INTRODUCTION

Merrychef® eikon® ovens oer operators the exibility of combination

cooking with additional control over fan speed and microwave power.

Combination cooking enables high quality results to be achieved in a

fraction of the time taken by conventional cooking, particularly when

baking, browning, roasting and grilling dishes.

Once established, precise instructions for combination or convection

cooking of selected items may be programmed into the oven’s memory

so that they can be repeated easily and accurately. Up to 1024 programs

can be stored and simply recalled.

Multistage Programming

The oven controls oer even greater exibility by allowing multistage

programming. This enables the exact conditions required for quality

results to be set according to the food type.

A single cooking program can have up to 6 stages, each stage

controlled with its own time, fan speed and microwave power settings

(model dependent).

WARNING

THIS IS A CLASS A PRODUCT. IN A DOMESTIC

ENVIRONMENT THIS PRODUCT MAY CAUSE RADIO

INTERFERENCE IN WHICH CASE THE USER MAY BE

REQUIRED TO TAKE ADEQUATE MEASURES.

PRECAUTIONS TO AVOID POSSIBLE

EXPOSURE TO EXCESSIVE MICROWAVE

ENERGY

a) Do not attempt to operate this oven with the door open since

open-door operation can result in harmful exposure to microwave

energy. It is important not to defeat or tamper with the safety

interlocks.

b) Do not place any object between the oven front face and the

door or allow soil or cleaner residue to accumulate on sealing

surfaces.

c) Do not operate the oven if it is damaged. It is particularly

important that the oven door closes properly and that there is no

damage to the (1) door (bent) (2) hinges and latches (broken or

loosened) (3) door seals and sealing surfaces.

d) The oven should not be adjusted or repaired by anyone except

properly qualied service personnel.

PLEASE READ THE FOLLOWING SAFETY

INSTRUCTIONS CAREFULLY

The instructions outlined in this guide are intended to ensure the

safety and long life of your Merrychef® eikon® oven.

Quick Start Guide. Original instructions.

Part Number 32Z3848 GB Issue 3 3

SAFETY &

REGULATIONS

PRODUCT DETAILSOPERATION &

CONTROLS

CLEANING &

MAINTENANCE

FAULT FINDING

CONTENTS

IMPORTANT INFORMATION READ BEFORE

USE

Users are cautioned that maintenance and repairs should

be performed by a Merrychef® authorized service agent

using genuine Merrychef® replacement parts. Merrychef®

will have no obligation with respect to any product that

has been improperly installed, adjusted, operated or not

maintained in accordance with national and local codes or

installation instructions provided with the product, or any

product that has its serial number defaced, obliterated or

removed, or which has been modied or repaired using

unauthorized parts or by unauthorized service agents.

For a list of authorized service agents, please refer to the

back page of this booklet. The information contained

herein (including design and parts specications) may be

superseded and is subject to change without notice.

INTRODUCTION 2

SAFETY & REGULATIONS

IMPORTANT SAFETY INSTRUCTIONS 4

PRECAUTIONS TO BE OBSERVED 8

SUITABLE COOKING UTENSILS 9

PRODUCT DETAILS

MAIN FEATURES 10

TECHNICAL SPECIFICATIONS 12

Specications 12

Serial Number (Rating Plate) 13

Compliances 13

INSTALLATION 14

Oven Location and Positioning 14

OPERATION & CONTROLS

QUICK START GUIDE: QUICK SERVICE OVEN 15

Start Up 15

Using a Cooking Program 16

Screen Saver 16

CLEANING & MAINTENANCE

COOLING THE OVEN DOWN BEFORE CLEANING 17

Oven cool down 17

Preparing to clean the oven 17

COLD OVEN CLEANING INSTRUCTIONS 18

FAULT FINDING

FAULT FINDING CHART 21

This is a Quick Start Guide only. For further information

refer to the relevant Installation and Operating

instructions available from www.merrychef.com

The easyToUCH® screen display, layout and icons shown

herein are for guidance purposes only and are not intended to

be an exact representation of those supplied with the oven.

4Quick Start Guide. Original instructions.

Part Number 32Z3848 GB Issue 3

SAFETY &

REGULATIONS

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances basic safety

precautions should be followed, including

the following:

WARNING: To reduce the risk of burns,

electric shock, re, injury to persons, or

exposure to excessive microwave energy:

1. Read all instructions before using the

appliance.

2. Read and follow the specic

“PRECAUTIONS TO AVOID POSSIBLE

EXPOSURE TO EXCESSIVE MICROWAVE

ENERGY” found on the Introduction page.

3. This appliance must be grounded. Connect

only to a properly grounded outlet. See

“ELECTRICAL INSTALLATION”.

4. Install or locate this appliance only in

accordance with the provided installation

instructions.

5. WARNING: Liquids or other foods must not

be heated in sealed containers since they are

liable to explode.

6. Use this appliance only for its intended

use as described in the manual. Do not

use corrosive chemicals or vapours in this

appliance. This type of oven is specically

designed to heat, cook or dry food. It is not

designed for industrial or laboratory use.

7. This appliance is not intended for use by

children (see clause 31 for more details).

8. If the supply cord is damaged, it must be

replaced by the manufacturer, its service

agent or similarly qualied persons in order

to avoid a hazard.

9. WARNING: It is hazardous for anyone other

than a competent person to carry out any

service or repair operation that involves the

removal of any cover which gives protection

against exposure to microwave energy.

Quick Start Guide. Original instructions.

Part Number 32Z3848 GB Issue 3 5

SAFETY &

REGULATIONS

10. Do not cover or block any openings on

the appliance including air vents/lters and

steam outlet.

11. Do not store this appliance outdoors.

Do not use this product near water — for

example, near a kitchen sink, in a wet

basement, or near a swimming pool, and the

like.

12. Do not immerse the power cord or plug

in water.

13. Keep the cord away from heated surfaces.

14. Do not let the cord hang over an edge of

a table or counter.

15. Either:

i) When cleaning surfaces of door and oven

that come together on closing the door, use

only mild non-abrasive soaps, or detergents

applied with a sponge or soft cloth.

ii) When separate cleaning instructions

are provided, see door surface cleaning

instructions.

16. To reduce risk of re in the cavity:

i) When heating food in plastic or paper

containers, keep an eye on the oven due to

the possibility of ignition.

ii) Remove wire twist-ties from paper or

plastic bags before placing bag in oven.

iii) If materials inside the oven should ignite,

keep oven door closed, turn oven o, and

disconnect the power cord, or shut o power

at the fuse or circuit breaker panel.

iv) If smoke is observed, switch o or unplug

the appliance and keep the door closed in

order to stie any ames.

v) Do not use the cavity for storage purposes.

Do not leave paper products, cooking

utensils or food in the cavity when not in use.

IMPORTANT SAFETY INSTRUCTIONS

6Quick Start Guide. Original instructions.

Part Number 32Z3848 GB Issue 3

SAFETY &

REGULATIONS

17. WARNING: Microwave heating of

beverages can result in delayed eruptive

boiling therefore care must be taken when

handling the container.

18. DO NOT operate using microwave only

or combination function without food or

liquid inside the oven as this may result in

overheating and may cause damage.

19. Eggs in their shells and whole hard boiled

eggs should not be heated in microwave

ovens since they may explode even after

microwave heating has ended.

20. NEVER remove the exterior of the oven.

21. NEVER remove any xed internal parts of

the oven.

22. NEVER tamper with the control panel,

door, seals, or any other oven part.

23. DO NOT obstruct air vents/lters or steam

outlet.

24. NEVER hang dish towels or cloths on any

part of the oven.

25. WARNING: If the door or door seals are

damaged, the oven must not be operated

until it has been repaired by a competent

person.

26. If the power cable is damaged in any way

it MUST be replaced by an approved Service

Agent.

27. When handling hot liquids, foods, and

containers, care should be taken to avoid

scalds and burns.

28. When heating liquids using microwave

only or combination function, the contents

should be stirred prior to heating to avoid

eruptive boiling.

29. WARNING: The contents of feeding

bottles and baby food jars must be stirred or

shaken and the temperature checked before

consumption, in order to avoid burns.

IMPORTANT SAFETY INSTRUCTIONS

Quick Start Guide. Original instructions.

Part Number 32Z3848 GB Issue 3 7

SAFETY &

REGULATIONS

30. Never use the oven to heat alcohol, e.g.

brandy, rum etc. Food containing alcohol

can more easily catch re if overheated,

observe caution and do not leave the oven

unattended.

31. Never attempt to deep fry in the oven.

32. This appliance is not intended for use

by children aged 8 years and above and

persons with reduced physical sensory or

mental capabilities or lack of experience and

knowledge unless they have been given

supervision or instruction concerning use of

the appliance in a safe way and understand

the hazards involved. Children shall not

play with the appliance. Cleaning and user

maintenance shall not be made by children

without supervision.

33. The oven must not be operated without

the air lter in place.

34. The minimum height of free space

necessary above the top surface of the oven

is 50mm (2”).

35. Only use utensils that are suitable for use

in microwave ovens.

36. Details for cleaning Door Seals, Cavities

and adjacent parts are provided in the

‘Cleaning’ section of this manual.

37. The oven should be cleaned regularly and

any food deposits removed.

38. Failure to maintain the oven in a clean

condition could lead to deterioration of

the surface that could adversely aect the

life of the appliance and possibly result in a

hazardous situation.

39. The appliance should not be cleaned with

a water jet.

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

8Quick Start Guide. Original instructions.

Part Number 32Z3848 GB Issue 3

SAFETY &

REGULATIONS

1. Read this manual before using your oven.

2. As with all electrical appliances, it is wise to have the

electrical connections inspected at least once a year.

3. The oven interior and door seals should be cleaned

frequently following the instructions described in the

‘Cleaning’ section. Failure to do so could possibly result

in a hazardous situation.

4. Switch o the oven at the end of all the cooking

sessions for that day.

5. The oven should not be used to dry linen.

6. As with any cooking appliance, care should be taken

to avoid combustion of the items within the oven.

7. Food in combustible plastic or paper containers

should be transferred to a microwave/oven proof

container to avoid the possibility of ignition.

PRECAUTIONS TO BE OBSERVED

IF SMOKE IS OBSERVED:

●Switch o

●Isolate from the electrical supply

●Keep the door closed to stie any ames

8. Items should be unwrapped when using convection

and combination functions.

9. Eggs in their shells and whole hard boiled eggs

should not be heated in microwave ovens since they

may explode even after microwave heating has ended.

10. Food with a skin, e.g. potatoes, apples, sausages,

etc. should be pierced before heating.

11. Food should not be heated in a completely sealed

container as the build-up of steam may cause it to

explode.

12. Excess fat should be removed during ‘roasting’and

before lifting heavy containers from the oven.

13. In the event of glass breaking or shattering within

the oven, ensure that food is totally free of glass

particles. If in doubt, dispose of any food that was in

the oven at the time of the breakage.

14. DO NOT attempt to operate the oven with: object

caught in door, that does not close properly or

damaged door, hinge, latch, sealing surface or without

food in the oven.

Quick Start Guide. Original instructions.

Part Number 32Z3848 GB Issue 3 9

SAFETY &

REGULATIONS

SUITABLE COOKING UTENSILS

Manufacturer’s instructions should be checked to determine the suitability of individual containers or utensils using each of the cooking functions.

The following chart provides general guidelines:

Heat resistant containers

Toughened glass

Vitreous ceramics

Earthenware

(porcelain/crockery/china etc.)

Do not use items with metallic decoration.

Metallic & Foil Trays

Metallic trays

DO NOT USE ANY OTHER METAL OR FOIL CONTAINERS

Metallic trays may only be used when placed on the

VITREOUS RACK in the oven cavity. Do not cook food directly

on the vitreous enamel rack.

Plastic containers

Dual-ovenable plastic containers (up to certain temperatures) are now available.

Check manufacturer’s instructions before use.

Disposables

DO NOT USE

Combustibles (paper/card etc.)

Other utensils

Tie tags

Cutlery

Temperature probes

No kitchen utensil should be left in food while it is cooking in

the oven.

10 Quick Start Guide. Original instructions.

Part Number 32Z3848 GB Issue 3

PRODUCT DETAILS

MAIN FEATURES

1 ON/OFF SWITCH

When switched ON the easyToUCH® screen illuminates the oven

controls.

NOTE: Turning this switch OFF does not isolate the oven from the

electricity supply.

2 easyToUCH® SCREEN CONTROL PANEL

See ‘OPERATION & CONTROLS’ for details.

3 RATING PLATE

Located on the rear panel of the oven states the serial number,

model type & electrical specications.

4 USB port/Merrychef badge

A USB socket located under the ‘Merrychef’ logo allows changes to

programs stored on the oven (See USB MenuConnect® User Manual,

and ‘OPERATION & CONTROLS’section of this manual, for details of

updating oven programs).

5 AIR OUTLETS

Air used to cool internal components and steam from the cavity

escape through the air outlet vents located on the rear of the oven.

The air outlets must be kept free from obstruction and they will not

allow microwave energy to escape into the environment.

6 AIR INLET FILTER

The air lter situated at the lower front of the oven is part of the

ventilation system and must be kept free of obstruction and cleaned

daily as described under ‘CLEANING & MAINTENANCE’.

NOTE: The oven will not operate without the air lter tted.

7 DOOR HANDLE

This is a rigid bar which is pulled downwards and away from the oven

to open.

8 OVEN DOOR

This is a precision-made energy barrier with three microwave

safety interlocks. The door must be kept clean (see ‘CLEANING &

MAINTENANCE’) and should NOT be used to support heavy objects.

9 DOOR SEALS

These ensure a tight seal around the door. They should be kept clean

and checked regularly for signs of damage. At the rst sign of wear

they should be replaced by a Merrychef approved Service Agent.

10 CONVECTION FAN, AIR DIFFUSER & CATALYTIC CONVERTOR

The convection fan must be kept clean and free of debris. Great

care should be taken when cleaning this area of the oven noting

the dierent oven requirements shown under‘CLEANING &

MAINTENANCE’in this manual.

11 OVEN CAVITY

The oven cavity is constructed from stainless steel and must be kept

clean by following the cleaning instructions in the‘CLEANING &

MAINTENANCE’section of this manual.

Otros manuales para eikon e4s

Tabla de contenidos

Otros manuales de Horno de Merrychef

Merrychef

Merrychef EC402S Manual de usuario

Merrychef

Merrychef Microcook HD Manual de usuario

Merrychef

Merrychef eikon e3 Manual de usuario

Merrychef

Merrychef eikon e4s Guía

Merrychef

Merrychef 501 Manual de usuario

Merrychef

Merrychef eikon e2 Per Oven Guía

Merrychef

Merrychef Mealstream 400 Series Manual de usuario

Merrychef

Merrychef Evolution Manual de usuario

Merrychef

Merrychef 402s Guía

Merrychef

Merrychef EC402S Guía

Merrychef

Merrychef eikon e3 Manual de usuario

Merrychef

Merrychef s Guía

Merrychef

Merrychef 402s Manual de usuario

Merrychef

Merrychef eikon e3 Manual de usuario

Merrychef

Merrychef Mealstream EC501 Manual de usuario

Merrychef

Merrychef Mealstream EC501 Manual de usuario

Merrychef

Merrychef eikon e6 Series Manual de usuario

Merrychef

Merrychef eikon e3 Guía

Merrychef

Merrychef eikon e2 Per Oven Manual de usuario

Manuales populares de Horno de otras marcas

Bosch

Bosch HVA531NS0 Manual de usuario

Electrolux

Electrolux EOF6P46X Manual de usuario

NEFF

NEFF B44S32 5GB Series Manual de usuario

Combi

Combi BLODGETT BC142GDS Manual de usuario

AEG

AEG COMPETENCE 311704300 Manual de usuario

Falcon

Falcon DOMINATOR PLUS G3106 Series Guía del usuario

Rational

Rational SCC WE 61G Manual de usuario

Smeg

Smeg DOSPA38X Manual de instalación y operación

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manual de usuario

Miele

Miele HR 1954-2 Manual de usuario

KHIND

KHIND OT50 Manual de usuario

Henny Penny

Henny Penny Smoker Box Manual de usuario

Lang

Lang ECOD-AP Manual de usuario

AEG

AEG BEK455310M Manual de usuario

Frigidaire

Frigidaire FNGE90JGR Manual de usuario

Hotpoint

Hotpoint FE9 S831 JSH IX Manual de usuario

GE Advantium SCB2000 Manual de usuario

AEG

AEG DE401301DM Manual de usuario

Merrychef eikon e4s Manual de usuario

Manuales populares de Horno de otras marcas
