This user manual was correct at time of printing.The online version
is the most up-to-date and must be referred to as the
correct version.To download the most current user manual please
visit www.mgigolf.com. Images shown throughout this manual
may not be of the particular model you have purchased.
Contents
1.0 Registration 04
2.0 What Is Included 04
3.0 Assembling the Zip Navigator 05
3.1 Attaching the Rear Wheels 05
3.2 Rear Wheel Positions 06
3.3 Unfolding 07
3.4 Folding 08
3.5 Fourth Foldable Rear Wheel 09
3.6 GPS Holder and Top Handle Compartment 09
3.7 Inverting Rear Wheels 09
4.0 Battery Charging & Connection 10
4.1 Initial Charge 10
4.2 Connecting the Battery onto the Zip Navigator 10
4.3 Charging the Battery after Use 11
5.0 Fitting the Golf Bag 11
6.0 Operating the Digital Top Box 12
6.1 Top Box Display 12
6.2 Start / Stop the Zip Navigator 12
6.3 Turn the Zip Navigator Off 13
6.4 Battery Level Indicator 13
6.5 Unit Measurements 13
6.6 Distance Modes 13
6.7 Competition Mode 14
7.0 Remote Control 15
7.1 Charging Your Remote Control 15
7.2 Forward Arrow 15
7.3 Down Arrow 15
7.4 Left and Right Arrow 16
7.5 Speed Control – Manually and Remotely 16
7.6 Keypad Unlock and Lock 16
7.7 Remote Range and Safety Stop 16
7.8 Pairing a Remote 16
8.0 Gyroscope Straight Tracker Navigation System 17
9.0 Warranty 17
9.1 Warranty Policy 17
9.2 Warranty Exclusions 18
9.3 Parts Installed During Warranty 19
10.0 Preventative Maintenance Program 19
10.1 Cleaning Your Zip Navigator 19
10.2 Rear Wheel Axles Maintenance 19
10.3 Upper and Lower Bag Strap 20
10.4 Correcting the Alignment 20
10.5 MGI Service Schedule 20
10.6 Service Record 21
11.0 Service and Repair Centres 22
12.0 Purchasing Parts and Accessories 22
13.0 Contacting MGI 22
14.0 Contacting Local Agent 23
15.0 Frequently Asked Questions 23
MGI Zip Navigator User Manual 03
1.0 Registration
It important you register your MGI Zip Navigator online immediately
as registration:
• Records your Zip Navigator for warranty purposes
• Speeds up any servicing required on your Zip Navigator
• Assists us to contact you with any updates to your
Zip Navigator
To register your Zip Navigator, visit mgigolf.com
You will need to record your MGI serial number.This is found within
the top handle compartment or on the rear of the buggy chassis.
Please keep this user manual on le for your own reference
and a copy of your serial number;
My MGI Zip Navigator Serial Number is
[example AZXNV7223012345]
Purchased Date
/ /
You may be required to show proof of purchase so we recommend
you keep your receipt with this manual.
2.0 What’s Included
• MGI Zip Navigator
• 24v Lithium Battery
• Battery Charger
• GPS Holder
• Remote Control
• MGI Pouch with:
- Quick Guide
- Accessory Guide
MGI Zip Navigator User Manual 04
3.0 Assembling Your Zip Navigator
3.1 Attaching the Rear Wheels
First, lubricate both axles using the black lubricant cloth provided
in the MGI Pouch. Lubrication of the axles should be performed
regularly to keep your cart in optimal condition. (Refer to 10.5 MGI
Service Schedule)
Press the grey release button on the wheel hub. Place the wheel
onto the axle.You will need to match up the inner female groove on
the axle and the male of the wheel.When placed in position simply
release the button.You hear a “click” when the wheel is properly
secured.
To check that the wheel is properly in position pull on the wheel. If it is
properly in position it will not slide off. Repeat for the other wheel.
MGI Zip Navigator User Manual 05
3.2 Rear Wheels Positions
The MGI Zip Navigator is designed to allow the rear wheels to be
in two positions.The position is determined by where the wheel is
locked on the axle in either of the two grooves [see picture].The drive
position is used during the normal operation of the Zip Navigator.The
free wheel position is used to push the Zip Navigator freely, if required.
i. Drive position – Lock the wheel onto the groove closest to the
battery base.To do this, press the grey release button on the wheel
hub, push the wheel on to the axle as far as possible.To test for drive
position try rolling the wheel backwards. If you feel resistance then
the wheel is now in drive position and ready to use. Repeat for other
wheel.
ii. Free wheel – Lock the wheel into the groove closest to the end of
the axle.To do this, press the grey release button on the wheel hub,
push the wheel on to the axle and push the release button onto the
groove.To test for free wheel position try rolling the wheel backwards.
The wheel should spin freely with no resistance. Repeat for other
wheel.
MGI Zip Navigator User Manual 06
Free wheel position
Drive position
3.3 Unfolding
Please see below the steps to unfold a Zip Navigator Handle.
Step 7: Push the top bag support down to move it into position.
Step 1: Ensure both rear
wheels are attached.
Step 2: Release fold lever.
Step 4: The handle is now free to pull
upwards.The handle will naturally
unfold as you continue to pull until the
handle is completely open.
Step 3: Move the top bag
support away from front
wheel assembly until you
hear it click.
Step 6: Close the fold lever to lock
the handle into place in one of three
positions.
Step 5: Ensure that the
latch at the bottom of the
handle clicks into place.
MGI Zip Navigator User Manual 07
3.4 Folding
Step 1: Disconnect the battery by lifting
the battery handle. It can be left on or
removed from the Zip Navigator.
Step 2: Open the fold lever to release
the handle.
Step 3: Pull the latch up at the bottom of
the handle.
Step 4: Lower the handle until at.
Step 6: Close the fold lever to lock the
handle into place.
Step 5: Push the toggle
down on the top bag
support and then move
the top bag support
down so that it locks
over the front wheel
assembly.
Toggle
MGI Zip Navigator User Manual 08
3.5 Fourth Foldable Rear Wheel
The MGI Zip Navigator comes standard with a fourth foldable and
extendable rear wheel.This wheel MUST be unfolded and extended
into position at all times when the Zip Navigator is in use.This will
provide the ultimate stability across all terrains.This fourth wheel should
be cleaned regularly with a cloth to ensure it can be folded and
retracted as required for storage.
3.6 GPS Holder and Top Handle Compartment
In the top handle compartment there is a position for a GPS/mobile
device holder. Open the compartment and connect the holder into
position.To open, press the button at the top of the holder. Place the
GPS into the cradle, then close the holder by squeezing the two sides
closer together.To remove, gently push the GPS Holder up and away
from the Navigator
3.7 Inverting Rear Wheels
The rear wheels can be inverted on the axle to reduce the size of the
Zip Navigator when folded.To invert the rear wheels, press the grey
release button on the wheels hub and remove from the axle. Invert the
rear wheels so that the wheels hub protrudes away from the axles.
Press the grey release button on the wheels hub and release once the
wheel is tted onto the axle.
MGI Zip Navigator User Manual 09
4.0 Battery Charging & Connection
The MGI Zip Navigator can only be used with the:
MGI 24v 380Wh Lithium battery
4.1 Initial Charge
• Before using your MGI Zip Navigator for the rst time you must
fully charge the battery overnight.
• Plug the charger AC lead into a power point - the green LED
illuminates to indicate the charger is on.
• Plug the charger output connection into the connector on
the front of the battery - the red LED illuminates to indicate it is
charging.
• When the charging LED indicator has turned green, the
battery is fully charged and ready for use.
Please refer to the battery charger user manual for further information.
4.2 Connecting the Battery onto the Zip Navigator
Position the battery on the Zip Navigator and push the battery down
to secure it.
Push the handle down to connect the battery to the
Zip Navigator.
Your Zip Navigator has been equipped with a fail safe battery
connection, so the Zip Navigator will not move when you connect the
battery.Your Zip Navigator will only start via the top handle button or
the remote.
MGI Zip Navigator User Manual 10
